Samwon ACT R6T Series 6-Point 3-Common Economy Relay Terminals

Compact 6-point economy relay terminals with 3-point input/output commons, fitted with 5 mm Panasonic PA-N relays.

Key features

Ultra-compact 6-point relay terminal, 40.0 mm wide and 77.0 mm long
Economical type with 5 mm Panasonic PA-N relays. 3-point commons on input and output
Coil-side surge absorption diode prevents malfunction
Front PC cover protects parts and circuits; transparent window prevents terminal shorts
Contact LEDs; channel or screw mounting

Specifications

Material	Case: Modified PPO; Cover: Polycarbonate; PCB: Epoxy 1.6 t / 2 oz
Terminal Screw	M3 x 6L
Screw Torque	7-8 kgf.cm (0.68-0.78 N.m)
Operating Temperature	-10 to +50 C (no condensation)
Applicable Wire	AWG 22-16 (1.5 mm2 max.)
Points	6 (1a x 6)
Coil Rated Voltage	24 V DC
Relay	Panasonic APAN3124 (1 Form A, 5 A 250 V AC / 5 A 30 V DC)
Contact Common	3-point COM
Interface	Screw terminal, 7.62 mm pitch
Dimensions	40.0 x 77.0 mm (W x D)
Mounting	Screw / DIN rail (channel)

R6T-16P-A		Coil common: NPN (+COM)
R6T-16P-B		Coil common: PNP (-COM)
