Mitsubishi Electric - SLD-N80FK Class 1 Heat Resistant Mechanical Latch Magnetic Contactor (DC Operated Closing Coil, 94.5A Carrying, 80A AC-3 at 220V)

Mitsubishi Electric - SLD-N80FK Class 1 Heat Resistant Mechanical Latch Magnetic Contactor (DC Operated Closing Coil, 94.5A Carrying, 80A AC-3 at 220V)

Mitsubishi Electric MS-T/N series SLD-N80FK class 1 heat-resistant mechanical latch magnetic contactor for distribution boards and panelboards of dedicated emergency power receiving equipment.

Key features

  • Retains conduction and insulation function at high temperature during a fire, switching and carrying the heat-resistant rated current for 30 minutes under the one third fire temperature curve
  • Heat-resistant carrying current 94.5A, heat-resistant rated current 80A at AC220V, 80A at AC440V, 75A at AC550V under AC-3 class, 3a main contacts with 1a2b auxiliary contacts
  • Separate closing coil MC and tripping coil MT are specified independently; the closing coil is DC operated in DC100V and DC200V designations and the tripping coil may be any of the AC24V, AC100V, AC200V, AC230V, DC100V and DC200V designations
  • Mechanical and electrical durability 250,000 operations
  • Reversing type SLD-2XN80FK is available, and the contactor can be switched from its own auxiliary contacts
  • Outline dimensions are the same as the standard product

Specifications

Type Class 1 heat-resistant magnetic contactor for emergency power switchboards
Frame N80
Main Contact 3a
Mechanism Mechanical latch
Operation DC operated closing coil
Heat Resistant Carrying Current 94.5A
Heat Resistant Rated Current AC-3 Class 80A at AC220V, 80A at AC440V, 75A at AC550V
Heat Resistant Rated Current AC-1 Class 94.5A at AC220V, 94.5A at AC440V
DC Rated Current at DC48V 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class)
DC Rated Current at DC110V 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class)
DC Rated Current at DC220V 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class)
Coil Inrush Input Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping
SLD-N80FK MC-DC100V MT-AC24V SLD-N80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC24V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC24V rated 24V 50Hz, 24V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC100V MT-AC24V SLD-2XN80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC24V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC24V rated 24V 50Hz, 24V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC100V MT-AC100V SLD-N80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC100V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC100V rated 100V 50Hz, 100-110V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC100V MT-AC100V SLD-2XN80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC100V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC100V rated 100V 50Hz, 100-110V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC100V MT-AC200V SLD-N80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC200V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC200V rated 200V 50Hz, 200-220V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC100V MT-AC200V SLD-2XN80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC200V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC200V rated 200V 50Hz, 200-220V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC100V MT-AC230V SLD-N80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC230V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC230V rated 220-240V 50Hz, 230-240V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC100V MT-AC230V SLD-2XN80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC230V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC230V rated 220-240V 50Hz, 230-240V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC100V MT-DC100V SLD-N80FK class 1 heat-resistant latch contactor, MC DC100V and MT DC100V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: DC100V rated DC100-110V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC100V MT-DC100V SLD-2XN80FK class 1 heat-resistant latch contactor, MC DC100V and MT DC100V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: DC100V rated DC100-110V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC100V MT-DC200V SLD-N80FK class 1 heat-resistant latch contactor, MC DC100V and MT DC200V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: DC200V rated DC200-220V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC100V MT-DC200V SLD-2XN80FK class 1 heat-resistant latch contactor, MC DC100V and MT DC200V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: DC200V rated DC200-220V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC200V MT-AC24V SLD-N80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC24V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC24V rated 24V 50Hz, 24V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC200V MT-AC24V SLD-2XN80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC24V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC24V rated 24V 50Hz, 24V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC200V MT-AC100V SLD-N80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC100V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC100V rated 100V 50Hz, 100-110V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC200V MT-AC100V SLD-2XN80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC100V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC100V rated 100V 50Hz, 100-110V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC200V MT-AC200V SLD-N80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC200V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC200V rated 200V 50Hz, 200-220V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC200V MT-AC200V SLD-2XN80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC200V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC200V rated 200V 50Hz, 200-220V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC200V MT-AC230V SLD-N80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC230V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC230V rated 220-240V 50Hz, 230-240V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC200V MT-AC230V SLD-2XN80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC230V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC230V rated 220-240V 50Hz, 230-240V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC200V MT-DC100V SLD-N80FK class 1 heat-resistant latch contactor, MC DC200V and MT DC100V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: DC100V rated DC100-110V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC200V MT-DC100V SLD-2XN80FK class 1 heat-resistant latch contactor, MC DC200V and MT DC100V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: DC100V rated DC100-110V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC200V MT-DC200V SLD-N80FK class 1 heat-resistant latch contactor, MC DC200V and MT DC200V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: DC200V rated DC200-220V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC200V MT-DC200V SLD-2XN80FK class 1 heat-resistant latch contactor, MC DC200V and MT DC200V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: DC200V rated DC200-220V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
Magnetic ContactorsMitsubishi Electric
24 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - SLD-N80FK Class 1 Heat Resistant Mechanical Latch Magnetic Contactor (DC Operated Closing Coil, 94.5A Carrying, 80A AC-3 at 220V)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (24)

SLD-N80FK MC-DC100V MT-AC24V, SLD-2XN80FK MC-DC100V MT-AC24V, SLD-N80FK MC-DC100V MT-AC100V, SLD-2XN80FK MC-DC100V MT-AC100V, SLD-N80FK MC-DC100V MT-AC200V, SLD-2XN80FK MC-DC100V MT-AC200V, SLD-N80FK MC-DC100V MT-AC230V, SLD-2XN80FK MC-DC100V MT-AC230V, SLD-N80FK MC-DC100V MT-DC100V, SLD-2XN80FK MC-DC100V MT-DC100V + 14 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SLD-N80FK MC-DC100V MT-AC24VSLD-N80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC24V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC24V rated 24V 50Hz, 24V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC100V MT-AC24VSLD-2XN80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC24V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC24V rated 24V 50Hz, 24V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC100V MT-AC100VSLD-N80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC100V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC100V rated 100V 50Hz, 100-110V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC100V MT-AC100VSLD-2XN80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC100V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC100V rated 100V 50Hz, 100-110V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC100V MT-AC200VSLD-N80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC200V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC200V rated 200V 50Hz, 200-220V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC100V MT-AC200VSLD-2XN80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC200V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC200V rated 200V 50Hz, 200-220V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC100V MT-AC230VSLD-N80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC230V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC230V rated 220-240V 50Hz, 230-240V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC100V MT-AC230VSLD-2XN80FK class 1 heat-resistant latch contactor, MC DC100V and MT AC230V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: AC230V rated 220-240V 50Hz, 230-240V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC100V MT-DC100VSLD-N80FK class 1 heat-resistant latch contactor, MC DC100V and MT DC100V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: DC100V rated DC100-110V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC100V MT-DC100VSLD-2XN80FK class 1 heat-resistant latch contactor, MC DC100V and MT DC100V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: DC100V rated DC100-110V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC100V MT-DC200VSLD-N80FK class 1 heat-resistant latch contactor, MC DC100V and MT DC200V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: DC200V rated DC200-220V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC100V MT-DC200VSLD-2XN80FK class 1 heat-resistant latch contactor, MC DC100V and MT DC200V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC100V rated DC100-110V | Tripping Coil MT: DC200V rated DC200-220V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC200V MT-AC24VSLD-N80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC24V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC24V rated 24V 50Hz, 24V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC200V MT-AC24VSLD-2XN80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC24V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC24V rated 24V 50Hz, 24V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC200V MT-AC100VSLD-N80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC100V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC100V rated 100V 50Hz, 100-110V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC200V MT-AC100VSLD-2XN80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC100V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC100V rated 100V 50Hz, 100-110V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC200V MT-AC200VSLD-N80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC200V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC200V rated 200V 50Hz, 200-220V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC200V MT-AC200VSLD-2XN80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC200V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC200V rated 200V 50Hz, 200-220V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC200V MT-AC230VSLD-N80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC230V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC230V rated 220-240V 50Hz, 230-240V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC200V MT-AC230VSLD-2XN80FK class 1 heat-resistant latch contactor, MC DC200V and MT AC230V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: AC230V rated 220-240V 50Hz, 230-240V 60Hz | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC200V MT-DC100VSLD-N80FK class 1 heat-resistant latch contactor, MC DC200V and MT DC100V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: DC100V rated DC100-110V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC200V MT-DC100VSLD-2XN80FK class 1 heat-resistant latch contactor, MC DC200V and MT DC100V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: DC100V rated DC100-110V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-N80FK MC-DC200V MT-DC200VSLD-N80FK class 1 heat-resistant latch contactor, MC DC200V and MT DC200V, non-reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Non-reversing | Main Contact: 3a | Aux Contact: 1a2b | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: DC200V rated DC200-220V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
SLD-2XN80FK MC-DC200V MT-DC200VSLD-2XN80FK class 1 heat-resistant latch contactor, MC DC200V and MT DC200V, reversing | Type: Class 1 heat-resistant magnetic contactor for emergency power switchboards | Frame: N80 | Configuration: Reversing | Main Contact: 3a | Aux Contact: 1a2b x2 | Mechanism: Mechanical latch | Operation: DC operated closing coil | Closing Coil MC: DC200V rated DC200-220V | Tripping Coil MT: DC200V rated DC200-220V | Heat Resistant Carrying Current: 94.5A | Heat Resistant Rated Current AC-3 Class: 80A at AC220V, 80A at AC440V, 75A at AC550V | Heat Resistant Rated Current AC-1 Class: 94.5A at AC220V, 94.5A at AC440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Aux Contact Rating: Carry 10A, AC-15 class 6A at 110V and 5A at 220V and 3A at 550V, AC-12 class 10A at 110V and 10A at 220V, DC-13 class 3A at DC48V and 0.6A at DC110V and 0.2A at DC220V, DC-12 class 5A at DC110V and 1A at DC220V | Coil Inrush Input: Inrush AC operated 3900VA closing and 1500VA tripping, DC operated 460VA closing and 390VA tripping | Operating Voltage: AC operated 110V closing and 100V tripping, DC operated 45V closing and 40V tripping | Operating Time: AC operated 11ms closing and 8ms tripping, DC operated 17ms closing and 10ms tripping | Durability: Mechanical and electrical 250,000 operations | Type Approval Number: 1MC-99041 | Heat Performance: Class 1 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one third fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981
