NTN NU4 Series Cylindrical Roller Bearings (NU, NJ, NUP, N, NF)

NTN NU4 Series Cylindrical Roller Bearings (NU, NJ, NUP, N, NF)

NTN single-row cylindrical roller bearings of dimension series 4, bore 25-80 mm, in NU, NJ, NUP, N and NF configurations as listed.

Key features

  • High radial load capacity with line-contact rollers
  • NU/N: separable, free axial movement; NJ: one-direction axial location; NUP/NF: locating designs
  • E suffix: high-capacity internal design where listed
  • Mass shown for NU type

Specifications

Dimension series 4
Bearing type Single-row cylindrical roller bearing
Bore range 25-80 mm
Configurations NU, NJ, NUP, N, NF
Load rating unit kN
Source NTN NTN Ball and Roller Bearings catalogue, p. 56-59
NU405 d: 25 mm | D: 80 mm | B: 21 mm | Cr: 46.5 kN | C0r: 40 kN | Mass: 0.55 kg
NJ405 d: 25 mm | D: 80 mm | B: 21 mm | Cr: 46.5 kN | C0r: 40 kN | Mass: 0.55 kg
NUP405 d: 25 mm | D: 80 mm | B: 21 mm | Cr: 46.5 kN | C0r: 40 kN | Mass: 0.55 kg
N405 d: 25 mm | D: 80 mm | B: 21 mm | Cr: 46.5 kN | C0r: 40 kN | Mass: 0.55 kg
NF405 d: 25 mm | D: 80 mm | B: 21 mm | Cr: 46.5 kN | C0r: 40 kN | Mass: 0.55 kg
NU406 d: 30 mm | D: 90 mm | B: 23 mm | Cr: 62.5 kN | C0r: 55 kN | Mass: 0.751 kg
NJ406 d: 30 mm | D: 90 mm | B: 23 mm | Cr: 62.5 kN | C0r: 55 kN | Mass: 0.751 kg
NUP406 d: 30 mm | D: 90 mm | B: 23 mm | Cr: 62.5 kN | C0r: 55 kN | Mass: 0.751 kg
N406 d: 30 mm | D: 90 mm | B: 23 mm | Cr: 62.5 kN | C0r: 55 kN | Mass: 0.751 kg
NF406 d: 30 mm | D: 90 mm | B: 23 mm | Cr: 62.5 kN | C0r: 55 kN | Mass: 0.751 kg
NU407 d: 35 mm | D: 100 mm | B: 25 mm | Cr: 75.5 kN | C0r: 69 kN | Mass: 0.99 kg
NJ407 d: 35 mm | D: 100 mm | B: 25 mm | Cr: 75.5 kN | C0r: 69 kN | Mass: 0.99 kg
NUP407 d: 35 mm | D: 100 mm | B: 25 mm | Cr: 75.5 kN | C0r: 69 kN | Mass: 0.99 kg
N407 d: 35 mm | D: 100 mm | B: 25 mm | Cr: 75.5 kN | C0r: 69 kN | Mass: 0.99 kg
NF407 d: 35 mm | D: 100 mm | B: 25 mm | Cr: 75.5 kN | C0r: 69 kN | Mass: 0.99 kg
NU408 d: 40 mm | D: 110 mm | B: 27 mm | Cr: 95.5 kN | C0r: 89 kN | Mass: 1.3 kg
NJ408 d: 40 mm | D: 110 mm | B: 27 mm | Cr: 95.5 kN | C0r: 89 kN | Mass: 1.3 kg
NUP408 d: 40 mm | D: 110 mm | B: 27 mm | Cr: 95.5 kN | C0r: 89 kN | Mass: 1.3 kg
N408 d: 40 mm | D: 110 mm | B: 27 mm | Cr: 95.5 kN | C0r: 89 kN | Mass: 1.3 kg
NF408 d: 40 mm | D: 110 mm | B: 27 mm | Cr: 95.5 kN | C0r: 89 kN | Mass: 1.3 kg
NU409 d: 45 mm | D: 120 mm | B: 29 mm | Cr: 107 kN | C0r: 102 kN | Mass: 1.62 kg
NJ409 d: 45 mm | D: 120 mm | B: 29 mm | Cr: 107 kN | C0r: 102 kN | Mass: 1.62 kg
NUP409 d: 45 mm | D: 120 mm | B: 29 mm | Cr: 107 kN | C0r: 102 kN | Mass: 1.62 kg
N409 d: 45 mm | D: 120 mm | B: 29 mm | Cr: 107 kN | C0r: 102 kN | Mass: 1.62 kg
NF409 d: 45 mm | D: 120 mm | B: 29 mm | Cr: 107 kN | C0r: 102 kN | Mass: 1.62 kg
NU410 d: 50 mm | D: 130 mm | B: 31 mm | Cr: 129 kN | C0r: 124 kN | Mass: 2.02 kg
NJ410 d: 50 mm | D: 130 mm | B: 31 mm | Cr: 129 kN | C0r: 124 kN | Mass: 2.02 kg
NUP410 d: 50 mm | D: 130 mm | B: 31 mm | Cr: 129 kN | C0r: 124 kN | Mass: 2.02 kg
N410 d: 50 mm | D: 130 mm | B: 31 mm | Cr: 129 kN | C0r: 124 kN | Mass: 2.02 kg
NU411 d: 55 mm | D: 140 mm | B: 33 mm | Cr: 139 kN | C0r: 138 kN | Mass: 2.48 kg
NJ411 d: 55 mm | D: 140 mm | B: 33 mm | Cr: 139 kN | C0r: 138 kN | Mass: 2.48 kg
NUP411 d: 55 mm | D: 140 mm | B: 33 mm | Cr: 139 kN | C0r: 138 kN | Mass: 2.48 kg
N411 d: 55 mm | D: 140 mm | B: 33 mm | Cr: 139 kN | C0r: 138 kN | Mass: 2.48 kg
NU412 d: 60 mm | D: 150 mm | B: 35 mm | Cr: 167 kN | C0r: 168 kN | Mass: 3 kg
NJ412 d: 60 mm | D: 150 mm | B: 35 mm | Cr: 167 kN | C0r: 168 kN | Mass: 3 kg
NUP412 d: 60 mm | D: 150 mm | B: 35 mm | Cr: 167 kN | C0r: 168 kN | Mass: 3 kg
N412 d: 60 mm | D: 150 mm | B: 35 mm | Cr: 167 kN | C0r: 168 kN | Mass: 3 kg
NF412 d: 60 mm | D: 150 mm | B: 35 mm | Cr: 167 kN | C0r: 168 kN | Mass: 3 kg
NU413 d: 65 mm | D: 160 mm | B: 37 mm | Cr: 182 kN | C0r: 186 kN | Mass: 3.6 kg
NJ413 d: 65 mm | D: 160 mm | B: 37 mm | Cr: 182 kN | C0r: 186 kN | Mass: 3.6 kg
NUP413 d: 65 mm | D: 160 mm | B: 37 mm | Cr: 182 kN | C0r: 186 kN | Mass: 3.6 kg
N413 d: 65 mm | D: 160 mm | B: 37 mm | Cr: 182 kN | C0r: 186 kN | Mass: 3.6 kg
NF413 d: 65 mm | D: 160 mm | B: 37 mm | Cr: 182 kN | C0r: 186 kN | Mass: 3.6 kg
NU414 d: 70 mm | D: 180 mm | B: 42 mm | Cr: 228 kN | C0r: 236 kN | Mass: 5.24 kg
NJ414 d: 70 mm | D: 180 mm | B: 42 mm | Cr: 228 kN | C0r: 236 kN | Mass: 5.24 kg
NUP414 d: 70 mm | D: 180 mm | B: 42 mm | Cr: 228 kN | C0r: 236 kN | Mass: 5.24 kg
N414 d: 70 mm | D: 180 mm | B: 42 mm | Cr: 228 kN | C0r: 236 kN | Mass: 5.24 kg
NF414 d: 70 mm | D: 180 mm | B: 42 mm | Cr: 228 kN | C0r: 236 kN | Mass: 5.24 kg
NU415 d: 75 mm | D: 190 mm | B: 45 mm | Cr: 262 kN | C0r: 274 kN | Mass: 6.22 kg
NJ415 d: 75 mm | D: 190 mm | B: 45 mm | Cr: 262 kN | C0r: 274 kN | Mass: 6.22 kg
NUP415 d: 75 mm | D: 190 mm | B: 45 mm | Cr: 262 kN | C0r: 274 kN | Mass: 6.22 kg
N415 d: 75 mm | D: 190 mm | B: 45 mm | Cr: 262 kN | C0r: 274 kN | Mass: 6.22 kg
NF415 d: 75 mm | D: 190 mm | B: 45 mm | Cr: 262 kN | C0r: 274 kN | Mass: 6.22 kg
NU416 d: 80 mm | D: 200 mm | B: 48 mm | Cr: 299 kN | C0r: 315 kN | Mass: 7.32 kg
NJ416 d: 80 mm | D: 200 mm | B: 48 mm | Cr: 299 kN | C0r: 315 kN | Mass: 7.32 kg
NUP416 d: 80 mm | D: 200 mm | B: 48 mm | Cr: 299 kN | C0r: 315 kN | Mass: 7.32 kg
N416 d: 80 mm | D: 200 mm | B: 48 mm | Cr: 299 kN | C0r: 315 kN | Mass: 7.32 kg
NF416 d: 80 mm | D: 200 mm | B: 48 mm | Cr: 299 kN | C0r: 315 kN | Mass: 7.32 kg
