NTN K Series Needle Roller and Cage Assemblies

NTN K Series Needle Roller and Cage Assemblies

NTN K series radial needle roller and cage assemblies, designated by roller inscribed diameter x outer diameter x width, for use directly on hardened shafts and housings.

Key features

  • Designation K Fw x Ew x Bc
  • Very compact radial section
  • Runs directly on hardened and ground shaft and housing bores
  • T2 suffix: polyamide cage; S, ZW (double row) and other variants as listed

Specifications

Bearing type Radial needle roller and cage assembly
Fw range 3-265 mm
Load rating unit kN
Brand NTN
Product category Needle Roller Bearings
Source NTN NTN Ball and Roller Bearings catalogue, p. 172-182
K3x6x7T2 Fw: 3 mm | Ew: 6 mm | Bc: 7 mm | Cr: 1.46 kN | C0r: 0.97 kN
K4x7x7T2 Fw: 4 mm | Ew: 7 mm | Bc: 7 mm | Cr: 1.77 kN | C0r: 1.27 kN
K5x8x8T2 Fw: 5 mm | Ew: 8 mm | Bc: 8 mm | Cr: 2.64 kN | C0r: 2.19 kN
K5x8x10T2 Fw: 5 mm | Ew: 8 mm | Bc: 10 mm | Cr: 2.72 kN | C0r: 2.25 kN
K6x9x8T2 Fw: 6 mm | Ew: 9 mm | Bc: 8 mm | Cr: 2.66 kN | C0r: 2.28 kN
K6x9x10T2 Fw: 6 mm | Ew: 9 mm | Bc: 10 mm | Cr: 3.4 kN | C0r: 3.15 kN
K6x10x13T2 Fw: 6 mm | Ew: 10 mm | Bc: 13 mm | Cr: 4.4 kN | C0r: 3.7 kN
K7x10x8T2 Fw: 7 mm | Ew: 10 mm | Bc: 8 mm | Cr: 2.67 kN | C0r: 2.35 kN
K7x10x10T2 Fw: 7 mm | Ew: 10 mm | Bc: 10 mm | Cr: 3.4 kN | C0r: 3.2 kN
K8x11x8T2 Fw: 8 mm | Ew: 11 mm | Bc: 8 mm | Cr: 3.15 kN | C0r: 3 kN
K8x11x10T2 Fw: 8 mm | Ew: 11 mm | Bc: 10 mm | Cr: 4 kN | C0r: 4.1 kN
K8x11x13 Fw: 8 mm | Ew: 11 mm | Bc: 13 mm | Cr: 4.85 kN | C0r: 5.2 kN
K8x12x10T2 Fw: 8 mm | Ew: 12 mm | Bc: 10 mm | Cr: 4.65 kN | C0r: 4.15 kN
K8x12x12 Fw: 8 mm | Ew: 12 mm | Bc: 12 mm | Cr: 5.6 kN | C0r: 5.3 kN
K8x12x13 Fw: 8 mm | Ew: 12 mm | Bc: 13 mm | Cr: 5.6 kN | C0r: 5.3 kN
K9x12x10T2 Fw: 9 mm | Ew: 12 mm | Bc: 10 mm | Cr: 4.55 kN | C0r: 5 kN
K9x12x13T2 Fw: 9 mm | Ew: 12 mm | Bc: 13 mm | Cr: 5.5 kN | C0r: 6.4 kN
K10x13x10T2 Fw: 10 mm | Ew: 13 mm | Bc: 10 mm | Cr: 4.55 kN | C0r: 5.1 kN
K10x13x13 Fw: 10 mm | Ew: 13 mm | Bc: 13 mm | Cr: 5.45 kN | C0r: 6.45 kN
K10x14x8 Fw: 10 mm | Ew: 14 mm | Bc: 8 mm | Cr: 4.3 kN | C0r: 3.95 kN
K10x14x10 Fw: 10 mm | Ew: 14 mm | Bc: 10 mm | Cr: 5.5 kN | C0r: 5.45 kN
K10x14x13 Fw: 10 mm | Ew: 14 mm | Bc: 13 mm | Cr: 6.6 kN | C0r: 6.9 kN
K10x16x12 Fw: 10 mm | Ew: 16 mm | Bc: 12 mm | Cr: 7.1 kN | C0r: 5.95 kN
K11x14x10 Fw: 11 mm | Ew: 14 mm | Bc: 10 mm | Cr: 4.05 kN | C0r: 6 kN
K12x15x9 Fw: 12 mm | Ew: 15 mm | Bc: 9 mm | Cr: 5.45 kN | C0r: 5.25 kN
K12x15x10S Fw: 12 mm | Ew: 15 mm | Bc: 10 mm | Cr: 6 kN | C0r: 6.1 kN
K12x15x13 Fw: 12 mm | Ew: 15 mm | Bc: 13 mm | Cr: 8 kN | C0r: 7.7 kN
K12x15x20ZW Fw: 12 mm | Ew: 15 mm | Bc: 20 mm | Cr: 0.55 kN | C0r: 12.2 kN
K12x16x8 Fw: 12 mm | Ew: 16 mm | Bc: 8 mm | Cr: 4.85 kN | C0r: 4.9 kN
K12x16x13 Fw: 12 mm | Ew: 16 mm | Bc: 13 mm | Cr: 7.5 kN | C0r: 8.5 kN
K12x17x13 Fw: 12 mm | Ew: 17 mm | Bc: 13 mm | Cr: 9 kN | C0r: 9.4 kN
K12x18x12 Fw: 12 mm | Ew: 18 mm | Bc: 12 mm | Cr: 8.65 kN | C0r: 8 kN
K14x17x10 Fw: 14 mm | Ew: 17 mm | Bc: 10 mm | Cr: 5.4 kN | C0r: 7.05 kN
K14x18x10 Fw: 14 mm | Ew: 18 mm | Bc: 10 mm | Cr: 6.9 kN | C0r: 8 kN
K14x18x11 Fw: 14 mm | Ew: 18 mm | Bc: 11 mm | Cr: 7.6 kN | C0r: 9.05 kN
K14x18x13 Fw: 14 mm | Ew: 18 mm | Bc: 13 mm | Cr: 8.3 kN | C0r: 10.1 kN
K14x18x15S Fw: 14 mm | Ew: 18 mm | Bc: 15 mm | Cr: 9.65 kN | C0r: 12.3 kN
K14x18x17 Fw: 14 mm | Ew: 18 mm | Bc: 17 mm | Cr: 10.9 kN | C0r: 14.4 kN
K14x18x39ZW Fw: 14 mm | Ew: 18 mm | Bc: 39 mm | Cr: 18.8 kN | C0r: 28.9 kN
K14x19x13 Fw: 14 mm | Ew: 19 mm | Bc: 13 mm | Cr: 8.95 kN | C0r: 9.65 kN
K14x20x12 Fw: 14 mm | Ew: 20 mm | Bc: 12 mm | Cr: 9.35 kN | C0r: 9.15 kN
K14x20x17 Fw: 14 mm | Ew: 20 mm | Bc: 17 mm | Cr: 13.5 kN | C0r: 14.6 kN
K15x18x14 Fw: 15 mm | Ew: 18 mm | Bc: 14 mm | Cr: 7.85 kN | C0r: 11.6 kN
K15x19x10S Fw: 15 mm | Ew: 19 mm | Bc: 10 mm | Cr: 6.85 kN | C0r: 8.05 kN
K15x19x13S Fw: 15 mm | Ew: 19 mm | Bc: 13 mm | Cr: 8.25 kN | C0r: 10.2 kN
K15x19x17 Fw: 15 mm | Ew: 19 mm | Bc: 17 mm | Cr: 10.9 kN | C0r: 14.6 kN
K15x19x24ZW Fw: 15 mm | Ew: 19 mm | Bc: 24 mm | Cr: 14.1 kN | C0r: 20.4 kN
K15x20x13 Fw: 15 mm | Ew: 20 mm | Bc: 13 mm | Cr: 10.1 kN | C0r: 11.5 kN
K15x21x15 Fw: 15 mm | Ew: 21 mm | Bc: 15 mm | Cr: 11.9 kN | C0r: 12.5 kN
K15x21x21 Fw: 15 mm | Ew: 21 mm | Bc: 21 mm | Cr: 16.5 kN | C0r: 19.1 kN
K16x20x10 Fw: 16 mm | Ew: 20 mm | Bc: 10 mm | Cr: 7.5 kN | C0r: 9.25 kN
K16x20x11 Fw: 16 mm | Ew: 20 mm | Bc: 11 mm | Cr: 8.3 kN | C0r: 10.5 kN
K16x20x13 Fw: 16 mm | Ew: 20 mm | Bc: 13 mm | Cr: 9.05 kN | C0r: 11.8 kN
K16x20x17S Fw: 16 mm | Ew: 20 mm | Bc: 17 mm | Cr: 11.9 kN | C0r: 16.8 kN
K16x22x12 Fw: 16 mm | Ew: 22 mm | Bc: 12 mm | Cr: 11.7 kN | C0r: 12.5 kN
K16x22x17 Fw: 16 mm | Ew: 22 mm | Bc: 17 mm | Cr: 14.4 kN | C0r: 16.4 kN
K16x22x20 Fw: 16 mm | Ew: 22 mm | Bc: 20 mm | Cr: 16 kN | C0r: 18.8 kN
K17x21x10S Fw: 17 mm | Ew: 21 mm | Bc: 10 mm | Cr: 7.45 kN | C0r: 9.3 kN
K17x21x13S Fw: 17 mm | Ew: 21 mm | Bc: 13 mm | Cr: 9.4 kN | C0r: 12.6 kN
K17x21x15 Fw: 17 mm | Ew: 21 mm | Bc: 15 mm | Cr: 10.4 kN | C0r: 14.4 kN
K17x21x17 Fw: 17 mm | Ew: 21 mm | Bc: 17 mm | Cr: 11.8 kN | C0r: 16.9 kN
K17x22x20 Fw: 17 mm | Ew: 22 mm | Bc: 20 mm | Cr: 14.7 kN | C0r: 19.2 kN
K17x23x17 Fw: 17 mm | Ew: 23 mm | Bc: 17 mm | Cr: 14.4 kN | C0r: 16.5 kN
K18x22x10 Fw: 18 mm | Ew: 22 mm | Bc: 10 mm | Cr: 7.4 kN | C0r: 9.4 kN
K18x22x13 Fw: 18 mm | Ew: 22 mm | Bc: 13 mm | Cr: 8.9 kN | C0r: 11.9 kN
K18x22x17 Fw: 18 mm | Ew: 22 mm | Bc: 17 mm | Cr: 11.7 kN | C0r: 17 kN
K18x23x20S Fw: 18 mm | Ew: 23 mm | Bc: 20 mm | Cr: 14.6 kN | C0r: 19.3 kN
K18x24x12 Fw: 18 mm | Ew: 24 mm | Bc: 12 mm | Cr: 12.3 kN | C0r: 13.8 kN
K18x24x13 Fw: 18 mm | Ew: 24 mm | Bc: 13 mm | Cr: 11.6 kN | C0r: 12.8 kN
K18x24x20 Fw: 18 mm | Ew: 24 mm | Bc: 20 mm | Cr: 17 kN | C0r: 20.9 kN
K18x25x17 Fw: 18 mm | Ew: 25 mm | Bc: 17 mm | Cr: 18 kN | C0r: 20.4 kN
K18x25x22 Fw: 18 mm | Ew: 25 mm | Bc: 22 mm | Cr: 22.1 kN | C0r: 26.6 kN
K19x23x13 Fw: 19 mm | Ew: 23 mm | Bc: 13 mm | Cr: 9.65 kN | C0r: 13.5 kN
K19x23x17 Fw: 19 mm | Ew: 23 mm | Bc: 17 mm | Cr: 12.7 kN | C0r: 19.2 kN
K20x24x10S Fw: 20 mm | Ew: 24 mm | Bc: 10 mm | Cr: 8.3 kN | C0r: 11.2 kN
K20x24x11 Fw: 20 mm | Ew: 24 mm | Bc: 11 mm | Cr: 9.5 kN | C0r: 13.4 kN
K20x24x13S Fw: 20 mm | Ew: 24 mm | Bc: 13 mm | Cr: 10 kN | C0r: 14.3 kN
K20x24x17S Fw: 20 mm | Ew: 24 mm | Bc: 17 mm | Cr: 13.2 kN | C0r: 20.4 kN
K20x24x45ZW Fw: 20 mm | Ew: 24 mm | Bc: 45 mm | Cr: 16.4 kN | C0r: 27.1 kN
K20x25x40ZW Fw: 20 mm | Ew: 25 mm | Bc: 40 mm | Cr: 29 kN | C0r: 48 kN
K20x26x12 Fw: 20 mm | Ew: 26 mm | Bc: 12 mm | Cr: 12 kN | C0r: 15.1 kN
K20x28x25 Fw: 20 mm | Ew: 28 mm | Bc: 25 mm | Cr: 27.1 kN | C0r: 32.5 kN
K21x25x13 Fw: 21 mm | Ew: 25 mm | Bc: 13 mm | Cr: 10.3 kN | C0r: 15.1 kN
K21x25x17 Fw: 21 mm | Ew: 25 mm | Bc: 17 mm | Cr: 13.6 kN | C0r: 21.5 kN
K22x26x10S Fw: 22 mm | Ew: 26 mm | Bc: 10 mm | Cr: 8.5 kN | C0r: 11.9 kN
K22x26x11S Fw: 22 mm | Ew: 26 mm | Bc: 11 mm | Cr: 10.1 kN | C0r: 14.9 kN
K22x26x13 Fw: 22 mm | Ew: 26 mm | Bc: 13 mm | Cr: 10.2 kN | C0r: 15.2 kN
K22x26x17S Fw: 22 mm | Ew: 26 mm | Bc: 17 mm | Cr: 13.5 kN | C0r: 21.6 kN
K22x27x20 Fw: 22 mm | Ew: 27 mm | Bc: 20 mm | Cr: 17.5 kN | C0r: 25.9 kN
K22x27x40ZW Fw: 22 mm | Ew: 27 mm | Bc: 40 mm | Cr: 29.9 kN | C0r: 51.5 kN
K22x28x17 Fw: 22 mm | Ew: 28 mm | Bc: 17 mm | Cr: 17.7 kN | C0r: 23.3 kN
K22x30x15 Fw: 22 mm | Ew: 30 mm | Bc: 15 mm | Cr: 19.3 kN | C0r: 21.7 kN
K23x28x24 Fw: 23 mm | Ew: 28 mm | Bc: 24 mm | Cr: 19.8 kN | C0r: 31 kN
K24x28x10S Fw: 24 mm | Ew: 28 mm | Bc: 10 mm | Cr: 9 kN | C0r: 13.2 kN
K24x28x13 Fw: 24 mm | Ew: 28 mm | Bc: 13 mm | Cr: 10.8 kN | C0r: 16.8 kN
K24x28x17 Fw: 24 mm | Ew: 28 mm | Bc: 17 mm | Cr: 14.3 kN | C0r: 23.9 kN
K24x29x13 Fw: 24 mm | Ew: 29 mm | Bc: 13 mm | Cr: 12.3 kN | C0r: 16.9 kN
K24x30x17 Fw: 24 mm | Ew: 30 mm | Bc: 17 mm | Cr: 18.4 kN | C0r: 25.2 kN
K24x30x31ZW Fw: 24 mm | Ew: 30 mm | Bc: 31 mm | Cr: 27.9 kN | C0r: 43 kN
K25x29x10 Fw: 25 mm | Ew: 29 mm | Bc: 10 mm | Cr: 8.95 kN | C0r: 13.3 kN
K25x29x13 Fw: 25 mm | Ew: 29 mm | Bc: 13 mm | Cr: 10.8 kN | C0r: 16.9 kN
K25x29x17S Fw: 25 mm | Ew: 29 mm | Bc: 17 mm | Cr: 14.2 kN | C0r: 24 kN
K25x30x13 Fw: 25 mm | Ew: 30 mm | Bc: 13 mm | Cr: 13.2 kN | C0r: 18.8 kN
K25x30x17S Fw: 25 mm | Ew: 30 mm | Bc: 17 mm | Cr: 17.4 kN | C0r: 26.8 kN
K25x30x20S Fw: 25 mm | Ew: 30 mm | Bc: 20 mm | Cr: 19.4 kN | C0r: 31 kN
K25x30x26ZW Fw: 25 mm | Ew: 30 mm | Bc: 26 mm | Cr: 21.8 kN | C0r: 35.5 kN
K25x30x39ZW Fw: 25 mm | Ew: 30 mm | Bc: 39 mm | Cr: 29.8 kN | C0r: 53.5 kN
K25x31x13 Fw: 25 mm | Ew: 31 mm | Bc: 13 mm | Cr: 15.2 kN | C0r: 19.9 kN
K25x31x14 Fw: 25 mm | Ew: 31 mm | Bc: 14 mm | Cr: 16.5 kN | C0r: 22.1 kN
K25x31x17 Fw: 25 mm | Ew: 31 mm | Bc: 17 mm | Cr: 18.3 kN | C0r: 25.3 kN
K25x31x21 Fw: 25 mm | Ew: 31 mm | Bc: 21 mm | Cr: 22.5 kN | C0r: 33 kN
K26x30x13 Fw: 26 mm | Ew: 30 mm | Bc: 13 mm | Cr: 11.8 kN | C0r: 19.2 kN
K26x30x17 Fw: 26 mm | Ew: 30 mm | Bc: 17 mm | Cr: 15.5 kN | C0r: 27.4 kN
K26x34x22 Fw: 26 mm | Ew: 34 mm | Bc: 22 mm | Cr: 24.2 kN | C0r: 30 kN
K28x32x17 Fw: 28 mm | Ew: 32 mm | Bc: 17 mm | Cr: 15.3 kN | C0r: 27.5 kN
K28x32x21 Fw: 28 mm | Ew: 32 mm | Bc: 21 mm | Cr: 18.7 kN | C0r: 35.5 kN
K28x33x13 Fw: 28 mm | Ew: 33 mm | Bc: 13 mm | Cr: 13.9 kN | C0r: 20.9 kN
K28x33x17S Fw: 28 mm | Ew: 33 mm | Bc: 17 mm | Cr: 18.3 kN | C0r: 29.8 kN
K28x33x26ZW Fw: 28 mm | Ew: 33 mm | Bc: 26 mm | Cr: 23.9 kN | C0r: 42 kN
K28x33x27 Fw: 28 mm | Ew: 33 mm | Bc: 27 mm | Cr: 28.3 kN | C0r: 52 kN
K28x34x14 Fw: 28 mm | Ew: 34 mm | Bc: 14 mm | Cr: 17.5 kN | C0r: 24.8 kN
K28x34x17 Fw: 28 mm | Ew: 34 mm | Bc: 17 mm | Cr: 18.1 kN | C0r: 25.8 kN
K28x35x16 Fw: 28 mm | Ew: 35 mm | Bc: 16 mm | Cr: 21.2 kN | C0r: 28.4 kN
K28x35x18 Fw: 28 mm | Ew: 35 mm | Bc: 18 mm | Cr: 21.5 kN | C0r: 28.9 kN
K29x34x17S Fw: 29 mm | Ew: 34 mm | Bc: 17 mm | Cr: 18.9 kN | C0r: 31 kN
K29x34x27 Fw: 29 mm | Ew: 34 mm | Bc: 27 mm | Cr: 28.1 kN | C0r: 52 kN
K30x35x11S Fw: 30 mm | Ew: 35 mm | Bc: 11 mm | Cr: 12.2 kN | C0r: 18 kN
K30x35x13S Fw: 30 mm | Ew: 35 mm | Bc: 13 mm | Cr: 14.7 kN | C0r: 22.9 kN
K30x35x20S Fw: 30 mm | Ew: 35 mm | Bc: 20 mm | Cr: 21.6 kN | C0r: 37.5 kN
K30x35x26ZW Fw: 30 mm | Ew: 35 mm | Bc: 26 mm | Cr: 25.2 kN | C0r: 46 kN
K30x35x27S Fw: 30 mm | Ew: 35 mm | Bc: 27 mm | Cr: 29.9 kN | C0r: 57 kN
K30x37x16 Fw: 30 mm | Ew: 37 mm | Bc: 16 mm | Cr: 21.9 kN | C0r: 30.5 kN
K30x37x18 Fw: 30 mm | Ew: 37 mm | Bc: 18 mm | Cr: 23.3 kN | C0r: 33 kN
K30x37x48ZW Fw: 30 mm | Ew: 37 mm | Bc: 48 mm | Cr: 40 kN | C0r: 65.5 kN
K30x38x18 Fw: 30 mm | Ew: 38 mm | Bc: 18 mm | Cr: 25 kN | C0r: 33 kN
K32x36x15S Fw: 32 mm | Ew: 36 mm | Bc: 15 mm | Cr: 14.3 kN | C0r: 26.4 kN
K32x37x13 Fw: 32 mm | Ew: 37 mm | Bc: 13 mm | Cr: 14.5 kN | C0r: 23 kN
K32x37x17S Fw: 32 mm | Ew: 37 mm | Bc: 17 mm | Cr: 19.2 kN | C0r: 33 kN
K32x37x26ZW Fw: 32 mm | Ew: 37 mm | Bc: 26 mm | Cr: 24.9 kN | C0r: 46 kN
K32x38x26 Fw: 32 mm | Ew: 38 mm | Bc: 26 mm | Cr: 31.5 kN | C0r: 54 kN
K32x39x16 Fw: 32 mm | Ew: 39 mm | Bc: 16 mm | Cr: 22.6 kN | C0r: 32 kN
K32x39x18 Fw: 32 mm | Ew: 39 mm | Bc: 18 mm | Cr: 24 kN | C0r: 35 kN
K35x40x13 Fw: 35 mm | Ew: 40 mm | Bc: 13 mm | Cr: 15.2 kN | C0r: 25.1 kN
K35x40x17 Fw: 35 mm | Ew: 40 mm | Bc: 17 mm | Cr: 20 kN | C0r: 36 kN
K35x40x26ZW Fw: 35 mm | Ew: 40 mm | Bc: 26 mm | Cr: 26.1 kN | C0r: 50 kN
K35x40x30ZW Fw: 35 mm | Ew: 40 mm | Bc: 30 mm | Cr: 26.1 kN | C0r: 50 kN
K35x41x14 Fw: 35 mm | Ew: 41 mm | Bc: 14 mm | Cr: 19.4 kN | C0r: 30.5 kN
K35x41x15 Fw: 35 mm | Ew: 41 mm | Bc: 15 mm | Cr: 20.9 kN | C0r: 33.5 kN
K35x41x40ZW Fw: 35 mm | Ew: 41 mm | Bc: 40 mm | Cr: 43 kN | C0r: 84 kN
K35x42x16 Fw: 35 mm | Ew: 42 mm | Bc: 16 mm | Cr: 24.1 kN | C0r: 36 kN
K35x42x18 Fw: 35 mm | Ew: 42 mm | Bc: 18 mm | Cr: 24.7 kN | C0r: 37 kN
K35x42x20 Fw: 35 mm | Ew: 42 mm | Bc: 20 mm | Cr: 28.5 kN | C0r: 44.5 kN
K35x42x30 Fw: 35 mm | Ew: 42 mm | Bc: 30 mm | Cr: 39.5 kN | C0r: 68 kN
K35x42x45ZW Fw: 35 mm | Ew: 42 mm | Bc: 45 mm | Cr: 42.5 kN | C0r: 74 kN
K36x42x46ZW Fw: 36 mm | Ew: 42 mm | Bc: 46 mm | Cr: 51 kN | C0r: 106 kN
K37x42x13 Fw: 37 mm | Ew: 42 mm | Bc: 13 mm | Cr: 15.9 kN | C0r: 27.1 kN
K37x44x18 Fw: 37 mm | Ew: 44 mm | Bc: 18 mm | Cr: 26.3 kN | C0r: 41 kN
K38x43x17 Fw: 38 mm | Ew: 43 mm | Bc: 17 mm | Cr: 20.9 kN | C0r: 38.5 kN
K38x43x27 Fw: 38 mm | Ew: 43 mm | Bc: 27 mm | Cr: 32 kN | C0r: 67.5 kN
K38x46x32 Fw: 38 mm | Ew: 46 mm | Bc: 32 mm | Cr: 54 kN | C0r: 95.5 kN
K40x45x13 Fw: 40 mm | Ew: 45 mm | Bc: 13 mm | Cr: 16.5 kN | C0r: 29.2 kN
K40x45x17 Fw: 40 mm | Ew: 45 mm | Bc: 17 mm | Cr: 21.8 kN | C0r: 41.5 kN
K40x45x21 Fw: 40 mm | Ew: 45 mm | Bc: 21 mm | Cr: 26.7 kN | C0r: 54 kN
K40x45x27 Fw: 40 mm | Ew: 45 mm | Bc: 27 mm | Cr: 33.5 kN | C0r: 72.5 kN
K40x46x17 Fw: 40 mm | Ew: 46 mm | Bc: 17 mm | Cr: 24.6 kN | C0r: 43 kN
K40x47x18 Fw: 40 mm | Ew: 47 mm | Bc: 18 mm | Cr: 27.7 kN | C0r: 45 kN
K40x47x20 Fw: 40 mm | Ew: 47 mm | Bc: 20 mm | Cr: 31 kN | C0r: 51.5 kN
K40x48x20 Fw: 40 mm | Ew: 48 mm | Bc: 20 mm | Cr: 33 kN | C0r: 51 kN
K40x48x25 Fw: 40 mm | Ew: 48 mm | Bc: 25 mm | Cr: 42.5 kN | C0r: 71 kN
K42x47x17 Fw: 42 mm | Ew: 47 mm | Bc: 17 mm | Cr: 22.1 kN | C0r: 43 kN
K42x47x27 Fw: 42 mm | Ew: 47 mm | Bc: 27 mm | Cr: 34 kN | C0r: 75.5 kN
K42x48x17 Fw: 42 mm | Ew: 48 mm | Bc: 17 mm | Cr: 25.7 kN | C0r: 46 kN
K42x50x20 Fw: 42 mm | Ew: 50 mm | Bc: 20 mm | Cr: 34 kN | C0r: 53.5 kN
K43x48x17 Fw: 43 mm | Ew: 48 mm | Bc: 17 mm | Cr: 22 kN | C0r: 43 kN
K43x48x27 Fw: 43 mm | Ew: 48 mm | Bc: 27 mm | Cr: 34 kN | C0r: 75.5 kN
K43x50x18 Fw: 43 mm | Ew: 50 mm | Bc: 18 mm | Cr: 29.1 kN | C0r: 49 kN
K45x49x19 Fw: 45 mm | Ew: 49 mm | Bc: 19 mm | Cr: 22.1 kN | C0r: 52 kN
K45x50x27 Fw: 45 mm | Ew: 50 mm | Bc: 27 mm | Cr: 34.5 kN | C0r: 78 kN
K45x52x18 Fw: 45 mm | Ew: 52 mm | Bc: 18 mm | Cr: 29.7 kN | C0r: 51 kN
K45x52x21 Fw: 45 mm | Ew: 52 mm | Bc: 21 mm | Cr: 32 kN | C0r: 56.5 kN
K45x53x20 Fw: 45 mm | Ew: 53 mm | Bc: 20 mm | Cr: 36 kN | C0r: 59 kN
K45x53x25 Fw: 45 mm | Ew: 53 mm | Bc: 25 mm | Cr: 46.5 kN | C0r: 82 kN
K47x52x17 Fw: 47 mm | Ew: 52 mm | Bc: 17 mm | Cr: 23.2 kN | C0r: 47.5 kN
K47x52x27 Fw: 47 mm | Ew: 52 mm | Bc: 27 mm | Cr: 35.5 kN | C0r: 83 kN
K48x53x37.5ZW Fw: 48 mm | Ew: 53 mm | Bc: 37.5 mm | Cr: 41.5 kN | C0r: 101 kN
K48x54x19 Fw: 48 mm | Ew: 54 mm | Bc: 19 mm | Cr: 31 kN | C0r: 61 kN
K50x55x13.5 Fw: 50 mm | Ew: 55 mm | Bc: 13.5 mm | Cr: 18.1 kN | C0r: 35.5 kN
K50x55x20 Fw: 50 mm | Ew: 55 mm | Bc: 20 mm | Cr: 27.9 kN | C0r: 62 kN
K50x55x27 Fw: 50 mm | Ew: 55 mm | Bc: 27 mm | Cr: 37 kN | C0r: 88.5 kN
K50x55x30 Fw: 50 mm | Ew: 55 mm | Bc: 30 mm | Cr: 39.5 kN | C0r: 97 kN
K50x57x18 Fw: 50 mm | Ew: 57 mm | Bc: 18 mm | Cr: 31.5 kN | C0r: 57 kN
K50x58x20 Fw: 50 mm | Ew: 58 mm | Bc: 20 mm | Cr: 38.5 kN | C0r: 67.5 kN
K50x58x25 Fw: 50 mm | Ew: 58 mm | Bc: 25 mm | Cr: 48.5 kN | C0r: 90 kN
K52x58x19 Fw: 52 mm | Ew: 58 mm | Bc: 19 mm | Cr: 32 kN | C0r: 65.5 kN
K55x60x17 Fw: 55 mm | Ew: 60 mm | Bc: 17 mm | Cr: 25.8 kN | C0r: 58 kN
K55x60x20 Fw: 55 mm | Ew: 60 mm | Bc: 20 mm | Cr: 28.8 kN | C0r: 66.5 kN
K55x60x30 Fw: 55 mm | Ew: 60 mm | Bc: 30 mm | Cr: 42 kN | C0r: 108 kN
K55x61x19 Fw: 55 mm | Ew: 61 mm | Bc: 19 mm | Cr: 33 kN | C0r: 69.5 kN
K55x61x20 Fw: 55 mm | Ew: 61 mm | Bc: 20 mm | Cr: 33 kN | C0r: 69.5 kN
K55x61x30 Fw: 55 mm | Ew: 61 mm | Bc: 30 mm | Cr: 48 kN | C0r: 113 kN
K55x62x18 Fw: 55 mm | Ew: 62 mm | Bc: 18 mm | Cr: 33.5 kN | C0r: 63 kN
K55x63x20 Fw: 55 mm | Ew: 63 mm | Bc: 20 mm | Cr: 39 kN | C0r: 70 kN
K55x63x25 Fw: 55 mm | Ew: 63 mm | Bc: 25 mm | Cr: 50.5 kN | C0r: 97.5 kN
K55x63x32 Fw: 55 mm | Ew: 63 mm | Bc: 32 mm | Cr: 61 kN | C0r: 125 kN
K58x64x19 Fw: 58 mm | Ew: 64 mm | Bc: 19 mm | Cr: 34 kN | C0r: 73.5 kN
K60x65x20 Fw: 60 mm | Ew: 65 mm | Bc: 20 mm | Cr: 29.8 kN | C0r: 71.5 kN
K60x65x30 Fw: 60 mm | Ew: 65 mm | Bc: 30 mm | Cr: 43.5 kN | C0r: 116 kN
K60x66x19 Fw: 60 mm | Ew: 66 mm | Bc: 19 mm | Cr: 33.5 kN | C0r: 73.5 kN
K60x66x20 Fw: 60 mm | Ew: 66 mm | Bc: 20 mm | Cr: 33.5 kN | C0r: 73.5 kN
K60x66x30 Fw: 60 mm | Ew: 66 mm | Bc: 30 mm | Cr: 49 kN | C0r: 119 kN
K60x68x15 Fw: 60 mm | Ew: 68 mm | Bc: 15 mm | Cr: 27.2 kN | C0r: 45.5 kN
K60x68x20 Fw: 60 mm | Ew: 68 mm | Bc: 20 mm | Cr: 40 kN | C0r: 75 kN
K60x68x23 Fw: 60 mm | Ew: 68 mm | Bc: 23 mm | Cr: 44.5 kN | C0r: 85 kN
K60x68x25 Fw: 60 mm | Ew: 68 mm | Bc: 25 mm | Cr: 52 kN | C0r: 105 kN
K60x68x27 Fw: 60 mm | Ew: 68 mm | Bc: 27 mm | Cr: 52 kN | C0r: 105 kN
K120x127x34 Fw: 120 mm | Ew: 127 mm | Bc: 34 mm | Cr: 82.2 kN | C0r: 260 kN
K125x133x35 Fw: 125 mm | Ew: 133 mm | Bc: 35 mm | Cr: 87 kN | C0r: 260 kN
K125x135x34 Fw: 125 mm | Ew: 135 mm | Bc: 34 mm | Cr: 100 kN | C0r: 265 kN
K130x137x24 Fw: 130 mm | Ew: 137 mm | Bc: 24 mm | Cr: 59 kN | C0r: 175 kN
K130x137x34 Fw: 130 mm | Ew: 137 mm | Bc: 34 mm | Cr: 84.5 kN | C0r: 277 kN
K135x143x35 Fw: 135 mm | Ew: 143 mm | Bc: 35 mm | Cr: 92.5 kN | C0r: 288 kN
K135x150x38 Fw: 135 mm | Ew: 150 mm | Bc: 38 mm | Cr: 145 kN | C0r: 325 kN
K145x153x26 Fw: 145 mm | Ew: 153 mm | Bc: 26 mm | Cr: 72 kN | C0r: 214 kN
K145x153x28 Fw: 145 mm | Ew: 153 mm | Bc: 28 mm | Cr: 80.5 kN | C0r: 247 kN
K145x153x36 Fw: 145 mm | Ew: 153 mm | Bc: 36 mm | Cr: 100 kN | C0r: 325 kN
K150x160x46 Fw: 150 mm | Ew: 160 mm | Bc: 46 mm | Cr: 149 kN | C0r: 470 kN
K155x163x26 Fw: 155 mm | Ew: 163 mm | Bc: 26 mm | Cr: 73.5 kN | C0r: 224 kN
K155x163x36 Fw: 155 mm | Ew: 163 mm | Bc: 36 mm | Cr: 102 kN | C0r: 340 kN
K160x170x46 Fw: 160 mm | Ew: 170 mm | Bc: 46 mm | Cr: 155 kN | C0r: 505 kN
K165x173x26 Fw: 165 mm | Ew: 173 mm | Bc: 26 mm | Cr: 79 kN | C0r: 251 kN
K165x173x32 Fw: 165 mm | Ew: 173 mm | Bc: 32 mm | Cr: 97 kN | C0r: 330 kN
K165x173x36 Fw: 165 mm | Ew: 173 mm | Bc: 36 mm | Cr: 109 kN | C0r: 380 kN
K170x180x46 Fw: 170 mm | Ew: 180 mm | Bc: 46 mm | Cr: 160 kN | C0r: 540 kN
K175x183x32 Fw: 175 mm | Ew: 183 mm | Bc: 32 mm | Cr: 101 kN | C0r: 350 kN
K185x195x37 Fw: 185 mm | Ew: 195 mm | Bc: 37 mm | Cr: 131 kN | C0r: 425 kN
K195x205x37 Fw: 195 mm | Ew: 205 mm | Bc: 37 mm | Cr: 135 kN | C0r: 450 kN
K210x220x42 Fw: 210 mm | Ew: 220 mm | Bc: 42 mm | Cr: 156 kN | C0r: 560 kN
K220x230x42 Fw: 220 mm | Ew: 230 mm | Bc: 42 mm | Cr: 161 kN | C0r: 590 kN
K240x250x42 Fw: 240 mm | Ew: 250 mm | Bc: 42 mm | Cr: 167 kN | C0r: 635 kN
K265x280x50 Fw: 265 mm | Ew: 280 mm | Bc: 50 mm | Cr: 256 kN | C0r: 850 kN
K285x300x50 Fw: 285 mm | Ew: 300 mm | Bc: 50 mm | Cr: 268 kN | C0r: 930 kN
Needle Roller BearingsNTN
241 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NTN K Series Needle Roller and Cage Assemblies

Brand NTN·Needle Roller Bearings

Available part numbers (241)

K3x6x7T2, K4x7x7T2, K5x8x8T2, K5x8x10T2, K6x9x8T2, K6x9x10T2, K6x10x13T2, K7x10x8T2, K7x10x10T2, K8x11x8T2 + 231 more — see full table ↓

How to order

Send the NTN part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
K3x6x7T2Fw: 3 mm | Ew: 6 mm | Bc: 7 mm | Cr: 1.46 kN | C0r: 0.97 kN
K4x7x7T2Fw: 4 mm | Ew: 7 mm | Bc: 7 mm | Cr: 1.77 kN | C0r: 1.27 kN
K5x8x8T2Fw: 5 mm | Ew: 8 mm | Bc: 8 mm | Cr: 2.64 kN | C0r: 2.19 kN
K5x8x10T2Fw: 5 mm | Ew: 8 mm | Bc: 10 mm | Cr: 2.72 kN | C0r: 2.25 kN
K6x9x8T2Fw: 6 mm | Ew: 9 mm | Bc: 8 mm | Cr: 2.66 kN | C0r: 2.28 kN
K6x9x10T2Fw: 6 mm | Ew: 9 mm | Bc: 10 mm | Cr: 3.4 kN | C0r: 3.15 kN
K6x10x13T2Fw: 6 mm | Ew: 10 mm | Bc: 13 mm | Cr: 4.4 kN | C0r: 3.7 kN
K7x10x8T2Fw: 7 mm | Ew: 10 mm | Bc: 8 mm | Cr: 2.67 kN | C0r: 2.35 kN
K7x10x10T2Fw: 7 mm | Ew: 10 mm | Bc: 10 mm | Cr: 3.4 kN | C0r: 3.2 kN
K8x11x8T2Fw: 8 mm | Ew: 11 mm | Bc: 8 mm | Cr: 3.15 kN | C0r: 3 kN
K8x11x10T2Fw: 8 mm | Ew: 11 mm | Bc: 10 mm | Cr: 4 kN | C0r: 4.1 kN
K8x11x13Fw: 8 mm | Ew: 11 mm | Bc: 13 mm | Cr: 4.85 kN | C0r: 5.2 kN
K8x12x10T2Fw: 8 mm | Ew: 12 mm | Bc: 10 mm | Cr: 4.65 kN | C0r: 4.15 kN
K8x12x12Fw: 8 mm | Ew: 12 mm | Bc: 12 mm | Cr: 5.6 kN | C0r: 5.3 kN
K8x12x13Fw: 8 mm | Ew: 12 mm | Bc: 13 mm | Cr: 5.6 kN | C0r: 5.3 kN
K9x12x10T2Fw: 9 mm | Ew: 12 mm | Bc: 10 mm | Cr: 4.55 kN | C0r: 5 kN
K9x12x13T2Fw: 9 mm | Ew: 12 mm | Bc: 13 mm | Cr: 5.5 kN | C0r: 6.4 kN
K10x13x10T2Fw: 10 mm | Ew: 13 mm | Bc: 10 mm | Cr: 4.55 kN | C0r: 5.1 kN
K10x13x13Fw: 10 mm | Ew: 13 mm | Bc: 13 mm | Cr: 5.45 kN | C0r: 6.45 kN
K10x14x8Fw: 10 mm | Ew: 14 mm | Bc: 8 mm | Cr: 4.3 kN | C0r: 3.95 kN
K10x14x10Fw: 10 mm | Ew: 14 mm | Bc: 10 mm | Cr: 5.5 kN | C0r: 5.45 kN
K10x14x13Fw: 10 mm | Ew: 14 mm | Bc: 13 mm | Cr: 6.6 kN | C0r: 6.9 kN
K10x16x12Fw: 10 mm | Ew: 16 mm | Bc: 12 mm | Cr: 7.1 kN | C0r: 5.95 kN
K11x14x10Fw: 11 mm | Ew: 14 mm | Bc: 10 mm | Cr: 4.05 kN | C0r: 6 kN
K12x15x9Fw: 12 mm | Ew: 15 mm | Bc: 9 mm | Cr: 5.45 kN | C0r: 5.25 kN
K12x15x10SFw: 12 mm | Ew: 15 mm | Bc: 10 mm | Cr: 6 kN | C0r: 6.1 kN
K12x15x13Fw: 12 mm | Ew: 15 mm | Bc: 13 mm | Cr: 8 kN | C0r: 7.7 kN
K12x15x20ZWFw: 12 mm | Ew: 15 mm | Bc: 20 mm | Cr: 0.55 kN | C0r: 12.2 kN
K12x16x8Fw: 12 mm | Ew: 16 mm | Bc: 8 mm | Cr: 4.85 kN | C0r: 4.9 kN
K12x16x13Fw: 12 mm | Ew: 16 mm | Bc: 13 mm | Cr: 7.5 kN | C0r: 8.5 kN
K12x17x13Fw: 12 mm | Ew: 17 mm | Bc: 13 mm | Cr: 9 kN | C0r: 9.4 kN
K12x18x12Fw: 12 mm | Ew: 18 mm | Bc: 12 mm | Cr: 8.65 kN | C0r: 8 kN
K14x17x10Fw: 14 mm | Ew: 17 mm | Bc: 10 mm | Cr: 5.4 kN | C0r: 7.05 kN
K14x18x10Fw: 14 mm | Ew: 18 mm | Bc: 10 mm | Cr: 6.9 kN | C0r: 8 kN
K14x18x11Fw: 14 mm | Ew: 18 mm | Bc: 11 mm | Cr: 7.6 kN | C0r: 9.05 kN
K14x18x13Fw: 14 mm | Ew: 18 mm | Bc: 13 mm | Cr: 8.3 kN | C0r: 10.1 kN
K14x18x15SFw: 14 mm | Ew: 18 mm | Bc: 15 mm | Cr: 9.65 kN | C0r: 12.3 kN
K14x18x17Fw: 14 mm | Ew: 18 mm | Bc: 17 mm | Cr: 10.9 kN | C0r: 14.4 kN
K14x18x39ZWFw: 14 mm | Ew: 18 mm | Bc: 39 mm | Cr: 18.8 kN | C0r: 28.9 kN
K14x19x13Fw: 14 mm | Ew: 19 mm | Bc: 13 mm | Cr: 8.95 kN | C0r: 9.65 kN
K14x20x12Fw: 14 mm | Ew: 20 mm | Bc: 12 mm | Cr: 9.35 kN | C0r: 9.15 kN
K14x20x17Fw: 14 mm | Ew: 20 mm | Bc: 17 mm | Cr: 13.5 kN | C0r: 14.6 kN
K15x18x14Fw: 15 mm | Ew: 18 mm | Bc: 14 mm | Cr: 7.85 kN | C0r: 11.6 kN
K15x19x10SFw: 15 mm | Ew: 19 mm | Bc: 10 mm | Cr: 6.85 kN | C0r: 8.05 kN
K15x19x13SFw: 15 mm | Ew: 19 mm | Bc: 13 mm | Cr: 8.25 kN | C0r: 10.2 kN
K15x19x17Fw: 15 mm | Ew: 19 mm | Bc: 17 mm | Cr: 10.9 kN | C0r: 14.6 kN
K15x19x24ZWFw: 15 mm | Ew: 19 mm | Bc: 24 mm | Cr: 14.1 kN | C0r: 20.4 kN
K15x20x13Fw: 15 mm | Ew: 20 mm | Bc: 13 mm | Cr: 10.1 kN | C0r: 11.5 kN
K15x21x15Fw: 15 mm | Ew: 21 mm | Bc: 15 mm | Cr: 11.9 kN | C0r: 12.5 kN
K15x21x21Fw: 15 mm | Ew: 21 mm | Bc: 21 mm | Cr: 16.5 kN | C0r: 19.1 kN
K16x20x10Fw: 16 mm | Ew: 20 mm | Bc: 10 mm | Cr: 7.5 kN | C0r: 9.25 kN
K16x20x11Fw: 16 mm | Ew: 20 mm | Bc: 11 mm | Cr: 8.3 kN | C0r: 10.5 kN
K16x20x13Fw: 16 mm | Ew: 20 mm | Bc: 13 mm | Cr: 9.05 kN | C0r: 11.8 kN
K16x20x17SFw: 16 mm | Ew: 20 mm | Bc: 17 mm | Cr: 11.9 kN | C0r: 16.8 kN
K16x22x12Fw: 16 mm | Ew: 22 mm | Bc: 12 mm | Cr: 11.7 kN | C0r: 12.5 kN
K16x22x17Fw: 16 mm | Ew: 22 mm | Bc: 17 mm | Cr: 14.4 kN | C0r: 16.4 kN
K16x22x20Fw: 16 mm | Ew: 22 mm | Bc: 20 mm | Cr: 16 kN | C0r: 18.8 kN
K17x21x10SFw: 17 mm | Ew: 21 mm | Bc: 10 mm | Cr: 7.45 kN | C0r: 9.3 kN
K17x21x13SFw: 17 mm | Ew: 21 mm | Bc: 13 mm | Cr: 9.4 kN | C0r: 12.6 kN
K17x21x15Fw: 17 mm | Ew: 21 mm | Bc: 15 mm | Cr: 10.4 kN | C0r: 14.4 kN
K17x21x17Fw: 17 mm | Ew: 21 mm | Bc: 17 mm | Cr: 11.8 kN | C0r: 16.9 kN
K17x22x20Fw: 17 mm | Ew: 22 mm | Bc: 20 mm | Cr: 14.7 kN | C0r: 19.2 kN
K17x23x17Fw: 17 mm | Ew: 23 mm | Bc: 17 mm | Cr: 14.4 kN | C0r: 16.5 kN
K18x22x10Fw: 18 mm | Ew: 22 mm | Bc: 10 mm | Cr: 7.4 kN | C0r: 9.4 kN
K18x22x13Fw: 18 mm | Ew: 22 mm | Bc: 13 mm | Cr: 8.9 kN | C0r: 11.9 kN
K18x22x17Fw: 18 mm | Ew: 22 mm | Bc: 17 mm | Cr: 11.7 kN | C0r: 17 kN
K18x23x20SFw: 18 mm | Ew: 23 mm | Bc: 20 mm | Cr: 14.6 kN | C0r: 19.3 kN
K18x24x12Fw: 18 mm | Ew: 24 mm | Bc: 12 mm | Cr: 12.3 kN | C0r: 13.8 kN
K18x24x13Fw: 18 mm | Ew: 24 mm | Bc: 13 mm | Cr: 11.6 kN | C0r: 12.8 kN
K18x24x20Fw: 18 mm | Ew: 24 mm | Bc: 20 mm | Cr: 17 kN | C0r: 20.9 kN
K18x25x17Fw: 18 mm | Ew: 25 mm | Bc: 17 mm | Cr: 18 kN | C0r: 20.4 kN
K18x25x22Fw: 18 mm | Ew: 25 mm | Bc: 22 mm | Cr: 22.1 kN | C0r: 26.6 kN
K19x23x13Fw: 19 mm | Ew: 23 mm | Bc: 13 mm | Cr: 9.65 kN | C0r: 13.5 kN
K19x23x17Fw: 19 mm | Ew: 23 mm | Bc: 17 mm | Cr: 12.7 kN | C0r: 19.2 kN
K20x24x10SFw: 20 mm | Ew: 24 mm | Bc: 10 mm | Cr: 8.3 kN | C0r: 11.2 kN
K20x24x11Fw: 20 mm | Ew: 24 mm | Bc: 11 mm | Cr: 9.5 kN | C0r: 13.4 kN
K20x24x13SFw: 20 mm | Ew: 24 mm | Bc: 13 mm | Cr: 10 kN | C0r: 14.3 kN
K20x24x17SFw: 20 mm | Ew: 24 mm | Bc: 17 mm | Cr: 13.2 kN | C0r: 20.4 kN
K20x24x45ZWFw: 20 mm | Ew: 24 mm | Bc: 45 mm | Cr: 16.4 kN | C0r: 27.1 kN
K20x25x40ZWFw: 20 mm | Ew: 25 mm | Bc: 40 mm | Cr: 29 kN | C0r: 48 kN
K20x26x12Fw: 20 mm | Ew: 26 mm | Bc: 12 mm | Cr: 12 kN | C0r: 15.1 kN
K20x28x25Fw: 20 mm | Ew: 28 mm | Bc: 25 mm | Cr: 27.1 kN | C0r: 32.5 kN
K21x25x13Fw: 21 mm | Ew: 25 mm | Bc: 13 mm | Cr: 10.3 kN | C0r: 15.1 kN
K21x25x17Fw: 21 mm | Ew: 25 mm | Bc: 17 mm | Cr: 13.6 kN | C0r: 21.5 kN
K22x26x10SFw: 22 mm | Ew: 26 mm | Bc: 10 mm | Cr: 8.5 kN | C0r: 11.9 kN
K22x26x11SFw: 22 mm | Ew: 26 mm | Bc: 11 mm | Cr: 10.1 kN | C0r: 14.9 kN
K22x26x13Fw: 22 mm | Ew: 26 mm | Bc: 13 mm | Cr: 10.2 kN | C0r: 15.2 kN
K22x26x17SFw: 22 mm | Ew: 26 mm | Bc: 17 mm | Cr: 13.5 kN | C0r: 21.6 kN
K22x27x20Fw: 22 mm | Ew: 27 mm | Bc: 20 mm | Cr: 17.5 kN | C0r: 25.9 kN
K22x27x40ZWFw: 22 mm | Ew: 27 mm | Bc: 40 mm | Cr: 29.9 kN | C0r: 51.5 kN
K22x28x17Fw: 22 mm | Ew: 28 mm | Bc: 17 mm | Cr: 17.7 kN | C0r: 23.3 kN
K22x30x15Fw: 22 mm | Ew: 30 mm | Bc: 15 mm | Cr: 19.3 kN | C0r: 21.7 kN
K23x28x24Fw: 23 mm | Ew: 28 mm | Bc: 24 mm | Cr: 19.8 kN | C0r: 31 kN
K24x28x10SFw: 24 mm | Ew: 28 mm | Bc: 10 mm | Cr: 9 kN | C0r: 13.2 kN
K24x28x13Fw: 24 mm | Ew: 28 mm | Bc: 13 mm | Cr: 10.8 kN | C0r: 16.8 kN
K24x28x17Fw: 24 mm | Ew: 28 mm | Bc: 17 mm | Cr: 14.3 kN | C0r: 23.9 kN
K24x29x13Fw: 24 mm | Ew: 29 mm | Bc: 13 mm | Cr: 12.3 kN | C0r: 16.9 kN
K24x30x17Fw: 24 mm | Ew: 30 mm | Bc: 17 mm | Cr: 18.4 kN | C0r: 25.2 kN
K24x30x31ZWFw: 24 mm | Ew: 30 mm | Bc: 31 mm | Cr: 27.9 kN | C0r: 43 kN
K25x29x10Fw: 25 mm | Ew: 29 mm | Bc: 10 mm | Cr: 8.95 kN | C0r: 13.3 kN
K25x29x13Fw: 25 mm | Ew: 29 mm | Bc: 13 mm | Cr: 10.8 kN | C0r: 16.9 kN
K25x29x17SFw: 25 mm | Ew: 29 mm | Bc: 17 mm | Cr: 14.2 kN | C0r: 24 kN
K25x30x13Fw: 25 mm | Ew: 30 mm | Bc: 13 mm | Cr: 13.2 kN | C0r: 18.8 kN
K25x30x17SFw: 25 mm | Ew: 30 mm | Bc: 17 mm | Cr: 17.4 kN | C0r: 26.8 kN
K25x30x20SFw: 25 mm | Ew: 30 mm | Bc: 20 mm | Cr: 19.4 kN | C0r: 31 kN
K25x30x26ZWFw: 25 mm | Ew: 30 mm | Bc: 26 mm | Cr: 21.8 kN | C0r: 35.5 kN
K25x30x39ZWFw: 25 mm | Ew: 30 mm | Bc: 39 mm | Cr: 29.8 kN | C0r: 53.5 kN
K25x31x13Fw: 25 mm | Ew: 31 mm | Bc: 13 mm | Cr: 15.2 kN | C0r: 19.9 kN
K25x31x14Fw: 25 mm | Ew: 31 mm | Bc: 14 mm | Cr: 16.5 kN | C0r: 22.1 kN
K25x31x17Fw: 25 mm | Ew: 31 mm | Bc: 17 mm | Cr: 18.3 kN | C0r: 25.3 kN
K25x31x21Fw: 25 mm | Ew: 31 mm | Bc: 21 mm | Cr: 22.5 kN | C0r: 33 kN
K26x30x13Fw: 26 mm | Ew: 30 mm | Bc: 13 mm | Cr: 11.8 kN | C0r: 19.2 kN
K26x30x17Fw: 26 mm | Ew: 30 mm | Bc: 17 mm | Cr: 15.5 kN | C0r: 27.4 kN
K26x34x22Fw: 26 mm | Ew: 34 mm | Bc: 22 mm | Cr: 24.2 kN | C0r: 30 kN
K28x32x17Fw: 28 mm | Ew: 32 mm | Bc: 17 mm | Cr: 15.3 kN | C0r: 27.5 kN
K28x32x21Fw: 28 mm | Ew: 32 mm | Bc: 21 mm | Cr: 18.7 kN | C0r: 35.5 kN
K28x33x13Fw: 28 mm | Ew: 33 mm | Bc: 13 mm | Cr: 13.9 kN | C0r: 20.9 kN
K28x33x17SFw: 28 mm | Ew: 33 mm | Bc: 17 mm | Cr: 18.3 kN | C0r: 29.8 kN
K28x33x26ZWFw: 28 mm | Ew: 33 mm | Bc: 26 mm | Cr: 23.9 kN | C0r: 42 kN
K28x33x27Fw: 28 mm | Ew: 33 mm | Bc: 27 mm | Cr: 28.3 kN | C0r: 52 kN
K28x34x14Fw: 28 mm | Ew: 34 mm | Bc: 14 mm | Cr: 17.5 kN | C0r: 24.8 kN
K28x34x17Fw: 28 mm | Ew: 34 mm | Bc: 17 mm | Cr: 18.1 kN | C0r: 25.8 kN
K28x35x16Fw: 28 mm | Ew: 35 mm | Bc: 16 mm | Cr: 21.2 kN | C0r: 28.4 kN
K28x35x18Fw: 28 mm | Ew: 35 mm | Bc: 18 mm | Cr: 21.5 kN | C0r: 28.9 kN
K29x34x17SFw: 29 mm | Ew: 34 mm | Bc: 17 mm | Cr: 18.9 kN | C0r: 31 kN
K29x34x27Fw: 29 mm | Ew: 34 mm | Bc: 27 mm | Cr: 28.1 kN | C0r: 52 kN
K30x35x11SFw: 30 mm | Ew: 35 mm | Bc: 11 mm | Cr: 12.2 kN | C0r: 18 kN
K30x35x13SFw: 30 mm | Ew: 35 mm | Bc: 13 mm | Cr: 14.7 kN | C0r: 22.9 kN
K30x35x20SFw: 30 mm | Ew: 35 mm | Bc: 20 mm | Cr: 21.6 kN | C0r: 37.5 kN
K30x35x26ZWFw: 30 mm | Ew: 35 mm | Bc: 26 mm | Cr: 25.2 kN | C0r: 46 kN
K30x35x27SFw: 30 mm | Ew: 35 mm | Bc: 27 mm | Cr: 29.9 kN | C0r: 57 kN
K30x37x16Fw: 30 mm | Ew: 37 mm | Bc: 16 mm | Cr: 21.9 kN | C0r: 30.5 kN
K30x37x18Fw: 30 mm | Ew: 37 mm | Bc: 18 mm | Cr: 23.3 kN | C0r: 33 kN
K30x37x48ZWFw: 30 mm | Ew: 37 mm | Bc: 48 mm | Cr: 40 kN | C0r: 65.5 kN
K30x38x18Fw: 30 mm | Ew: 38 mm | Bc: 18 mm | Cr: 25 kN | C0r: 33 kN
K32x36x15SFw: 32 mm | Ew: 36 mm | Bc: 15 mm | Cr: 14.3 kN | C0r: 26.4 kN
K32x37x13Fw: 32 mm | Ew: 37 mm | Bc: 13 mm | Cr: 14.5 kN | C0r: 23 kN
K32x37x17SFw: 32 mm | Ew: 37 mm | Bc: 17 mm | Cr: 19.2 kN | C0r: 33 kN
K32x37x26ZWFw: 32 mm | Ew: 37 mm | Bc: 26 mm | Cr: 24.9 kN | C0r: 46 kN
K32x38x26Fw: 32 mm | Ew: 38 mm | Bc: 26 mm | Cr: 31.5 kN | C0r: 54 kN
K32x39x16Fw: 32 mm | Ew: 39 mm | Bc: 16 mm | Cr: 22.6 kN | C0r: 32 kN
K32x39x18Fw: 32 mm | Ew: 39 mm | Bc: 18 mm | Cr: 24 kN | C0r: 35 kN
K35x40x13Fw: 35 mm | Ew: 40 mm | Bc: 13 mm | Cr: 15.2 kN | C0r: 25.1 kN
K35x40x17Fw: 35 mm | Ew: 40 mm | Bc: 17 mm | Cr: 20 kN | C0r: 36 kN
K35x40x26ZWFw: 35 mm | Ew: 40 mm | Bc: 26 mm | Cr: 26.1 kN | C0r: 50 kN
K35x40x30ZWFw: 35 mm | Ew: 40 mm | Bc: 30 mm | Cr: 26.1 kN | C0r: 50 kN
K35x41x14Fw: 35 mm | Ew: 41 mm | Bc: 14 mm | Cr: 19.4 kN | C0r: 30.5 kN
K35x41x15Fw: 35 mm | Ew: 41 mm | Bc: 15 mm | Cr: 20.9 kN | C0r: 33.5 kN
K35x41x40ZWFw: 35 mm | Ew: 41 mm | Bc: 40 mm | Cr: 43 kN | C0r: 84 kN
K35x42x16Fw: 35 mm | Ew: 42 mm | Bc: 16 mm | Cr: 24.1 kN | C0r: 36 kN
K35x42x18Fw: 35 mm | Ew: 42 mm | Bc: 18 mm | Cr: 24.7 kN | C0r: 37 kN
K35x42x20Fw: 35 mm | Ew: 42 mm | Bc: 20 mm | Cr: 28.5 kN | C0r: 44.5 kN
K35x42x30Fw: 35 mm | Ew: 42 mm | Bc: 30 mm | Cr: 39.5 kN | C0r: 68 kN
K35x42x45ZWFw: 35 mm | Ew: 42 mm | Bc: 45 mm | Cr: 42.5 kN | C0r: 74 kN
K36x42x46ZWFw: 36 mm | Ew: 42 mm | Bc: 46 mm | Cr: 51 kN | C0r: 106 kN
K37x42x13Fw: 37 mm | Ew: 42 mm | Bc: 13 mm | Cr: 15.9 kN | C0r: 27.1 kN
K37x44x18Fw: 37 mm | Ew: 44 mm | Bc: 18 mm | Cr: 26.3 kN | C0r: 41 kN
K38x43x17Fw: 38 mm | Ew: 43 mm | Bc: 17 mm | Cr: 20.9 kN | C0r: 38.5 kN
K38x43x27Fw: 38 mm | Ew: 43 mm | Bc: 27 mm | Cr: 32 kN | C0r: 67.5 kN
K38x46x32Fw: 38 mm | Ew: 46 mm | Bc: 32 mm | Cr: 54 kN | C0r: 95.5 kN
K40x45x13Fw: 40 mm | Ew: 45 mm | Bc: 13 mm | Cr: 16.5 kN | C0r: 29.2 kN
K40x45x17Fw: 40 mm | Ew: 45 mm | Bc: 17 mm | Cr: 21.8 kN | C0r: 41.5 kN
K40x45x21Fw: 40 mm | Ew: 45 mm | Bc: 21 mm | Cr: 26.7 kN | C0r: 54 kN
K40x45x27Fw: 40 mm | Ew: 45 mm | Bc: 27 mm | Cr: 33.5 kN | C0r: 72.5 kN
K40x46x17Fw: 40 mm | Ew: 46 mm | Bc: 17 mm | Cr: 24.6 kN | C0r: 43 kN
K40x47x18Fw: 40 mm | Ew: 47 mm | Bc: 18 mm | Cr: 27.7 kN | C0r: 45 kN
K40x47x20Fw: 40 mm | Ew: 47 mm | Bc: 20 mm | Cr: 31 kN | C0r: 51.5 kN
K40x48x20Fw: 40 mm | Ew: 48 mm | Bc: 20 mm | Cr: 33 kN | C0r: 51 kN
K40x48x25Fw: 40 mm | Ew: 48 mm | Bc: 25 mm | Cr: 42.5 kN | C0r: 71 kN
K42x47x17Fw: 42 mm | Ew: 47 mm | Bc: 17 mm | Cr: 22.1 kN | C0r: 43 kN
K42x47x27Fw: 42 mm | Ew: 47 mm | Bc: 27 mm | Cr: 34 kN | C0r: 75.5 kN
K42x48x17Fw: 42 mm | Ew: 48 mm | Bc: 17 mm | Cr: 25.7 kN | C0r: 46 kN
K42x50x20Fw: 42 mm | Ew: 50 mm | Bc: 20 mm | Cr: 34 kN | C0r: 53.5 kN
K43x48x17Fw: 43 mm | Ew: 48 mm | Bc: 17 mm | Cr: 22 kN | C0r: 43 kN
K43x48x27Fw: 43 mm | Ew: 48 mm | Bc: 27 mm | Cr: 34 kN | C0r: 75.5 kN
K43x50x18Fw: 43 mm | Ew: 50 mm | Bc: 18 mm | Cr: 29.1 kN | C0r: 49 kN
K45x49x19Fw: 45 mm | Ew: 49 mm | Bc: 19 mm | Cr: 22.1 kN | C0r: 52 kN
K45x50x27Fw: 45 mm | Ew: 50 mm | Bc: 27 mm | Cr: 34.5 kN | C0r: 78 kN
K45x52x18Fw: 45 mm | Ew: 52 mm | Bc: 18 mm | Cr: 29.7 kN | C0r: 51 kN
K45x52x21Fw: 45 mm | Ew: 52 mm | Bc: 21 mm | Cr: 32 kN | C0r: 56.5 kN
K45x53x20Fw: 45 mm | Ew: 53 mm | Bc: 20 mm | Cr: 36 kN | C0r: 59 kN
K45x53x25Fw: 45 mm | Ew: 53 mm | Bc: 25 mm | Cr: 46.5 kN | C0r: 82 kN
K47x52x17Fw: 47 mm | Ew: 52 mm | Bc: 17 mm | Cr: 23.2 kN | C0r: 47.5 kN
K47x52x27Fw: 47 mm | Ew: 52 mm | Bc: 27 mm | Cr: 35.5 kN | C0r: 83 kN
K48x53x37.5ZWFw: 48 mm | Ew: 53 mm | Bc: 37.5 mm | Cr: 41.5 kN | C0r: 101 kN
K48x54x19Fw: 48 mm | Ew: 54 mm | Bc: 19 mm | Cr: 31 kN | C0r: 61 kN
K50x55x13.5Fw: 50 mm | Ew: 55 mm | Bc: 13.5 mm | Cr: 18.1 kN | C0r: 35.5 kN
K50x55x20Fw: 50 mm | Ew: 55 mm | Bc: 20 mm | Cr: 27.9 kN | C0r: 62 kN
K50x55x27Fw: 50 mm | Ew: 55 mm | Bc: 27 mm | Cr: 37 kN | C0r: 88.5 kN
K50x55x30Fw: 50 mm | Ew: 55 mm | Bc: 30 mm | Cr: 39.5 kN | C0r: 97 kN
K50x57x18Fw: 50 mm | Ew: 57 mm | Bc: 18 mm | Cr: 31.5 kN | C0r: 57 kN
K50x58x20Fw: 50 mm | Ew: 58 mm | Bc: 20 mm | Cr: 38.5 kN | C0r: 67.5 kN
K50x58x25Fw: 50 mm | Ew: 58 mm | Bc: 25 mm | Cr: 48.5 kN | C0r: 90 kN
K52x58x19Fw: 52 mm | Ew: 58 mm | Bc: 19 mm | Cr: 32 kN | C0r: 65.5 kN
K55x60x17Fw: 55 mm | Ew: 60 mm | Bc: 17 mm | Cr: 25.8 kN | C0r: 58 kN
K55x60x20Fw: 55 mm | Ew: 60 mm | Bc: 20 mm | Cr: 28.8 kN | C0r: 66.5 kN
K55x60x30Fw: 55 mm | Ew: 60 mm | Bc: 30 mm | Cr: 42 kN | C0r: 108 kN
K55x61x19Fw: 55 mm | Ew: 61 mm | Bc: 19 mm | Cr: 33 kN | C0r: 69.5 kN
K55x61x20Fw: 55 mm | Ew: 61 mm | Bc: 20 mm | Cr: 33 kN | C0r: 69.5 kN
K55x61x30Fw: 55 mm | Ew: 61 mm | Bc: 30 mm | Cr: 48 kN | C0r: 113 kN
K55x62x18Fw: 55 mm | Ew: 62 mm | Bc: 18 mm | Cr: 33.5 kN | C0r: 63 kN
K55x63x20Fw: 55 mm | Ew: 63 mm | Bc: 20 mm | Cr: 39 kN | C0r: 70 kN
K55x63x25Fw: 55 mm | Ew: 63 mm | Bc: 25 mm | Cr: 50.5 kN | C0r: 97.5 kN
K55x63x32Fw: 55 mm | Ew: 63 mm | Bc: 32 mm | Cr: 61 kN | C0r: 125 kN
K58x64x19Fw: 58 mm | Ew: 64 mm | Bc: 19 mm | Cr: 34 kN | C0r: 73.5 kN
K60x65x20Fw: 60 mm | Ew: 65 mm | Bc: 20 mm | Cr: 29.8 kN | C0r: 71.5 kN
K60x65x30Fw: 60 mm | Ew: 65 mm | Bc: 30 mm | Cr: 43.5 kN | C0r: 116 kN
K60x66x19Fw: 60 mm | Ew: 66 mm | Bc: 19 mm | Cr: 33.5 kN | C0r: 73.5 kN
K60x66x20Fw: 60 mm | Ew: 66 mm | Bc: 20 mm | Cr: 33.5 kN | C0r: 73.5 kN
K60x66x30Fw: 60 mm | Ew: 66 mm | Bc: 30 mm | Cr: 49 kN | C0r: 119 kN
K60x68x15Fw: 60 mm | Ew: 68 mm | Bc: 15 mm | Cr: 27.2 kN | C0r: 45.5 kN
K60x68x20Fw: 60 mm | Ew: 68 mm | Bc: 20 mm | Cr: 40 kN | C0r: 75 kN
K60x68x23Fw: 60 mm | Ew: 68 mm | Bc: 23 mm | Cr: 44.5 kN | C0r: 85 kN
K60x68x25Fw: 60 mm | Ew: 68 mm | Bc: 25 mm | Cr: 52 kN | C0r: 105 kN
K60x68x27Fw: 60 mm | Ew: 68 mm | Bc: 27 mm | Cr: 52 kN | C0r: 105 kN
K120x127x34Fw: 120 mm | Ew: 127 mm | Bc: 34 mm | Cr: 82.2 kN | C0r: 260 kN
K125x133x35Fw: 125 mm | Ew: 133 mm | Bc: 35 mm | Cr: 87 kN | C0r: 260 kN
K125x135x34Fw: 125 mm | Ew: 135 mm | Bc: 34 mm | Cr: 100 kN | C0r: 265 kN
K130x137x24Fw: 130 mm | Ew: 137 mm | Bc: 24 mm | Cr: 59 kN | C0r: 175 kN
K130x137x34Fw: 130 mm | Ew: 137 mm | Bc: 34 mm | Cr: 84.5 kN | C0r: 277 kN
K135x143x35Fw: 135 mm | Ew: 143 mm | Bc: 35 mm | Cr: 92.5 kN | C0r: 288 kN
K135x150x38Fw: 135 mm | Ew: 150 mm | Bc: 38 mm | Cr: 145 kN | C0r: 325 kN
K145x153x26Fw: 145 mm | Ew: 153 mm | Bc: 26 mm | Cr: 72 kN | C0r: 214 kN
K145x153x28Fw: 145 mm | Ew: 153 mm | Bc: 28 mm | Cr: 80.5 kN | C0r: 247 kN
K145x153x36Fw: 145 mm | Ew: 153 mm | Bc: 36 mm | Cr: 100 kN | C0r: 325 kN
K150x160x46Fw: 150 mm | Ew: 160 mm | Bc: 46 mm | Cr: 149 kN | C0r: 470 kN
K155x163x26Fw: 155 mm | Ew: 163 mm | Bc: 26 mm | Cr: 73.5 kN | C0r: 224 kN
K155x163x36Fw: 155 mm | Ew: 163 mm | Bc: 36 mm | Cr: 102 kN | C0r: 340 kN
K160x170x46Fw: 160 mm | Ew: 170 mm | Bc: 46 mm | Cr: 155 kN | C0r: 505 kN
K165x173x26Fw: 165 mm | Ew: 173 mm | Bc: 26 mm | Cr: 79 kN | C0r: 251 kN
K165x173x32Fw: 165 mm | Ew: 173 mm | Bc: 32 mm | Cr: 97 kN | C0r: 330 kN
K165x173x36Fw: 165 mm | Ew: 173 mm | Bc: 36 mm | Cr: 109 kN | C0r: 380 kN
K170x180x46Fw: 170 mm | Ew: 180 mm | Bc: 46 mm | Cr: 160 kN | C0r: 540 kN
K175x183x32Fw: 175 mm | Ew: 183 mm | Bc: 32 mm | Cr: 101 kN | C0r: 350 kN
K185x195x37Fw: 185 mm | Ew: 195 mm | Bc: 37 mm | Cr: 131 kN | C0r: 425 kN
K195x205x37Fw: 195 mm | Ew: 205 mm | Bc: 37 mm | Cr: 135 kN | C0r: 450 kN
K210x220x42Fw: 210 mm | Ew: 220 mm | Bc: 42 mm | Cr: 156 kN | C0r: 560 kN
K220x230x42Fw: 220 mm | Ew: 230 mm | Bc: 42 mm | Cr: 161 kN | C0r: 590 kN
K240x250x42Fw: 240 mm | Ew: 250 mm | Bc: 42 mm | Cr: 167 kN | C0r: 635 kN
K265x280x50Fw: 265 mm | Ew: 280 mm | Bc: 50 mm | Cr: 256 kN | C0r: 850 kN
K285x300x50Fw: 285 mm | Ew: 300 mm | Bc: 50 mm | Cr: 268 kN | C0r: 930 kN

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Linear Motion & Bearings →
