Myung Shin IP Series Power Base Rack-and-Pinion Lift Guide Unit (General Type, 4-Unit Set with Flange)

Myung Shin IP Series Power Base Rack-and-Pinion Lift Guide Unit (General Type, 4-Unit Set with Flange)

Set of four flanged IP power base gearboxes connected by torque shafts, forming a complete rack-and-pinion up/down guide frame.

Key features

  • Four rack-and-pinion gearboxes linked by shafts for synchronized lifting
  • Rack gear flange for direct mounting of the upper frame
  • Power base center distances L x W and stroke specified at order
  • Load capacities from 300 kg to 20,000 kg

Specifications

Type Standard
Units per set 4
Flange With rack gear flange
Myung Shin IP Series Power Base Rack-and-Pinion Lift Guide Unit (General Type, 4-Unit Set with Flange) - reference 2
IP300F-4S Load: max. 300 kg | Max stroke: 350 mm | Gear module: M1
IP500F-4S Load: max. 500 kg | Max stroke: 600 mm | Gear module: M1.5
IP900F-4S Load: max. 900 kg | Max stroke: 1300 mm | Gear module: M1.5
IP1500F-4S Load: max. 1500 kg | Max stroke: 1300 mm | Gear module: M2
IP3000F-4S Load: max. 3000 kg | Max stroke: 1500 mm | Gear module: M3
IP5000F-4S Load: max. 5000 kg | Max stroke: 1500 mm | Gear module: M3
IP10000F-4S Load: max. 10000 kg | Max stroke: 2000 mm | Gear module: M3
IP20000F-4S Load: max. 20000 kg | Max stroke: 2200 mm | Gear module: M4
Power BasesMyung Shin
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Myung Shin IP Series Power Base Rack-and-Pinion Lift Guide Unit (General Type, 4-Unit Set with Flange)

Brand Myung Shin·Power Bases

Available part numbers (8)

IP300F-4S, IP500F-4S, IP900F-4S, IP1500F-4S, IP3000F-4S, IP5000F-4S, IP10000F-4S, IP20000F-4S

How to order

Send the Myung Shin part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
Myung Shin IP Series Power Base Rack-and-Pinion Lift Guide Unit (General Type, 4-Unit Set with Flange) - reference 2
0 selected
RFQ List (0)
Product codeSpec
IP300F-4SLoad: max. 300 kg | Max stroke: 350 mm | Gear module: M1
IP500F-4SLoad: max. 500 kg | Max stroke: 600 mm | Gear module: M1.5
IP900F-4SLoad: max. 900 kg | Max stroke: 1300 mm | Gear module: M1.5
IP1500F-4SLoad: max. 1500 kg | Max stroke: 1300 mm | Gear module: M2
IP3000F-4SLoad: max. 3000 kg | Max stroke: 1500 mm | Gear module: M3
IP5000F-4SLoad: max. 5000 kg | Max stroke: 1500 mm | Gear module: M3
IP10000F-4SLoad: max. 10000 kg | Max stroke: 2000 mm | Gear module: M3
IP20000F-4SLoad: max. 20000 kg | Max stroke: 2200 mm | Gear module: M4
