SMC AK1000 General Gas Regulator (Single-Stage, Low-Medium Flow)

SMC AK1000 General Gas Regulator (Single-Stage, Low-Medium Flow)

SMC AK1000 series single-stage general gas regulator in stainless steel or brass for low to medium flow, inlet up to 24.1 MPa.

Key features

  • Stainless steel (SUS316) or brass body for general and specialty gases; Ni-Cr-Mo internals available for corrosive gases
  • Inlet up to 3500 psig (24.1 MPa) (AK1001: 2.1 MPa); flow below 30 slpm, HF option below 120 slpm
  • Eight set pressure ranges from 0.0034-0.07 MPa up to 0.07-3.4 MPa
  • NPT1/4 female, 1/4 or 3/8 compression fitting connections
  • 2P, 3P, 4P bodies (stainless) and 4PL, 5PC bodies (stainless or brass)
  • Listed codes: gauge ports "0" (NPT1/4 port, no gauge); gauges (V3 to 40), plug C, MPA scale, VS/PK/TF seat and panel mount (P) are ordered as suffixes

Specifications

Fluid Gases that do not corrode wetted parts
External leakage 1x10^-10 Pa m3/s
Ambient and fluid temperature -40 to 71 C (no freezing)
Port connection NPT female thread or compression fitting
Proof pressure (inlet) 4500 psig (30.7 MPa)
Pressure characteristic 0.0026 MPa rise per 0.7 MPa inlet drop
Internal volume 8 cm3
Mass 1.09 kg
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP_SL_AZ_AK_BP.pdf), p. 710-711
AK1001B4PL4400 Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1001B4PL4T4T00 Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1001B4PL6T6T00 Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1001B5PC44000 Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1001B5PC4T4T000 Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1001B5PC6T6T000 Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1001S2P44 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1001S2P4T4T Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1001S2P6T6T Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1001S3P440 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1001S3P4T4T0 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1001S3P6T6T0 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1001S4P4400 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1001S4P4T4T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1001S4P6T6T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1001S4PL4400 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1001S4PL4T4T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1001S4PL6T6T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1001S5PC44000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1001S5PC4T4T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1001S5PC6T6T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1001SH2P44 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1001SH2P4T4T Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1001SH2P6T6T Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1001SH3P440 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1001SH3P4T4T0 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1001SH3P6T6T0 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1001SH4P4400 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1001SH4P4T4T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1001SH4P6T6T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1001SH4PL4400 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1001SH4PL4T4T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1001SH4PL6T6T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1001SH5PC44000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1001SH5PC4T4T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1001SH5PC6T6T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1002B4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1002B4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1002B4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1002B5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1002B5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1002B5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1002S2P44 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1002S2P4T4T Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1002S2P6T6T Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1002S3P440 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1002S3P4T4T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1002S3P6T6T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1002S4P4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1002S4P4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1002S4P6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1002S4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1002S4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1002S4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1002S5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1002S5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1002S5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1002SH2P44 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1002SH2P4T4T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1002SH2P6T6T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1002SH3P440 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1002SH3P4T4T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1002SH3P6T6T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1002SH4P4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1002SH4P4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1002SH4P6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1002SH4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1002SH4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1002SH4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1002SH5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1002SH5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1002SH5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1006B4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1006B4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1006B4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1006B5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1006B5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1006B5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1006S2P44 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1006S2P4T4T Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1006S2P6T6T Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1006S3P440 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1006S3P4T4T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1006S3P6T6T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1006S4P4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1006S4P4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1006S4P6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1006S4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1006S4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1006S4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1006S5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1006S5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1006S5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1006SH2P44 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1006SH2P4T4T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1006SH2P6T6T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1006SH3P440 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1006SH3P4T4T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1006SH3P6T6T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1006SH4P4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1006SH4P4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1006SH4P6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1006SH4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1006SH4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1006SH4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1006SH5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1006SH5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1006SH5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1010B4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1010B4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1010B4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1010B5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1010B5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1010B5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1010S2P44 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1010S2P4T4T Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1010S2P6T6T Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1010S3P440 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1010S3P4T4T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1010S3P6T6T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1010S4P4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1010S4P4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1010S4P6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1010S4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1010S4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1010S4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1010S5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1010S5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1010S5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1010SH2P44 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1010SH2P4T4T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1010SH2P6T6T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1010SH3P440 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1010SH3P4T4T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1010SH3P6T6T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1010SH4P4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1010SH4P4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1010SH4P6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1010SH4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1010SH4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1010SH4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1010SH5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1010SH5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1010SH5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1015B4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1015B4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1015B4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1015B5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1015B5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1015B5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1015S2P44 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1015S2P4T4T Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1015S2P6T6T Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1015S3P440 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1015S3P4T4T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1015S3P6T6T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1015S4P4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1015S4P4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1015S4P6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1015S4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1015S4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1015S4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1015S5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1015S5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1015S5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1015SH2P44 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1015SH2P4T4T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1015SH2P6T6T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1015SH3P440 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1015SH3P4T4T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1015SH3P6T6T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1015SH4P4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1015SH4P4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1015SH4P6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1015SH4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1015SH4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1015SH4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1015SH5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1015SH5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1015SH5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1020B4PL4400 Set pressure: 0.034 to 1.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1020B4PL4T4T00 Set pressure: 0.034 to 1.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1020B4PL6T6T00 Set pressure: 0.034 to 1.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1020B5PC44000 Set pressure: 0.034 to 1.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1020B5PC4T4T000 Set pressure: 0.034 to 1.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1020B5PC6T6T000 Set pressure: 0.034 to 1.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1020S2P44 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1020S2P4T4T Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1020S2P6T6T Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1020S3P440 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1020S3P4T4T0 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1020S3P6T6T0 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1020S4P4400 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1020S4P4T4T00 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1020S4P6T6T00 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1020S4PL4400 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1020S4PL4T4T00 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1020S4PL6T6T00 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1020S5PC44000 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1020S5PC4T4T000 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1020S5PC6T6T000 Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1020SH2P44 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1020SH2P4T4T Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1020SH2P6T6T Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1020SH3P440 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1020SH3P4T4T0 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1020SH3P6T6T0 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1020SH4P4400 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1020SH4P4T4T00 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1020SH4P6T6T00 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1020SH4PL4400 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1020SH4PL4T4T00 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1020SH4PL6T6T00 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1020SH5PC44000 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1020SH5PC4T4T000 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1020SH5PC6T6T000 Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1030B4PL4400 Set pressure: 0.034 to 2.1 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1030B4PL4T4T00 Set pressure: 0.034 to 2.1 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1030B4PL6T6T00 Set pressure: 0.034 to 2.1 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1030B5PC44000 Set pressure: 0.034 to 2.1 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1030B5PC4T4T000 Set pressure: 0.034 to 2.1 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1030B5PC6T6T000 Set pressure: 0.034 to 2.1 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1030S2P44 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1030S2P4T4T Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1030S2P6T6T Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1030S3P440 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1030S3P4T4T0 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1030S3P6T6T0 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1030S4P4400 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1030S4P4T4T00 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1030S4P6T6T00 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1030S4PL4400 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1030S4PL4T4T00 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1030S4PL6T6T00 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1030S5PC44000 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1030S5PC4T4T000 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1030S5PC6T6T000 Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1030SH2P44 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1030SH2P4T4T Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1030SH2P6T6T Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1030SH3P440 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1030SH3P4T4T0 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1030SH3P6T6T0 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1030SH4P4400 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1030SH4P4T4T00 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1030SH4P6T6T00 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1030SH4PL4400 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1030SH4PL4T4T00 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1030SH4PL6T6T00 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1030SH5PC44000 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1030SH5PC4T4T000 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1030SH5PC6T6T000 Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1050B4PL4400 Set pressure: 0.07 to 3.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1050B4PL4T4T00 Set pressure: 0.07 to 3.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1050B4PL6T6T00 Set pressure: 0.07 to 3.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1050B5PC44000 Set pressure: 0.07 to 3.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1050B5PC4T4T000 Set pressure: 0.07 to 3.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1050B5PC6T6T000 Set pressure: 0.07 to 3.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1050S2P44 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1050S2P4T4T Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1050S2P6T6T Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1050S3P440 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1050S3P4T4T0 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1050S3P6T6T0 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1050S4P4400 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1050S4P4T4T00 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1050S4P6T6T00 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1050S4PL4400 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1050S4PL4T4T00 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1050S4PL6T6T00 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1050S5PC44000 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1050S5PC4T4T000 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1050S5PC6T6T000 Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1050SH2P44 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1050SH2P4T4T Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1050SH2P6T6T Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1050SH3P440 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1050SH3P4T4T0 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1050SH3P6T6T0 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1050SH4P4400 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1050SH4P4T4T00 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1050SH4P6T6T00 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1050SH4PL4400 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1050SH4PL4T4T00 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1050SH4PL6T6T00 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1050SH5PC44000 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1050SH5PC4T4T000 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1050SH5PC6T6T000 Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
RegulatorsSMC
288 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AK1000 General Gas Regulator (Single-Stage, Low-Medium Flow)

Brand SMC·Regulators

Available part numbers (288)

AK1001B4PL4400, AK1001B4PL4T4T00, AK1001B4PL6T6T00, AK1001B5PC44000, AK1001B5PC4T4T000, AK1001B5PC6T6T000, AK1001S2P44, AK1001S2P4T4T, AK1001S2P6T6T, AK1001S3P440 + 278 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AK1001B4PL4400Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1001B4PL4T4T00Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1001B4PL6T6T00Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1001B5PC44000Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1001B5PC4T4T000Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1001B5PC6T6T000Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1001S2P44Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1001S2P4T4TSet pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1001S2P6T6TSet pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1001S3P440Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1001S3P4T4T0Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1001S3P6T6T0Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1001S4P4400Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1001S4P4T4T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1001S4P6T6T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1001S4PL4400Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1001S4PL4T4T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1001S4PL6T6T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1001S5PC44000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1001S5PC4T4T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1001S5PC6T6T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1001SH2P44Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1001SH2P4T4TSet pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1001SH2P6T6TSet pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1001SH3P440Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1001SH3P4T4T0Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1001SH3P6T6T0Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1001SH4P4400Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1001SH4P4T4T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1001SH4P6T6T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1001SH4PL4400Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1001SH4PL4T4T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1001SH4PL6T6T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1001SH5PC44000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1001SH5PC4T4T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1001SH5PC6T6T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1002B4PL4400Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1002B4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1002B4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1002B5PC44000Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1002B5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1002B5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1002S2P44Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1002S2P4T4TSet pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1002S2P6T6TSet pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1002S3P440Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1002S3P4T4T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1002S3P6T6T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1002S4P4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1002S4P4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1002S4P6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1002S4PL4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1002S4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1002S4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1002S5PC44000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1002S5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1002S5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1002SH2P44Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1002SH2P4T4TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1002SH2P6T6TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1002SH3P440Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1002SH3P4T4T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1002SH3P6T6T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1002SH4P4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1002SH4P4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1002SH4P6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1002SH4PL4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1002SH4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1002SH4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1002SH5PC44000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1002SH5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1002SH5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1006B4PL4400Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1006B4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1006B4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1006B5PC44000Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1006B5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1006B5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1006S2P44Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1006S2P4T4TSet pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1006S2P6T6TSet pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1006S3P440Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1006S3P4T4T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1006S3P6T6T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1006S4P4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1006S4P4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1006S4P6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1006S4PL4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1006S4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1006S4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1006S5PC44000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1006S5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1006S5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1006SH2P44Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1006SH2P4T4TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1006SH2P6T6TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1006SH3P440Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1006SH3P4T4T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1006SH3P6T6T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1006SH4P4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1006SH4P4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1006SH4P6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1006SH4PL4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1006SH4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1006SH4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1006SH5PC44000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1006SH5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1006SH5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1010B4PL4400Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1010B4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1010B4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1010B5PC44000Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1010B5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1010B5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1010S2P44Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1010S2P4T4TSet pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1010S2P6T6TSet pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1010S3P440Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1010S3P4T4T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1010S3P6T6T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1010S4P4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1010S4P4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1010S4P6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1010S4PL4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1010S4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1010S4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1010S5PC44000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1010S5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1010S5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1010SH2P44Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1010SH2P4T4TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1010SH2P6T6TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1010SH3P440Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1010SH3P4T4T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1010SH3P6T6T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1010SH4P4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1010SH4P4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1010SH4P6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1010SH4PL4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1010SH4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1010SH4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1010SH5PC44000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1010SH5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1010SH5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1015B4PL4400Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1015B4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1015B4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1015B5PC44000Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1015B5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1015B5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1015S2P44Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1015S2P4T4TSet pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1015S2P6T6TSet pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1015S3P440Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1015S3P4T4T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1015S3P6T6T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1015S4P4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1015S4P4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1015S4P6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1015S4PL4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1015S4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1015S4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1015S5PC44000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1015S5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1015S5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1015SH2P44Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1015SH2P4T4TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1015SH2P6T6TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1015SH3P440Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1015SH3P4T4T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1015SH3P6T6T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1015SH4P4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1015SH4P4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1015SH4P6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1015SH4PL4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1015SH4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1015SH4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1015SH5PC44000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1015SH5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1015SH5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1020B4PL4400Set pressure: 0.034 to 1.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1020B4PL4T4T00Set pressure: 0.034 to 1.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1020B4PL6T6T00Set pressure: 0.034 to 1.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1020B5PC44000Set pressure: 0.034 to 1.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1020B5PC4T4T000Set pressure: 0.034 to 1.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1020B5PC6T6T000Set pressure: 0.034 to 1.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1020S2P44Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1020S2P4T4TSet pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1020S2P6T6TSet pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1020S3P440Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1020S3P4T4T0Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1020S3P6T6T0Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1020S4P4400Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1020S4P4T4T00Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1020S4P6T6T00Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1020S4PL4400Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1020S4PL4T4T00Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1020S4PL6T6T00Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1020S5PC44000Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1020S5PC4T4T000Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1020S5PC6T6T000Set pressure: 0.034 to 1.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1020SH2P44Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1020SH2P4T4TSet pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1020SH2P6T6TSet pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1020SH3P440Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1020SH3P4T4T0Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1020SH3P6T6T0Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1020SH4P4400Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1020SH4P4T4T00Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1020SH4P6T6T00Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1020SH4PL4400Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1020SH4PL4T4T00Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1020SH4PL6T6T00Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1020SH5PC44000Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1020SH5PC4T4T000Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1020SH5PC6T6T000Set pressure: 0.034 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1030B4PL4400Set pressure: 0.034 to 2.1 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1030B4PL4T4T00Set pressure: 0.034 to 2.1 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1030B4PL6T6T00Set pressure: 0.034 to 2.1 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1030B5PC44000Set pressure: 0.034 to 2.1 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1030B5PC4T4T000Set pressure: 0.034 to 2.1 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1030B5PC6T6T000Set pressure: 0.034 to 2.1 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1030S2P44Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1030S2P4T4TSet pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1030S2P6T6TSet pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1030S3P440Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1030S3P4T4T0Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1030S3P6T6T0Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1030S4P4400Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1030S4P4T4T00Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1030S4P6T6T00Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1030S4PL4400Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1030S4PL4T4T00Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1030S4PL6T6T00Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1030S5PC44000Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1030S5PC4T4T000Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1030S5PC6T6T000Set pressure: 0.034 to 2.1 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1030SH2P44Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1030SH2P4T4TSet pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1030SH2P6T6TSet pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1030SH3P440Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1030SH3P4T4T0Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1030SH3P6T6T0Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1030SH4P4400Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1030SH4P4T4T00Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1030SH4P6T6T00Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1030SH4PL4400Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1030SH4PL4T4T00Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1030SH4PL6T6T00Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1030SH5PC44000Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1030SH5PC4T4T000Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1030SH5PC6T6T000Set pressure: 0.034 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1050B4PL4400Set pressure: 0.07 to 3.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1050B4PL4T4T00Set pressure: 0.07 to 3.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1050B4PL6T6T00Set pressure: 0.07 to 3.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1050B5PC44000Set pressure: 0.07 to 3.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1050B5PC4T4T000Set pressure: 0.07 to 3.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1050B5PC6T6T000Set pressure: 0.07 to 3.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1050S2P44Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1050S2P4T4TSet pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1050S2P6T6TSet pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1050S3P440Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1050S3P4T4T0Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1050S3P6T6T0Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1050S4P4400Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1050S4P4T4T00Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1050S4P6T6T00Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1050S4PL4400Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1050S4PL4T4T00Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1050S4PL6T6T00Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1050S5PC44000Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1050S5PC4T4T000Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1050S5PC6T6T000Set pressure: 0.07 to 3.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1050SH2P44Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1050SH2P4T4TSet pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1050SH2P6T6TSet pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1050SH3P440Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1050SH3P4T4T0Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1050SH3P6T6T0Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1050SH4P4400Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: NPT1/4 female
AK1050SH4P4T4T00Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 compression fitting
AK1050SH4P6T6T00Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 compression fitting
AK1050SH4PL4400Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1050SH4PL4T4T00Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1050SH4PL6T6T00Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1050SH5PC44000Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1050SH5PC4T4T000Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1050SH5PC6T6T000Set pressure: 0.07 to 3.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
