SMC AK1200 General Gas Regulator (High Flow, Tied Diaphragm)

SMC AK1200 General Gas Regulator (High Flow, Tied Diaphragm)

SMC AK1200 series single-stage tied-diaphragm general gas regulator in stainless steel or brass for high flow (below 800 slpm), inlet up to 11.7 MPa.

Key features

  • Stainless steel (SUS316) or brass body for general and specialty gases; Ni-Cr-Mo internals available for corrosive gases
  • Inlet up to 1700 psig (11.7 MPa), HR option 3000 psig (20.7 MPa); flow below 800 slpm, HF below 1000 slpm, FC below 1500 slpm
  • Set pressure 0.007-0.2 MPa up to 1.7 MPa (AK1225)
  • NPT1/4 to 1/2 female or 1/4 to 1/2 compression fitting connections
  • 2P, 3P bodies (stainless) and 4PL, 5PC bodies (stainless or brass)
  • Listed codes: gauge ports "0" (NPT1/4 port, no gauge); gauges (V3 to 40), plug C, MPA scale, VS/PK/TF seat and panel mount (P) are ordered as suffixes

Specifications

Fluid Gases that do not corrode wetted parts
External leakage 1x10^-10 Pa m3/s
Ambient and fluid temperature -40 to 71 C (no freezing)
Port connection NPT female thread or compression fitting
Pressure characteristic 0.024 MPa rise per 0.7 MPa inlet drop
Internal volume 10.6 cm3
Mass 2.0 kg
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP_SL_AZ_AK_BP.pdf), p. 718-719
AK1202B4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1202B4PL6600 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1202B4PL8800 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1202B4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1202B4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1202B4PL8T8T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1202B5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1202B5PC66000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1202B5PC88000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1202B5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1202B5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1202B5PC8T8T000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1202S2P44 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1202S2P66 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1202S2P88 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1202S2P4T4T Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1202S2P6T6T Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1202S2P8T8T Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1202S3P440 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1202S3P660 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1202S3P880 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1202S3P4T4T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1202S3P6T6T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1202S3P8T8T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1202S4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1202S4PL6600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1202S4PL8800 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1202S4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1202S4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1202S4PL8T8T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1202S5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1202S5PC66000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1202S5PC88000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1202S5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1202S5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1202S5PC8T8T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1202SH2P44 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/4 female
AK1202SH2P66 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT3/8 female
AK1202SH2P88 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/2 female
AK1202SH2P4T4T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 compression fitting
AK1202SH2P6T6T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 compression fitting
AK1202SH2P8T8T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 compression fitting
AK1202SH3P440 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1202SH3P660 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1202SH3P880 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1202SH3P4T4T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1202SH3P6T6T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1202SH3P8T8T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1202SH4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1202SH4PL6600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1202SH4PL8800 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1202SH4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1202SH4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1202SH4PL8T8T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1202SH5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1202SH5PC66000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1202SH5PC88000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1202SH5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1202SH5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1202SH5PC8T8T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1206B4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1206B4PL6600 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1206B4PL8800 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1206B4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1206B4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1206B4PL8T8T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1206B5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1206B5PC66000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1206B5PC88000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1206B5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1206B5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1206B5PC8T8T000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1206S2P44 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1206S2P66 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1206S2P88 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1206S2P4T4T Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1206S2P6T6T Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1206S2P8T8T Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1206S3P440 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1206S3P660 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1206S3P880 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1206S3P4T4T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1206S3P6T6T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1206S3P8T8T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1206S4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1206S4PL6600 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1206S4PL8800 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1206S4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1206S4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1206S4PL8T8T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1206S5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1206S5PC66000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1206S5PC88000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1206S5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1206S5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1206S5PC8T8T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1206SH2P44 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/4 female
AK1206SH2P66 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT3/8 female
AK1206SH2P88 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/2 female
AK1206SH2P4T4T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 compression fitting
AK1206SH2P6T6T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 compression fitting
AK1206SH2P8T8T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 compression fitting
AK1206SH3P440 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1206SH3P660 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1206SH3P880 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1206SH3P4T4T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1206SH3P6T6T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1206SH3P8T8T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1206SH4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1206SH4PL6600 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1206SH4PL8800 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1206SH4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1206SH4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1206SH4PL8T8T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1206SH5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1206SH5PC66000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1206SH5PC88000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1206SH5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1206SH5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1206SH5PC8T8T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1210B4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1210B4PL6600 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1210B4PL8800 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1210B4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1210B4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1210B4PL8T8T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1210B5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1210B5PC66000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1210B5PC88000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1210B5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1210B5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1210B5PC8T8T000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1210S2P44 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1210S2P66 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1210S2P88 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1210S2P4T4T Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1210S2P6T6T Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1210S2P8T8T Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1210S3P440 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1210S3P660 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1210S3P880 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1210S3P4T4T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1210S3P6T6T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1210S3P8T8T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1210S4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1210S4PL6600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1210S4PL8800 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1210S4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1210S4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1210S4PL8T8T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1210S5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1210S5PC66000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1210S5PC88000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1210S5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1210S5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1210S5PC8T8T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1210SH2P44 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/4 female
AK1210SH2P66 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT3/8 female
AK1210SH2P88 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/2 female
AK1210SH2P4T4T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 compression fitting
AK1210SH2P6T6T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 compression fitting
AK1210SH2P8T8T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 compression fitting
AK1210SH3P440 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1210SH3P660 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1210SH3P880 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1210SH3P4T4T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1210SH3P6T6T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1210SH3P8T8T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1210SH4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1210SH4PL6600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1210SH4PL8800 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1210SH4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1210SH4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1210SH4PL8T8T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1210SH5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1210SH5PC66000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1210SH5PC88000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1210SH5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1210SH5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1210SH5PC8T8T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1215B4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1215B4PL6600 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1215B4PL8800 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1215B4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1215B4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1215B4PL8T8T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1215B5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1215B5PC66000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1215B5PC88000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1215B5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1215B5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1215B5PC8T8T000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1215S2P44 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1215S2P66 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1215S2P88 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1215S2P4T4T Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1215S2P6T6T Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1215S2P8T8T Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1215S3P440 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1215S3P660 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1215S3P880 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1215S3P4T4T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1215S3P6T6T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1215S3P8T8T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1215S4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1215S4PL6600 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1215S4PL8800 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1215S4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1215S4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1215S4PL8T8T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1215S5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1215S5PC66000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1215S5PC88000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1215S5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1215S5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1215S5PC8T8T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1215SH2P44 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/4 female
AK1215SH2P66 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT3/8 female
AK1215SH2P88 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/2 female
AK1215SH2P4T4T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 compression fitting
AK1215SH2P6T6T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 compression fitting
AK1215SH2P8T8T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 compression fitting
AK1215SH3P440 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1215SH3P660 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1215SH3P880 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1215SH3P4T4T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1215SH3P6T6T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1215SH3P8T8T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1215SH4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1215SH4PL6600 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1215SH4PL8800 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1215SH4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1215SH4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1215SH4PL8T8T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1215SH5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1215SH5PC66000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1215SH5PC88000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1215SH5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1215SH5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1215SH5PC8T8T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1225B4PL4400 Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1225B4PL6600 Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1225B4PL8800 Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1225B4PL4T4T00 Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1225B4PL6T6T00 Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1225B4PL8T8T00 Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1225B5PC44000 Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1225B5PC66000 Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1225B5PC88000 Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1225B5PC4T4T000 Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1225B5PC6T6T000 Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1225B5PC8T8T000 Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1225S2P44 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1225S2P66 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1225S2P88 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1225S2P4T4T Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1225S2P6T6T Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1225S2P8T8T Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1225S3P440 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1225S3P660 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1225S3P880 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1225S3P4T4T0 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1225S3P6T6T0 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1225S3P8T8T0 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1225S4PL4400 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1225S4PL6600 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1225S4PL8800 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1225S4PL4T4T00 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1225S4PL6T6T00 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1225S4PL8T8T00 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1225S5PC44000 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1225S5PC66000 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1225S5PC88000 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1225S5PC4T4T000 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1225S5PC6T6T000 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1225S5PC8T8T000 Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1225SH2P44 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/4 female
AK1225SH2P66 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT3/8 female
AK1225SH2P88 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/2 female
AK1225SH2P4T4T Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 compression fitting
AK1225SH2P6T6T Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 compression fitting
AK1225SH2P8T8T Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 compression fitting
AK1225SH3P440 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1225SH3P660 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1225SH3P880 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1225SH3P4T4T0 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1225SH3P6T6T0 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1225SH3P8T8T0 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1225SH4PL4400 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1225SH4PL6600 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1225SH4PL8800 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1225SH4PL4T4T00 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1225SH4PL6T6T00 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1225SH4PL8T8T00 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1225SH5PC44000 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1225SH5PC66000 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1225SH5PC88000 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1225SH5PC4T4T000 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1225SH5PC6T6T000 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1225SH5PC8T8T000 Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
RegulatorsSMC
300 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AK1200 General Gas Regulator (High Flow, Tied Diaphragm)

Brand SMC·Regulators

Available part numbers (300)

AK1202B4PL4400, AK1202B4PL6600, AK1202B4PL8800, AK1202B4PL4T4T00, AK1202B4PL6T6T00, AK1202B4PL8T8T00, AK1202B5PC44000, AK1202B5PC66000, AK1202B5PC88000, AK1202B5PC4T4T000 + 290 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AK1202B4PL4400Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1202B4PL6600Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1202B4PL8800Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1202B4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1202B4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1202B4PL8T8T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1202B5PC44000Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1202B5PC66000Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1202B5PC88000Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1202B5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1202B5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1202B5PC8T8T000Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1202S2P44Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1202S2P66Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1202S2P88Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1202S2P4T4TSet pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1202S2P6T6TSet pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1202S2P8T8TSet pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1202S3P440Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1202S3P660Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1202S3P880Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1202S3P4T4T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1202S3P6T6T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1202S3P8T8T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1202S4PL4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1202S4PL6600Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1202S4PL8800Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1202S4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1202S4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1202S4PL8T8T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1202S5PC44000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1202S5PC66000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1202S5PC88000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1202S5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1202S5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1202S5PC8T8T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1202SH2P44Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/4 female
AK1202SH2P66Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT3/8 female
AK1202SH2P88Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/2 female
AK1202SH2P4T4TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 compression fitting
AK1202SH2P6T6TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 compression fitting
AK1202SH2P8T8TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 compression fitting
AK1202SH3P440Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1202SH3P660Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1202SH3P880Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1202SH3P4T4T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1202SH3P6T6T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1202SH3P8T8T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1202SH4PL4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1202SH4PL6600Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1202SH4PL8800Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1202SH4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1202SH4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1202SH4PL8T8T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1202SH5PC44000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1202SH5PC66000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1202SH5PC88000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1202SH5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1202SH5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1202SH5PC8T8T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1206B4PL4400Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1206B4PL6600Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1206B4PL8800Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1206B4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1206B4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1206B4PL8T8T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1206B5PC44000Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1206B5PC66000Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1206B5PC88000Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1206B5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1206B5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1206B5PC8T8T000Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1206S2P44Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1206S2P66Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1206S2P88Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1206S2P4T4TSet pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1206S2P6T6TSet pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1206S2P8T8TSet pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1206S3P440Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1206S3P660Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1206S3P880Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1206S3P4T4T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1206S3P6T6T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1206S3P8T8T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1206S4PL4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1206S4PL6600Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1206S4PL8800Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1206S4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1206S4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1206S4PL8T8T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1206S5PC44000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1206S5PC66000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1206S5PC88000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1206S5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1206S5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1206S5PC8T8T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1206SH2P44Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/4 female
AK1206SH2P66Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT3/8 female
AK1206SH2P88Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/2 female
AK1206SH2P4T4TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 compression fitting
AK1206SH2P6T6TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 compression fitting
AK1206SH2P8T8TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 compression fitting
AK1206SH3P440Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1206SH3P660Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1206SH3P880Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1206SH3P4T4T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1206SH3P6T6T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1206SH3P8T8T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1206SH4PL4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1206SH4PL6600Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1206SH4PL8800Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1206SH4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1206SH4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1206SH4PL8T8T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1206SH5PC44000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1206SH5PC66000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1206SH5PC88000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1206SH5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1206SH5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1206SH5PC8T8T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1210B4PL4400Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1210B4PL6600Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1210B4PL8800Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1210B4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1210B4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1210B4PL8T8T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1210B5PC44000Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1210B5PC66000Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1210B5PC88000Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1210B5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1210B5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1210B5PC8T8T000Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1210S2P44Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1210S2P66Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1210S2P88Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1210S2P4T4TSet pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1210S2P6T6TSet pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1210S2P8T8TSet pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1210S3P440Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1210S3P660Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1210S3P880Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1210S3P4T4T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1210S3P6T6T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1210S3P8T8T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1210S4PL4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1210S4PL6600Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1210S4PL8800Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1210S4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1210S4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1210S4PL8T8T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1210S5PC44000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1210S5PC66000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1210S5PC88000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1210S5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1210S5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1210S5PC8T8T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1210SH2P44Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/4 female
AK1210SH2P66Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT3/8 female
AK1210SH2P88Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/2 female
AK1210SH2P4T4TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 compression fitting
AK1210SH2P6T6TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 compression fitting
AK1210SH2P8T8TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 compression fitting
AK1210SH3P440Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1210SH3P660Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1210SH3P880Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1210SH3P4T4T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1210SH3P6T6T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1210SH3P8T8T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1210SH4PL4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1210SH4PL6600Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1210SH4PL8800Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1210SH4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1210SH4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1210SH4PL8T8T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1210SH5PC44000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1210SH5PC66000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1210SH5PC88000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1210SH5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1210SH5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1210SH5PC8T8T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1215B4PL4400Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1215B4PL6600Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1215B4PL8800Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1215B4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1215B4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1215B4PL8T8T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1215B5PC44000Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1215B5PC66000Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1215B5PC88000Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1215B5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1215B5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1215B5PC8T8T000Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1215S2P44Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1215S2P66Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1215S2P88Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1215S2P4T4TSet pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1215S2P6T6TSet pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1215S2P8T8TSet pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1215S3P440Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1215S3P660Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1215S3P880Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1215S3P4T4T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1215S3P6T6T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1215S3P8T8T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1215S4PL4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1215S4PL6600Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1215S4PL8800Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1215S4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1215S4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1215S4PL8T8T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1215S5PC44000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1215S5PC66000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1215S5PC88000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1215S5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1215S5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1215S5PC8T8T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1215SH2P44Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/4 female
AK1215SH2P66Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT3/8 female
AK1215SH2P88Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/2 female
AK1215SH2P4T4TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 compression fitting
AK1215SH2P6T6TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 compression fitting
AK1215SH2P8T8TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 compression fitting
AK1215SH3P440Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1215SH3P660Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1215SH3P880Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1215SH3P4T4T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1215SH3P6T6T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1215SH3P8T8T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1215SH4PL4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1215SH4PL6600Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1215SH4PL8800Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1215SH4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1215SH4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1215SH4PL8T8T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1215SH5PC44000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1215SH5PC66000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1215SH5PC88000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1215SH5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1215SH5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1215SH5PC8T8T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1225B4PL4400Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1225B4PL6600Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1225B4PL8800Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1225B4PL4T4T00Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1225B4PL6T6T00Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1225B4PL8T8T00Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1225B5PC44000Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1225B5PC66000Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1225B5PC88000Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1225B5PC4T4T000Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1225B5PC6T6T000Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1225B5PC8T8T000Set pressure: up to 1.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1225S2P44Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1225S2P66Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1225S2P88Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1225S2P4T4TSet pressure: up to 1.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1225S2P6T6TSet pressure: up to 1.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1225S2P8T8TSet pressure: up to 1.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1225S3P440Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1225S3P660Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1225S3P880Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1225S3P4T4T0Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1225S3P6T6T0Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1225S3P8T8T0Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1225S4PL4400Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1225S4PL6600Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1225S4PL8800Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1225S4PL4T4T00Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1225S4PL6T6T00Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1225S4PL8T8T00Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1225S5PC44000Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1225S5PC66000Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1225S5PC88000Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1225S5PC4T4T000Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1225S5PC6T6T000Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1225S5PC8T8T000Set pressure: up to 1.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1225SH2P44Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/4 female
AK1225SH2P66Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT3/8 female
AK1225SH2P88Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: NPT1/2 female
AK1225SH2P4T4TSet pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 compression fitting
AK1225SH2P6T6TSet pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 compression fitting
AK1225SH2P8T8TSet pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 compression fitting
AK1225SH3P440Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1225SH3P660Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1225SH3P880Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1225SH3P4T4T0Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1225SH3P6T6T0Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1225SH3P8T8T0Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1225SH4PL4400Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1225SH4PL6600Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1225SH4PL8800Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1225SH4PL4T4T00Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1225SH4PL6T6T00Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1225SH4PL8T8T00Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1225SH5PC44000Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1225SH5PC66000Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1225SH5PC88000Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1225SH5PC4T4T000Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1225SH5PC6T6T000Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1225SH5PC8T8T000Set pressure: up to 1.7 MPa | Material: SUS316, Ni-Cr-Mo poppet | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
