NTN AS2 Series Insert Bearings (Set Screw Type)

NTN AS2 Series Insert Bearings (Set Screw Type)

NTN AS2 series insert bearings (bearing unit inserts) with set screw locking and spherical outer ring, as listed in the NTN bearing unit tables.

Key features

  • Spherical outer ring self-aligns in the housing
  • Set screw locking to the shaft
  • Sealed and pre-lubricated
  • Replacement insert for NTN housed units of the matching series

Specifications

Series AS2
Product type Insert bearing (set screw type)
Locking Set screw
Brand NTN
Product category Insert Bearings
Source NTN NTN Bearing Units Dimension Table, p. 108-201
AS201-008D1 Shaft: 1/2 in | Bore: Inch | Used in e.g.: ASPB201-008D1
AS201D1 Shaft: 12 mm | Bore: Metric | Used in e.g.: ASPB201D1
AS202-009D1 Shaft: 9/16 in | Bore: Inch | Used in e.g.: ASPB202-009D1
AS202-010D1 Shaft: 5/8 in | Bore: Inch | Used in e.g.: ASPB202-010D1
AS202D1 Shaft: 15 mm | Bore: Metric | Used in e.g.: ASPB202D1
AS203-011D1 Shaft: 11/16 in | Bore: Inch | Used in e.g.: ASPB203-011D1
AS203D1 Shaft: 17 mm | Bore: Metric | Used in e.g.: ASPB203D1
AS204-012D1 Shaft: 3/4 in | Bore: Inch | Used in e.g.: ASPB204-012D1
AS204D1 Shaft: 20 mm | Bore: Metric | Used in e.g.: ASPB204D1
AS205-013D1 Shaft: 13/16 in | Bore: Inch | Used in e.g.: ASPB205-013D1
AS205-014D1 Shaft: 7/8 in | Bore: Inch | Used in e.g.: ASPB205-014D1
AS205-015D1 Shaft: 15/16 in | Bore: Inch | Used in e.g.: ASPB205-015D1
AS205-100D1 Shaft: 1 in | Bore: Inch | Used in e.g.: ASPB205-100D1
AS205D1 Shaft: 25 mm | Bore: Metric | Used in e.g.: ASPB205D1
AS206-101D1 Shaft: 1-1/16 in | Bore: Inch | Used in e.g.: ASPB206-101D1
AS206-102D1 Shaft: 1-1/8 in | Bore: Inch | Used in e.g.: ASPB206-102D1
AS206-103D1 Shaft: 1-3/16 in | Bore: Inch | Used in e.g.: ASPB206-103D1
AS206-104D1 Shaft: 1-1/4 in | Bore: Inch | Used in e.g.: ASPB206-104D1
AS206D1 Shaft: 30 mm | Bore: Metric | Used in e.g.: ASPB206D1
AS207-104D1 Shaft: 1-1/4 in | Bore: Inch | Used in e.g.: ASPB207-104D1
AS207-105D1 Shaft: 1-5/16 in | Bore: Inch | Used in e.g.: ASPB207-105D1
AS207-106D1 Shaft: 1-3/8 in | Bore: Inch | Used in e.g.: ASPB207-106D1
AS207-107D1 Shaft: 1-7/16 in | Bore: Inch | Used in e.g.: ASPB207-107D1
AS207D1 Shaft: 35 mm | Bore: Metric | Used in e.g.: ASPB207D1
AS208-108D1 Shaft: 1-1/2 in | Bore: Inch | Used in e.g.: ASPB208-108D1
AS208-109D1 Shaft: 1-9/16 in | Bore: Inch | Used in e.g.: ASPB208-109D1
AS208D1 Shaft: 40 mm | Bore: Metric | Used in e.g.: ASPB208D1
AS208 Shaft: 40 mm | Bore: Metric | Used in e.g.: ASPF208
AS208-108 Shaft: 1-1/2 in | Bore: Inch | Used in e.g.: ASPF208-108
AS208-109 Shaft: 1-9/16 in | Bore: Inch | Used in e.g.: ASPF208-109
AS209-110D1 Shaft: 1-5/8 in | Bore: Inch | Used in e.g.: ASPL209-110D1
AS209-111D1 Shaft: 1-11/16 in | Bore: Inch | Used in e.g.: ASPL209-111D1
AS209-112D1 Shaft: 1-3/4 in | Bore: Inch | Used in e.g.: ASPL209-112D1
AS209D1 Shaft: 45 mm | Bore: Metric | Used in e.g.: ASPL209D1
AS210-113D1 Shaft: 1-13/16 in | Bore: Inch | Used in e.g.: ASPL210-113D1
AS210-114D1 Shaft: 1-7/8 in | Bore: Inch | Used in e.g.: ASPL210-114D1
AS210-115D1 Shaft: 1-15/16 in | Bore: Inch | Used in e.g.: ASPL210-115D1
AS210-200D1 Shaft: 2 in | Bore: Inch | Used in e.g.: ASPL210-200D1
AS210D1 Shaft: 50 mm | Bore: Metric | Used in e.g.: ASPL210D1
AS201 Shaft: 12 mm | Bore: Metric | Used in e.g.: ASPP201
AS201-008 Shaft: 1/2 in | Bore: Inch | Used in e.g.: ASPP201-008
AS202 Shaft: 15 mm | Bore: Metric | Used in e.g.: ASPP202
AS202-009 Shaft: 9/16 in | Bore: Inch | Used in e.g.: ASPP202-009
AS202-010 Shaft: 5/8 in | Bore: Inch | Used in e.g.: ASPP202-010
AS203 Shaft: 17 mm | Bore: Metric | Used in e.g.: ASPP203
AS203-011 Shaft: 11/16 in | Bore: Inch | Used in e.g.: ASPP203-011
AS204 Shaft: 20 mm | Bore: Metric | Used in e.g.: ASPP204
AS204-012 Shaft: 3/4 in | Bore: Inch | Used in e.g.: ASPP204-012
AS205 Shaft: 25 mm | Bore: Metric | Used in e.g.: ASPP205
AS205-013 Shaft: 13/16 in | Bore: Inch | Used in e.g.: ASPP205-013
AS205-014 Shaft: 7/8 in | Bore: Inch | Used in e.g.: ASPP205-014
AS205-015 Shaft: 15/16 in | Bore: Inch | Used in e.g.: ASPP205-015
AS205-100 Shaft: 1 in | Bore: Inch | Used in e.g.: ASPP205-100
AS206 Shaft: 30 mm | Bore: Metric | Used in e.g.: ASPP206
AS206-101 Shaft: 1-1/16 in | Bore: Inch | Used in e.g.: ASPP206-101
AS206-102 Shaft: 1-1/8 in | Bore: Inch | Used in e.g.: ASPP206-102
AS206-103 Shaft: 1-3/16 in | Bore: Inch | Used in e.g.: ASPP206-103
AS206-104 Shaft: 1-1/4 in | Bore: Inch | Used in e.g.: ASPP206-104
AS207 Shaft: 35 mm | Bore: Metric | Used in e.g.: ASPP207
AS207-104 Shaft: 1-1/4 in | Bore: Inch | Used in e.g.: ASPP207-104
AS207-105 Shaft: 1-5/16 in | Bore: Inch | Used in e.g.: ASPP207-105
AS207-106 Shaft: 1-3/8 in | Bore: Inch | Used in e.g.: ASPP207-106
AS207-107 Shaft: 1-7/16 in | Bore: Inch | Used in e.g.: ASPP207-107
Insert BearingsNTN
63 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NTN AS2 Series Insert Bearings (Set Screw Type)

Brand NTN·Insert Bearings

Available part numbers (63)

AS201-008D1, AS201D1, AS202-009D1, AS202-010D1, AS202D1, AS203-011D1, AS203D1, AS204-012D1, AS204D1, AS205-013D1 + 53 more — see full table ↓

How to order

Send the NTN part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
