SMC AK1500 General Gas Regulator (Low Flow, Tied Diaphragm)

SMC AK1500 General Gas Regulator (Low Flow, Tied Diaphragm)

SMC AK1500 series single-stage tied-diaphragm general gas regulator in stainless steel or brass for low flow, inlet up to 24.1 MPa.

Key features

  • Stainless steel (SUS316) or brass body for general and specialty gases; Ni-Cr-Mo internals available for corrosive gases
  • Tied diaphragm construction; inlet up to 3500 psig (24.1 MPa); flow below 30 slpm
  • Set pressure 0.007-0.2 to 0.034-1.0 MPa
  • NPT1/4 female, 1/4 or 3/8 compression fitting connections
  • 2P, 3P bodies (stainless) and 4PL, 5PC bodies (stainless or brass)
  • Listed codes: gauge ports "0" (NPT1/4 port, no gauge); gauges (V3 to 40), plug C, MPA scale, VS/PK/TF seat and panel mount (P) are ordered as suffixes

Specifications

Fluid Gases that do not corrode wetted parts
External leakage 1x10^-10 Pa m3/s
Ambient and fluid temperature -40 to 71 C (no freezing)
Port connection NPT female thread or compression fitting
Pressure characteristic 0.0028 MPa rise per 0.7 MPa inlet drop
Internal volume 8 cm3
Mass 1.18 kg
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP_SL_AZ_AK_BP.pdf), p. 712-713
AK1502B4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1502B4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1502B4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1502B5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1502B5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1502B5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1502S2P44 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1502S2P4T4T Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1502S2P6T6T Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1502S3P440 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1502S3P4T4T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1502S3P6T6T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1502S4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1502S4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1502S4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1502S5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1502S5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1502S5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1502SH2P44 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1502SH2P4T4T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1502SH2P6T6T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1502SH3P440 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1502SH3P4T4T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1502SH3P6T6T0 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1502SH4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1502SH4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1502SH4PL6T6T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1502SH5PC44000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1502SH5PC4T4T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1502SH5PC6T6T000 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1506B4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1506B4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1506B4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1506B5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1506B5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1506B5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1506S2P44 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1506S2P4T4T Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1506S2P6T6T Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1506S3P440 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1506S3P4T4T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1506S3P6T6T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1506S4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1506S4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1506S4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1506S5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1506S5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1506S5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1506SH2P44 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1506SH2P4T4T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1506SH2P6T6T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1506SH3P440 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1506SH3P4T4T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1506SH3P6T6T0 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1506SH4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1506SH4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1506SH4PL6T6T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1506SH5PC44000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1506SH5PC4T4T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1506SH5PC6T6T000 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1510B4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1510B4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1510B4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1510B5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1510B5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1510B5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1510S2P44 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1510S2P4T4T Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1510S2P6T6T Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1510S3P440 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1510S3P4T4T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1510S3P6T6T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1510S4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1510S4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1510S4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1510S5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1510S5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1510S5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1510SH2P44 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1510SH2P4T4T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1510SH2P6T6T Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1510SH3P440 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1510SH3P4T4T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1510SH3P6T6T0 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1510SH4PL4400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1510SH4PL4T4T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1510SH4PL6T6T00 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1510SH5PC44000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1510SH5PC4T4T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1510SH5PC6T6T000 Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1515B4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1515B4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1515B4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1515B5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1515B5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1515B5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1515S2P44 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1515S2P4T4T Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1515S2P6T6T Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1515S3P440 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1515S3P4T4T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1515S3P6T6T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1515S4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1515S4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1515S4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1515S5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1515S5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1515S5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1515SH2P44 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1515SH2P4T4T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1515SH2P6T6T Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1515SH3P440 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1515SH3P4T4T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1515SH3P6T6T0 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1515SH4PL4400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1515SH4PL4T4T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1515SH4PL6T6T00 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1515SH5PC44000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1515SH5PC4T4T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1515SH5PC6T6T000 Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
RegulatorsSMC
120 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AK1500 General Gas Regulator (Low Flow, Tied Diaphragm)

Brand SMC·Regulators

Available part numbers (120)

AK1502B4PL4400, AK1502B4PL4T4T00, AK1502B4PL6T6T00, AK1502B5PC44000, AK1502B5PC4T4T000, AK1502B5PC6T6T000, AK1502S2P44, AK1502S2P4T4T, AK1502S2P6T6T, AK1502S3P440 + 110 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AK1502B4PL4400Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1502B4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1502B4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1502B5PC44000Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1502B5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1502B5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1502S2P44Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1502S2P4T4TSet pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1502S2P6T6TSet pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1502S3P440Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1502S3P4T4T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1502S3P6T6T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1502S4PL4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1502S4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1502S4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1502S5PC44000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1502S5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1502S5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1502SH2P44Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1502SH2P4T4TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1502SH2P6T6TSet pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1502SH3P440Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1502SH3P4T4T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1502SH3P6T6T0Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1502SH4PL4400Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1502SH4PL4T4T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1502SH4PL6T6T00Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1502SH5PC44000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1502SH5PC4T4T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1502SH5PC6T6T000Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1506B4PL4400Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1506B4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1506B4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1506B5PC44000Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1506B5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1506B5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1506S2P44Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1506S2P4T4TSet pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1506S2P6T6TSet pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1506S3P440Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1506S3P4T4T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1506S3P6T6T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1506S4PL4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1506S4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1506S4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1506S5PC44000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1506S5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1506S5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1506SH2P44Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1506SH2P4T4TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1506SH2P6T6TSet pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1506SH3P440Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1506SH3P4T4T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1506SH3P6T6T0Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1506SH4PL4400Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1506SH4PL4T4T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1506SH4PL6T6T00Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1506SH5PC44000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1506SH5PC4T4T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1506SH5PC6T6T000Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1510B4PL4400Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1510B4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1510B4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1510B5PC44000Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1510B5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1510B5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1510S2P44Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1510S2P4T4TSet pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1510S2P6T6TSet pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1510S3P440Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1510S3P4T4T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1510S3P6T6T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1510S4PL4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1510S4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1510S4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1510S5PC44000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1510S5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1510S5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1510SH2P44Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1510SH2P4T4TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1510SH2P6T6TSet pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1510SH3P440Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1510SH3P4T4T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1510SH3P6T6T0Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1510SH4PL4400Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1510SH4PL4T4T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1510SH4PL6T6T00Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1510SH5PC44000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1510SH5PC4T4T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1510SH5PC6T6T000Set pressure: 0.014 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1515B4PL4400Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1515B4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1515B4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1515B5PC44000Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1515B5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1515B5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: Brass body | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1515S2P44Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
AK1515S2P4T4TSet pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
AK1515S2P6T6TSet pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 2 ports | Connection: 3/8 compression fitting
AK1515S3P440Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1515S3P4T4T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1515S3P6T6T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1515S4PL4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1515S4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1515S4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1515S5PC44000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1515S5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1515S5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316 | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting
AK1515SH2P44Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
AK1515SH2P4T4TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
AK1515SH2P6T6TSet pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 compression fitting
AK1515SH3P440Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: NPT1/4 female
AK1515SH3P4T4T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 1/4 compression fitting
AK1515SH3P6T6T0Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (OUT gauge) | Connection: 3/8 compression fitting
AK1515SH4PL4400Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
AK1515SH4PL4T4T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
AK1515SH4PL6T6T00Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 3/8 compression fitting
AK1515SH5PC44000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: NPT1/4 female
AK1515SH5PC4T4T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 1/4 compression fitting
AK1515SH5PC6T6T000Set pressure: 0.034 to 1.0 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 5 ports (extra, IN, OUT gauge) | Connection: 3/8 compression fitting

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
