SMC ALF400 to ALF900 Auto-Feed Lubricator (Rc1/4 to Rc2)

SMC ALF400 to ALF900 Auto-Feed Lubricator (Rc1/4 to Rc2)

SMC ALF series auto-feed lubricator that is refilled automatically from an ALT auto-feed tank by a float valve, eliminating oil run-out and manual refilling, with ports from 1/4 to 2 inch.

Key features

  • Oil pressure-fed from an ALT-5/-9 tank through a felt-filtered nozzle; a float and lever valve stop feeding when the bowl is full
  • Eliminates oil shortage problems and refilling labour; usable differential pressure (tank minus line) 0.1 to 0.6 MPa
  • Six body sizes ALF400 to ALF900 with polycarbonate bowl and bowl guard
  • Accessories/suffixes not listed: B bracket (ALF400 to 600), X208 metal bowl with level gauge, R right-to-left flow
  • Thread Rc standard; NPT (N) and G (F) available. CE/UKCA

Specifications

Fluid Air
Proof pressure 1.5 MPa
Max. operating pressure 0.7 MPa
Differential pressure range 0.1 to 0.6 MPa (tank pressure minus line pressure)
Vibration resistance 1G or less (differential 0.3 MPa)
Recommended oil Class 1 turbine oil (no additive) ISO VG32
Ambient and fluid temperature -5 to 60°C (no freezing)
Bowl material Polycarbonate
Mass ALF400 0.85, ALF400-06 0.88, ALF500 1, ALF600 1.15, ALF800 1.85, ALF900 1.9 kg
Brackets B44P (ALF400), B44-1P (ALF400-06), B45-1P/B45-2P (ALF500), B46P (ALF600)
Source SMC Korea catalog ALF400-900/ALT (SMCKR_ALF400-900_ALT_.pdf), p. 1314-1317 (PDF p. 1-4)
ALF400-02 Model: ALF400 | Port: Rc1/4 | Min drip flow: 65 L/min (ANR)
ALF400-03 Model: ALF400 | Port: Rc3/8 | Min drip flow: 100 L/min (ANR)
ALF400-04 Model: ALF400 | Port: Rc1/2 | Min drip flow: 120 L/min (ANR)
ALF400-06 Model: ALF400-06 | Port: Rc3/4 | Min drip flow: 120 L/min (ANR)
ALF500-06 Model: ALF500 | Port: Rc3/4 | Min drip flow: 190 L/min (ANR)
ALF500-10 Model: ALF500 | Port: Rc1 | Min drip flow: 190 L/min (ANR)
ALF600-10 Model: ALF600 | Port: Rc1 | Min drip flow: 220 L/min (ANR)
ALF800-12 Model: ALF800 | Port: Rc1 1/4 | Min drip flow: 460 L/min (ANR)
ALF800-14 Model: ALF800 | Port: Rc1 1/2 | Min drip flow: 650 L/min (ANR)
ALF900-20 Model: ALF900 | Port: Rc2 | Min drip flow: 1800 L/min (ANR)
LubricatorsSMC
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC ALF400 to ALF900 Auto-Feed Lubricator (Rc1/4 to Rc2)

Brand SMC·Lubricators

Available part numbers (10)

ALF400-02, ALF400-03, ALF400-04, ALF400-06, ALF500-06, ALF500-10, ALF600-10, ALF800-12, ALF800-14, ALF900-20

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ALF400-02Model: ALF400 | Port: Rc1/4 | Min drip flow: 65 L/min (ANR)
ALF400-03Model: ALF400 | Port: Rc3/8 | Min drip flow: 100 L/min (ANR)
ALF400-04Model: ALF400 | Port: Rc1/2 | Min drip flow: 120 L/min (ANR)
ALF400-06Model: ALF400-06 | Port: Rc3/4 | Min drip flow: 120 L/min (ANR)
ALF500-06Model: ALF500 | Port: Rc3/4 | Min drip flow: 190 L/min (ANR)
ALF500-10Model: ALF500 | Port: Rc1 | Min drip flow: 190 L/min (ANR)
ALF600-10Model: ALF600 | Port: Rc1 | Min drip flow: 220 L/min (ANR)
ALF800-12Model: ALF800 | Port: Rc1 1/4 | Min drip flow: 460 L/min (ANR)
ALF800-14Model: ALF800 | Port: Rc1 1/2 | Min drip flow: 650 L/min (ANR)
ALF900-20Model: ALF900 | Port: Rc2 | Min drip flow: 1800 L/min (ANR)
