Sanyo Denki San Ace 80 DC Axial Fan 80x80x25 mm (San Cooler)

Sanyo Denki San Ace 80 DC Axial Fan 80x80x25 mm (San Cooler)

The San Ace 80 San Cooler is a DC axial cooling fan in a 80x80x25 mm frame.

Key features

  • Models are offered for 12 and 24 V DC rated voltage
  • Rated speeds range from 1,850 to 4,500 min-1 with maximum air flow up to 1.5 m3/min and maximum static pressure up to 80.3 Pa
  • The frame is made of plastic
  • Expected life is rated as L10 (90% survival) at 60°C, rated voltage, continuous operation in free air

Specifications

Size 80x80x25 mm
Mass 90 g
9A0812G401 Size: 80x80x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.2 V | Rated current: 0.38 A | Rated input: 4.56 W | Speed: 4,500 min-1 | Max air flow: 1.5 m3/min (53.0 CFM) | Max static pressure: 80.3 Pa (0.323 inchH2O) | Noise: 40 dB(A) | Operating temperature: -10 to +60 °C | Expected life: 30,000 h | Mass: 90 g
9A0812S401 Size: 80x80x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.18 A | Rated input: 2.16 W | Speed: 3,400 min-1 | Max air flow: 1.2 m3/min (42.4 CFM) | Max static pressure: 48 Pa (0.193 inchH2O) | Noise: 34 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0812H401 Size: 80x80x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.13 A | Rated input: 1.56 W | Speed: 2,900 min-1 | Max air flow: 1.03 m3/min (36.4 CFM) | Max static pressure: 35.3 Pa (0.142 inchH2O) | Noise: 29 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0812F401 Size: 80x80x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.11 A | Rated input: 1.32 W | Speed: 2,600 min-1 | Max air flow: 0.92 m3/min (32.5 CFM) | Max static pressure: 28.4 Pa (0.114 inchH2O) | Noise: 26 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0812M401 Size: 80x80x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.09 A | Rated input: 1.08 W | Speed: 2,350 min-1 | Max air flow: 0.83 m3/min (29.3 CFM) | Max static pressure: 22.5 Pa (0.090 inchH2O) | Noise: 23 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0812L401 Size: 80x80x25 mm | Rated voltage: 12 V | Operating voltage range: 7 to 13.8 V | Rated current: 0.06 A | Rated input: 0.72 W | Speed: 1,850 min-1 | Max air flow: 0.65 m3/min (23.0 CFM) | Max static pressure: 14.7 Pa (0.059 inchH2O) | Noise: 20 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0824G401 Size: 80x80x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 26.4 V | Rated current: 0.21 A | Rated input: 5.04 W | Speed: 4,500 min-1 | Max air flow: 1.5 m3/min (53.0 CFM) | Max static pressure: 80.3 Pa (0.323 inchH2O) | Noise: 40 dB(A) | Operating temperature: -10 to +60 °C | Expected life: 30,000 h | Mass: 90 g
9A0824S401 Size: 80x80x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.1 A | Rated input: 2.4 W | Speed: 3,400 min-1 | Max air flow: 1.2 m3/min (42.4 CFM) | Max static pressure: 48 Pa (0.193 inchH2O) | Noise: 34 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0824H401 Size: 80x80x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.07 A | Rated input: 1.68 W | Speed: 2,900 min-1 | Max air flow: 1.03 m3/min (36.4 CFM) | Max static pressure: 35.3 Pa (0.142 inchH2O) | Noise: 29 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0824F401 Size: 80x80x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.06 A | Rated input: 1.44 W | Speed: 2,600 min-1 | Max air flow: 0.92 m3/min (32.5 CFM) | Max static pressure: 28.4 Pa (0.114 inchH2O) | Noise: 26 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0824M401 Size: 80x80x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.05 A | Rated input: 1.2 W | Speed: 2,350 min-1 | Max air flow: 0.83 m3/min (29.3 CFM) | Max static pressure: 22.5 Pa (0.090 inchH2O) | Noise: 23 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0824L401 Size: 80x80x25 mm | Rated voltage: 24 V | Operating voltage range: 14 to 27.6 V | Rated current: 0.04 A | Rated input: 0.96 W | Speed: 1,850 min-1 | Max air flow: 0.65 m3/min (23.0 CFM) | Max static pressure: 14.7 Pa (0.059 inchH2O) | Noise: 20 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
DC Axial FansSanyo Denki
12 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sanyo Denki San Ace 80 DC Axial Fan 80x80x25 mm (San Cooler)

Brand Sanyo Denki·DC Axial Fans

Available part numbers (12)

9A0812G401, 9A0812S401, 9A0812H401, 9A0812F401, 9A0812M401, 9A0812L401, 9A0824G401, 9A0824S401, 9A0824H401, 9A0824F401 + 2 more — see full table ↓

How to order

Send the Sanyo Denki part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
9A0812G401Size: 80x80x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.2 V | Rated current: 0.38 A | Rated input: 4.56 W | Speed: 4,500 min-1 | Max air flow: 1.5 m3/min (53.0 CFM) | Max static pressure: 80.3 Pa (0.323 inchH2O) | Noise: 40 dB(A) | Operating temperature: -10 to +60 °C | Expected life: 30,000 h | Mass: 90 g
9A0812S401Size: 80x80x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.18 A | Rated input: 2.16 W | Speed: 3,400 min-1 | Max air flow: 1.2 m3/min (42.4 CFM) | Max static pressure: 48 Pa (0.193 inchH2O) | Noise: 34 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0812H401Size: 80x80x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.13 A | Rated input: 1.56 W | Speed: 2,900 min-1 | Max air flow: 1.03 m3/min (36.4 CFM) | Max static pressure: 35.3 Pa (0.142 inchH2O) | Noise: 29 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0812F401Size: 80x80x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.11 A | Rated input: 1.32 W | Speed: 2,600 min-1 | Max air flow: 0.92 m3/min (32.5 CFM) | Max static pressure: 28.4 Pa (0.114 inchH2O) | Noise: 26 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0812M401Size: 80x80x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.09 A | Rated input: 1.08 W | Speed: 2,350 min-1 | Max air flow: 0.83 m3/min (29.3 CFM) | Max static pressure: 22.5 Pa (0.090 inchH2O) | Noise: 23 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0812L401Size: 80x80x25 mm | Rated voltage: 12 V | Operating voltage range: 7 to 13.8 V | Rated current: 0.06 A | Rated input: 0.72 W | Speed: 1,850 min-1 | Max air flow: 0.65 m3/min (23.0 CFM) | Max static pressure: 14.7 Pa (0.059 inchH2O) | Noise: 20 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0824G401Size: 80x80x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 26.4 V | Rated current: 0.21 A | Rated input: 5.04 W | Speed: 4,500 min-1 | Max air flow: 1.5 m3/min (53.0 CFM) | Max static pressure: 80.3 Pa (0.323 inchH2O) | Noise: 40 dB(A) | Operating temperature: -10 to +60 °C | Expected life: 30,000 h | Mass: 90 g
9A0824S401Size: 80x80x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.1 A | Rated input: 2.4 W | Speed: 3,400 min-1 | Max air flow: 1.2 m3/min (42.4 CFM) | Max static pressure: 48 Pa (0.193 inchH2O) | Noise: 34 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0824H401Size: 80x80x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.07 A | Rated input: 1.68 W | Speed: 2,900 min-1 | Max air flow: 1.03 m3/min (36.4 CFM) | Max static pressure: 35.3 Pa (0.142 inchH2O) | Noise: 29 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0824F401Size: 80x80x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.06 A | Rated input: 1.44 W | Speed: 2,600 min-1 | Max air flow: 0.92 m3/min (32.5 CFM) | Max static pressure: 28.4 Pa (0.114 inchH2O) | Noise: 26 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0824M401Size: 80x80x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.05 A | Rated input: 1.2 W | Speed: 2,350 min-1 | Max air flow: 0.83 m3/min (29.3 CFM) | Max static pressure: 22.5 Pa (0.090 inchH2O) | Noise: 23 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
9A0824L401Size: 80x80x25 mm | Rated voltage: 24 V | Operating voltage range: 14 to 27.6 V | Rated current: 0.04 A | Rated input: 0.96 W | Speed: 1,850 min-1 | Max air flow: 0.65 m3/min (23.0 CFM) | Max static pressure: 14.7 Pa (0.059 inchH2O) | Noise: 20 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 90 g
