SMC AP1000 High-Purity Regulator (Single-Stage, Low-Medium Flow)

SMC AP1000 High-Purity Regulator (Single-Stage, Low-Medium Flow)

SMC AP1000 series single-stage high-purity regulator for process gas supply lines, rated for inlet pressure up to 24.1 MPa with low to medium flow.

Key features

  • High-purity SUS316L double-melt body, electropolished and passivated; precision cleaned and helium leak tested
  • Inlet pressure up to 3500 psig (24.1 MPa) (AP1001: 2.1 MPa); flow below 30 slpm, HF option below 120 slpm (Cv 0.15)
  • Five set pressure ranges from 0.007-0.07 MPa to 0.034-1.0 MPa
  • Materials S, SHP, SH and H (Ni-Cr-Mo alloy wetted internals or body) for corrosive gases
  • 2, 3 or 4-port bodies with 1/4 or 3/8 face seal (female/male) or tube weld connections; IN/OUT may be combined on order
  • Listed codes: gauge ports "0" (1/4 face seal male port, no gauge); gauges (V3, L, 1, H, 2, 4, 40), MPA scale, VS/TF seat, HF high-flow and panel mount (P) are ordered as suffixes

Specifications

Fluid Gases that do not corrode wetted parts
Leakage Inboard 2x10^-11, outboard 2x10^-10 Pa m3/s
Ambient and fluid temperature -40 to 71 C (no freezing)
Mounting Bottom mount (panel mount option P)
Inlet pressure Vacuum to 24.1 MPa
Internal finish Ra max 0.4 um (options 0.25/0.18/0.13 um)
Bonnet port NPT1/8
Pressure characteristic 0.0026 MPa rise per 0.7 MPa inlet drop
Mass 1.25 kg
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP_SL_AZ_AK_BP.pdf), p. 668-669
AP1001S2PWFV4FV4 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP1001S2PWMV4MV4 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP1001S2PWTW4TW4 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP1001S2PWFV6FV6 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
AP1001S2PWMV6MV6 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
AP1001S2PWTW6TW6 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
AP1001S3PWFV4FV40 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1001S3PWMV4MV40 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1001S3PWTW4TW40 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1001S3PWFV6FV60 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1001S3PWMV6MV60 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1001S3PWTW6TW60 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1001S4PWFV4FV400 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1001S4PWMV4MV400 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1001S4PWTW4TW400 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1001S4PWFV6FV600 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1001S4PWMV6MV600 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1001S4PWTW6TW600 Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1001SHP2PWFV4FV4 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP1001SHP2PWMV4MV4 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP1001SHP2PWTW4TW4 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP1001SHP2PWFV6FV6 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
AP1001SHP2PWMV6MV6 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
AP1001SHP2PWTW6TW6 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
AP1001SHP3PWFV4FV40 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1001SHP3PWMV4MV40 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1001SHP3PWTW4TW40 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1001SHP3PWFV6FV60 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1001SHP3PWMV6MV60 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1001SHP3PWTW6TW60 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1001SHP4PWFV4FV400 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1001SHP4PWMV4MV400 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1001SHP4PWTW4TW400 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1001SHP4PWFV6FV600 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1001SHP4PWMV6MV600 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1001SHP4PWTW6TW600 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1001SH2PWFV4FV4 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
AP1001SH2PWMV4MV4 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
AP1001SH2PWTW4TW4 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
AP1001SH2PWFV6FV6 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
AP1001SH2PWMV6MV6 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
AP1001SH2PWTW6TW6 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
AP1001SH3PWFV4FV40 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1001SH3PWMV4MV40 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1001SH3PWTW4TW40 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1001SH3PWFV6FV60 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1001SH3PWMV6MV60 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1001SH3PWTW6TW60 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1001SH4PWFV4FV400 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1001SH4PWMV4MV400 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1001SH4PWTW4TW400 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1001SH4PWFV6FV600 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1001SH4PWMV6MV600 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1001SH4PWTW6TW600 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1001H2PWFV4FV4 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal female
AP1001H2PWMV4MV4 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal male
AP1001H2PWTW4TW4 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 tube weld
AP1001H2PWFV6FV6 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal female
AP1001H2PWMV6MV6 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal male
AP1001H2PWTW6TW6 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 tube weld
AP1001H3PWFV4FV40 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1001H3PWMV4MV40 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1001H3PWTW4TW40 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1001H3PWFV6FV60 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1001H3PWMV6MV60 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1001H3PWTW6TW60 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1001H4PWFV4FV400 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1001H4PWMV4MV400 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1001H4PWTW4TW400 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1001H4PWFV6FV600 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1001H4PWMV6MV600 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1001H4PWTW6TW600 Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1002S2PWFV4FV4 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP1002S2PWMV4MV4 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP1002S2PWTW4TW4 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP1002S2PWFV6FV6 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
AP1002S2PWMV6MV6 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
AP1002S2PWTW6TW6 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
AP1002S3PWFV4FV40 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1002S3PWMV4MV40 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1002S3PWTW4TW40 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1002S3PWFV6FV60 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1002S3PWMV6MV60 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1002S3PWTW6TW60 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1002S4PWFV4FV400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1002S4PWMV4MV400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1002S4PWTW4TW400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1002S4PWFV6FV600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1002S4PWMV6MV600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1002S4PWTW6TW600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1002SHP2PWFV4FV4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP1002SHP2PWMV4MV4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP1002SHP2PWTW4TW4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP1002SHP2PWFV6FV6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
AP1002SHP2PWMV6MV6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
AP1002SHP2PWTW6TW6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
AP1002SHP3PWFV4FV40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1002SHP3PWMV4MV40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1002SHP3PWTW4TW40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1002SHP3PWFV6FV60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1002SHP3PWMV6MV60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1002SHP3PWTW6TW60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1002SHP4PWFV4FV400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1002SHP4PWMV4MV400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1002SHP4PWTW4TW400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1002SHP4PWFV6FV600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1002SHP4PWMV6MV600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1002SHP4PWTW6TW600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1002SH2PWFV4FV4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
AP1002SH2PWMV4MV4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
AP1002SH2PWTW4TW4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
AP1002SH2PWFV6FV6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
AP1002SH2PWMV6MV6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
AP1002SH2PWTW6TW6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
AP1002SH3PWFV4FV40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1002SH3PWMV4MV40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1002SH3PWTW4TW40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1002SH3PWFV6FV60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1002SH3PWMV6MV60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1002SH3PWTW6TW60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1002SH4PWFV4FV400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1002SH4PWMV4MV400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1002SH4PWTW4TW400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1002SH4PWFV6FV600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1002SH4PWMV6MV600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1002SH4PWTW6TW600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1002H2PWFV4FV4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal female
AP1002H2PWMV4MV4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal male
AP1002H2PWTW4TW4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 tube weld
AP1002H2PWFV6FV6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal female
AP1002H2PWMV6MV6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal male
AP1002H2PWTW6TW6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 tube weld
AP1002H3PWFV4FV40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1002H3PWMV4MV40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1002H3PWTW4TW40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1002H3PWFV6FV60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1002H3PWMV6MV60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1002H3PWTW6TW60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1002H4PWFV4FV400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1002H4PWMV4MV400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1002H4PWTW4TW400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1002H4PWFV6FV600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1002H4PWMV6MV600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1002H4PWTW6TW600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1006S2PWFV4FV4 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP1006S2PWMV4MV4 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP1006S2PWTW4TW4 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP1006S2PWFV6FV6 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
AP1006S2PWMV6MV6 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
AP1006S2PWTW6TW6 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
AP1006S3PWFV4FV40 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1006S3PWMV4MV40 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1006S3PWTW4TW40 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1006S3PWFV6FV60 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1006S3PWMV6MV60 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1006S3PWTW6TW60 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1006S4PWFV4FV400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1006S4PWMV4MV400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1006S4PWTW4TW400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1006S4PWFV6FV600 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1006S4PWMV6MV600 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1006S4PWTW6TW600 Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1006SHP2PWFV4FV4 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP1006SHP2PWMV4MV4 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP1006SHP2PWTW4TW4 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP1006SHP2PWFV6FV6 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
AP1006SHP2PWMV6MV6 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
AP1006SHP2PWTW6TW6 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
AP1006SHP3PWFV4FV40 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1006SHP3PWMV4MV40 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1006SHP3PWTW4TW40 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1006SHP3PWFV6FV60 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1006SHP3PWMV6MV60 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1006SHP3PWTW6TW60 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1006SHP4PWFV4FV400 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1006SHP4PWMV4MV400 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1006SHP4PWTW4TW400 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1006SHP4PWFV6FV600 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1006SHP4PWMV6MV600 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1006SHP4PWTW6TW600 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1006SH2PWFV4FV4 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
AP1006SH2PWMV4MV4 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
AP1006SH2PWTW4TW4 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
AP1006SH2PWFV6FV6 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
AP1006SH2PWMV6MV6 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
AP1006SH2PWTW6TW6 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
AP1006SH3PWFV4FV40 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1006SH3PWMV4MV40 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1006SH3PWTW4TW40 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1006SH3PWFV6FV60 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1006SH3PWMV6MV60 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1006SH3PWTW6TW60 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1006SH4PWFV4FV400 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1006SH4PWMV4MV400 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1006SH4PWTW4TW400 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1006SH4PWFV6FV600 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1006SH4PWMV6MV600 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1006SH4PWTW6TW600 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1006H2PWFV4FV4 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal female
AP1006H2PWMV4MV4 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal male
AP1006H2PWTW4TW4 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 tube weld
AP1006H2PWFV6FV6 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal female
AP1006H2PWMV6MV6 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal male
AP1006H2PWTW6TW6 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 tube weld
AP1006H3PWFV4FV40 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1006H3PWMV4MV40 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1006H3PWTW4TW40 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1006H3PWFV6FV60 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1006H3PWMV6MV60 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1006H3PWTW6TW60 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1006H4PWFV4FV400 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1006H4PWMV4MV400 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1006H4PWTW4TW400 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1006H4PWFV6FV600 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1006H4PWMV6MV600 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1006H4PWTW6TW600 Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1010S2PWFV4FV4 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP1010S2PWMV4MV4 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP1010S2PWTW4TW4 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP1010S2PWFV6FV6 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
AP1010S2PWMV6MV6 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
AP1010S2PWTW6TW6 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
AP1010S3PWFV4FV40 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1010S3PWMV4MV40 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1010S3PWTW4TW40 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1010S3PWFV6FV60 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1010S3PWMV6MV60 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1010S3PWTW6TW60 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1010S4PWFV4FV400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1010S4PWMV4MV400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1010S4PWTW4TW400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1010S4PWFV6FV600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1010S4PWMV6MV600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1010S4PWTW6TW600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1010SHP2PWFV4FV4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP1010SHP2PWMV4MV4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP1010SHP2PWTW4TW4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP1010SHP2PWFV6FV6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
AP1010SHP2PWMV6MV6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
AP1010SHP2PWTW6TW6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
AP1010SHP3PWFV4FV40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1010SHP3PWMV4MV40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1010SHP3PWTW4TW40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1010SHP3PWFV6FV60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1010SHP3PWMV6MV60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1010SHP3PWTW6TW60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1010SHP4PWFV4FV400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1010SHP4PWMV4MV400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1010SHP4PWTW4TW400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1010SHP4PWFV6FV600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1010SHP4PWMV6MV600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1010SHP4PWTW6TW600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1010SH2PWFV4FV4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
AP1010SH2PWMV4MV4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
AP1010SH2PWTW4TW4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
AP1010SH2PWFV6FV6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
AP1010SH2PWMV6MV6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
AP1010SH2PWTW6TW6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
AP1010SH3PWFV4FV40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1010SH3PWMV4MV40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1010SH3PWTW4TW40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1010SH3PWFV6FV60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1010SH3PWMV6MV60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1010SH3PWTW6TW60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1010SH4PWFV4FV400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1010SH4PWMV4MV400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1010SH4PWTW4TW400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1010SH4PWFV6FV600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1010SH4PWMV6MV600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1010SH4PWTW6TW600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1010H2PWFV4FV4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal female
AP1010H2PWMV4MV4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal male
AP1010H2PWTW4TW4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 tube weld
AP1010H2PWFV6FV6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal female
AP1010H2PWMV6MV6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal male
AP1010H2PWTW6TW6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 tube weld
AP1010H3PWFV4FV40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1010H3PWMV4MV40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1010H3PWTW4TW40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1010H3PWFV6FV60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1010H3PWMV6MV60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1010H3PWTW6TW60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1010H4PWFV4FV400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1010H4PWMV4MV400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1010H4PWTW4TW400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1010H4PWFV6FV600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1010H4PWMV6MV600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1010H4PWTW6TW600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1015S2PWFV4FV4 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP1015S2PWMV4MV4 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP1015S2PWTW4TW4 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP1015S2PWFV6FV6 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
AP1015S2PWMV6MV6 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
AP1015S2PWTW6TW6 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
AP1015S3PWFV4FV40 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1015S3PWMV4MV40 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1015S3PWTW4TW40 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1015S3PWFV6FV60 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1015S3PWMV6MV60 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1015S3PWTW6TW60 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1015S4PWFV4FV400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1015S4PWMV4MV400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1015S4PWTW4TW400 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1015S4PWFV6FV600 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1015S4PWMV6MV600 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1015S4PWTW6TW600 Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1015SHP2PWFV4FV4 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP1015SHP2PWMV4MV4 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP1015SHP2PWTW4TW4 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP1015SHP2PWFV6FV6 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
AP1015SHP2PWMV6MV6 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
AP1015SHP2PWTW6TW6 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
AP1015SHP3PWFV4FV40 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1015SHP3PWMV4MV40 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1015SHP3PWTW4TW40 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1015SHP3PWFV6FV60 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1015SHP3PWMV6MV60 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1015SHP3PWTW6TW60 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1015SHP4PWFV4FV400 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1015SHP4PWMV4MV400 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1015SHP4PWTW4TW400 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1015SHP4PWFV6FV600 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1015SHP4PWMV6MV600 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1015SHP4PWTW6TW600 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1015SH2PWFV4FV4 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
AP1015SH2PWMV4MV4 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
AP1015SH2PWTW4TW4 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
AP1015SH2PWFV6FV6 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
AP1015SH2PWMV6MV6 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
AP1015SH2PWTW6TW6 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
AP1015SH3PWFV4FV40 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1015SH3PWMV4MV40 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1015SH3PWTW4TW40 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1015SH3PWFV6FV60 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1015SH3PWMV6MV60 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1015SH3PWTW6TW60 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1015SH4PWFV4FV400 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1015SH4PWMV4MV400 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1015SH4PWTW4TW400 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1015SH4PWFV6FV600 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1015SH4PWMV6MV600 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1015SH4PWTW6TW600 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1015H2PWFV4FV4 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal female
AP1015H2PWMV4MV4 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal male
AP1015H2PWTW4TW4 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 tube weld
AP1015H2PWFV6FV6 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal female
AP1015H2PWMV6MV6 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal male
AP1015H2PWTW6TW6 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 tube weld
AP1015H3PWFV4FV40 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1015H3PWMV4MV40 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1015H3PWTW4TW40 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1015H3PWFV6FV60 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1015H3PWMV6MV60 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1015H3PWTW6TW60 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1015H4PWFV4FV400 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1015H4PWMV4MV400 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1015H4PWTW4TW400 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1015H4PWFV6FV600 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1015H4PWMV6MV600 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1015H4PWTW6TW600 Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
RegulatorsSMC
360 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AP1000 High-Purity Regulator (Single-Stage, Low-Medium Flow)

Brand SMC·Regulators

Available part numbers (360)

AP1001S2PWFV4FV4, AP1001S2PWMV4MV4, AP1001S2PWTW4TW4, AP1001S2PWFV6FV6, AP1001S2PWMV6MV6, AP1001S2PWTW6TW6, AP1001S3PWFV4FV40, AP1001S3PWMV4MV40, AP1001S3PWTW4TW40, AP1001S3PWFV6FV60 + 350 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AP1001S2PWFV4FV4Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP1001S2PWMV4MV4Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP1001S2PWTW4TW4Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP1001S2PWFV6FV6Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
AP1001S2PWMV6MV6Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
AP1001S2PWTW6TW6Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
AP1001S3PWFV4FV40Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1001S3PWMV4MV40Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1001S3PWTW4TW40Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1001S3PWFV6FV60Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1001S3PWMV6MV60Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1001S3PWTW6TW60Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1001S4PWFV4FV400Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1001S4PWMV4MV400Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1001S4PWTW4TW400Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1001S4PWFV6FV600Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1001S4PWMV6MV600Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1001S4PWTW6TW600Set pressure: 0.007 to 0.07 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1001SHP2PWFV4FV4Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP1001SHP2PWMV4MV4Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP1001SHP2PWTW4TW4Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP1001SHP2PWFV6FV6Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
AP1001SHP2PWMV6MV6Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
AP1001SHP2PWTW6TW6Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
AP1001SHP3PWFV4FV40Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1001SHP3PWMV4MV40Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1001SHP3PWTW4TW40Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1001SHP3PWFV6FV60Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1001SHP3PWMV6MV60Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1001SHP3PWTW6TW60Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1001SHP4PWFV4FV400Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1001SHP4PWMV4MV400Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1001SHP4PWTW4TW400Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1001SHP4PWFV6FV600Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1001SHP4PWMV6MV600Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1001SHP4PWTW6TW600Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1001SH2PWFV4FV4Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
AP1001SH2PWMV4MV4Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
AP1001SH2PWTW4TW4Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
AP1001SH2PWFV6FV6Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
AP1001SH2PWMV6MV6Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
AP1001SH2PWTW6TW6Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
AP1001SH3PWFV4FV40Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1001SH3PWMV4MV40Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1001SH3PWTW4TW40Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1001SH3PWFV6FV60Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1001SH3PWMV6MV60Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1001SH3PWTW6TW60Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1001SH4PWFV4FV400Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1001SH4PWMV4MV400Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1001SH4PWTW4TW400Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1001SH4PWFV6FV600Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1001SH4PWMV6MV600Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1001SH4PWTW6TW600Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1001H2PWFV4FV4Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal female
AP1001H2PWMV4MV4Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal male
AP1001H2PWTW4TW4Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 tube weld
AP1001H2PWFV6FV6Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal female
AP1001H2PWMV6MV6Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal male
AP1001H2PWTW6TW6Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 tube weld
AP1001H3PWFV4FV40Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1001H3PWMV4MV40Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1001H3PWTW4TW40Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1001H3PWFV6FV60Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1001H3PWMV6MV60Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1001H3PWTW6TW60Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1001H4PWFV4FV400Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1001H4PWMV4MV400Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1001H4PWTW4TW400Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1001H4PWFV6FV600Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1001H4PWMV6MV600Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1001H4PWTW6TW600Set pressure: 0.007 to 0.07 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1002S2PWFV4FV4Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP1002S2PWMV4MV4Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP1002S2PWTW4TW4Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP1002S2PWFV6FV6Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
AP1002S2PWMV6MV6Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
AP1002S2PWTW6TW6Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
AP1002S3PWFV4FV40Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1002S3PWMV4MV40Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1002S3PWTW4TW40Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1002S3PWFV6FV60Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1002S3PWMV6MV60Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1002S3PWTW6TW60Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1002S4PWFV4FV400Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1002S4PWMV4MV400Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1002S4PWTW4TW400Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1002S4PWFV6FV600Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1002S4PWMV6MV600Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1002S4PWTW6TW600Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1002SHP2PWFV4FV4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP1002SHP2PWMV4MV4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP1002SHP2PWTW4TW4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP1002SHP2PWFV6FV6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
AP1002SHP2PWMV6MV6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
AP1002SHP2PWTW6TW6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
AP1002SHP3PWFV4FV40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1002SHP3PWMV4MV40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1002SHP3PWTW4TW40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1002SHP3PWFV6FV60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1002SHP3PWMV6MV60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1002SHP3PWTW6TW60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1002SHP4PWFV4FV400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1002SHP4PWMV4MV400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1002SHP4PWTW4TW400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1002SHP4PWFV6FV600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1002SHP4PWMV6MV600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1002SHP4PWTW6TW600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1002SH2PWFV4FV4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
AP1002SH2PWMV4MV4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
AP1002SH2PWTW4TW4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
AP1002SH2PWFV6FV6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
AP1002SH2PWMV6MV6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
AP1002SH2PWTW6TW6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
AP1002SH3PWFV4FV40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1002SH3PWMV4MV40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1002SH3PWTW4TW40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1002SH3PWFV6FV60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1002SH3PWMV6MV60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1002SH3PWTW6TW60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1002SH4PWFV4FV400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1002SH4PWMV4MV400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1002SH4PWTW4TW400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1002SH4PWFV6FV600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1002SH4PWMV6MV600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1002SH4PWTW6TW600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1002H2PWFV4FV4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal female
AP1002H2PWMV4MV4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal male
AP1002H2PWTW4TW4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 tube weld
AP1002H2PWFV6FV6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal female
AP1002H2PWMV6MV6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal male
AP1002H2PWTW6TW6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 tube weld
AP1002H3PWFV4FV40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1002H3PWMV4MV40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1002H3PWTW4TW40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1002H3PWFV6FV60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1002H3PWMV6MV60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1002H3PWTW6TW60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1002H4PWFV4FV400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1002H4PWMV4MV400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1002H4PWTW4TW400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1002H4PWFV6FV600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1002H4PWMV6MV600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1002H4PWTW6TW600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1006S2PWFV4FV4Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP1006S2PWMV4MV4Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP1006S2PWTW4TW4Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP1006S2PWFV6FV6Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
AP1006S2PWMV6MV6Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
AP1006S2PWTW6TW6Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
AP1006S3PWFV4FV40Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1006S3PWMV4MV40Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1006S3PWTW4TW40Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1006S3PWFV6FV60Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1006S3PWMV6MV60Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1006S3PWTW6TW60Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1006S4PWFV4FV400Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1006S4PWMV4MV400Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1006S4PWTW4TW400Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1006S4PWFV6FV600Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1006S4PWMV6MV600Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1006S4PWTW6TW600Set pressure: 0.014 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1006SHP2PWFV4FV4Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP1006SHP2PWMV4MV4Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP1006SHP2PWTW4TW4Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP1006SHP2PWFV6FV6Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
AP1006SHP2PWMV6MV6Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
AP1006SHP2PWTW6TW6Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
AP1006SHP3PWFV4FV40Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1006SHP3PWMV4MV40Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1006SHP3PWTW4TW40Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1006SHP3PWFV6FV60Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1006SHP3PWMV6MV60Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1006SHP3PWTW6TW60Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1006SHP4PWFV4FV400Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1006SHP4PWMV4MV400Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1006SHP4PWTW4TW400Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1006SHP4PWFV6FV600Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1006SHP4PWMV6MV600Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1006SHP4PWTW6TW600Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1006SH2PWFV4FV4Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
AP1006SH2PWMV4MV4Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
AP1006SH2PWTW4TW4Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
AP1006SH2PWFV6FV6Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
AP1006SH2PWMV6MV6Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
AP1006SH2PWTW6TW6Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
AP1006SH3PWFV4FV40Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1006SH3PWMV4MV40Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1006SH3PWTW4TW40Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1006SH3PWFV6FV60Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1006SH3PWMV6MV60Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1006SH3PWTW6TW60Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1006SH4PWFV4FV400Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1006SH4PWMV4MV400Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1006SH4PWTW4TW400Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1006SH4PWFV6FV600Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1006SH4PWMV6MV600Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1006SH4PWTW6TW600Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1006H2PWFV4FV4Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal female
AP1006H2PWMV4MV4Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal male
AP1006H2PWTW4TW4Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 tube weld
AP1006H2PWFV6FV6Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal female
AP1006H2PWMV6MV6Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal male
AP1006H2PWTW6TW6Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 tube weld
AP1006H3PWFV4FV40Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1006H3PWMV4MV40Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1006H3PWTW4TW40Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1006H3PWFV6FV60Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1006H3PWMV6MV60Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1006H3PWTW6TW60Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1006H4PWFV4FV400Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1006H4PWMV4MV400Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1006H4PWTW4TW400Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1006H4PWFV6FV600Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1006H4PWMV6MV600Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1006H4PWTW6TW600Set pressure: 0.014 to 0.4 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1010S2PWFV4FV4Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP1010S2PWMV4MV4Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP1010S2PWTW4TW4Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP1010S2PWFV6FV6Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
AP1010S2PWMV6MV6Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
AP1010S2PWTW6TW6Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
AP1010S3PWFV4FV40Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1010S3PWMV4MV40Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1010S3PWTW4TW40Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1010S3PWFV6FV60Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1010S3PWMV6MV60Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1010S3PWTW6TW60Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1010S4PWFV4FV400Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1010S4PWMV4MV400Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1010S4PWTW4TW400Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1010S4PWFV6FV600Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1010S4PWMV6MV600Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1010S4PWTW6TW600Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1010SHP2PWFV4FV4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP1010SHP2PWMV4MV4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP1010SHP2PWTW4TW4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP1010SHP2PWFV6FV6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
AP1010SHP2PWMV6MV6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
AP1010SHP2PWTW6TW6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
AP1010SHP3PWFV4FV40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1010SHP3PWMV4MV40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1010SHP3PWTW4TW40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1010SHP3PWFV6FV60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1010SHP3PWMV6MV60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1010SHP3PWTW6TW60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1010SHP4PWFV4FV400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1010SHP4PWMV4MV400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1010SHP4PWTW4TW400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1010SHP4PWFV6FV600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1010SHP4PWMV6MV600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1010SHP4PWTW6TW600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1010SH2PWFV4FV4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
AP1010SH2PWMV4MV4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
AP1010SH2PWTW4TW4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
AP1010SH2PWFV6FV6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
AP1010SH2PWMV6MV6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
AP1010SH2PWTW6TW6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
AP1010SH3PWFV4FV40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1010SH3PWMV4MV40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1010SH3PWTW4TW40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1010SH3PWFV6FV60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1010SH3PWMV6MV60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1010SH3PWTW6TW60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1010SH4PWFV4FV400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1010SH4PWMV4MV400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1010SH4PWTW4TW400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1010SH4PWFV6FV600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1010SH4PWMV6MV600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1010SH4PWTW6TW600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1010H2PWFV4FV4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal female
AP1010H2PWMV4MV4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal male
AP1010H2PWTW4TW4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 tube weld
AP1010H2PWFV6FV6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal female
AP1010H2PWMV6MV6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal male
AP1010H2PWTW6TW6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 tube weld
AP1010H3PWFV4FV40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1010H3PWMV4MV40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1010H3PWTW4TW40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1010H3PWFV6FV60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1010H3PWMV6MV60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1010H3PWTW6TW60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1010H4PWFV4FV400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1010H4PWMV4MV400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1010H4PWTW4TW400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1010H4PWFV6FV600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1010H4PWMV6MV600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1010H4PWTW6TW600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1015S2PWFV4FV4Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP1015S2PWMV4MV4Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP1015S2PWTW4TW4Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP1015S2PWFV6FV6Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
AP1015S2PWMV6MV6Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
AP1015S2PWTW6TW6Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
AP1015S3PWFV4FV40Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1015S3PWMV4MV40Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1015S3PWTW4TW40Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1015S3PWFV6FV60Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1015S3PWMV6MV60Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1015S3PWTW6TW60Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1015S4PWFV4FV400Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1015S4PWMV4MV400Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1015S4PWTW4TW400Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1015S4PWFV6FV600Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1015S4PWMV6MV600Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1015S4PWTW6TW600Set pressure: 0.034 to 1.0 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1015SHP2PWFV4FV4Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP1015SHP2PWMV4MV4Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP1015SHP2PWTW4TW4Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP1015SHP2PWFV6FV6Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
AP1015SHP2PWMV6MV6Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
AP1015SHP2PWTW6TW6Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
AP1015SHP3PWFV4FV40Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1015SHP3PWMV4MV40Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1015SHP3PWTW4TW40Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1015SHP3PWFV6FV60Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1015SHP3PWMV6MV60Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1015SHP3PWTW6TW60Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1015SHP4PWFV4FV400Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1015SHP4PWMV4MV400Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1015SHP4PWTW4TW400Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1015SHP4PWFV6FV600Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1015SHP4PWMV6MV600Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1015SHP4PWTW6TW600Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1015SH2PWFV4FV4Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
AP1015SH2PWMV4MV4Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
AP1015SH2PWTW4TW4Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
AP1015SH2PWFV6FV6Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
AP1015SH2PWMV6MV6Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
AP1015SH2PWTW6TW6Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
AP1015SH3PWFV4FV40Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1015SH3PWMV4MV40Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1015SH3PWTW4TW40Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1015SH3PWFV6FV60Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1015SH3PWMV6MV60Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1015SH3PWTW6TW60Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1015SH4PWFV4FV400Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1015SH4PWMV4MV400Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1015SH4PWTW4TW400Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1015SH4PWFV6FV600Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1015SH4PWMV6MV600Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1015SH4PWTW6TW600Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1015H2PWFV4FV4Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal female
AP1015H2PWMV4MV4Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal male
AP1015H2PWTW4TW4Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 tube weld
AP1015H2PWFV6FV6Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal female
AP1015H2PWMV6MV6Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal male
AP1015H2PWTW6TW6Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 tube weld
AP1015H3PWFV4FV40Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1015H3PWMV4MV40Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1015H3PWTW4TW40Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1015H3PWFV6FV60Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1015H3PWMV6MV60Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1015H3PWTW6TW60Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1015H4PWFV4FV400Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1015H4PWMV4MV400Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1015H4PWTW4TW400Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1015H4PWFV6FV600Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1015H4PWMV6MV600Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1015H4PWTW6TW600Set pressure: 0.034 to 1.0 MPa | Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
