SMC AF10-A Modular Air Filter (Size 10, M5, 5 µm)

SMC AF10-A Modular Air Filter (Size 10, M5, 5 µm)

SMC AF10-A miniature modular air filter with 5 µm filtration and M5 x 0.8 ports, for modular connection with AR10-A and AL10-A units.

Key features

  • 5 µm filtration in the smallest modular body size (10)
  • Float type auto drain N.C. (C) option; no drain discharge when unpressurised
  • Polycarbonate case standard; metal (2) or nylon (6) case as semi-standard
  • Replacement element AF10P-060S, case assembly C1SF-A
  • Made to order: long case (-X64, 9 cm³ drain capacity); right-to-left flow (R) and psi units (Z) semi-standard

Specifications

Fluid Air
Port size M5 x 0.8
Ambient and fluid temperature -5 to 60°C (no freezing)
Proof pressure 1.5 MPa
Max. operating pressure 1.0 MPa
Filtration rating 5 µm
Drain capacity 2.5 cm³
Mass 0.06 kg
Source SMC Korea catalog AC10-A series (SMCKR_AC-A.pdf), p. 9-12
AF10-M5-A Auto drain: None | Case: Polycarbonate
AF10-M5-2-A Auto drain: None | Case: Metal
AF10-M5-6-A Auto drain: None | Case: Nylon
AF10-M5C-A Auto drain: Float N.C. (C) | Case: Polycarbonate
AF10-M5C-2-A Auto drain: Float N.C. (C) | Case: Metal
AF10-M5C-6-A Auto drain: Float N.C. (C) | Case: Nylon
FiltersSMC
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AF10-A Modular Air Filter (Size 10, M5, 5 µm)

Brand SMC·Filters

Available part numbers (6)

AF10-M5-A, AF10-M5-2-A, AF10-M5-6-A, AF10-M5C-A, AF10-M5C-2-A, AF10-M5C-6-A
