• SMC AK1300 General Gas Regulator (High Flow, 2.1 MPa Inlet)
1 1

SMC AK1300 General Gas Regulator (High Flow, 2.1 MPa Inlet)

SMC AK1300 General Gas Regulator (High Flow, 2.1 MPa Inlet)

SMC AK1300 series single-stage general gas regulator in stainless steel or brass for high flow (below 1000 slpm) with inlet up to 2.1 MPa.

Key features

  • Stainless steel (SUS316) or brass body for general and specialty gases; Ni-Cr-Mo internals available for corrosive gases
  • Flow below 1000 slpm; inlet up to 300 psig (2.1 MPa)
  • Set pressure 0.007-0.2 to 0.034-1.0 MPa
  • NPT1/4 to 1/2 female or 1/4 to 1/2 compression fitting connections
  • 2P, 3P bodies (stainless) and 4PL body (stainless or brass); gauge ports both on outlet side
  • Listed codes: gauge ports "0" (NPT1/4 port, no gauge); gauges (V3 to 40), plug C, MPA scale, VS/PK/TF seat and panel mount (P) are ordered as suffixes

Specifications

Fluid Gases that do not corrode wetted parts
External leakage 1x10^-10 Pa m3/s
Ambient and fluid temperature -40 to 71 C (no freezing)
Port connection NPT female thread or compression fitting
Pressure characteristic 0.031 MPa rise per 0.7 MPa inlet drop
Internal volume 10.6 cm3
Mass 2.0 kg
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP_SL_AZ_AK_BP.pdf), p. 716-717
AK1302B4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1302B4PL6600 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1302B4PL8800 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1302B4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1302B4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1302B4PL8T8T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1302S2P44 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1302S2P66 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1302S2P88 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1302S2P4T4T Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1302S2P6T6T Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1302S2P8T8T Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1302S3P440 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1302S3P660 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1302S3P880 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1302S3P4T4T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1302S3P6T6T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1302S3P8T8T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1302S4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1302S4PL6600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1302S4PL8800 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1302S4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1302S4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1302S4PL8T8T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1306B4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1306B4PL6600 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1306B4PL8800 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1306B4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1306B4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1306B4PL8T8T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1306S2P44 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1306S2P66 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1306S2P88 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1306S2P4T4T Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1306S2P6T6T Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1306S2P8T8T Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1306S3P440 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1306S3P660 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1306S3P880 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1306S3P4T4T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1306S3P6T6T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1306S3P8T8T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1306S4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1306S4PL6600 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1306S4PL8800 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1306S4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1306S4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1306S4PL8T8T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1310B4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1310B4PL6600 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1310B4PL8800 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1310B4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1310B4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1310B4PL8T8T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1310S2P44 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1310S2P66 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1310S2P88 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1310S2P4T4T Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1310S2P6T6T Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1310S2P8T8T Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1310S3P440 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1310S3P660 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1310S3P880 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1310S3P4T4T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1310S3P6T6T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1310S3P8T8T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1310S4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1310S4PL6600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1310S4PL8800 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1310S4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1310S4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1310S4PL8T8T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1315B4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1315B4PL6600 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1315B4PL8800 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1315B4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1315B4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1315B4PL8T8T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1315S2P44 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1315S2P66 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1315S2P88 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1315S2P4T4T Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1315S2P6T6T Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1315S2P8T8T Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1315S3P440 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1315S3P660 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1315S3P880 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1315S3P4T4T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1315S3P6T6T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1315S3P8T8T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1315S4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1315S4PL6600 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1315S4PL8800 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1315S4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1315S4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1315S4PL8T8T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
RegulatorsSMC
96 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AK1300 General Gas Regulator (High Flow, 2.1 MPa Inlet)

Brand SMC·Regulators

Available part numbers (96)

AK1302B4PL4400, AK1302B4PL6600, AK1302B4PL8800, AK1302B4PL4T4T00, AK1302B4PL6T6T00, AK1302B4PL8T8T00, AK1302S2P44, AK1302S2P66, AK1302S2P88, AK1302S2P4T4T + 86 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AK1302B4PL4400Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1302B4PL6600Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1302B4PL8800Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1302B4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1302B4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1302B4PL8T8T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1302S2P44Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1302S2P66Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1302S2P88Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1302S2P4T4TSet pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1302S2P6T6TSet pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1302S2P8T8TSet pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1302S3P440Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1302S3P660Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1302S3P880Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1302S3P4T4T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1302S3P6T6T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1302S3P8T8T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1302S4PL4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1302S4PL6600Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1302S4PL8800Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1302S4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1302S4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1302S4PL8T8T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1306B4PL4400Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1306B4PL6600Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1306B4PL8800Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1306B4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1306B4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1306B4PL8T8T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1306S2P44Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1306S2P66Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1306S2P88Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1306S2P4T4TSet pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1306S2P6T6TSet pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1306S2P8T8TSet pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1306S3P440Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1306S3P660Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1306S3P880Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1306S3P4T4T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1306S3P6T6T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1306S3P8T8T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1306S4PL4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1306S4PL6600Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1306S4PL8800Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1306S4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1306S4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1306S4PL8T8T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1310B4PL4400Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1310B4PL6600Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1310B4PL8800Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1310B4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1310B4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1310B4PL8T8T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1310S2P44Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1310S2P66Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1310S2P88Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1310S2P4T4TSet pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1310S2P6T6TSet pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1310S2P8T8TSet pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1310S3P440Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1310S3P660Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1310S3P880Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1310S3P4T4T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1310S3P6T6T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1310S3P8T8T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1310S4PL4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1310S4PL6600Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1310S4PL8800Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1310S4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1310S4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1310S4PL8T8T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1315B4PL4400Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1315B4PL6600Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1315B4PL8800Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1315B4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1315B4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1315B4PL8T8T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1315S2P44Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1315S2P66Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT3/8 female
AK1315S2P88Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/2 female
AK1315S2P4T4TSet pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1315S2P6T6TSet pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1315S2P8T8TSet pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/2 compression fitting
AK1315S3P440Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1315S3P660Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1315S3P880Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1315S3P4T4T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1315S3P6T6T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1315S3P8T8T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1315S4PL4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1315S4PL6600Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1315S4PL8800Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1315S4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1315S4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1315S4PL8T8T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
