NTN HJ L-Type Thrust Collars for Cylindrical Roller Bearings

NTN HJ L-Type Thrust Collars for Cylindrical Roller Bearings

NTN HJ L-shaped thrust collars (angle rings) used with NU or NJ cylindrical roller bearings to provide axial location (NU+HJ = NUJ, NJ+HJ = NH).

Key features

  • Converts NU bearings to NUJ and NJ bearings to NH arrangements
  • Provides axial guidance of the shaft in one or both directions
  • Sized to match 2, 3, 4, 22 and 23 series bearings
  • Mass listed per collar

Specifications

Product type L-type thrust collar (HJ)
Used with NU and NJ cylindrical roller bearings
Brand NTN
Product category Bearing Accessories
Dimension unit mm
Source NTN NTN Ball and Roller Bearings catalogue, p. 65-68
HJ204 Bearing bore d: 20 mm | d1: 29.9 mm | B1: 3 mm | B2: 6.75 mm | Mass: 0.012 kg
HJ208 Bearing bore d: 40 mm | d1: 54.2 mm | B1: 5 mm | B2: 9 mm | Mass: 0.046 kg
HJ204E Bearing bore d: 20 mm | d1: 29.5 mm | B1: 3 mm | B2: 5.5 mm | Mass: 0.009 kg
HJ208E Bearing bore d: 40 mm | d1: 53.9 mm | B1: 5 mm | B2: 8.5 mm | Mass: 0.042 kg
HJ2204 Bearing bore d: 20 mm | d1: 29.9 mm | B1: 3 mm | B2: 7.5 mm | Mass: 0.013 kg
HJ2208 Bearing bore d: 40 mm | d1: 54.2 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.047 kg
HJ2204E Bearing bore d: 20 mm | d1: 29.5 mm | B1: 3 mm | B2: 6.5 mm | Mass: 0.01 kg
HJ2208E Bearing bore d: 40 mm | d1: 53.9 mm | B1: 5 mm | B2: 9 mm | Mass: 0.045 kg
HJ304 Bearing bore d: 20 mm | d1: 31.8 mm | B1: 4 mm | B2: 7.5 mm | Mass: 0.017 kg
HJ308 Bearing bore d: 40 mm | d1: 58.4 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.083 kg
HJ304E Bearing bore d: 20 mm | d1: 31.1 mm | B1: 4 mm | B2: 6.5 mm | Mass: 0.014 kg
HJ308E Bearing bore d: 40 mm | d1: 57.6 mm | B1: 7 mm | B2: 11 mm | Mass: 0.07 kg
HJ2304 Bearing bore d: 20 mm | d1: 31.8 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.018 kg
HJ2308 Bearing bore d: 40 mm | d1: 58.4 mm | B1: 7 mm | B2: 14.5 mm | Mass: 0.09 kg
HJ2304E Bearing bore d: 20 mm | d1: 31.1 mm | B1: 4 mm | B2: 7.5 mm | Mass: 0.015 kg
HJ2308E Bearing bore d: 40 mm | d1: 57.6 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.08 kg
HJ205 Bearing bore d: 25 mm | d1: 34.8 mm | B1: 3 mm | B2: 7.25 mm | Mass: 0.015 kg
HJ2205 Bearing bore d: 25 mm | d1: 34.8 mm | B1: 3 mm | B2: 7.5 mm | Mass: 0.015 kg
HJ209E Bearing bore d: 45 mm | d1: 58.9 mm | B1: 5 mm | B2: 8.5 mm | Mass: 0.047 kg
HJ2205E Bearing bore d: 25 mm | d1: 34.5 mm | B1: 3 mm | B2: 6.5 mm | Mass: 0.013 kg
HJ2209E Bearing bore d: 45 mm | d1: 58.9 mm | B1: 5 mm | B2: 9 mm | Mass: 0.05 kg
HJ305 Bearing bore d: 25 mm | d1: 39 mm | B1: 4 mm | B2: 8 mm | Mass: 0.025 kg
HJ309 Bearing bore d: 45 mm | d1: 64 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.099 kg
HJ305E Bearing bore d: 25 mm | d1: 38 mm | B1: 4 mm | B2: 7 mm | Mass: 0.021 kg
HJ309E Bearing bore d: 45 mm | d1: 64.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.093 kg
HJ2305 Bearing bore d: 25 mm | d1: 39 mm | B1: 4 mm | B2: 9 mm | Mass: 0.027 kg
HJ2309 Bearing bore d: 45 mm | d1: 64 mm | B1: 7 mm | B2: 15 mm | Mass: 0.109 kg
HJ2305E Bearing bore d: 25 mm | d1: 38 mm | B1: 4 mm | B2: 8 mm | Mass: 0.024 kg
HJ2309E Bearing bore d: 45 mm | d1: 64.5 mm | B1: 7 mm | B2: 13 mm | Mass: 0.103 kg
HJ409 Bearing bore d: 45 mm | d1: 71.8 mm | B1: 8 mm | B2: 13.5 mm | Mass: 0.175 kg
HJ206 Bearing bore d: 30 mm | d1: 41.7 mm | B1: 4 mm | B2: 8.25 mm | Mass: 0.025 kg
HJ210 Bearing bore d: 50 mm | d1: 64.6 mm | B1: 5 mm | B2: 10 mm | Mass: 0.063 kg
HJ206E Bearing bore d: 30 mm | d1: 41.1 mm | B1: 4 mm | B2: 7 mm | Mass: 0.017 kg
HJ2206 Bearing bore d: 30 mm | d1: 41.7 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.025 kg
HJ2210 Bearing bore d: 50 mm | d1: 64.6 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.061 kg
HJ2206E Bearing bore d: 30 mm | d1: 41.1 mm | B1: 4 mm | B2: 7.5 mm | Mass: 0.02 kg
HJ310 Bearing bore d: 50 mm | d1: 71 mm | B1: 8 mm | B2: 14 mm | Mass: 0.142 kg
HJ306 Bearing bore d: 30 mm | d1: 45.9 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.039 kg
HJ310E Bearing bore d: 50 mm | d1: 71.4 mm | B1: 8 mm | B2: 13 mm | Mass: 0.134 kg
HJ306E Bearing bore d: 30 mm | d1: 44.9 mm | B1: 5 mm | B2: 8.5 mm | Mass: 0.035 kg
HJ2310 Bearing bore d: 50 mm | d1: 71 mm | B1: 8 mm | B2: 17 mm | Mass: 0.157 kg
HJ2306 Bearing bore d: 30 mm | d1: 45.9 mm | B1: 5 mm | B2: 11.5 mm | Mass: 0.043 kg
HJ2310E Bearing bore d: 50 mm | d1: 71.4 mm | B1: 8 mm | B2: 14.5 mm | Mass: 0.15 kg
HJ2306E Bearing bore d: 30 mm | d1: 44.9 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.035 kg
HJ410 Bearing bore d: 50 mm | d1: 78.8 mm | B1: 9 mm | B2: 14.5 mm | Mass: 0.23 kg
HJ406 Bearing bore d: 30 mm | d1: 50.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.08 kg
HJ207 Bearing bore d: 35 mm | d1: 47.6 mm | B1: 4 mm | B2: 8 mm | Mass: 0.03 kg
HJ211E Bearing bore d: 55 mm | d1: 70.8 mm | B1: 6 mm | B2: 9.5 mm | Mass: 0.072 kg
HJ207E Bearing bore d: 35 mm | d1: 48 mm | B1: 4 mm | B2: 7 mm | Mass: 0.027 kg
HJ2211E Bearing bore d: 55 mm | d1: 70.8 mm | B1: 6 mm | B2: 10 mm | Mass: 0.076 kg
HJ2207 Bearing bore d: 35 mm | d1: 47.6 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.031 kg
HJ311 Bearing bore d: 55 mm | d1: 77.2 mm | B1: 9 mm | B2: 15 mm | Mass: 0.182 kg
HJ2207E Bearing bore d: 35 mm | d1: 48 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.031 kg
HJ311E Bearing bore d: 55 mm | d1: 77.7 mm | B1: 9 mm | B2: 14 mm | Mass: 0.168 kg
HJ307 Bearing bore d: 35 mm | d1: 50.8 mm | B1: 6 mm | B2: 11 mm | Mass: 0.056 kg
HJ2311 Bearing bore d: 55 mm | d1: 77.2 mm | B1: 9 mm | B2: 18.5 mm | Mass: 0.203 kg
HJ307E Bearing bore d: 35 mm | d1: 51 mm | B1: 6 mm | B2: 9.5 mm | Mass: 0.048 kg
HJ2311E Bearing bore d: 55 mm | d1: 77.7 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.185 kg
HJ2307 Bearing bore d: 35 mm | d1: 50.8 mm | B1: 6 mm | B2: 14 mm | Mass: 0.064 kg
HJ411 Bearing bore d: 55 mm | d1: 85.2 mm | B1: 10 mm | B2: 16.5 mm | Mass: 0.29 kg
HJ2307E Bearing bore d: 35 mm | d1: 51 mm | B1: 6 mm | B2: 11 mm | Mass: 0.055 kg
HJ407 Bearing bore d: 35 mm | d1: 59 mm | B1: 8 mm | B2: 13 mm | Mass: 0.12 kg
HJ312 Bearing bore d: 60 mm | d1: 84.2 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.22 kg
HJ2316E Bearing bore d: 80 mm | d1: 111 mm | B1: 11 mm | B2: 20 mm | Mass: 0.45 kg
HJ312E Bearing bore d: 60 mm | d1: 84.6 mm | B1: 9 mm | B2: 14.5 mm | Mass: 0.205 kg
HJ416 Bearing bore d: 80 mm | d1: 122 mm | B1: 13 mm | B2: 22 mm | Mass: 0.78 kg
HJ2312 Bearing bore d: 60 mm | d1: 84.2 mm | B1: 9 mm | B2: 19 mm | Mass: 0.245 kg
HJ2312E Bearing bore d: 60 mm | d1: 84.6 mm | B1: 9 mm | B2: 16 mm | Mass: 0.23 kg
HJ412 Bearing bore d: 60 mm | d1: 91.8 mm | B1: 10 mm | B2: 16.5 mm | Mass: 0.34 kg
HJ217E Bearing bore d: 85 mm | d1: 107.7 mm | B1: 8 mm | B2: 12.5 mm | Mass: 0.21 kg
HJ2217E Bearing bore d: 85 mm | d1: 107.7 mm | B1: 8 mm | B2: 13 mm | Mass: 0.216 kg
HJ213 Bearing bore d: 65 mm | d1: 84.8 mm | B1: 6 mm | B2: 11 mm | Mass: 0.123 kg
HJ317 Bearing bore d: 85 mm | d1: 117.5 mm | B1: 12 mm | B2: 20.5 mm | Mass: 0.56 kg
HJ213E Bearing bore d: 65 mm | d1: 84.5 mm | B1: 6 mm | B2: 10 mm | Mass: 0.111 kg
HJ317E Bearing bore d: 85 mm | d1: 118.4 mm | B1: 12 mm | B2: 18.5 mm | Mass: 0.505 kg
HJ2213 Bearing bore d: 65 mm | d1: 84.8 mm | B1: 6 mm | B2: 11.5 mm | Mass: 0.126 kg
HJ2317 Bearing bore d: 85 mm | d1: 117.5 mm | B1: 12 mm | B2: 24 mm | Mass: 0.606 kg
HJ2317E Bearing bore d: 85 mm | d1: 118.4 mm | B1: 12 mm | B2: 22 mm | Mass: 0.55 kg
HJ313 Bearing bore d: 65 mm | d1: 91 mm | B1: 10 mm | B2: 17 mm | Mass: 0.28 kg
HJ313E Bearing bore d: 65 mm | d1: 91 mm | B1: 10 mm | B2: 15.5 mm | Mass: 0.25 kg
HJ218 Bearing bore d: 90 mm | d1: 114.2 mm | B1: 9 mm | B2: 15 mm | Mass: 0.305 kg
HJ2313 Bearing bore d: 65 mm | d1: 91 mm | B1: 10 mm | B2: 20 mm | Mass: 0.304 kg
HJ218E Bearing bore d: 90 mm | d1: 114.6 mm | B1: 9 mm | B2: 14 mm | Mass: 0.272 kg
HJ2313E Bearing bore d: 65 mm | d1: 91 mm | B1: 10 mm | B2: 18 mm | Mass: 0.29 kg
HJ2218 Bearing bore d: 90 mm | d1: 114.2 mm | B1: 9 mm | B2: 16 mm | Mass: 0.315 kg
HJ413 Bearing bore d: 65 mm | d1: 98.5 mm | B1: 11 mm | B2: 18 mm | Mass: 0.42 kg
HJ2218E Bearing bore d: 90 mm | d1: 114.6 mm | B1: 9 mm | B2: 15 mm | Mass: 0.308 kg
HJ318 Bearing bore d: 90 mm | d1: 125 mm | B1: 12 mm | B2: 21 mm | Mass: 0.63 kg
HJ318E Bearing bore d: 90 mm | d1: 124.7 mm | B1: 12 mm | B2: 18.5 mm | Mass: 0.548 kg
HJ214E Bearing bore d: 70 mm | d1: 89.5 mm | B1: 7 mm | B2: 11 mm | Mass: 0.13 kg
HJ2318 Bearing bore d: 90 mm | d1: 125 mm | B1: 12 mm | B2: 26 mm | Mass: 0.704 kg
HJ2214E Bearing bore d: 70 mm | d1: 89.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.138 kg
HJ2318E Bearing bore d: 90 mm | d1: 124.7 mm | B1: 12 mm | B2: 22 mm | Mass: 0.69 kg
HJ314 Bearing bore d: 70 mm | d1: 98 mm | B1: 10 mm | B2: 17.5 mm | Mass: 0.33 kg
HJ314E Bearing bore d: 70 mm | d1: 98 mm | B1: 10 mm | B2: 15.5 mm | Mass: 0.293 kg
HJ219 Bearing bore d: 95 mm | d1: 121 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.352 kg
HJ2314 Bearing bore d: 70 mm | d1: 98 mm | B1: 10 mm | B2: 20.5 mm | Mass: 0.358 kg
HJ219E Bearing bore d: 95 mm | d1: 121 mm | B1: 9 mm | B2: 14 mm | Mass: 0.304 kg
HJ2314E Bearing bore d: 70 mm | d1: 98 mm | B1: 10 mm | B2: 18.5 mm | Mass: 0.35 kg
HJ2219 Bearing bore d: 95 mm | d1: 121 mm | B1: 9 mm | B2: 16.5 mm | Mass: 0.363 kg
HJ414 Bearing bore d: 70 mm | d1: 110.5 mm | B1: 12 mm | B2: 20 mm | Mass: 0.605 kg
HJ2219E Bearing bore d: 95 mm | d1: 121 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.335 kg
HJ319 Bearing bore d: 95 mm | d1: 132 mm | B1: 13 mm | B2: 22.5 mm | Mass: 0.76 kg
HJ319E Bearing bore d: 95 mm | d1: 132.7 mm | B1: 13 mm | B2: 20.5 mm | Mass: 0.7 kg
HJ215E Bearing bore d: 75 mm | d1: 94.5 mm | B1: 7 mm | B2: 11 mm | Mass: 0.141 kg
HJ2319 Bearing bore d: 95 mm | d1: 132 mm | B1: 13 mm | B2: 26.5 mm | Mass: 0.826 kg
HJ2215E Bearing bore d: 75 mm | d1: 94.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.164 kg
HJ2319E Bearing bore d: 95 mm | d1: 132.7 mm | B1: 13 mm | B2: 24.5 mm | Mass: 0.8 kg
HJ315 Bearing bore d: 75 mm | d1: 104.2 mm | B1: 11 mm | B2: 18.5 mm | Mass: 0.4 kg
HJ315E Bearing bore d: 75 mm | d1: 104.6 mm | B1: 11 mm | B2: 16.5 mm | Mass: 0.35 kg
HJ220 Bearing bore d: 100 mm | d1: 128 mm | B1: 10 mm | B2: 17 mm | Mass: 0.444 kg
HJ2315 Bearing bore d: 75 mm | d1: 104.2 mm | B1: 11 mm | B2: 21.5 mm | Mass: 0.432 kg
HJ220E Bearing bore d: 100 mm | d1: 128 mm | B1: 10 mm | B2: 15 mm | Mass: 0.38 kg
HJ2315E Bearing bore d: 75 mm | d1: 104.6 mm | B1: 11 mm | B2: 19.5 mm | Mass: 0.41 kg
HJ2220 Bearing bore d: 100 mm | d1: 128 mm | B1: 10 mm | B2: 18 mm | Mass: 0.456 kg
HJ415 Bearing bore d: 75 mm | d1: 116 mm | B1: 13 mm | B2: 21.5 mm | Mass: 0.71 kg
HJ2220E Bearing bore d: 100 mm | d1: 128 mm | B1: 10 mm | B2: 16 mm | Mass: 0.385 kg
HJ320 Bearing bore d: 100 mm | d1: 140.5 mm | B1: 13 mm | B2: 22.5 mm | Mass: 0.895 kg
HJ320E Bearing bore d: 100 mm | d1: 140.3 mm | B1: 13 mm | B2: 20.5 mm | Mass: 0.8 kg
HJ2320 Bearing bore d: 100 mm | d1: 140.5 mm | B1: 13 mm | B2: 27.5 mm | Mass: 0.986 kg
HJ316 Bearing bore d: 80 mm | d1: 111.8 mm | B1: 11 mm | B2: 19.5 mm | Mass: 0.47 kg
HJ2320E Bearing bore d: 100 mm | d1: 140.3 mm | B1: 13 mm | B2: 23.5 mm | Mass: 0.92 kg
HJ316E Bearing bore d: 80 mm | d1: 111 mm | B1: 11 mm | B2: 17 mm | Mass: 0.405 kg
HJ2316 Bearing bore d: 80 mm | d1: 111.8 mm | B1: 11 mm | B2: 23 mm | Mass: 0.511 kg
HJ221 Bearing bore d: 105 mm | d1: 135 mm | B1: 10 mm | B2: 17.5 mm | Mass: 0.505 kg
HJ321 Bearing bore d: 105 mm | d1: 147 mm | B1: 13 mm | B2: 22.5 mm | Mass: 0.97 kg
HJ230E Bearing bore d: 150 mm | d1: 194 mm | B1: 12 mm | B2: 19.5 mm | Mass: 1.18 kg
HJ2230 Bearing bore d: 150 mm | d1: 193 mm | B1: 12 mm | B2: 26.5 mm | Mass: 1.39 kg
HJ222 Bearing bore d: 110 mm | d1: 141.5 mm | B1: 11 mm | B2: 18.5 mm | Mass: 0.615 kg
HJ2230E Bearing bore d: 150 mm | d1: 194 mm | B1: 12 mm | B2: 24.5 mm | Mass: 1.42 kg
HJ222E Bearing bore d: 110 mm | d1: 142.1 mm | B1: 11 mm | B2: 17 mm | Mass: 0.553 kg
HJ330 Bearing bore d: 150 mm | d1: 210 mm | B1: 15 mm | B2: 26.5 mm | Mass: 2.37 kg
HJ2222 Bearing bore d: 110 mm | d1: 141.5 mm | B1: 11 mm | B2: 20.5 mm | Mass: 0.645 kg
HJ330E Bearing bore d: 150 mm | d1: 211 mm | B1: 15 mm | B2: 25 mm | Mass: 2.25 kg
HJ2222E Bearing bore d: 110 mm | d1: 142.1 mm | B1: 11 mm | B2: 19.5 mm | Mass: 0.605 kg
HJ2330 Bearing bore d: 150 mm | d1: 210 mm | B1: 15 mm | B2: 34 mm | Mass: 2.69 kg
HJ322 Bearing bore d: 110 mm | d1: 155.5 mm | B1: 14 mm | B2: 23 mm | Mass: 1.17 kg
HJ2330E Bearing bore d: 150 mm | d1: 211 mm | B1: 15 mm | B2: 31.5 mm | Mass: 2.6 kg
HJ322E Bearing bore d: 110 mm | d1: 156.6 mm | B1: 14 mm | B2: 22 mm | Mass: 1.09 kg
HJ2322 Bearing bore d: 110 mm | d1: 155.5 mm | B1: 14 mm | B2: 28 mm | Mass: 1.28 kg
HJ232 Bearing bore d: 160 mm | d1: 207 mm | B1: 12 mm | B2: 21 mm | Mass: 1.48 kg
HJ2322E Bearing bore d: 110 mm | d1: 156.6 mm | B1: 14 mm | B2: 26.5 mm | Mass: 1.25 kg
HJ232E Bearing bore d: 160 mm | d1: 207.8 mm | B1: 12 mm | B2: 20 mm | Mass: 1.34 kg
HJ2232 Bearing bore d: 160 mm | d1: 207 mm | B1: 12 mm | B2: 28 mm | Mass: 1.69 kg
HJ2232E Bearing bore d: 160 mm | d1: 206.6 mm | B1: 12 mm | B2: 24.5 mm | Mass: 1.61 kg
HJ224E Bearing bore d: 120 mm | d1: 153.9 mm | B1: 11 mm | B2: 17 mm | Mass: 0.634 kg
HJ332 Bearing bore d: 160 mm | d1: 225 mm | B1: 15 mm | B2: 28 mm | Mass: 2.75 kg
HJ2224 Bearing bore d: 120 mm | d1: 153 mm | B1: 11 mm | B2: 22 mm | Mass: 0.767 kg
HJ332E Bearing bore d: 160 mm | d1: 223.2 mm | B1: 15 mm | B2: 25 mm | Mass: 2.4 kg
HJ2224E Bearing bore d: 120 mm | d1: 153.9 mm | B1: 11 mm | B2: 20 mm | Mass: 0.705 kg
HJ2332 Bearing bore d: 160 mm | d1: 225 mm | B1: 15 mm | B2: 37 mm | Mass: 3.16 kg
HJ324 Bearing bore d: 120 mm | d1: 168.5 mm | B1: 14 mm | B2: 23.5 mm | Mass: 1.4 kg
HJ2332E Bearing bore d: 160 mm | d1: 223.2 mm | B1: 15 mm | B2: 32 mm | Mass: 2.85 kg
HJ324E Bearing bore d: 120 mm | d1: 169.2 mm | B1: 14 mm | B2: 22.5 mm | Mass: 1.28 kg
HJ2324 Bearing bore d: 120 mm | d1: 168.5 mm | B1: 14 mm | B2: 28 mm | Mass: 1.53 kg
HJ234 Bearing bore d: 170 mm | d1: 220.5 mm | B1: 12 mm | B2: 22 mm | Mass: 1.7 kg
HJ2324E Bearing bore d: 120 mm | d1: 169.2 mm | B1: 14 mm | B2: 26 mm | Mass: 1.42 kg
HJ234E Bearing bore d: 170 mm | d1: 221.4 mm | B1: 12 mm | B2: 20 mm | Mass: 1.51 kg
HJ2234 Bearing bore d: 170 mm | d1: 220.5 mm | B1: 12 mm | B2: 29 mm | Mass: 1.93 kg
HJ226 Bearing bore d: 130 mm | d1: 165.5 mm | B1: 11 mm | B2: 19 mm | Mass: 0.84 kg
HJ2234E Bearing bore d: 170 mm | d1: 220.2 mm | B1: 12 mm | B2: 24 mm | Mass: 1.82 kg
HJ226E Bearing bore d: 130 mm | d1: 164.7 mm | B1: 11 mm | B2: 17 mm | Mass: 0.684 kg
HJ334 Bearing bore d: 170 mm | d1: 238 mm | B1: 16 mm | B2: 29.5 mm | Mass: 3.25 kg
HJ2226 Bearing bore d: 130 mm | d1: 165.5 mm | B1: 11 mm | B2: 25 mm | Mass: 0.953 kg
HJ2334 Bearing bore d: 170 mm | d1: 238 mm | B1: 16 mm | B2: 38.5 mm | Mass: 3.71 kg
HJ2226E Bearing bore d: 130 mm | d1: 164.7 mm | B1: 11 mm | B2: 21 mm | Mass: 0.831 kg
HJ326 Bearing bore d: 130 mm | d1: 182 mm | B1: 14 mm | B2: 24 mm | Mass: 1.62 kg
HJ236 Bearing bore d: 180 mm | d1: 230.5 mm | B1: 12 mm | B2: 22 mm | Mass: 1.8 kg
HJ326E Bearing bore d: 130 mm | d1: 183 mm | B1: 14 mm | B2: 23 mm | Mass: 1.53 kg
HJ236E Bearing bore d: 180 mm | d1: 231.4 mm | B1: 12 mm | B2: 20 mm | Mass: 1.7 kg
HJ2326 Bearing bore d: 130 mm | d1: 182 mm | B1: 14 mm | B2: 29.5 mm | Mass: 1.8 kg
HJ2236 Bearing bore d: 180 mm | d1: 230.5 mm | B1: 12 mm | B2: 29 mm | Mass: 2.04 kg
HJ2326E Bearing bore d: 130 mm | d1: 183 mm | B1: 14 mm | B2: 28 mm | Mass: 1.75 kg
HJ2236E Bearing bore d: 180 mm | d1: 230.2 mm | B1: 12 mm | B2: 24 mm | Mass: 1.91 kg
HJ336 Bearing bore d: 180 mm | d1: 252 mm | B1: 17 mm | B2: 30.5 mm | Mass: 3.85 kg
HJ228 Bearing bore d: 140 mm | d1: 179.5 mm | B1: 11 mm | B2: 19 mm | Mass: 1 kg
HJ2336 Bearing bore d: 180 mm | d1: 252 mm | B1: 17 mm | B2: 40 mm | Mass: 4.42 kg
HJ228E Bearing bore d: 140 mm | d1: 180.2 mm | B1: 11 mm | B2: 18 mm | Mass: 0.929 kg
HJ2228 Bearing bore d: 140 mm | d1: 179.5 mm | B1: 11 mm | B2: 25 mm | Mass: 1.14 kg
HJ238 Bearing bore d: 190 mm | d1: 244.5 mm | B1: 13 mm | B2: 23.5 mm | Mass: 2.2 kg
HJ2228E Bearing bore d: 140 mm | d1: 180.2 mm | B1: 11 mm | B2: 23 mm | Mass: 1.11 kg
HJ238E Bearing bore d: 190 mm | d1: 245.2 mm | B1: 13 mm | B2: 21.5 mm | Mass: 1.94 kg
HJ328 Bearing bore d: 140 mm | d1: 196 mm | B1: 15 mm | B2: 26 mm | Mass: 1.93 kg
HJ2238 Bearing bore d: 190 mm | d1: 244.5 mm | B1: 13 mm | B2: 31.5 mm | Mass: 2.52 kg
HJ328E Bearing bore d: 140 mm | d1: 196.8 mm | B1: 15 mm | B2: 25 mm | Mass: 1.91 kg
HJ2238E Bearing bore d: 190 mm | d1: 244 mm | B1: 13 mm | B2: 26.5 mm | Mass: 2.38 kg
HJ2328 Bearing bore d: 140 mm | d1: 196 mm | B1: 15 mm | B2: 33.5 mm | Mass: 2.21 kg
HJ338 Bearing bore d: 190 mm | d1: 265 mm | B1: 18 mm | B2: 32 mm | Mass: 4.45 kg
HJ2328E Bearing bore d: 140 mm | d1: 196.8 mm | B1: 15 mm | B2: 31 mm | Mass: 2.3 kg
HJ2338 Bearing bore d: 190 mm | d1: 265 mm | B1: 18 mm | B2: 41.5 mm | Mass: 5.05 kg
HJ230 Bearing bore d: 150 mm | d1: 193 mm | B1: 12 mm | B2: 20.5 mm | Mass: 1.24 kg
HJ240 Bearing bore d: 200 mm | d1: 258 mm | B1: 14 mm | B2: 25 mm | Mass: 2.6 kg
HJ240E Bearing bore d: 200 mm | d1: 259 mm | B1: 14 mm | B2: 23 mm | Mass: 2.35 kg
HJ2240 Bearing bore d: 200 mm | d1: 258 mm | B1: 14 mm | B2: 34 mm | Mass: 2.99 kg
HJ2240E Bearing bore d: 200 mm | d1: 257.8 mm | B1: 14 mm | B2: 28 mm | Mass: 2.86 kg
HJ340 Bearing bore d: 200 mm | d1: 280 mm | B1: 18 mm | B2: 33 mm | Mass: 5 kg
HJ2340 Bearing bore d: 200 mm | d1: 280 mm | B1: 18 mm | B2: 44.5 mm | Mass: 5.76 kg
HJ244 Bearing bore d: 220 mm | d1: 286 mm | B1: 15 mm | B2: 27.5 mm | Mass: 3.55 kg
HJ344 Bearing bore d: 220 mm | d1: 307 mm | B1: 20 mm | B2: 36 mm | Mass: 7.05 kg
HJ248 Bearing bore d: 240 mm | d1: 313 mm | B1: 16 mm | B2: 29.5 mm | Mass: 4.65 kg
HJ348 Bearing bore d: 240 mm | d1: 335 mm | B1: 22 mm | B2: 39.5 mm | Mass: 8.2 kg
HJ352 Bearing bore d: 260 mm | d1: 362 mm | B1: 24 mm | B2: 43 mm | Mass: 11.4 kg
HJ256 Bearing bore d: 280 mm | d1: 360 mm | B1: 18 mm | B2: 33 mm | Mass: 7.39 kg
HJ356 Bearing bore d: 280 mm | d1: 390 mm | B1: 26 mm | B2: 46 mm | Mass: 13.9 kg
HJ260 Bearing bore d: 300 mm | d1: 387 mm | B1: 20 mm | B2: 34.5 mm | Mass: 9.14 kg
HJ264 Bearing bore d: 320 mm | d1: 415 mm | B1: 21 mm | B2: 37 mm | Mass: 11.3 kg
Bearing AccessoriesNTN
206 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NTN HJ L-Type Thrust Collars for Cylindrical Roller Bearings

Brand NTN·Bearing Accessories

Available part numbers (206)

HJ204, HJ208, HJ204E, HJ208E, HJ2204, HJ2208, HJ2204E, HJ2208E, HJ304, HJ308 + 196 more — see full table ↓

How to order

Send the NTN part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
HJ204Bearing bore d: 20 mm | d1: 29.9 mm | B1: 3 mm | B2: 6.75 mm | Mass: 0.012 kg
HJ208Bearing bore d: 40 mm | d1: 54.2 mm | B1: 5 mm | B2: 9 mm | Mass: 0.046 kg
HJ204EBearing bore d: 20 mm | d1: 29.5 mm | B1: 3 mm | B2: 5.5 mm | Mass: 0.009 kg
HJ208EBearing bore d: 40 mm | d1: 53.9 mm | B1: 5 mm | B2: 8.5 mm | Mass: 0.042 kg
HJ2204Bearing bore d: 20 mm | d1: 29.9 mm | B1: 3 mm | B2: 7.5 mm | Mass: 0.013 kg
HJ2208Bearing bore d: 40 mm | d1: 54.2 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.047 kg
HJ2204EBearing bore d: 20 mm | d1: 29.5 mm | B1: 3 mm | B2: 6.5 mm | Mass: 0.01 kg
HJ2208EBearing bore d: 40 mm | d1: 53.9 mm | B1: 5 mm | B2: 9 mm | Mass: 0.045 kg
HJ304Bearing bore d: 20 mm | d1: 31.8 mm | B1: 4 mm | B2: 7.5 mm | Mass: 0.017 kg
HJ308Bearing bore d: 40 mm | d1: 58.4 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.083 kg
HJ304EBearing bore d: 20 mm | d1: 31.1 mm | B1: 4 mm | B2: 6.5 mm | Mass: 0.014 kg
HJ308EBearing bore d: 40 mm | d1: 57.6 mm | B1: 7 mm | B2: 11 mm | Mass: 0.07 kg
HJ2304Bearing bore d: 20 mm | d1: 31.8 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.018 kg
HJ2308Bearing bore d: 40 mm | d1: 58.4 mm | B1: 7 mm | B2: 14.5 mm | Mass: 0.09 kg
HJ2304EBearing bore d: 20 mm | d1: 31.1 mm | B1: 4 mm | B2: 7.5 mm | Mass: 0.015 kg
HJ2308EBearing bore d: 40 mm | d1: 57.6 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.08 kg
HJ205Bearing bore d: 25 mm | d1: 34.8 mm | B1: 3 mm | B2: 7.25 mm | Mass: 0.015 kg
HJ2205Bearing bore d: 25 mm | d1: 34.8 mm | B1: 3 mm | B2: 7.5 mm | Mass: 0.015 kg
HJ209EBearing bore d: 45 mm | d1: 58.9 mm | B1: 5 mm | B2: 8.5 mm | Mass: 0.047 kg
HJ2205EBearing bore d: 25 mm | d1: 34.5 mm | B1: 3 mm | B2: 6.5 mm | Mass: 0.013 kg
HJ2209EBearing bore d: 45 mm | d1: 58.9 mm | B1: 5 mm | B2: 9 mm | Mass: 0.05 kg
HJ305Bearing bore d: 25 mm | d1: 39 mm | B1: 4 mm | B2: 8 mm | Mass: 0.025 kg
HJ309Bearing bore d: 45 mm | d1: 64 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.099 kg
HJ305EBearing bore d: 25 mm | d1: 38 mm | B1: 4 mm | B2: 7 mm | Mass: 0.021 kg
HJ309EBearing bore d: 45 mm | d1: 64.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.093 kg
HJ2305Bearing bore d: 25 mm | d1: 39 mm | B1: 4 mm | B2: 9 mm | Mass: 0.027 kg
HJ2309Bearing bore d: 45 mm | d1: 64 mm | B1: 7 mm | B2: 15 mm | Mass: 0.109 kg
HJ2305EBearing bore d: 25 mm | d1: 38 mm | B1: 4 mm | B2: 8 mm | Mass: 0.024 kg
HJ2309EBearing bore d: 45 mm | d1: 64.5 mm | B1: 7 mm | B2: 13 mm | Mass: 0.103 kg
HJ409Bearing bore d: 45 mm | d1: 71.8 mm | B1: 8 mm | B2: 13.5 mm | Mass: 0.175 kg
HJ206Bearing bore d: 30 mm | d1: 41.7 mm | B1: 4 mm | B2: 8.25 mm | Mass: 0.025 kg
HJ210Bearing bore d: 50 mm | d1: 64.6 mm | B1: 5 mm | B2: 10 mm | Mass: 0.063 kg
HJ206EBearing bore d: 30 mm | d1: 41.1 mm | B1: 4 mm | B2: 7 mm | Mass: 0.017 kg
HJ2206Bearing bore d: 30 mm | d1: 41.7 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.025 kg
HJ2210Bearing bore d: 50 mm | d1: 64.6 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.061 kg
HJ2206EBearing bore d: 30 mm | d1: 41.1 mm | B1: 4 mm | B2: 7.5 mm | Mass: 0.02 kg
HJ310Bearing bore d: 50 mm | d1: 71 mm | B1: 8 mm | B2: 14 mm | Mass: 0.142 kg
HJ306Bearing bore d: 30 mm | d1: 45.9 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.039 kg
HJ310EBearing bore d: 50 mm | d1: 71.4 mm | B1: 8 mm | B2: 13 mm | Mass: 0.134 kg
HJ306EBearing bore d: 30 mm | d1: 44.9 mm | B1: 5 mm | B2: 8.5 mm | Mass: 0.035 kg
HJ2310Bearing bore d: 50 mm | d1: 71 mm | B1: 8 mm | B2: 17 mm | Mass: 0.157 kg
HJ2306Bearing bore d: 30 mm | d1: 45.9 mm | B1: 5 mm | B2: 11.5 mm | Mass: 0.043 kg
HJ2310EBearing bore d: 50 mm | d1: 71.4 mm | B1: 8 mm | B2: 14.5 mm | Mass: 0.15 kg
HJ2306EBearing bore d: 30 mm | d1: 44.9 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.035 kg
HJ410Bearing bore d: 50 mm | d1: 78.8 mm | B1: 9 mm | B2: 14.5 mm | Mass: 0.23 kg
HJ406Bearing bore d: 30 mm | d1: 50.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.08 kg
HJ207Bearing bore d: 35 mm | d1: 47.6 mm | B1: 4 mm | B2: 8 mm | Mass: 0.03 kg
HJ211EBearing bore d: 55 mm | d1: 70.8 mm | B1: 6 mm | B2: 9.5 mm | Mass: 0.072 kg
HJ207EBearing bore d: 35 mm | d1: 48 mm | B1: 4 mm | B2: 7 mm | Mass: 0.027 kg
HJ2211EBearing bore d: 55 mm | d1: 70.8 mm | B1: 6 mm | B2: 10 mm | Mass: 0.076 kg
HJ2207Bearing bore d: 35 mm | d1: 47.6 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.031 kg
HJ311Bearing bore d: 55 mm | d1: 77.2 mm | B1: 9 mm | B2: 15 mm | Mass: 0.182 kg
HJ2207EBearing bore d: 35 mm | d1: 48 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.031 kg
HJ311EBearing bore d: 55 mm | d1: 77.7 mm | B1: 9 mm | B2: 14 mm | Mass: 0.168 kg
HJ307Bearing bore d: 35 mm | d1: 50.8 mm | B1: 6 mm | B2: 11 mm | Mass: 0.056 kg
HJ2311Bearing bore d: 55 mm | d1: 77.2 mm | B1: 9 mm | B2: 18.5 mm | Mass: 0.203 kg
HJ307EBearing bore d: 35 mm | d1: 51 mm | B1: 6 mm | B2: 9.5 mm | Mass: 0.048 kg
HJ2311EBearing bore d: 55 mm | d1: 77.7 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.185 kg
HJ2307Bearing bore d: 35 mm | d1: 50.8 mm | B1: 6 mm | B2: 14 mm | Mass: 0.064 kg
HJ411Bearing bore d: 55 mm | d1: 85.2 mm | B1: 10 mm | B2: 16.5 mm | Mass: 0.29 kg
HJ2307EBearing bore d: 35 mm | d1: 51 mm | B1: 6 mm | B2: 11 mm | Mass: 0.055 kg
HJ407Bearing bore d: 35 mm | d1: 59 mm | B1: 8 mm | B2: 13 mm | Mass: 0.12 kg
HJ312Bearing bore d: 60 mm | d1: 84.2 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.22 kg
HJ2316EBearing bore d: 80 mm | d1: 111 mm | B1: 11 mm | B2: 20 mm | Mass: 0.45 kg
HJ312EBearing bore d: 60 mm | d1: 84.6 mm | B1: 9 mm | B2: 14.5 mm | Mass: 0.205 kg
HJ416Bearing bore d: 80 mm | d1: 122 mm | B1: 13 mm | B2: 22 mm | Mass: 0.78 kg
HJ2312Bearing bore d: 60 mm | d1: 84.2 mm | B1: 9 mm | B2: 19 mm | Mass: 0.245 kg
HJ2312EBearing bore d: 60 mm | d1: 84.6 mm | B1: 9 mm | B2: 16 mm | Mass: 0.23 kg
HJ412Bearing bore d: 60 mm | d1: 91.8 mm | B1: 10 mm | B2: 16.5 mm | Mass: 0.34 kg
HJ217EBearing bore d: 85 mm | d1: 107.7 mm | B1: 8 mm | B2: 12.5 mm | Mass: 0.21 kg
HJ2217EBearing bore d: 85 mm | d1: 107.7 mm | B1: 8 mm | B2: 13 mm | Mass: 0.216 kg
HJ213Bearing bore d: 65 mm | d1: 84.8 mm | B1: 6 mm | B2: 11 mm | Mass: 0.123 kg
HJ317Bearing bore d: 85 mm | d1: 117.5 mm | B1: 12 mm | B2: 20.5 mm | Mass: 0.56 kg
HJ213EBearing bore d: 65 mm | d1: 84.5 mm | B1: 6 mm | B2: 10 mm | Mass: 0.111 kg
HJ317EBearing bore d: 85 mm | d1: 118.4 mm | B1: 12 mm | B2: 18.5 mm | Mass: 0.505 kg
HJ2213Bearing bore d: 65 mm | d1: 84.8 mm | B1: 6 mm | B2: 11.5 mm | Mass: 0.126 kg
HJ2317Bearing bore d: 85 mm | d1: 117.5 mm | B1: 12 mm | B2: 24 mm | Mass: 0.606 kg
HJ2317EBearing bore d: 85 mm | d1: 118.4 mm | B1: 12 mm | B2: 22 mm | Mass: 0.55 kg
HJ313Bearing bore d: 65 mm | d1: 91 mm | B1: 10 mm | B2: 17 mm | Mass: 0.28 kg
HJ313EBearing bore d: 65 mm | d1: 91 mm | B1: 10 mm | B2: 15.5 mm | Mass: 0.25 kg
HJ218Bearing bore d: 90 mm | d1: 114.2 mm | B1: 9 mm | B2: 15 mm | Mass: 0.305 kg
HJ2313Bearing bore d: 65 mm | d1: 91 mm | B1: 10 mm | B2: 20 mm | Mass: 0.304 kg
HJ218EBearing bore d: 90 mm | d1: 114.6 mm | B1: 9 mm | B2: 14 mm | Mass: 0.272 kg
HJ2313EBearing bore d: 65 mm | d1: 91 mm | B1: 10 mm | B2: 18 mm | Mass: 0.29 kg
HJ2218Bearing bore d: 90 mm | d1: 114.2 mm | B1: 9 mm | B2: 16 mm | Mass: 0.315 kg
HJ413Bearing bore d: 65 mm | d1: 98.5 mm | B1: 11 mm | B2: 18 mm | Mass: 0.42 kg
HJ2218EBearing bore d: 90 mm | d1: 114.6 mm | B1: 9 mm | B2: 15 mm | Mass: 0.308 kg
HJ318Bearing bore d: 90 mm | d1: 125 mm | B1: 12 mm | B2: 21 mm | Mass: 0.63 kg
HJ318EBearing bore d: 90 mm | d1: 124.7 mm | B1: 12 mm | B2: 18.5 mm | Mass: 0.548 kg
HJ214EBearing bore d: 70 mm | d1: 89.5 mm | B1: 7 mm | B2: 11 mm | Mass: 0.13 kg
HJ2318Bearing bore d: 90 mm | d1: 125 mm | B1: 12 mm | B2: 26 mm | Mass: 0.704 kg
HJ2214EBearing bore d: 70 mm | d1: 89.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.138 kg
HJ2318EBearing bore d: 90 mm | d1: 124.7 mm | B1: 12 mm | B2: 22 mm | Mass: 0.69 kg
HJ314Bearing bore d: 70 mm | d1: 98 mm | B1: 10 mm | B2: 17.5 mm | Mass: 0.33 kg
HJ314EBearing bore d: 70 mm | d1: 98 mm | B1: 10 mm | B2: 15.5 mm | Mass: 0.293 kg
HJ219Bearing bore d: 95 mm | d1: 121 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.352 kg
HJ2314Bearing bore d: 70 mm | d1: 98 mm | B1: 10 mm | B2: 20.5 mm | Mass: 0.358 kg
HJ219EBearing bore d: 95 mm | d1: 121 mm | B1: 9 mm | B2: 14 mm | Mass: 0.304 kg
HJ2314EBearing bore d: 70 mm | d1: 98 mm | B1: 10 mm | B2: 18.5 mm | Mass: 0.35 kg
HJ2219Bearing bore d: 95 mm | d1: 121 mm | B1: 9 mm | B2: 16.5 mm | Mass: 0.363 kg
HJ414Bearing bore d: 70 mm | d1: 110.5 mm | B1: 12 mm | B2: 20 mm | Mass: 0.605 kg
HJ2219EBearing bore d: 95 mm | d1: 121 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.335 kg
HJ319Bearing bore d: 95 mm | d1: 132 mm | B1: 13 mm | B2: 22.5 mm | Mass: 0.76 kg
HJ319EBearing bore d: 95 mm | d1: 132.7 mm | B1: 13 mm | B2: 20.5 mm | Mass: 0.7 kg
HJ215EBearing bore d: 75 mm | d1: 94.5 mm | B1: 7 mm | B2: 11 mm | Mass: 0.141 kg
HJ2319Bearing bore d: 95 mm | d1: 132 mm | B1: 13 mm | B2: 26.5 mm | Mass: 0.826 kg
HJ2215EBearing bore d: 75 mm | d1: 94.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.164 kg
HJ2319EBearing bore d: 95 mm | d1: 132.7 mm | B1: 13 mm | B2: 24.5 mm | Mass: 0.8 kg
HJ315Bearing bore d: 75 mm | d1: 104.2 mm | B1: 11 mm | B2: 18.5 mm | Mass: 0.4 kg
HJ315EBearing bore d: 75 mm | d1: 104.6 mm | B1: 11 mm | B2: 16.5 mm | Mass: 0.35 kg
HJ220Bearing bore d: 100 mm | d1: 128 mm | B1: 10 mm | B2: 17 mm | Mass: 0.444 kg
HJ2315Bearing bore d: 75 mm | d1: 104.2 mm | B1: 11 mm | B2: 21.5 mm | Mass: 0.432 kg
HJ220EBearing bore d: 100 mm | d1: 128 mm | B1: 10 mm | B2: 15 mm | Mass: 0.38 kg
HJ2315EBearing bore d: 75 mm | d1: 104.6 mm | B1: 11 mm | B2: 19.5 mm | Mass: 0.41 kg
HJ2220Bearing bore d: 100 mm | d1: 128 mm | B1: 10 mm | B2: 18 mm | Mass: 0.456 kg
HJ415Bearing bore d: 75 mm | d1: 116 mm | B1: 13 mm | B2: 21.5 mm | Mass: 0.71 kg
HJ2220EBearing bore d: 100 mm | d1: 128 mm | B1: 10 mm | B2: 16 mm | Mass: 0.385 kg
HJ320Bearing bore d: 100 mm | d1: 140.5 mm | B1: 13 mm | B2: 22.5 mm | Mass: 0.895 kg
HJ320EBearing bore d: 100 mm | d1: 140.3 mm | B1: 13 mm | B2: 20.5 mm | Mass: 0.8 kg
HJ2320Bearing bore d: 100 mm | d1: 140.5 mm | B1: 13 mm | B2: 27.5 mm | Mass: 0.986 kg
HJ316Bearing bore d: 80 mm | d1: 111.8 mm | B1: 11 mm | B2: 19.5 mm | Mass: 0.47 kg
HJ2320EBearing bore d: 100 mm | d1: 140.3 mm | B1: 13 mm | B2: 23.5 mm | Mass: 0.92 kg
HJ316EBearing bore d: 80 mm | d1: 111 mm | B1: 11 mm | B2: 17 mm | Mass: 0.405 kg
HJ2316Bearing bore d: 80 mm | d1: 111.8 mm | B1: 11 mm | B2: 23 mm | Mass: 0.511 kg
HJ221Bearing bore d: 105 mm | d1: 135 mm | B1: 10 mm | B2: 17.5 mm | Mass: 0.505 kg
HJ321Bearing bore d: 105 mm | d1: 147 mm | B1: 13 mm | B2: 22.5 mm | Mass: 0.97 kg
HJ230EBearing bore d: 150 mm | d1: 194 mm | B1: 12 mm | B2: 19.5 mm | Mass: 1.18 kg
HJ2230Bearing bore d: 150 mm | d1: 193 mm | B1: 12 mm | B2: 26.5 mm | Mass: 1.39 kg
HJ222Bearing bore d: 110 mm | d1: 141.5 mm | B1: 11 mm | B2: 18.5 mm | Mass: 0.615 kg
HJ2230EBearing bore d: 150 mm | d1: 194 mm | B1: 12 mm | B2: 24.5 mm | Mass: 1.42 kg
HJ222EBearing bore d: 110 mm | d1: 142.1 mm | B1: 11 mm | B2: 17 mm | Mass: 0.553 kg
HJ330Bearing bore d: 150 mm | d1: 210 mm | B1: 15 mm | B2: 26.5 mm | Mass: 2.37 kg
HJ2222Bearing bore d: 110 mm | d1: 141.5 mm | B1: 11 mm | B2: 20.5 mm | Mass: 0.645 kg
HJ330EBearing bore d: 150 mm | d1: 211 mm | B1: 15 mm | B2: 25 mm | Mass: 2.25 kg
HJ2222EBearing bore d: 110 mm | d1: 142.1 mm | B1: 11 mm | B2: 19.5 mm | Mass: 0.605 kg
HJ2330Bearing bore d: 150 mm | d1: 210 mm | B1: 15 mm | B2: 34 mm | Mass: 2.69 kg
HJ322Bearing bore d: 110 mm | d1: 155.5 mm | B1: 14 mm | B2: 23 mm | Mass: 1.17 kg
HJ2330EBearing bore d: 150 mm | d1: 211 mm | B1: 15 mm | B2: 31.5 mm | Mass: 2.6 kg
HJ322EBearing bore d: 110 mm | d1: 156.6 mm | B1: 14 mm | B2: 22 mm | Mass: 1.09 kg
HJ2322Bearing bore d: 110 mm | d1: 155.5 mm | B1: 14 mm | B2: 28 mm | Mass: 1.28 kg
HJ232Bearing bore d: 160 mm | d1: 207 mm | B1: 12 mm | B2: 21 mm | Mass: 1.48 kg
HJ2322EBearing bore d: 110 mm | d1: 156.6 mm | B1: 14 mm | B2: 26.5 mm | Mass: 1.25 kg
HJ232EBearing bore d: 160 mm | d1: 207.8 mm | B1: 12 mm | B2: 20 mm | Mass: 1.34 kg
HJ2232Bearing bore d: 160 mm | d1: 207 mm | B1: 12 mm | B2: 28 mm | Mass: 1.69 kg
HJ2232EBearing bore d: 160 mm | d1: 206.6 mm | B1: 12 mm | B2: 24.5 mm | Mass: 1.61 kg
HJ224EBearing bore d: 120 mm | d1: 153.9 mm | B1: 11 mm | B2: 17 mm | Mass: 0.634 kg
HJ332Bearing bore d: 160 mm | d1: 225 mm | B1: 15 mm | B2: 28 mm | Mass: 2.75 kg
HJ2224Bearing bore d: 120 mm | d1: 153 mm | B1: 11 mm | B2: 22 mm | Mass: 0.767 kg
HJ332EBearing bore d: 160 mm | d1: 223.2 mm | B1: 15 mm | B2: 25 mm | Mass: 2.4 kg
HJ2224EBearing bore d: 120 mm | d1: 153.9 mm | B1: 11 mm | B2: 20 mm | Mass: 0.705 kg
HJ2332Bearing bore d: 160 mm | d1: 225 mm | B1: 15 mm | B2: 37 mm | Mass: 3.16 kg
HJ324Bearing bore d: 120 mm | d1: 168.5 mm | B1: 14 mm | B2: 23.5 mm | Mass: 1.4 kg
HJ2332EBearing bore d: 160 mm | d1: 223.2 mm | B1: 15 mm | B2: 32 mm | Mass: 2.85 kg
HJ324EBearing bore d: 120 mm | d1: 169.2 mm | B1: 14 mm | B2: 22.5 mm | Mass: 1.28 kg
HJ2324Bearing bore d: 120 mm | d1: 168.5 mm | B1: 14 mm | B2: 28 mm | Mass: 1.53 kg
HJ234Bearing bore d: 170 mm | d1: 220.5 mm | B1: 12 mm | B2: 22 mm | Mass: 1.7 kg
HJ2324EBearing bore d: 120 mm | d1: 169.2 mm | B1: 14 mm | B2: 26 mm | Mass: 1.42 kg
HJ234EBearing bore d: 170 mm | d1: 221.4 mm | B1: 12 mm | B2: 20 mm | Mass: 1.51 kg
HJ2234Bearing bore d: 170 mm | d1: 220.5 mm | B1: 12 mm | B2: 29 mm | Mass: 1.93 kg
HJ226Bearing bore d: 130 mm | d1: 165.5 mm | B1: 11 mm | B2: 19 mm | Mass: 0.84 kg
HJ2234EBearing bore d: 170 mm | d1: 220.2 mm | B1: 12 mm | B2: 24 mm | Mass: 1.82 kg
HJ226EBearing bore d: 130 mm | d1: 164.7 mm | B1: 11 mm | B2: 17 mm | Mass: 0.684 kg
HJ334Bearing bore d: 170 mm | d1: 238 mm | B1: 16 mm | B2: 29.5 mm | Mass: 3.25 kg
HJ2226Bearing bore d: 130 mm | d1: 165.5 mm | B1: 11 mm | B2: 25 mm | Mass: 0.953 kg
HJ2334Bearing bore d: 170 mm | d1: 238 mm | B1: 16 mm | B2: 38.5 mm | Mass: 3.71 kg
HJ2226EBearing bore d: 130 mm | d1: 164.7 mm | B1: 11 mm | B2: 21 mm | Mass: 0.831 kg
HJ326Bearing bore d: 130 mm | d1: 182 mm | B1: 14 mm | B2: 24 mm | Mass: 1.62 kg
HJ236Bearing bore d: 180 mm | d1: 230.5 mm | B1: 12 mm | B2: 22 mm | Mass: 1.8 kg
HJ326EBearing bore d: 130 mm | d1: 183 mm | B1: 14 mm | B2: 23 mm | Mass: 1.53 kg
HJ236EBearing bore d: 180 mm | d1: 231.4 mm | B1: 12 mm | B2: 20 mm | Mass: 1.7 kg
HJ2326Bearing bore d: 130 mm | d1: 182 mm | B1: 14 mm | B2: 29.5 mm | Mass: 1.8 kg
HJ2236Bearing bore d: 180 mm | d1: 230.5 mm | B1: 12 mm | B2: 29 mm | Mass: 2.04 kg
HJ2326EBearing bore d: 130 mm | d1: 183 mm | B1: 14 mm | B2: 28 mm | Mass: 1.75 kg
HJ2236EBearing bore d: 180 mm | d1: 230.2 mm | B1: 12 mm | B2: 24 mm | Mass: 1.91 kg
HJ336Bearing bore d: 180 mm | d1: 252 mm | B1: 17 mm | B2: 30.5 mm | Mass: 3.85 kg
HJ228Bearing bore d: 140 mm | d1: 179.5 mm | B1: 11 mm | B2: 19 mm | Mass: 1 kg
HJ2336Bearing bore d: 180 mm | d1: 252 mm | B1: 17 mm | B2: 40 mm | Mass: 4.42 kg
HJ228EBearing bore d: 140 mm | d1: 180.2 mm | B1: 11 mm | B2: 18 mm | Mass: 0.929 kg
HJ2228Bearing bore d: 140 mm | d1: 179.5 mm | B1: 11 mm | B2: 25 mm | Mass: 1.14 kg
HJ238Bearing bore d: 190 mm | d1: 244.5 mm | B1: 13 mm | B2: 23.5 mm | Mass: 2.2 kg
HJ2228EBearing bore d: 140 mm | d1: 180.2 mm | B1: 11 mm | B2: 23 mm | Mass: 1.11 kg
HJ238EBearing bore d: 190 mm | d1: 245.2 mm | B1: 13 mm | B2: 21.5 mm | Mass: 1.94 kg
HJ328Bearing bore d: 140 mm | d1: 196 mm | B1: 15 mm | B2: 26 mm | Mass: 1.93 kg
HJ2238Bearing bore d: 190 mm | d1: 244.5 mm | B1: 13 mm | B2: 31.5 mm | Mass: 2.52 kg
HJ328EBearing bore d: 140 mm | d1: 196.8 mm | B1: 15 mm | B2: 25 mm | Mass: 1.91 kg
HJ2238EBearing bore d: 190 mm | d1: 244 mm | B1: 13 mm | B2: 26.5 mm | Mass: 2.38 kg
HJ2328Bearing bore d: 140 mm | d1: 196 mm | B1: 15 mm | B2: 33.5 mm | Mass: 2.21 kg
HJ338Bearing bore d: 190 mm | d1: 265 mm | B1: 18 mm | B2: 32 mm | Mass: 4.45 kg
HJ2328EBearing bore d: 140 mm | d1: 196.8 mm | B1: 15 mm | B2: 31 mm | Mass: 2.3 kg
HJ2338Bearing bore d: 190 mm | d1: 265 mm | B1: 18 mm | B2: 41.5 mm | Mass: 5.05 kg
HJ230Bearing bore d: 150 mm | d1: 193 mm | B1: 12 mm | B2: 20.5 mm | Mass: 1.24 kg
HJ240Bearing bore d: 200 mm | d1: 258 mm | B1: 14 mm | B2: 25 mm | Mass: 2.6 kg
HJ240EBearing bore d: 200 mm | d1: 259 mm | B1: 14 mm | B2: 23 mm | Mass: 2.35 kg
HJ2240Bearing bore d: 200 mm | d1: 258 mm | B1: 14 mm | B2: 34 mm | Mass: 2.99 kg
HJ2240EBearing bore d: 200 mm | d1: 257.8 mm | B1: 14 mm | B2: 28 mm | Mass: 2.86 kg
HJ340Bearing bore d: 200 mm | d1: 280 mm | B1: 18 mm | B2: 33 mm | Mass: 5 kg
HJ2340Bearing bore d: 200 mm | d1: 280 mm | B1: 18 mm | B2: 44.5 mm | Mass: 5.76 kg
HJ244Bearing bore d: 220 mm | d1: 286 mm | B1: 15 mm | B2: 27.5 mm | Mass: 3.55 kg
HJ344Bearing bore d: 220 mm | d1: 307 mm | B1: 20 mm | B2: 36 mm | Mass: 7.05 kg
HJ248Bearing bore d: 240 mm | d1: 313 mm | B1: 16 mm | B2: 29.5 mm | Mass: 4.65 kg
HJ348Bearing bore d: 240 mm | d1: 335 mm | B1: 22 mm | B2: 39.5 mm | Mass: 8.2 kg
HJ352Bearing bore d: 260 mm | d1: 362 mm | B1: 24 mm | B2: 43 mm | Mass: 11.4 kg
HJ256Bearing bore d: 280 mm | d1: 360 mm | B1: 18 mm | B2: 33 mm | Mass: 7.39 kg
HJ356Bearing bore d: 280 mm | d1: 390 mm | B1: 26 mm | B2: 46 mm | Mass: 13.9 kg
HJ260Bearing bore d: 300 mm | d1: 387 mm | B1: 20 mm | B2: 34.5 mm | Mass: 9.14 kg
HJ264Bearing bore d: 320 mm | d1: 415 mm | B1: 21 mm | B2: 37 mm | Mass: 11.3 kg

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Linear Motion & Bearings →
