SMC AK1400T General Gas Regulator (Medium Flow, Tied Diaphragm)

SMC AK1400T General Gas Regulator (Medium Flow, Tied Diaphragm)

SMC AK1400T series single-stage tied-diaphragm general gas regulator in stainless steel or brass for medium flow (below 400 slpm), inlet up to 15.9 MPa.

Key features

  • Stainless steel (SUS316) or brass body for general and specialty gases; Ni-Cr-Mo internals available for corrosive gases
  • Inlet up to 2300 psig (15.9 MPa), HR option 3000 psig (20.7 MPa); flow below 400 slpm
  • Set pressure 0.007-0.2 to 0.034-1.0 MPa; vacuum-regulation version AK1402T..A
  • NPT1/4 to 1/2 female or 1/4 to 1/2 compression fitting connections
  • 2P, 3P bodies (stainless) and 4PL, 5PC bodies (stainless or brass)
  • Listed codes: gauge ports "0" (NPT1/4 port, no gauge); gauges (V3 to 40), plug C, MPA scale, VS/PK/TF seat and panel mount (P) are ordered as suffixes

Specifications

Fluid Gases that do not corrode wetted parts
External leakage 1x10^-10 Pa m3/s
Ambient and fluid temperature -40 to 71 C (no freezing)
Port connection NPT female thread or compression fitting
Pressure characteristic 0.011 MPa rise per 0.7 MPa inlet drop
Internal volume 10.6 cm3
Mass 2.04 kg
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP_SL_AZ_AK_BP.pdf), p. 714-715
AK1402TB4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1402TB4PL6600 Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1402TB4PL8800 Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1402TB4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1402TB4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1402TB4PL8T8T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1402TB5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1402TB5PC66000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1402TB5PC88000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1402TB5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1402TB5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1402TB5PC8T8T000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1402TS2P44 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/4 female
AK1402TS2P66 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT3/8 female
AK1402TS2P88 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/2 female
AK1402TS2P4T4T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/4 compression fitting
AK1402TS2P6T6T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 3/8 compression fitting
AK1402TS2P8T8T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/2 compression fitting
AK1402TS3P440 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1402TS3P660 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1402TS3P880 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1402TS3P4T4T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1402TS3P6T6T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1402TS3P8T8T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1402TS4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1402TS4PL6600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1402TS4PL8800 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1402TS4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1402TS4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1402TS4PL8T8T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1402TS5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1402TS5PC66000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1402TS5PC88000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1402TS5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1402TS5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1402TS5PC8T8T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1402TSH2P44 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/4 female
AK1402TSH2P66 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT3/8 female
AK1402TSH2P88 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/2 female
AK1402TSH2P4T4T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/4 compression fitting
AK1402TSH2P6T6T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 3/8 compression fitting
AK1402TSH2P8T8T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/2 compression fitting
AK1402TSH3P440 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1402TSH3P660 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1402TSH3P880 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1402TSH3P4T4T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1402TSH3P6T6T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1402TSH3P8T8T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1402TSH4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1402TSH4PL6600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1402TSH4PL8800 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1402TSH4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1402TSH4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1402TSH4PL8T8T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1402TSH5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1402TSH5PC66000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1402TSH5PC88000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1402TSH5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1402TSH5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1402TSH5PC8T8T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1406TB4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1406TB4PL6600 Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1406TB4PL8800 Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1406TB4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1406TB4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1406TB4PL8T8T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1406TB5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1406TB5PC66000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1406TB5PC88000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1406TB5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1406TB5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1406TB5PC8T8T000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1406TS2P44 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/4 female
AK1406TS2P66 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT3/8 female
AK1406TS2P88 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/2 female
AK1406TS2P4T4T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/4 compression fitting
AK1406TS2P6T6T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 3/8 compression fitting
AK1406TS2P8T8T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/2 compression fitting
AK1406TS3P440 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1406TS3P660 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1406TS3P880 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1406TS3P4T4T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1406TS3P6T6T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1406TS3P8T8T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1406TS4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1406TS4PL6600 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1406TS4PL8800 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1406TS4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1406TS4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1406TS4PL8T8T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1406TS5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1406TS5PC66000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1406TS5PC88000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1406TS5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1406TS5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1406TS5PC8T8T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1406TSH2P44 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/4 female
AK1406TSH2P66 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT3/8 female
AK1406TSH2P88 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/2 female
AK1406TSH2P4T4T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/4 compression fitting
AK1406TSH2P6T6T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 3/8 compression fitting
AK1406TSH2P8T8T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/2 compression fitting
AK1406TSH3P440 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1406TSH3P660 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1406TSH3P880 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1406TSH3P4T4T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1406TSH3P6T6T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1406TSH3P8T8T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1406TSH4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1406TSH4PL6600 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1406TSH4PL8800 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1406TSH4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1406TSH4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1406TSH4PL8T8T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1406TSH5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1406TSH5PC66000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1406TSH5PC88000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1406TSH5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1406TSH5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1406TSH5PC8T8T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1410TB4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1410TB4PL6600 Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1410TB4PL8800 Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1410TB4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1410TB4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1410TB4PL8T8T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1410TB5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1410TB5PC66000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1410TB5PC88000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1410TB5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1410TB5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1410TB5PC8T8T000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1410TS2P44 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/4 female
AK1410TS2P66 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT3/8 female
AK1410TS2P88 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/2 female
AK1410TS2P4T4T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/4 compression fitting
AK1410TS2P6T6T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 3/8 compression fitting
AK1410TS2P8T8T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/2 compression fitting
AK1410TS3P440 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1410TS3P660 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1410TS3P880 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1410TS3P4T4T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1410TS3P6T6T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1410TS3P8T8T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1410TS4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1410TS4PL6600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1410TS4PL8800 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1410TS4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1410TS4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1410TS4PL8T8T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1410TS5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1410TS5PC66000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1410TS5PC88000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1410TS5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1410TS5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1410TS5PC8T8T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1410TSH2P44 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/4 female
AK1410TSH2P66 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT3/8 female
AK1410TSH2P88 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/2 female
AK1410TSH2P4T4T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/4 compression fitting
AK1410TSH2P6T6T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 3/8 compression fitting
AK1410TSH2P8T8T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/2 compression fitting
AK1410TSH3P440 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1410TSH3P660 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1410TSH3P880 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1410TSH3P4T4T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1410TSH3P6T6T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1410TSH3P8T8T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1410TSH4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1410TSH4PL6600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1410TSH4PL8800 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1410TSH4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1410TSH4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1410TSH4PL8T8T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1410TSH5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1410TSH5PC66000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1410TSH5PC88000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1410TSH5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1410TSH5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1410TSH5PC8T8T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1415TB4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1415TB4PL6600 Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1415TB4PL8800 Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1415TB4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1415TB4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1415TB4PL8T8T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1415TB5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1415TB5PC66000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1415TB5PC88000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1415TB5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1415TB5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1415TB5PC8T8T000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1415TS2P44 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/4 female
AK1415TS2P66 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT3/8 female
AK1415TS2P88 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/2 female
AK1415TS2P4T4T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/4 compression fitting
AK1415TS2P6T6T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 3/8 compression fitting
AK1415TS2P8T8T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/2 compression fitting
AK1415TS3P440 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1415TS3P660 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1415TS3P880 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1415TS3P4T4T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1415TS3P6T6T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1415TS3P8T8T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1415TS4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1415TS4PL6600 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1415TS4PL8800 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1415TS4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1415TS4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1415TS4PL8T8T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1415TS5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1415TS5PC66000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1415TS5PC88000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1415TS5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1415TS5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1415TS5PC8T8T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1415TSH2P44 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/4 female
AK1415TSH2P66 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT3/8 female
AK1415TSH2P88 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/2 female
AK1415TSH2P4T4T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/4 compression fitting
AK1415TSH2P6T6T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 3/8 compression fitting
AK1415TSH2P8T8T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/2 compression fitting
AK1415TSH3P440 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1415TSH3P660 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1415TSH3P880 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1415TSH3P4T4T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1415TSH3P6T6T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1415TSH3P8T8T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1415TSH4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1415TSH4PL6600 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1415TSH4PL8800 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1415TSH4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1415TSH4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1415TSH4PL8T8T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1415TSH5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1415TSH5PC66000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1415TSH5PC88000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1415TSH5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1415TSH5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1415TSH5PC8T8T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1402TBA4PL4400 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1402TBA4PL6600 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1402TBA4PL8800 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1402TBA4PL4T4T00 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1402TBA4PL6T6T00 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1402TBA4PL8T8T00 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1402TBA5PC44000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1402TBA5PC66000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1402TBA5PC88000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1402TBA5PC4T4T000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1402TBA5PC6T6T000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1402TBA5PC8T8T000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1402TSA2P44 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/4 female
AK1402TSA2P66 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT3/8 female
AK1402TSA2P88 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/2 female
AK1402TSA2P4T4T Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/4 compression fitting
AK1402TSA2P6T6T Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 3/8 compression fitting
AK1402TSA2P8T8T Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/2 compression fitting
AK1402TSA3P440 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1402TSA3P660 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1402TSA3P880 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1402TSA3P4T4T0 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1402TSA3P6T6T0 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1402TSA3P8T8T0 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1402TSA4PL4400 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1402TSA4PL6600 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1402TSA4PL8800 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1402TSA4PL4T4T00 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1402TSA4PL6T6T00 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1402TSA4PL8T8T00 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1402TSA5PC44000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1402TSA5PC66000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1402TSA5PC88000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1402TSA5PC4T4T000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1402TSA5PC6T6T000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1402TSA5PC8T8T000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1402TSHA2P44 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/4 female
AK1402TSHA2P66 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT3/8 female
AK1402TSHA2P88 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/2 female
AK1402TSHA2P4T4T Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/4 compression fitting
AK1402TSHA2P6T6T Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 3/8 compression fitting
AK1402TSHA2P8T8T Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/2 compression fitting
AK1402TSHA3P440 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1402TSHA3P660 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1402TSHA3P880 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1402TSHA3P4T4T0 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1402TSHA3P6T6T0 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1402TSHA3P8T8T0 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1402TSHA4PL4400 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1402TSHA4PL6600 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1402TSHA4PL8800 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1402TSHA4PL4T4T00 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1402TSHA4PL6T6T00 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1402TSHA4PL8T8T00 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1402TSHA5PC44000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1402TSHA5PC66000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1402TSHA5PC88000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1402TSHA5PC4T4T000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1402TSHA5PC6T6T000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1402TSHA5PC8T8T000 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
RegulatorsSMC
300 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AK1400T General Gas Regulator (Medium Flow, Tied Diaphragm)

Brand SMC·Regulators

Available part numbers (300)

AK1402TB4PL4400, AK1402TB4PL6600, AK1402TB4PL8800, AK1402TB4PL4T4T00, AK1402TB4PL6T6T00, AK1402TB4PL8T8T00, AK1402TB5PC44000, AK1402TB5PC66000, AK1402TB5PC88000, AK1402TB5PC4T4T000 + 290 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AK1402TB4PL4400Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1402TB4PL6600Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1402TB4PL8800Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1402TB4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1402TB4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1402TB4PL8T8T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1402TB5PC44000Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1402TB5PC66000Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1402TB5PC88000Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1402TB5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1402TB5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1402TB5PC8T8T000Set pressure: 0.007 to 0.2 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1402TS2P44Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/4 female
AK1402TS2P66Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT3/8 female
AK1402TS2P88Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/2 female
AK1402TS2P4T4TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/4 compression fitting
AK1402TS2P6T6TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 3/8 compression fitting
AK1402TS2P8T8TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/2 compression fitting
AK1402TS3P440Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1402TS3P660Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1402TS3P880Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1402TS3P4T4T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1402TS3P6T6T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1402TS3P8T8T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1402TS4PL4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1402TS4PL6600Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1402TS4PL8800Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1402TS4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1402TS4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1402TS4PL8T8T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1402TS5PC44000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1402TS5PC66000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1402TS5PC88000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1402TS5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1402TS5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1402TS5PC8T8T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1402TSH2P44Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/4 female
AK1402TSH2P66Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT3/8 female
AK1402TSH2P88Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/2 female
AK1402TSH2P4T4TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/4 compression fitting
AK1402TSH2P6T6TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 3/8 compression fitting
AK1402TSH2P8T8TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/2 compression fitting
AK1402TSH3P440Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1402TSH3P660Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1402TSH3P880Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1402TSH3P4T4T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1402TSH3P6T6T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1402TSH3P8T8T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1402TSH4PL4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1402TSH4PL6600Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1402TSH4PL8800Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1402TSH4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1402TSH4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1402TSH4PL8T8T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1402TSH5PC44000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1402TSH5PC66000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1402TSH5PC88000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1402TSH5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1402TSH5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1402TSH5PC8T8T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1406TB4PL4400Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1406TB4PL6600Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1406TB4PL8800Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1406TB4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1406TB4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1406TB4PL8T8T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1406TB5PC44000Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1406TB5PC66000Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1406TB5PC88000Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1406TB5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1406TB5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1406TB5PC8T8T000Set pressure: 0.014 to 0.4 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1406TS2P44Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/4 female
AK1406TS2P66Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT3/8 female
AK1406TS2P88Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/2 female
AK1406TS2P4T4TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/4 compression fitting
AK1406TS2P6T6TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 3/8 compression fitting
AK1406TS2P8T8TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/2 compression fitting
AK1406TS3P440Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1406TS3P660Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1406TS3P880Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1406TS3P4T4T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1406TS3P6T6T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1406TS3P8T8T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1406TS4PL4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1406TS4PL6600Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1406TS4PL8800Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1406TS4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1406TS4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1406TS4PL8T8T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1406TS5PC44000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1406TS5PC66000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1406TS5PC88000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1406TS5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1406TS5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1406TS5PC8T8T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1406TSH2P44Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/4 female
AK1406TSH2P66Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT3/8 female
AK1406TSH2P88Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/2 female
AK1406TSH2P4T4TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/4 compression fitting
AK1406TSH2P6T6TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 3/8 compression fitting
AK1406TSH2P8T8TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/2 compression fitting
AK1406TSH3P440Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1406TSH3P660Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1406TSH3P880Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1406TSH3P4T4T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1406TSH3P6T6T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1406TSH3P8T8T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1406TSH4PL4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1406TSH4PL6600Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1406TSH4PL8800Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1406TSH4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1406TSH4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1406TSH4PL8T8T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1406TSH5PC44000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1406TSH5PC66000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1406TSH5PC88000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1406TSH5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1406TSH5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1406TSH5PC8T8T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1410TB4PL4400Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1410TB4PL6600Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1410TB4PL8800Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1410TB4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1410TB4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1410TB4PL8T8T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1410TB5PC44000Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1410TB5PC66000Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1410TB5PC88000Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1410TB5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1410TB5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1410TB5PC8T8T000Set pressure: 0.014 to 0.7 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1410TS2P44Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/4 female
AK1410TS2P66Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT3/8 female
AK1410TS2P88Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/2 female
AK1410TS2P4T4TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/4 compression fitting
AK1410TS2P6T6TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 3/8 compression fitting
AK1410TS2P8T8TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/2 compression fitting
AK1410TS3P440Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1410TS3P660Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1410TS3P880Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1410TS3P4T4T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1410TS3P6T6T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1410TS3P8T8T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1410TS4PL4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1410TS4PL6600Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1410TS4PL8800Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1410TS4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1410TS4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1410TS4PL8T8T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1410TS5PC44000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1410TS5PC66000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1410TS5PC88000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1410TS5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1410TS5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1410TS5PC8T8T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1410TSH2P44Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/4 female
AK1410TSH2P66Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT3/8 female
AK1410TSH2P88Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/2 female
AK1410TSH2P4T4TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/4 compression fitting
AK1410TSH2P6T6TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 3/8 compression fitting
AK1410TSH2P8T8TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/2 compression fitting
AK1410TSH3P440Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1410TSH3P660Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1410TSH3P880Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1410TSH3P4T4T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1410TSH3P6T6T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1410TSH3P8T8T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1410TSH4PL4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1410TSH4PL6600Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1410TSH4PL8800Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1410TSH4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1410TSH4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1410TSH4PL8T8T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1410TSH5PC44000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1410TSH5PC66000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1410TSH5PC88000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1410TSH5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1410TSH5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1410TSH5PC8T8T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1415TB4PL4400Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1415TB4PL6600Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1415TB4PL8800Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1415TB4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1415TB4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1415TB4PL8T8T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1415TB5PC44000Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1415TB5PC66000Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1415TB5PC88000Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1415TB5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1415TB5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1415TB5PC8T8T000Set pressure: 0.034 to 1.0 MPa | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1415TS2P44Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/4 female
AK1415TS2P66Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT3/8 female
AK1415TS2P88Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/2 female
AK1415TS2P4T4TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/4 compression fitting
AK1415TS2P6T6TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 3/8 compression fitting
AK1415TS2P8T8TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/2 compression fitting
AK1415TS3P440Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1415TS3P660Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1415TS3P880Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1415TS3P4T4T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1415TS3P6T6T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1415TS3P8T8T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1415TS4PL4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1415TS4PL6600Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1415TS4PL8800Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1415TS4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1415TS4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1415TS4PL8T8T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1415TS5PC44000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1415TS5PC66000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1415TS5PC88000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1415TS5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1415TS5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1415TS5PC8T8T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1415TSH2P44Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/4 female
AK1415TSH2P66Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT3/8 female
AK1415TSH2P88Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/2 female
AK1415TSH2P4T4TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/4 compression fitting
AK1415TSH2P6T6TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 3/8 compression fitting
AK1415TSH2P8T8TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/2 compression fitting
AK1415TSH3P440Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1415TSH3P660Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1415TSH3P880Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1415TSH3P4T4T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1415TSH3P6T6T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1415TSH3P8T8T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1415TSH4PL4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1415TSH4PL6600Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1415TSH4PL8800Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1415TSH4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1415TSH4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1415TSH4PL8T8T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1415TSH5PC44000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1415TSH5PC66000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1415TSH5PC88000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1415TSH5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1415TSH5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1415TSH5PC8T8T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1402TBA4PL4400Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1402TBA4PL6600Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1402TBA4PL8800Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1402TBA4PL4T4T00Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1402TBA4PL6T6T00Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1402TBA4PL8T8T00Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1402TBA5PC44000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1402TBA5PC66000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1402TBA5PC88000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1402TBA5PC4T4T000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1402TBA5PC6T6T000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1402TBA5PC8T8T000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Brass body, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1402TSA2P44Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/4 female
AK1402TSA2P66Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT3/8 female
AK1402TSA2P88Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: NPT1/2 female
AK1402TSA2P4T4TSet pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/4 compression fitting
AK1402TSA2P6T6TSet pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 3/8 compression fitting
AK1402TSA2P8T8TSet pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 2 ports | Connection: 1/2 compression fitting
AK1402TSA3P440Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1402TSA3P660Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1402TSA3P880Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1402TSA3P4T4T0Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1402TSA3P6T6T0Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1402TSA3P8T8T0Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1402TSA4PL4400Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1402TSA4PL6600Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1402TSA4PL8800Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1402TSA4PL4T4T00Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1402TSA4PL6T6T00Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1402TSA4PL8T8T00Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1402TSA5PC44000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1402TSA5PC66000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1402TSA5PC88000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1402TSA5PC4T4T000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1402TSA5PC6T6T000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1402TSA5PC8T8T000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting
AK1402TSHA2P44Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/4 female
AK1402TSHA2P66Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT3/8 female
AK1402TSHA2P88Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: NPT1/2 female
AK1402TSHA2P4T4TSet pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/4 compression fitting
AK1402TSHA2P6T6TSet pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 3/8 compression fitting
AK1402TSHA2P8T8TSet pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 2 ports | Connection: 1/2 compression fitting
AK1402TSHA3P440Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1402TSHA3P660Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT3/8 female
AK1402TSHA3P880Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: NPT1/2 female
AK1402TSHA3P4T4T0Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1402TSHA3P6T6T0Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1402TSHA3P8T8T0Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 3 ports (OUT gauge) | Connection: 1/2 compression fitting
AK1402TSHA4PL4400Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1402TSHA4PL6600Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT3/8 female
AK1402TSHA4PL8800Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/2 female
AK1402TSHA4PL4T4T00Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1402TSHA4PL6T6T00Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1402TSHA4PL8T8T00Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/2 compression fitting
AK1402TSHA5PC44000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1402TSHA5PC66000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT3/8 female
AK1402TSHA5PC88000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/2 female
AK1402TSHA5PC4T4T000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1402TSHA5PC6T6T000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1402TSHA5PC8T8T000Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316, Ni-Cr-Mo internals/nozzle | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/2 compression fitting

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
