SMC AK1000T General Gas Regulator (SUS316, Inlet up to 24.1 MPa)

SMC AK1000T General Gas Regulator (SUS316, Inlet up to 24.1 MPa)

SMC AK1000T series compact SUS316 diaphragm gas regulator for semiconductor to general industrial gases, accepting inlet pressure up to 24.1 MPa with low to medium flow (<120 L/min nor).

Key features

  • Inlet pressure up to 3500 psig (24.1 MPa); five set pressure ranges up to 1.0 MPa
  • Wetted parts SUS316 with PCTFE seat (polyimide VS on order); Ni-Cr-Mo alloy poppet and diaphragm (SHP) for corrosive gases
  • Small internal volume reduces gas retention; passivated, precision cleaned, oil-free; external leakage 1x10^-10 Pa m3/s
  • 4-port (4PL) or 5-port (5PC) bodies with NPT1/4, Rc1/4 or 1/4 / 3/8 compression fittings
  • Listed codes have gauge ports plugged without gauge (0); gauge-assembled versions (V15 to 40, MPA scale), plug C, VS seat and bracket ordered separately

Specifications

Fluid Gases compatible with wetted materials
Inlet pressure Vacuum to 3500 psig (24.1 MPa)
Proof pressure 4500 psig (30.7 MPa)
Burst pressure 10000 psig (69 MPa)
Ambient and fluid temperature -40 to 71 C (no freezing)
External leakage 1x10^-10 Pa m3/s
Pressure characteristic Approx. 1.2 psig (0.008 MPa) rise per 100 psig (0.7 MPa) inlet drop
Internal volume 4.8 cm3
Mass 0.52 kg
Height 97.5 mm
Source SMC Korea catalog AK1000T (SMCKR_AK1000T.pdf), p. 819-823
AK1001TS4PL4400 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1001TS4PL44T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1001TS4PL46T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1001TS4PL4T400 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1001TS4PL4T4T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1001TS4PL4T6T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1001TS4PL6T400 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1001TS4PL6T4T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1001TS4PL6T6T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1001TS4PL4BR4BR00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1001TS5PC44000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1001TS5PC44T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1001TS5PC46T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1001TS5PC4T4000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1001TS5PC4T4T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1001TS5PC4T6T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1001TS5PC6T4000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1001TS5PC6T4T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1001TS5PC6T6T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1001TSHP4PL4400 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1001TSHP4PL44T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1001TSHP4PL46T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1001TSHP4PL4T400 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1001TSHP4PL4T4T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1001TSHP4PL4T6T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1001TSHP4PL6T400 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1001TSHP4PL6T4T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1001TSHP4PL6T6T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1001TSHP4PL4BR4BR00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1001TSHP5PC44000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1001TSHP5PC44T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1001TSHP5PC46T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1001TSHP5PC4T4000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1001TSHP5PC4T4T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1001TSHP5PC4T6T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1001TSHP5PC6T4000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1001TSHP5PC6T4T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1001TSHP5PC6T6T000 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1002TS4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1002TS4PL44T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1002TS4PL46T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1002TS4PL4T400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1002TS4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1002TS4PL4T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1002TS4PL6T400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1002TS4PL6T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1002TS4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1002TS4PL4BR4BR00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1002TS5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1002TS5PC44T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1002TS5PC46T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1002TS5PC4T4000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1002TS5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1002TS5PC4T6T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1002TS5PC6T4000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1002TS5PC6T4T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1002TS5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1002TSHP4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1002TSHP4PL44T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1002TSHP4PL46T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1002TSHP4PL4T400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1002TSHP4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1002TSHP4PL4T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1002TSHP4PL6T400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1002TSHP4PL6T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1002TSHP4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1002TSHP4PL4BR4BR00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1002TSHP5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1002TSHP5PC44T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1002TSHP5PC46T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1002TSHP5PC4T4000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1002TSHP5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1002TSHP5PC4T6T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1002TSHP5PC6T4000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1002TSHP5PC6T4T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1002TSHP5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1006TS4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1006TS4PL44T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1006TS4PL46T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1006TS4PL4T400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1006TS4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1006TS4PL4T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1006TS4PL6T400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1006TS4PL6T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1006TS4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1006TS4PL4BR4BR00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1006TS5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1006TS5PC44T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1006TS5PC46T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1006TS5PC4T4000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1006TS5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1006TS5PC4T6T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1006TS5PC6T4000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1006TS5PC6T4T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1006TS5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1006TSHP4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1006TSHP4PL44T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1006TSHP4PL46T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1006TSHP4PL4T400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1006TSHP4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1006TSHP4PL4T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1006TSHP4PL6T400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1006TSHP4PL6T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1006TSHP4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1006TSHP4PL4BR4BR00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1006TSHP5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1006TSHP5PC44T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1006TSHP5PC46T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1006TSHP5PC4T4000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1006TSHP5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1006TSHP5PC4T6T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1006TSHP5PC6T4000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1006TSHP5PC6T4T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1006TSHP5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1010TS4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1010TS4PL44T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1010TS4PL46T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1010TS4PL4T400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1010TS4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1010TS4PL4T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1010TS4PL6T400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1010TS4PL6T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1010TS4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1010TS4PL4BR4BR00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1010TS5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1010TS5PC44T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1010TS5PC46T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1010TS5PC4T4000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1010TS5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1010TS5PC4T6T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1010TS5PC6T4000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1010TS5PC6T4T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1010TS5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1010TSHP4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1010TSHP4PL44T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1010TSHP4PL46T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1010TSHP4PL4T400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1010TSHP4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1010TSHP4PL4T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1010TSHP4PL6T400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1010TSHP4PL6T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1010TSHP4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1010TSHP4PL4BR4BR00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1010TSHP5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1010TSHP5PC44T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1010TSHP5PC46T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1010TSHP5PC4T4000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1010TSHP5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1010TSHP5PC4T6T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1010TSHP5PC6T4000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1010TSHP5PC6T4T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1010TSHP5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1015TS4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1015TS4PL44T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1015TS4PL46T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1015TS4PL4T400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1015TS4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1015TS4PL4T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1015TS4PL6T400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1015TS4PL6T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1015TS4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1015TS4PL4BR4BR00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1015TS5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1015TS5PC44T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1015TS5PC46T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1015TS5PC4T4000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1015TS5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1015TS5PC4T6T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1015TS5PC6T4000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1015TS5PC6T4T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1015TS5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1015TSHP4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1015TSHP4PL44T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1015TSHP4PL46T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1015TSHP4PL4T400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1015TSHP4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1015TSHP4PL4T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1015TSHP4PL6T400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1015TSHP4PL6T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1015TSHP4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1015TSHP4PL4BR4BR00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1015TSHP5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1015TSHP5PC44T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1015TSHP5PC46T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1015TSHP5PC4T4000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1015TSHP5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1015TSHP5PC4T6T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1015TSHP5PC6T4000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1015TSHP5PC6T4T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1015TSHP5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
RegulatorsSMC
190 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AK1000T General Gas Regulator (SUS316, Inlet up to 24.1 MPa)

Brand SMC·Regulators

Available part numbers (190)

AK1001TS4PL4400, AK1001TS4PL44T00, AK1001TS4PL46T00, AK1001TS4PL4T400, AK1001TS4PL4T4T00, AK1001TS4PL4T6T00, AK1001TS4PL6T400, AK1001TS4PL6T4T00, AK1001TS4PL6T6T00, AK1001TS4PL4BR4BR00 + 180 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AK1001TS4PL4400Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1001TS4PL44T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1001TS4PL46T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1001TS4PL4T400Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1001TS4PL4T4T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1001TS4PL4T6T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1001TS4PL6T400Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1001TS4PL6T4T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1001TS4PL6T6T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1001TS4PL4BR4BR00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1001TS5PC44000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1001TS5PC44T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1001TS5PC46T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1001TS5PC4T4000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1001TS5PC4T4T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1001TS5PC4T6T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1001TS5PC6T4000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1001TS5PC6T4T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1001TS5PC6T6T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1001TSHP4PL4400Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1001TSHP4PL44T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1001TSHP4PL46T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1001TSHP4PL4T400Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1001TSHP4PL4T4T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1001TSHP4PL4T6T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1001TSHP4PL6T400Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1001TSHP4PL6T4T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1001TSHP4PL6T6T00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1001TSHP4PL4BR4BR00Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1001TSHP5PC44000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1001TSHP5PC44T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1001TSHP5PC46T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1001TSHP5PC4T4000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1001TSHP5PC4T4T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1001TSHP5PC4T6T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1001TSHP5PC6T4000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1001TSHP5PC6T4T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1001TSHP5PC6T6T000Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1002TS4PL4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1002TS4PL44T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1002TS4PL46T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1002TS4PL4T400Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1002TS4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1002TS4PL4T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1002TS4PL6T400Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1002TS4PL6T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1002TS4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1002TS4PL4BR4BR00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1002TS5PC44000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1002TS5PC44T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1002TS5PC46T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1002TS5PC4T4000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1002TS5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1002TS5PC4T6T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1002TS5PC6T4000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1002TS5PC6T4T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1002TS5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1002TSHP4PL4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1002TSHP4PL44T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1002TSHP4PL46T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1002TSHP4PL4T400Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1002TSHP4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1002TSHP4PL4T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1002TSHP4PL6T400Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1002TSHP4PL6T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1002TSHP4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1002TSHP4PL4BR4BR00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1002TSHP5PC44000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1002TSHP5PC44T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1002TSHP5PC46T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1002TSHP5PC4T4000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1002TSHP5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1002TSHP5PC4T6T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1002TSHP5PC6T4000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1002TSHP5PC6T4T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1002TSHP5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1006TS4PL4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1006TS4PL44T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1006TS4PL46T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1006TS4PL4T400Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1006TS4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1006TS4PL4T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1006TS4PL6T400Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1006TS4PL6T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1006TS4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1006TS4PL4BR4BR00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1006TS5PC44000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1006TS5PC44T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1006TS5PC46T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1006TS5PC4T4000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1006TS5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1006TS5PC4T6T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1006TS5PC6T4000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1006TS5PC6T4T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1006TS5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1006TSHP4PL4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1006TSHP4PL44T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1006TSHP4PL46T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1006TSHP4PL4T400Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1006TSHP4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1006TSHP4PL4T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1006TSHP4PL6T400Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1006TSHP4PL6T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1006TSHP4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1006TSHP4PL4BR4BR00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1006TSHP5PC44000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1006TSHP5PC44T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1006TSHP5PC46T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1006TSHP5PC4T4000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1006TSHP5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1006TSHP5PC4T6T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1006TSHP5PC6T4000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1006TSHP5PC6T4T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1006TSHP5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1010TS4PL4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1010TS4PL44T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1010TS4PL46T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1010TS4PL4T400Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1010TS4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1010TS4PL4T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1010TS4PL6T400Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1010TS4PL6T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1010TS4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1010TS4PL4BR4BR00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1010TS5PC44000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1010TS5PC44T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1010TS5PC46T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1010TS5PC4T4000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1010TS5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1010TS5PC4T6T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1010TS5PC6T4000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1010TS5PC6T4T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1010TS5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1010TSHP4PL4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1010TSHP4PL44T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1010TSHP4PL46T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1010TSHP4PL4T400Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1010TSHP4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1010TSHP4PL4T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1010TSHP4PL6T400Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1010TSHP4PL6T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1010TSHP4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1010TSHP4PL4BR4BR00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1010TSHP5PC44000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1010TSHP5PC44T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1010TSHP5PC46T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1010TSHP5PC4T4000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1010TSHP5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1010TSHP5PC4T6T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1010TSHP5PC6T4000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1010TSHP5PC6T4T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1010TSHP5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1015TS4PL4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1015TS4PL44T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1015TS4PL46T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1015TS4PL4T400Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1015TS4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1015TS4PL4T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1015TS4PL6T400Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1015TS4PL6T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1015TS4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1015TS4PL4BR4BR00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1015TS5PC44000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1015TS5PC44T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1015TS5PC46T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1015TS5PC4T4000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1015TS5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1015TS5PC4T6T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1015TS5PC6T4000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1015TS5PC6T4T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1015TS5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1015TSHP4PL4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1015TSHP4PL44T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1015TSHP4PL46T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1015TSHP4PL4T400Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1015TSHP4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1015TSHP4PL4T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1015TSHP4PL6T400Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1015TSHP4PL6T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1015TSHP4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: 3/8 compression | Outlet: 3/8 compression
AK1015TSHP4PL4BR4BR00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 4 ports | Inlet: Rc1/4 | Outlet: Rc1/4
AK1015TSHP5PC44000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: NPT1/4
AK1015TSHP5PC44T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 1/4 compression
AK1015TSHP5PC46T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: NPT1/4 | Outlet: 3/8 compression
AK1015TSHP5PC4T4000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: NPT1/4
AK1015TSHP5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 1/4 compression
AK1015TSHP5PC4T6T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 1/4 compression | Outlet: 3/8 compression
AK1015TSHP5PC6T4000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: NPT1/4
AK1015TSHP5PC6T4T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 1/4 compression
AK1015TSHP5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 / Ni-Cr-Mo alloy | Ports: 5 ports | Inlet: 3/8 compression | Outlet: 3/8 compression

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
