Mitsubishi Electric - SHL-V160 Vacuum Magnetic Contactor (Mechanical Latch, AC operated, 200A Ith, 180A 90kW at AC440V)

Mitsubishi Electric - SHL-V160 Vacuum Magnetic Contactor (Mechanical Latch, AC operated, 200A Ith, 180A 90kW at AC440V)

Mitsubishi Electric MS-T/N series SHL-V160 large capacity vacuum magnetic contactor combining a vacuum switch with an AC operated DC excited electromagnet for high performance, long life and maintenance free operation.

Key features

  • Mechanical latch mechanism holds the contacts without continuous coil excitation
  • No arc clearance is required so the panel can be made smaller, there is no coil humming or current interruption noise, and there is no arc blowout which keeps the unit safe in harsh ambient conditions
  • Switching frequency 1200 operations per hour
  • Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations
  • Standard auxiliary contacts 2a2b, with a 4a4b configuration available on request
  • Compliant with JIS C8201-4-1, JEM 1038, IEC 60947-4-1

Specifications

Type Mechanical latch vacuum magnetic contactor
Frame V160
Mechanism Mechanical latch
Operation AC operated
Rated Insulation Voltage 1500V three phase 50/60Hz
Rated Current and Capacity AC-3 Class 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V
Three Phase Capacitor Rating 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V
Open Thermal Current Ith 200A
Switching Frequency 1200 operations/h
Operating Voltage Pick up at 85 percent or less of rated voltage at 40 degrees C ambient
Characteristics Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping
Standards JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC100V MT-AC100V SHL-V160 vacuum latch contactor, MC AC100V and MT AC100V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC100V rated 100-127V | Tripping Coil MT: AC100V rated 100-127V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC100V MT-AC200V SHL-V160 vacuum latch contactor, MC AC100V and MT AC200V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC100V rated 100-127V | Tripping Coil MT: AC200V rated 200-240V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC100V MT-AC300V SHL-V160 vacuum latch contactor, MC AC100V and MT AC300V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC100V rated 100-127V | Tripping Coil MT: AC300V rated 260-350V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC100V MT-AC400V SHL-V160 vacuum latch contactor, MC AC100V and MT AC400V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC100V rated 100-127V | Tripping Coil MT: AC400V rated 380-440V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC100V MT-AC500V SHL-V160 vacuum latch contactor, MC AC100V and MT AC500V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC100V rated 100-127V | Tripping Coil MT: AC500V rated 460-550V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC200V MT-AC100V SHL-V160 vacuum latch contactor, MC AC200V and MT AC100V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC200V rated 200-240V | Tripping Coil MT: AC100V rated 100-127V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC200V MT-AC200V SHL-V160 vacuum latch contactor, MC AC200V and MT AC200V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC200V rated 200-240V | Tripping Coil MT: AC200V rated 200-240V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC200V MT-AC300V SHL-V160 vacuum latch contactor, MC AC200V and MT AC300V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC200V rated 200-240V | Tripping Coil MT: AC300V rated 260-350V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC200V MT-AC400V SHL-V160 vacuum latch contactor, MC AC200V and MT AC400V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC200V rated 200-240V | Tripping Coil MT: AC400V rated 380-440V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC200V MT-AC500V SHL-V160 vacuum latch contactor, MC AC200V and MT AC500V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC200V rated 200-240V | Tripping Coil MT: AC500V rated 460-550V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC300V MT-AC100V SHL-V160 vacuum latch contactor, MC AC300V and MT AC100V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC300V rated 260-350V | Tripping Coil MT: AC100V rated 100-127V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC300V MT-AC200V SHL-V160 vacuum latch contactor, MC AC300V and MT AC200V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC300V rated 260-350V | Tripping Coil MT: AC200V rated 200-240V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC300V MT-AC300V SHL-V160 vacuum latch contactor, MC AC300V and MT AC300V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC300V rated 260-350V | Tripping Coil MT: AC300V rated 260-350V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC300V MT-AC400V SHL-V160 vacuum latch contactor, MC AC300V and MT AC400V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC300V rated 260-350V | Tripping Coil MT: AC400V rated 380-440V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC300V MT-AC500V SHL-V160 vacuum latch contactor, MC AC300V and MT AC500V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC300V rated 260-350V | Tripping Coil MT: AC500V rated 460-550V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC400V MT-AC100V SHL-V160 vacuum latch contactor, MC AC400V and MT AC100V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC400V rated 380-440V | Tripping Coil MT: AC100V rated 100-127V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC400V MT-AC200V SHL-V160 vacuum latch contactor, MC AC400V and MT AC200V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC400V rated 380-440V | Tripping Coil MT: AC200V rated 200-240V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC400V MT-AC300V SHL-V160 vacuum latch contactor, MC AC400V and MT AC300V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC400V rated 380-440V | Tripping Coil MT: AC300V rated 260-350V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC400V MT-AC400V SHL-V160 vacuum latch contactor, MC AC400V and MT AC400V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC400V rated 380-440V | Tripping Coil MT: AC400V rated 380-440V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC400V MT-AC500V SHL-V160 vacuum latch contactor, MC AC400V and MT AC500V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC400V rated 380-440V | Tripping Coil MT: AC500V rated 460-550V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC500V MT-AC100V SHL-V160 vacuum latch contactor, MC AC500V and MT AC100V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC500V rated 460-550V | Tripping Coil MT: AC100V rated 100-127V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC500V MT-AC200V SHL-V160 vacuum latch contactor, MC AC500V and MT AC200V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC500V rated 460-550V | Tripping Coil MT: AC200V rated 200-240V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC500V MT-AC300V SHL-V160 vacuum latch contactor, MC AC500V and MT AC300V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC500V rated 460-550V | Tripping Coil MT: AC300V rated 260-350V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC500V MT-AC400V SHL-V160 vacuum latch contactor, MC AC500V and MT AC400V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC500V rated 460-550V | Tripping Coil MT: AC400V rated 380-440V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC500V MT-AC500V SHL-V160 vacuum latch contactor, MC AC500V and MT AC500V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC500V rated 460-550V | Tripping Coil MT: AC500V rated 460-550V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
Magnetic ContactorsMitsubishi Electric
25 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - SHL-V160 Vacuum Magnetic Contactor (Mechanical Latch, AC operated, 200A Ith, 180A 90kW at AC440V)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (25)

SHL-V160 MC-AC100V MT-AC100V, SHL-V160 MC-AC100V MT-AC200V, SHL-V160 MC-AC100V MT-AC300V, SHL-V160 MC-AC100V MT-AC400V, SHL-V160 MC-AC100V MT-AC500V, SHL-V160 MC-AC200V MT-AC100V, SHL-V160 MC-AC200V MT-AC200V, SHL-V160 MC-AC200V MT-AC300V, SHL-V160 MC-AC200V MT-AC400V, SHL-V160 MC-AC200V MT-AC500V + 15 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SHL-V160 MC-AC100V MT-AC100VSHL-V160 vacuum latch contactor, MC AC100V and MT AC100V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC100V rated 100-127V | Tripping Coil MT: AC100V rated 100-127V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC100V MT-AC200VSHL-V160 vacuum latch contactor, MC AC100V and MT AC200V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC100V rated 100-127V | Tripping Coil MT: AC200V rated 200-240V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC100V MT-AC300VSHL-V160 vacuum latch contactor, MC AC100V and MT AC300V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC100V rated 100-127V | Tripping Coil MT: AC300V rated 260-350V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC100V MT-AC400VSHL-V160 vacuum latch contactor, MC AC100V and MT AC400V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC100V rated 100-127V | Tripping Coil MT: AC400V rated 380-440V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC100V MT-AC500VSHL-V160 vacuum latch contactor, MC AC100V and MT AC500V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC100V rated 100-127V | Tripping Coil MT: AC500V rated 460-550V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC200V MT-AC100VSHL-V160 vacuum latch contactor, MC AC200V and MT AC100V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC200V rated 200-240V | Tripping Coil MT: AC100V rated 100-127V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC200V MT-AC200VSHL-V160 vacuum latch contactor, MC AC200V and MT AC200V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC200V rated 200-240V | Tripping Coil MT: AC200V rated 200-240V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC200V MT-AC300VSHL-V160 vacuum latch contactor, MC AC200V and MT AC300V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC200V rated 200-240V | Tripping Coil MT: AC300V rated 260-350V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC200V MT-AC400VSHL-V160 vacuum latch contactor, MC AC200V and MT AC400V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC200V rated 200-240V | Tripping Coil MT: AC400V rated 380-440V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC200V MT-AC500VSHL-V160 vacuum latch contactor, MC AC200V and MT AC500V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC200V rated 200-240V | Tripping Coil MT: AC500V rated 460-550V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC300V MT-AC100VSHL-V160 vacuum latch contactor, MC AC300V and MT AC100V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC300V rated 260-350V | Tripping Coil MT: AC100V rated 100-127V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC300V MT-AC200VSHL-V160 vacuum latch contactor, MC AC300V and MT AC200V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC300V rated 260-350V | Tripping Coil MT: AC200V rated 200-240V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC300V MT-AC300VSHL-V160 vacuum latch contactor, MC AC300V and MT AC300V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC300V rated 260-350V | Tripping Coil MT: AC300V rated 260-350V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC300V MT-AC400VSHL-V160 vacuum latch contactor, MC AC300V and MT AC400V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC300V rated 260-350V | Tripping Coil MT: AC400V rated 380-440V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC300V MT-AC500VSHL-V160 vacuum latch contactor, MC AC300V and MT AC500V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC300V rated 260-350V | Tripping Coil MT: AC500V rated 460-550V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC400V MT-AC100VSHL-V160 vacuum latch contactor, MC AC400V and MT AC100V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC400V rated 380-440V | Tripping Coil MT: AC100V rated 100-127V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC400V MT-AC200VSHL-V160 vacuum latch contactor, MC AC400V and MT AC200V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC400V rated 380-440V | Tripping Coil MT: AC200V rated 200-240V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC400V MT-AC300VSHL-V160 vacuum latch contactor, MC AC400V and MT AC300V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC400V rated 380-440V | Tripping Coil MT: AC300V rated 260-350V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC400V MT-AC400VSHL-V160 vacuum latch contactor, MC AC400V and MT AC400V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC400V rated 380-440V | Tripping Coil MT: AC400V rated 380-440V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC400V MT-AC500VSHL-V160 vacuum latch contactor, MC AC400V and MT AC500V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC400V rated 380-440V | Tripping Coil MT: AC500V rated 460-550V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC500V MT-AC100VSHL-V160 vacuum latch contactor, MC AC500V and MT AC100V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC500V rated 460-550V | Tripping Coil MT: AC100V rated 100-127V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC500V MT-AC200VSHL-V160 vacuum latch contactor, MC AC500V and MT AC200V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC500V rated 460-550V | Tripping Coil MT: AC200V rated 200-240V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC500V MT-AC300VSHL-V160 vacuum latch contactor, MC AC500V and MT AC300V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC500V rated 460-550V | Tripping Coil MT: AC300V rated 260-350V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC500V MT-AC400VSHL-V160 vacuum latch contactor, MC AC500V and MT AC400V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC500V rated 460-550V | Tripping Coil MT: AC400V rated 380-440V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
SHL-V160 MC-AC500V MT-AC500VSHL-V160 vacuum latch contactor, MC AC500V and MT AC500V | Type: Mechanical latch vacuum magnetic contactor | Frame: V160 | Mechanism: Mechanical latch | Operation: AC operated | Closing Coil MC: AC500V rated 460-550V | Tripping Coil MT: AC500V rated 460-550V | Rated Insulation Voltage: 1500V three phase 50/60Hz | Rated Current and Capacity AC-3 Class: 180A 45kW at AC220V, 180A 90kW at AC440V, 180A 110kW at AC550V, 160A 220kW at AC1000V, 160A 315kW at AC1500V | Three Phase Capacitor Rating: 150A 50kVA at AC220V, 150A 100kVA at AC440V, 150A 125kVA at AC550V | Open Thermal Current Ith: 200A | Switching Frequency: 1200 operations/h | Durability: Electrical 250,000 operations on three phase motor AC-3 class, 100,000 operations on three phase capacitor, mechanical 250,000 operations | Operating Voltage: Pick up at 85 percent or less of rated voltage at 40 degrees C ambient | Characteristics: Main contact ON 40ms, main contact OFF 30ms, inrush coil input 480VA closing and 650VA tripping | Aux Contact: 2a2b standard, rated operational current AC-15 class 5A at AC220V and 3A at AC440V, DC-13 class 0.6A at DC110V and 0.2A at DC220V, conforming to JIS C4531 (1994) | Standards: JIS C8201-4-1, JEM 1038, IEC 60947-4-1
