Myung Shin IPL Series Power Base Rack-and-Pinion Lift Guide Unit (LM Guide Type)

Myung Shin IPL Series Power Base Rack-and-Pinion Lift Guide Unit (LM Guide Type)

Power base that uses an LM guide instead of bushings for smooth operation and durability in high-frequency applications.

Key features

  • LM guide in place of the standard bush guide
  • Smooth operation and maximized durability for frequent use
  • Silicone bellows and lower cover
  • Tight shaft pitch and balance tolerances

Specifications

Gear module M2
Pinion teeth 18
Max stroke 700 mm
Shaft pitch tolerance ±0.5 mm
Balance tolerance ±0.1 mm
Lead per rev 113.04 mm
IPL600 Module: M2 | Pinion teeth: 18 | Max stroke: 700 mm | Shaft pitch tolerance: ±0.5 mm | Balance tolerance: ±0.1 mm | Lead per rev: 113.04 mm | Actuator: same as IP series
Power BasesMyung Shin
1 product code available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Myung Shin IPL Series Power Base Rack-and-Pinion Lift Guide Unit (LM Guide Type)

Brand Myung Shin·Power Bases

Available part numbers (1)

IPL600

How to order

Send the Myung Shin part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
IPL600Module: M2 | Pinion teeth: 18 | Max stroke: 700 mm | Shaft pitch tolerance: ±0.5 mm | Balance tolerance: ±0.1 mm | Lead per rev: 113.04 mm | Actuator: same as IP series
