SKF MS Locking Clips for HM Lock Nuts

SKF MS Locking Clips for HM Lock Nuts

SKF MS locking clips used to lock HM and HME lock nuts on large shafts, adapter sleeves and withdrawal sleeves.

Key features

  • Bolted to the lock nut face with a hexagon head screw and spring washer
  • Engages the slot of the sleeve or shaft keyway
  • Sized to match HM 30, HM 31 and other nut series
  • Catalogue lists the matching bolt and spring washer

Specifications

Product Locking clip
Use with HM / HME lock nuts
Source SKF General Catalogue 6000, p. 1018-1019
MS 3044 B: 20 mm | M: 12 mm | M1: 4 mm | Mass: 0.022 kg
MS 3052-48 B: 20 mm | M: 12 mm | M1: 4 mm | Mass: 0.024 kg
MS 3056 B: 24 mm | M: 12 mm | M1: 4 mm | Mass: 0.030 kg
MS 3060 B: 24 mm | M: 12 mm | M1: 4 mm | Mass: 0.033 kg
MS 3068-64 B: 24 mm | M: 15 mm | M1: 5 mm | Mass: 0.046 kg
MS 3072 B: 28 mm | M: 15 mm | M1: 5 mm | Mass: 0.051 kg
MS 3080-76 B: 28 mm | M: 15 mm | M1: 5 mm | Mass: 0.055 kg
MS 3084 B: 32 mm | M: 15 mm | M1: 5 mm | Mass: 0.063 kg
MS 3092-88 B: 32 mm | M: 15 mm | M1: 5 mm | Mass: 0.067 kg
MS 30/500-96 B: 36 mm | M: 15 mm | M1: 5 mm | Mass: 0.076 kg
MS 30/560 B: 40 mm | M: 21 mm | M1: 7 mm | Mass: 0.15 kg
MS 30/600-530 B: 40 mm | M: 21 mm | M1: 7 mm | Mass: 0.14 kg
MS 30/630 B: 45 mm | M: 21 mm | M1: 7 mm | Mass: 0.17 kg
MS 30/670 B: 45 mm | M: 21 mm | M1: 7 mm | Mass: 0.19 kg
MS 30/710 B: 50 mm | M: 21 mm | M1: 7 mm | Mass: 0.21 kg
MS 30/800-750 B: 55 mm | M: 21 mm | M1: 7 mm | Mass: 0.23 kg
MS 30/900-850 B: 60 mm | M: 21 mm | M1: 7 mm | Mass: 0.26 kg
MS 30/950 B: 60 mm | M: 21 mm | M1: 7 mm | Mass: 0.26 kg
MS 30/1000 B: 60 mm | M: 21 mm | M1: 7 mm | Mass: 0.28 kg
MS 3160 B: 24 mm | M: 12 mm | M1: 4 mm | Mass: 0.040 kg
MS 3164 B: 24 mm | M: 15 mm | M1: 5 mm | Mass: 0.055 kg
MS 3172-68 B: 28 mm | M: 15 mm | M1: 5 mm | Mass: 0.069 kg
MS 3176 B: 32 mm | M: 15 mm | M1: 5 mm | Mass: 0.083 kg
MS 3184-80 B: 32 mm | M: 15 mm | M1: 5 mm | Mass: 0.089 kg
MS 3192-88 B: 36 mm | M: 15 mm | M1: 5 mm | Mass: 0.097 kg
MS 3196 B: 36 mm | M: 15 mm | M1: 5 mm | Mass: 0.11 kg
MS 31/500 B: 40 mm | M: 15 mm | M1: 5 mm | Mass: 0.11 kg
MS 31/530 B: 40 mm | M: 21 mm | M1: 7 mm | Mass: 0.19 kg
MS 31/600-560 B: 45 mm | M: 21 mm | M1: 7 mm | Mass: 0.22 kg
MS 31/630 B: 50 mm | M: 21 mm | M1: 7 mm | Mass: 0.27 kg
MS 31/670 B: 50 mm | M: 21 mm | M1: 7 mm | Mass: 0.28 kg
MS 31/710 B: 55 mm | M: 21 mm | M1: 7 mm | Mass: 0.32 kg
MS 31/800-750 B: 60 mm | M: 21 mm | M1: 7 mm | Mass: 0.35 kg
MS 31/850 B: 70 mm | M: 21 mm | M1: 7 mm | Mass: 0.41 kg
MS 31/900 B: 70 mm | M: 21 mm | M1: 7 mm | Mass: 0.41 kg
MS 31/950 B: 70 mm | M: 21 mm | M1: 7 mm | Mass: 0.42 kg
MS 31/1000 B: 70 mm | M: 21 mm | M1: 7 mm | Mass: 0.50 kg
Lock Nuts & WashersSKF
37 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF MS Locking Clips for HM Lock Nuts

Brand SKF·Lock Nuts & Washers

Available part numbers (37)

MS 3044, MS 3052-48, MS 3056, MS 3060, MS 3068-64, MS 3072, MS 3080-76, MS 3084, MS 3092-88, MS 30/500-96 + 27 more — see full table ↓

How to order

Send the SKF part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MS 3044B: 20 mm | M: 12 mm | M1: 4 mm | Mass: 0.022 kg
MS 3052-48B: 20 mm | M: 12 mm | M1: 4 mm | Mass: 0.024 kg
MS 3056B: 24 mm | M: 12 mm | M1: 4 mm | Mass: 0.030 kg
MS 3060B: 24 mm | M: 12 mm | M1: 4 mm | Mass: 0.033 kg
MS 3068-64B: 24 mm | M: 15 mm | M1: 5 mm | Mass: 0.046 kg
MS 3072B: 28 mm | M: 15 mm | M1: 5 mm | Mass: 0.051 kg
MS 3080-76B: 28 mm | M: 15 mm | M1: 5 mm | Mass: 0.055 kg
MS 3084B: 32 mm | M: 15 mm | M1: 5 mm | Mass: 0.063 kg
MS 3092-88B: 32 mm | M: 15 mm | M1: 5 mm | Mass: 0.067 kg
MS 30/500-96B: 36 mm | M: 15 mm | M1: 5 mm | Mass: 0.076 kg
MS 30/560B: 40 mm | M: 21 mm | M1: 7 mm | Mass: 0.15 kg
MS 30/600-530B: 40 mm | M: 21 mm | M1: 7 mm | Mass: 0.14 kg
MS 30/630B: 45 mm | M: 21 mm | M1: 7 mm | Mass: 0.17 kg
MS 30/670B: 45 mm | M: 21 mm | M1: 7 mm | Mass: 0.19 kg
MS 30/710B: 50 mm | M: 21 mm | M1: 7 mm | Mass: 0.21 kg
MS 30/800-750B: 55 mm | M: 21 mm | M1: 7 mm | Mass: 0.23 kg
MS 30/900-850B: 60 mm | M: 21 mm | M1: 7 mm | Mass: 0.26 kg
MS 30/950B: 60 mm | M: 21 mm | M1: 7 mm | Mass: 0.26 kg
MS 30/1000B: 60 mm | M: 21 mm | M1: 7 mm | Mass: 0.28 kg
MS 3160B: 24 mm | M: 12 mm | M1: 4 mm | Mass: 0.040 kg
MS 3164B: 24 mm | M: 15 mm | M1: 5 mm | Mass: 0.055 kg
MS 3172-68B: 28 mm | M: 15 mm | M1: 5 mm | Mass: 0.069 kg
MS 3176B: 32 mm | M: 15 mm | M1: 5 mm | Mass: 0.083 kg
MS 3184-80B: 32 mm | M: 15 mm | M1: 5 mm | Mass: 0.089 kg
MS 3192-88B: 36 mm | M: 15 mm | M1: 5 mm | Mass: 0.097 kg
MS 3196B: 36 mm | M: 15 mm | M1: 5 mm | Mass: 0.11 kg
MS 31/500B: 40 mm | M: 15 mm | M1: 5 mm | Mass: 0.11 kg
MS 31/530B: 40 mm | M: 21 mm | M1: 7 mm | Mass: 0.19 kg
MS 31/600-560B: 45 mm | M: 21 mm | M1: 7 mm | Mass: 0.22 kg
MS 31/630B: 50 mm | M: 21 mm | M1: 7 mm | Mass: 0.27 kg
MS 31/670B: 50 mm | M: 21 mm | M1: 7 mm | Mass: 0.28 kg
MS 31/710B: 55 mm | M: 21 mm | M1: 7 mm | Mass: 0.32 kg
MS 31/800-750B: 60 mm | M: 21 mm | M1: 7 mm | Mass: 0.35 kg
MS 31/850B: 70 mm | M: 21 mm | M1: 7 mm | Mass: 0.41 kg
MS 31/900B: 70 mm | M: 21 mm | M1: 7 mm | Mass: 0.41 kg
MS 31/950B: 70 mm | M: 21 mm | M1: 7 mm | Mass: 0.42 kg
MS 31/1000B: 70 mm | M: 21 mm | M1: 7 mm | Mass: 0.50 kg
