Myung Shin IP Series Power Base Rack-and-Pinion Lift Guide Unit (General Type, 4-Unit Set, Reverse Mounting)

Myung Shin IP Series Power Base Rack-and-Pinion Lift Guide Unit (General Type, 4-Unit Set, Reverse Mounting)

Four-unit flanged IP power base set built for reverse (upside-down) mounting, where the rack gear extends from the bottom of the gearbox.

Key features

  • For installations where the power base is used inverted
  • Height H and stroke specified at order
  • Four gearboxes linked by torque shafts for synchronized travel
  • Load capacities from 300 kg to 20,000 kg

Specifications

Type Standard (reverse type)
Units per set 4
Flange With rack gear flange
Myung Shin IP Series Power Base Rack-and-Pinion Lift Guide Unit (General Type, 4-Unit Set, Reverse Mounting) - reference 2
IP300F-4S-RE Load: max. 300 kg | Max stroke: 350 mm | Gear module: M1
IP500F-4S-RE Load: max. 500 kg | Max stroke: 600 mm | Gear module: M1.5
IP900F-4S-RE Load: max. 900 kg | Max stroke: 1300 mm | Gear module: M1.5
IP1500F-4S-RE Load: max. 1500 kg | Max stroke: 1300 mm | Gear module: M2
IP3000F-4S-RE Load: max. 3000 kg | Max stroke: 1500 mm | Gear module: M3
IP5000F-4S-RE Load: max. 5000 kg | Max stroke: 1500 mm | Gear module: M3
IP10000F-4S-RE Load: max. 10000 kg | Max stroke: 2000 mm | Gear module: M3
IP20000F-4S-RE Load: max. 20000 kg | Max stroke: 2200 mm | Gear module: M4
Power BasesMyung Shin
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Myung Shin IP Series Power Base Rack-and-Pinion Lift Guide Unit (General Type, 4-Unit Set, Reverse Mounting)

Brand Myung Shin·Power Bases

Available part numbers (8)

IP300F-4S-RE, IP500F-4S-RE, IP900F-4S-RE, IP1500F-4S-RE, IP3000F-4S-RE, IP5000F-4S-RE, IP10000F-4S-RE, IP20000F-4S-RE

How to order

Send the Myung Shin part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
Myung Shin IP Series Power Base Rack-and-Pinion Lift Guide Unit (General Type, 4-Unit Set, Reverse Mounting) - reference 2
0 selected
RFQ List (0)
Product codeSpec
IP300F-4S-RELoad: max. 300 kg | Max stroke: 350 mm | Gear module: M1
IP500F-4S-RELoad: max. 500 kg | Max stroke: 600 mm | Gear module: M1.5
IP900F-4S-RELoad: max. 900 kg | Max stroke: 1300 mm | Gear module: M1.5
IP1500F-4S-RELoad: max. 1500 kg | Max stroke: 1300 mm | Gear module: M2
IP3000F-4S-RELoad: max. 3000 kg | Max stroke: 1500 mm | Gear module: M3
IP5000F-4S-RELoad: max. 5000 kg | Max stroke: 1500 mm | Gear module: M3
IP10000F-4S-RELoad: max. 10000 kg | Max stroke: 2000 mm | Gear module: M3
IP20000F-4S-RELoad: max. 20000 kg | Max stroke: 2200 mm | Gear module: M4
