Samwon ACT SFS4-SW-D24 / SFS6-SW-D24 Screw-Type Safety Relay Sockets

DIN-rail screw-terminal sockets with power LED and surge / reverse-voltage protection for PANASONIC SFS safety relays. 4-pole socket for SFS2 / SFS3 and 6-pole socket for SFS4 / SFS5 / SFS6 relays.

Key features

LED power indication
Built-in surge and reverse-voltage protection circuit
Screw terminals M3 x 7.5L

Specifications

Coil-Side Voltage	6-110 V DC
Rated Load	250 V AC, 6 A
Applicable Wire	AWG22-16 (1.5 mm2 max)
Terminal Screw	M3 x 7.5L
Screw Torque	1.0 N-m
Power Indicator	LED
Protection Circuit	Surge, reverse voltage
Ambient Temperature	-25 to +55 C
Approvals	cULus, CE

SFS4-SW-D24		Poles: 4 \| Relays: SFS2, SFS3 \| Dielectric Strength: 4,000 V AC (coil-contact) \| Weight: 49 g
SFS6-SW-D24		Poles: 6 \| Relays: SFS4, SFS5, SFS6 \| Dielectric Strength: 2,500 V AC (coil-contact) \| Weight: 63 g

Relay SocketsSamwon ACT

2 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Samwon ACT SFS4-SW-D24 / SFS6-SW-D24 Screw-Type Safety Relay Sockets

Brand Samwon ACT·Relay Sockets

Available part numbers (2)

SFS4-SW-D24, SFS6-SW-D24

How to order

Send the Samwon ACT part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	SFS4-SW-D24	Poles: 4 \| Relays: SFS2, SFS3 \| Dielectric Strength: 4,000 V AC (coil-contact) \| Weight: 49 g
	SFS6-SW-D24	Poles: 6 \| Relays: SFS4, SFS5, SFS6 \| Dielectric Strength: 2,500 V AC (coil-contact) \| Weight: 63 g
