Myung Shin IPC Series Power Base Rack-and-Pinion Lift Guide Unit (Clean Room Type)
Myung Shin IPC Series Power Base Rack-and-Pinion Lift Guide Unit (Clean Room Type)
Clean room version of the IP power base with plated surfaces and optional silicone bellows and lower cover to minimize particle emission.
Key features
- Hard chrome plating / electroless nickel plating surface treatment
- Optional silicone bellows (white or black) over the rack gear
- Optional lower cover to contain internal dust
- For FPD, LCD, glass pin-up, solar cell, medical and food production equipment
- Basic height H changes with the stroke used
Specifications
| Type | Clean room type |
|---|---|
| Bellows material | Silicone |
| Rack gear finish | Hard chrome plating / Raydent |
| Flange finish | Electroless nickel plating |
| IPC300-1S-CC | Load: max. 300 kg per set of 4 | Max stroke: 350 mm | Gear module: M1 | Version: Without flange | |
| IPC300F-1S-CC | Load: max. 300 kg per set of 4 | Max stroke: 350 mm | Gear module: M1 | Version: With flange | |
| IPC300F-1S-CCB | Load: max. 300 kg per set of 4 | Max stroke: 350 mm | Gear module: M1 | Version: With flange, silicone bellows | |
| IPC300F-1S-CCBL | Load: max. 300 kg per set of 4 | Max stroke: 350 mm | Gear module: M1 | Version: With flange, silicone bellows and lower cover | |
| IPC500-1S-CC | Load: max. 500 kg per set of 4 | Max stroke: 600 mm | Gear module: M1.5 | Version: Without flange | |
| IPC500F-1S-CC | Load: max. 500 kg per set of 4 | Max stroke: 600 mm | Gear module: M1.5 | Version: With flange | |
| IPC500F-1S-CCB | Load: max. 500 kg per set of 4 | Max stroke: 600 mm | Gear module: M1.5 | Version: With flange, silicone bellows | |
| IPC500F-1S-CCBL | Load: max. 500 kg per set of 4 | Max stroke: 600 mm | Gear module: M1.5 | Version: With flange, silicone bellows and lower cover | |
| IPC900-1S-CC | Load: max. 900 kg per set of 4 | Max stroke: 1300 mm | Gear module: M1.5 | Version: Without flange | |
| IPC900F-1S-CC | Load: max. 900 kg per set of 4 | Max stroke: 1300 mm | Gear module: M1.5 | Version: With flange | |
| IPC900F-1S-CCB | Load: max. 900 kg per set of 4 | Max stroke: 1300 mm | Gear module: M1.5 | Version: With flange, silicone bellows | |
| IPC900F-1S-CCBL | Load: max. 900 kg per set of 4 | Max stroke: 1300 mm | Gear module: M1.5 | Version: With flange, silicone bellows and lower cover | |
| IPC1500-1S-CC | Load: max. 1,500 kg per set of 4 | Max stroke: 1300 mm | Gear module: M2 | Version: Without flange | |
| IPC1500F-1S-CC | Load: max. 1,500 kg per set of 4 | Max stroke: 1300 mm | Gear module: M2 | Version: With flange | |
| IPC1500F-1S-CCB | Load: max. 1,500 kg per set of 4 | Max stroke: 1300 mm | Gear module: M2 | Version: With flange, silicone bellows | |
| IPC1500F-1S-CCBL | Load: max. 1,500 kg per set of 4 | Max stroke: 1300 mm | Gear module: M2 | Version: With flange, silicone bellows and lower cover | |
| IPC3000-1S-CC | Load: max. 3,000 kg per set of 4 | Max stroke: 1500 mm | Gear module: M3 | Version: Without flange | |
| IPC3000F-1S-CC | Load: max. 3,000 kg per set of 4 | Max stroke: 1500 mm | Gear module: M3 | Version: With flange | |
| IPC3000F-1S-CCB | Load: max. 3,000 kg per set of 4 | Max stroke: 1500 mm | Gear module: M3 | Version: With flange, silicone bellows | |
| IPC5000-1S-CC | Load: max. 5,000 kg per set of 4 | Max stroke: 1500 mm | Gear module: M3 | Version: Without flange | |
| IPC5000F-1S-CC | Load: max. 5,000 kg per set of 4 | Max stroke: 1500 mm | Gear module: M3 | Version: With flange | |
| IPC5000F-1S-CCB | Load: max. 5,000 kg per set of 4 | Max stroke: 1500 mm | Gear module: M3 | Version: With flange, silicone bellows |
Power BasesMyung Shin
22 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
Need a different model, or a part not listed here? Send us your parts list →
Myung Shin IPC Series Power Base Rack-and-Pinion Lift Guide Unit (Clean Room Type)
Available part numbers (22)
IPC300-1S-CC, IPC300F-1S-CC, IPC300F-1S-CCB, IPC300F-1S-CCBL, IPC500-1S-CC, IPC500F-1S-CC, IPC500F-1S-CCB, IPC500F-1S-CCBL, IPC900-1S-CC, IPC900F-1S-CC + 12 more — see full table ↓
How to order
Send the Myung Shin part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
Myung Shin
Power Bases
Photo on request
Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| IPC300-1S-CC | Load: max. 300 kg per set of 4 | Max stroke: 350 mm | Gear module: M1 | Version: Without flange | ||
| IPC300F-1S-CC | Load: max. 300 kg per set of 4 | Max stroke: 350 mm | Gear module: M1 | Version: With flange | ||
| IPC300F-1S-CCB | Load: max. 300 kg per set of 4 | Max stroke: 350 mm | Gear module: M1 | Version: With flange, silicone bellows | ||
| IPC300F-1S-CCBL | Load: max. 300 kg per set of 4 | Max stroke: 350 mm | Gear module: M1 | Version: With flange, silicone bellows and lower cover | ||
| IPC500-1S-CC | Load: max. 500 kg per set of 4 | Max stroke: 600 mm | Gear module: M1.5 | Version: Without flange | ||
| IPC500F-1S-CC | Load: max. 500 kg per set of 4 | Max stroke: 600 mm | Gear module: M1.5 | Version: With flange | ||
| IPC500F-1S-CCB | Load: max. 500 kg per set of 4 | Max stroke: 600 mm | Gear module: M1.5 | Version: With flange, silicone bellows | ||
| IPC500F-1S-CCBL | Load: max. 500 kg per set of 4 | Max stroke: 600 mm | Gear module: M1.5 | Version: With flange, silicone bellows and lower cover | ||
| IPC900-1S-CC | Load: max. 900 kg per set of 4 | Max stroke: 1300 mm | Gear module: M1.5 | Version: Without flange | ||
| IPC900F-1S-CC | Load: max. 900 kg per set of 4 | Max stroke: 1300 mm | Gear module: M1.5 | Version: With flange | ||
| IPC900F-1S-CCB | Load: max. 900 kg per set of 4 | Max stroke: 1300 mm | Gear module: M1.5 | Version: With flange, silicone bellows | ||
| IPC900F-1S-CCBL | Load: max. 900 kg per set of 4 | Max stroke: 1300 mm | Gear module: M1.5 | Version: With flange, silicone bellows and lower cover | ||
| IPC1500-1S-CC | Load: max. 1,500 kg per set of 4 | Max stroke: 1300 mm | Gear module: M2 | Version: Without flange | ||
| IPC1500F-1S-CC | Load: max. 1,500 kg per set of 4 | Max stroke: 1300 mm | Gear module: M2 | Version: With flange | ||
| IPC1500F-1S-CCB | Load: max. 1,500 kg per set of 4 | Max stroke: 1300 mm | Gear module: M2 | Version: With flange, silicone bellows | ||
| IPC1500F-1S-CCBL | Load: max. 1,500 kg per set of 4 | Max stroke: 1300 mm | Gear module: M2 | Version: With flange, silicone bellows and lower cover | ||
| IPC3000-1S-CC | Load: max. 3,000 kg per set of 4 | Max stroke: 1500 mm | Gear module: M3 | Version: Without flange | ||
| IPC3000F-1S-CC | Load: max. 3,000 kg per set of 4 | Max stroke: 1500 mm | Gear module: M3 | Version: With flange | ||
| IPC3000F-1S-CCB | Load: max. 3,000 kg per set of 4 | Max stroke: 1500 mm | Gear module: M3 | Version: With flange, silicone bellows | ||
| IPC5000-1S-CC | Load: max. 5,000 kg per set of 4 | Max stroke: 1500 mm | Gear module: M3 | Version: Without flange | ||
| IPC5000F-1S-CC | Load: max. 5,000 kg per set of 4 | Max stroke: 1500 mm | Gear module: M3 | Version: With flange | ||
| IPC5000F-1S-CCB | Load: max. 5,000 kg per set of 4 | Max stroke: 1500 mm | Gear module: M3 | Version: With flange, silicone bellows |
Need a different model, or a part not listed here? Send us your parts list →
