SMC AP1100 High-Purity Vacuum Regulator (Negative Pressure Regulation)

SMC AP1100 High-Purity Vacuum Regulator (Negative Pressure Regulation)

SMC AP1100 series single-stage high-purity regulator for negative-pressure (vacuum) regulation, supplying gas where the downstream side is below atmospheric pressure.

Key features

  • High-purity SUS316L double-melt body, electropolished and passivated; precision cleaned and helium leak tested
  • Set pressure absolute 100 mmHg to 10 psig (-88 kPa to 0.07 MPa); flow below 0.5 slpm
  • Inlet pressure vacuum to 300 psig (2.1 MPa)
  • Materials S, SHP, SH and H (Ni-Cr-Mo alloy) for corrosive gases
  • 2, 3 or 4-port bodies with 1/4 or 3/8 face seal or tube weld connections
  • Listed codes: gauge ports "0" (1/4 face seal male port, no gauge); gauges (V3, L, 1, H, 2, 4, 40), MPA scale, VS/TF seat, HF high-flow and panel mount (P) are ordered as suffixes

Specifications

Fluid Gases that do not corrode wetted parts
Leakage Inboard 2x10^-11, outboard 2x10^-10 Pa m3/s
Ambient and fluid temperature -40 to 71 C (no freezing)
Mounting Bottom mount (panel mount option P)
Set pressure -88 kPa to 0.07 MPa
Inlet pressure Vacuum to 2.1 MPa
Internal finish Ra max 0.4 um (options 0.25/0.18/0.13 um)
Internal volume 8 cm3
Mass 1.25 kg
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP_SL_AZ_AK_BP.pdf), p. 680-681
AP1101S2PWFV4FV4 Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP1101S2PWMV4MV4 Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP1101S2PWTW4TW4 Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP1101S2PWFV6FV6 Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
AP1101S2PWMV6MV6 Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
AP1101S2PWTW6TW6 Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
AP1101S3PWFV4FV40 Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1101S3PWMV4MV40 Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1101S3PWTW4TW40 Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1101S3PWFV6FV60 Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1101S3PWMV6MV60 Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1101S3PWTW6TW60 Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1101S4PWFV4FV400 Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1101S4PWMV4MV400 Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1101S4PWTW4TW400 Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1101S4PWFV6FV600 Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1101S4PWMV6MV600 Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1101S4PWTW6TW600 Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1101SHP2PWFV4FV4 Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP1101SHP2PWMV4MV4 Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP1101SHP2PWTW4TW4 Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP1101SHP2PWFV6FV6 Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
AP1101SHP2PWMV6MV6 Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
AP1101SHP2PWTW6TW6 Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
AP1101SHP3PWFV4FV40 Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1101SHP3PWMV4MV40 Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1101SHP3PWTW4TW40 Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1101SHP3PWFV6FV60 Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1101SHP3PWMV6MV60 Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1101SHP3PWTW6TW60 Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1101SHP4PWFV4FV400 Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1101SHP4PWMV4MV400 Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1101SHP4PWTW4TW400 Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1101SHP4PWFV6FV600 Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1101SHP4PWMV6MV600 Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1101SHP4PWTW6TW600 Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1101SH2PWFV4FV4 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
AP1101SH2PWMV4MV4 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
AP1101SH2PWTW4TW4 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
AP1101SH2PWFV6FV6 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
AP1101SH2PWMV6MV6 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
AP1101SH2PWTW6TW6 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
AP1101SH3PWFV4FV40 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1101SH3PWMV4MV40 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1101SH3PWTW4TW40 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1101SH3PWFV6FV60 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1101SH3PWMV6MV60 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1101SH3PWTW6TW60 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1101SH4PWFV4FV400 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1101SH4PWMV4MV400 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1101SH4PWTW4TW400 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1101SH4PWFV6FV600 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1101SH4PWMV6MV600 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1101SH4PWTW6TW600 Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
AP1101H2PWFV4FV4 Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal female
AP1101H2PWMV4MV4 Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 face seal male
AP1101H2PWTW4TW4 Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 1/4 tube weld
AP1101H2PWFV6FV6 Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal female
AP1101H2PWMV6MV6 Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 face seal male
AP1101H2PWTW6TW6 Material: Ni-Cr-Mo body and internals | Ports: 2 ports | Connection: 3/8 tube weld
AP1101H3PWFV4FV40 Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
AP1101H3PWMV4MV40 Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
AP1101H3PWTW4TW40 Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
AP1101H3PWFV6FV60 Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
AP1101H3PWMV6MV60 Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
AP1101H3PWTW6TW60 Material: Ni-Cr-Mo body and internals | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
AP1101H4PWFV4FV400 Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
AP1101H4PWMV4MV400 Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
AP1101H4PWTW4TW400 Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
AP1101H4PWFV6FV600 Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
AP1101H4PWMV6MV600 Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
AP1101H4PWTW6TW600 Material: Ni-Cr-Mo body and internals | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
RegulatorsSMC
72 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AP1100 High-Purity Vacuum Regulator (Negative Pressure Regulation)

Brand SMC·Regulators

Available part numbers (72)

AP1101S2PWFV4FV4, AP1101S2PWMV4MV4, AP1101S2PWTW4TW4, AP1101S2PWFV6FV6, AP1101S2PWMV6MV6, AP1101S2PWTW6TW6, AP1101S3PWFV4FV40, AP1101S3PWMV4MV40, AP1101S3PWTW4TW40, AP1101S3PWFV6FV60 + 62 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
