NTN 29400 Series Spherical Roller Thrust Bearings

NTN 29400 Series Spherical Roller Thrust Bearings

NTN 29400 series spherical roller thrust bearings, bore 60-480 mm, for heavy axial loads with some radial load and misalignment.

Key features

  • Very high axial load capacity
  • Accommodates misalignment through spherical housing washer raceway
  • Can also carry radial load up to a set proportion of axial load
  • Oil lubrication generally recommended

Specifications

Series 29400
Bearing type Spherical roller thrust bearing
Bore range 60-480 mm
Load rating unit kN (axial)
Brand NTN
Source NTN NTN Ball and Roller Bearings catalogue, p. 164-166
29412 d: 60 mm | D: 130 mm | T: 42 mm | Ca: 283 kN | C0a: 805 kN | Mass: 2.78 kg
29413 d: 65 mm | D: 140 mm | T: 45 mm | Ca: 330 kN | C0a: 945 kN | Mass: 3.44 kg
29414 d: 70 mm | D: 150 mm | T: 48 mm | Ca: 365 kN | C0a: 1040 kN | Mass: 4.19 kg
29415 d: 75 mm | D: 160 mm | T: 51 mm | Ca: 415 kN | C0a: 1190 kN | Mass: 5.07 kg
29416 d: 80 mm | D: 170 mm | T: 54 mm | Ca: 460 kN | C0a: 1380 kN | Mass: 6.09 kg
29417 d: 85 mm | D: 180 mm | T: 58 mm | Ca: 490 kN | C0a: 1480 kN | Mass: 7.2 kg
29418 d: 90 mm | D: 190 mm | T: 60 mm | Ca: 545 kN | C0a: 1680 kN | Mass: 8.38 kg
29420 d: 100 mm | D: 210 mm | T: 67 mm | Ca: 685 kN | C0a: 2130 kN | Mass: 11.5 kg
29422 d: 110 mm | D: 230 mm | T: 73 mm | Ca: 845 kN | C0a: 2620 kN | Mass: 15 kg
29424 d: 120 mm | D: 250 mm | T: 78 mm | Ca: 975 kN | C0a: 3050 kN | Mass: 18.6 kg
29426 d: 130 mm | D: 270 mm | T: 85 mm | Ca: 1080 kN | C0a: 3550 kN | Mass: 23.7 kg
29428 d: 140 mm | D: 280 mm | T: 85 mm | Ca: 1110 kN | C0a: 3750 kN | Mass: 25.2 kg
29430 d: 150 mm | D: 300 mm | T: 90 mm | Ca: 1280 kN | C0a: 4350 kN | Mass: 30.5 kg
29432 d: 160 mm | D: 320 mm | T: 95 mm | Ca: 1500 kN | C0a: 5150 kN | Mass: 37 kg
29434 d: 170 mm | D: 340 mm | T: 103 mm | Ca: 1660 kN | C0a: 5750 kN | Mass: 45 kg
29436 d: 180 mm | D: 360 mm | T: 109 mm | Ca: 1840 kN | C0a: 6200 kN | Mass: 52.9 kg
29438 d: 190 mm | D: 380 mm | T: 115 mm | Ca: 2010 kN | C0a: 6800 kN | Mass: 62 kg
29440 d: 200 mm | D: 400 mm | T: 122 mm | Ca: 2230 kN | C0a: 7650 kN | Mass: 73.3 kg
29444 d: 220 mm | D: 420 mm | T: 122 mm | Ca: 2300 kN | C0a: 8100 kN | Mass: 77.8 kg
29448 d: 240 mm | D: 440 mm | T: 122 mm | Ca: 2400 kN | C0a: 8700 kN | Mass: 82.6 kg
29452 d: 260 mm | D: 480 mm | T: 132 mm | Ca: 2740 kN | C0a: 10000 kN | Mass: 108 kg
29456 d: 280 mm | D: 520 mm | T: 145 mm | Ca: 3350 kN | C0a: 12400 kN | Mass: 140 kg
29460 d: 300 mm | D: 540 mm | T: 145 mm | Ca: 3450 kN | C0a: 13200 kN | Mass: 147 kg
29464 d: 320 mm | D: 580 mm | T: 155 mm | Ca: 3700 kN | C0a: 14200 kN | Mass: 181 kg
29468 d: 340 mm | D: 620 mm | T: 170 mm | Ca: 4400 kN | C0a: 17500 kN | Mass: 230 kg
29472 d: 360 mm | D: 640 mm | T: 170 mm | Ca: 4500 kN | C0a: 18500 kN | Mass: 240 kg
29476 d: 380 mm | D: 670 mm | T: 175 mm | Ca: 4900 kN | C0a: 19700 kN | Mass: 267 kg
29480 d: 400 mm | D: 710 mm | T: 185 mm | Ca: 5450 kN | C0a: 22100 kN | Mass: 321 kg
29484 d: 420 mm | D: 730 mm | T: 185 mm | Ca: 5500 kN | C0a: 22800 kN | Mass: 333 kg
29488 d: 440 mm | D: 780 mm | T: 206 mm | Ca: 6400 kN | C0a: 26200 kN | Mass: 428 kg
29492 d: 460 mm | D: 800 mm | T: 206 mm | Ca: 6600 kN | C0a: 27900 kN | Mass: 443 kg
29496 d: 480 mm | D: 850 mm | T: 224 mm | Ca: 7500 kN | C0a: 31500 kN | Mass: 552 kg
