SMC AP3600 High-Purity Diaphragm Valve (Manual, Cv 0.29)

SMC AP3600 High-Purity Diaphragm Valve (Manual, Cv 0.29)

SMC AP3600 series manual high-purity diaphragm valve (Cv 0.29) for process gas lines up to 20.7 MPa, with a choice of handle styles.

Key features

  • High-purity SUS316L double-melt body, electropolished and passivated; Ni-Co alloy diaphragm, PCTFE seat (polyimide VS option)
  • Manual operation; working pressure vacuum to 3000 psig (20.7 MPa); Cv 0.29
  • Handles: round multi-turn (600), lever 1/4 turn (625), round 1/4 turn with open/close indicator (650), flat round with LOTO (657)
  • 1/4 or 3/8 face seal (female/male) or tube weld connections; body S or H (Ni-Cr-Mo)
  • Indicator switch option ISH (AP3650), panel mount P and VS seat are suffixes

Specifications

Fluid Gases that do not corrode wetted parts
Leakage Inboard 2x10^-11, outboard 2x10^-10 Pa m3/s
Internal finish Ra max 0.4 um (options 0.25/0.18/0.13 um)
Mounting Bottom mount
Working pressure Vacuum to 20.7 MPa
Ambient and fluid temperature -40 to 71 C
Cv 0.29
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP3000_4000.pdf), p. 772-773
AP3600S2PWFV4FV4 Type: Round handle, multi-turn | Body: SUS316L double melt | Connection: 1/4 face seal female
AP3600S2PWMV4MV4 Type: Round handle, multi-turn | Body: SUS316L double melt | Connection: 1/4 face seal male
AP3600S2PWTW4TW4 Type: Round handle, multi-turn | Body: SUS316L double melt | Connection: 1/4 tube weld
AP3600S2PWFV6FV6 Type: Round handle, multi-turn | Body: SUS316L double melt | Connection: 3/8 face seal female
AP3600S2PWMV6MV6 Type: Round handle, multi-turn | Body: SUS316L double melt | Connection: 3/8 face seal male
AP3600S2PWTW6TW6 Type: Round handle, multi-turn | Body: SUS316L double melt | Connection: 3/8 tube weld
AP3600H2PWFV4FV4 Type: Round handle, multi-turn | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal female
AP3600H2PWMV4MV4 Type: Round handle, multi-turn | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal male
AP3600H2PWTW4TW4 Type: Round handle, multi-turn | Body: Ni-Cr-Mo alloy body | Connection: 1/4 tube weld
AP3600H2PWFV6FV6 Type: Round handle, multi-turn | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal female
AP3600H2PWMV6MV6 Type: Round handle, multi-turn | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal male
AP3600H2PWTW6TW6 Type: Round handle, multi-turn | Body: Ni-Cr-Mo alloy body | Connection: 3/8 tube weld
AP3625S2PWFV4FV4 Type: Lever handle, 1/4 turn | Body: SUS316L double melt | Connection: 1/4 face seal female
AP3625S2PWMV4MV4 Type: Lever handle, 1/4 turn | Body: SUS316L double melt | Connection: 1/4 face seal male
AP3625S2PWTW4TW4 Type: Lever handle, 1/4 turn | Body: SUS316L double melt | Connection: 1/4 tube weld
AP3625S2PWFV6FV6 Type: Lever handle, 1/4 turn | Body: SUS316L double melt | Connection: 3/8 face seal female
AP3625S2PWMV6MV6 Type: Lever handle, 1/4 turn | Body: SUS316L double melt | Connection: 3/8 face seal male
AP3625S2PWTW6TW6 Type: Lever handle, 1/4 turn | Body: SUS316L double melt | Connection: 3/8 tube weld
AP3625H2PWFV4FV4 Type: Lever handle, 1/4 turn | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal female
AP3625H2PWMV4MV4 Type: Lever handle, 1/4 turn | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal male
AP3625H2PWTW4TW4 Type: Lever handle, 1/4 turn | Body: Ni-Cr-Mo alloy body | Connection: 1/4 tube weld
AP3625H2PWFV6FV6 Type: Lever handle, 1/4 turn | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal female
AP3625H2PWMV6MV6 Type: Lever handle, 1/4 turn | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal male
AP3625H2PWTW6TW6 Type: Lever handle, 1/4 turn | Body: Ni-Cr-Mo alloy body | Connection: 3/8 tube weld
AP3650S2PWFV4FV4 Type: Round 1/4 turn, indicator | Body: SUS316L double melt | Connection: 1/4 face seal female
AP3650S2PWMV4MV4 Type: Round 1/4 turn, indicator | Body: SUS316L double melt | Connection: 1/4 face seal male
AP3650S2PWTW4TW4 Type: Round 1/4 turn, indicator | Body: SUS316L double melt | Connection: 1/4 tube weld
AP3650S2PWFV6FV6 Type: Round 1/4 turn, indicator | Body: SUS316L double melt | Connection: 3/8 face seal female
AP3650S2PWMV6MV6 Type: Round 1/4 turn, indicator | Body: SUS316L double melt | Connection: 3/8 face seal male
AP3650S2PWTW6TW6 Type: Round 1/4 turn, indicator | Body: SUS316L double melt | Connection: 3/8 tube weld
AP3650H2PWFV4FV4 Type: Round 1/4 turn, indicator | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal female
AP3650H2PWMV4MV4 Type: Round 1/4 turn, indicator | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal male
AP3650H2PWTW4TW4 Type: Round 1/4 turn, indicator | Body: Ni-Cr-Mo alloy body | Connection: 1/4 tube weld
AP3650H2PWFV6FV6 Type: Round 1/4 turn, indicator | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal female
AP3650H2PWMV6MV6 Type: Round 1/4 turn, indicator | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal male
AP3650H2PWTW6TW6 Type: Round 1/4 turn, indicator | Body: Ni-Cr-Mo alloy body | Connection: 3/8 tube weld
AP3657S2PWFV4FV4 Type: Flat round handle, LOTO | Body: SUS316L double melt | Connection: 1/4 face seal female
AP3657S2PWMV4MV4 Type: Flat round handle, LOTO | Body: SUS316L double melt | Connection: 1/4 face seal male
AP3657S2PWTW4TW4 Type: Flat round handle, LOTO | Body: SUS316L double melt | Connection: 1/4 tube weld
AP3657S2PWFV6FV6 Type: Flat round handle, LOTO | Body: SUS316L double melt | Connection: 3/8 face seal female
AP3657S2PWMV6MV6 Type: Flat round handle, LOTO | Body: SUS316L double melt | Connection: 3/8 face seal male
AP3657S2PWTW6TW6 Type: Flat round handle, LOTO | Body: SUS316L double melt | Connection: 3/8 tube weld
AP3657H2PWFV4FV4 Type: Flat round handle, LOTO | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal female
AP3657H2PWMV4MV4 Type: Flat round handle, LOTO | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal male
AP3657H2PWTW4TW4 Type: Flat round handle, LOTO | Body: Ni-Cr-Mo alloy body | Connection: 1/4 tube weld
AP3657H2PWFV6FV6 Type: Flat round handle, LOTO | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal female
AP3657H2PWMV6MV6 Type: Flat round handle, LOTO | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal male
AP3657H2PWTW6TW6 Type: Flat round handle, LOTO | Body: Ni-Cr-Mo alloy body | Connection: 3/8 tube weld
2-Port ValvesSMC
48 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AP3600 High-Purity Diaphragm Valve (Manual, Cv 0.29)

Brand SMC·2-Port Valves

Available part numbers (48)

AP3600S2PWFV4FV4, AP3600S2PWMV4MV4, AP3600S2PWTW4TW4, AP3600S2PWFV6FV6, AP3600S2PWMV6MV6, AP3600S2PWTW6TW6, AP3600H2PWFV4FV4, AP3600H2PWMV4MV4, AP3600H2PWTW4TW4, AP3600H2PWFV6FV6 + 38 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AP3600S2PWFV4FV4Type: Round handle, multi-turn | Body: SUS316L double melt | Connection: 1/4 face seal female
AP3600S2PWMV4MV4Type: Round handle, multi-turn | Body: SUS316L double melt | Connection: 1/4 face seal male
AP3600S2PWTW4TW4Type: Round handle, multi-turn | Body: SUS316L double melt | Connection: 1/4 tube weld
AP3600S2PWFV6FV6Type: Round handle, multi-turn | Body: SUS316L double melt | Connection: 3/8 face seal female
AP3600S2PWMV6MV6Type: Round handle, multi-turn | Body: SUS316L double melt | Connection: 3/8 face seal male
AP3600S2PWTW6TW6Type: Round handle, multi-turn | Body: SUS316L double melt | Connection: 3/8 tube weld
AP3600H2PWFV4FV4Type: Round handle, multi-turn | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal female
AP3600H2PWMV4MV4Type: Round handle, multi-turn | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal male
AP3600H2PWTW4TW4Type: Round handle, multi-turn | Body: Ni-Cr-Mo alloy body | Connection: 1/4 tube weld
AP3600H2PWFV6FV6Type: Round handle, multi-turn | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal female
AP3600H2PWMV6MV6Type: Round handle, multi-turn | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal male
AP3600H2PWTW6TW6Type: Round handle, multi-turn | Body: Ni-Cr-Mo alloy body | Connection: 3/8 tube weld
AP3625S2PWFV4FV4Type: Lever handle, 1/4 turn | Body: SUS316L double melt | Connection: 1/4 face seal female
AP3625S2PWMV4MV4Type: Lever handle, 1/4 turn | Body: SUS316L double melt | Connection: 1/4 face seal male
AP3625S2PWTW4TW4Type: Lever handle, 1/4 turn | Body: SUS316L double melt | Connection: 1/4 tube weld
AP3625S2PWFV6FV6Type: Lever handle, 1/4 turn | Body: SUS316L double melt | Connection: 3/8 face seal female
AP3625S2PWMV6MV6Type: Lever handle, 1/4 turn | Body: SUS316L double melt | Connection: 3/8 face seal male
AP3625S2PWTW6TW6Type: Lever handle, 1/4 turn | Body: SUS316L double melt | Connection: 3/8 tube weld
AP3625H2PWFV4FV4Type: Lever handle, 1/4 turn | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal female
AP3625H2PWMV4MV4Type: Lever handle, 1/4 turn | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal male
AP3625H2PWTW4TW4Type: Lever handle, 1/4 turn | Body: Ni-Cr-Mo alloy body | Connection: 1/4 tube weld
AP3625H2PWFV6FV6Type: Lever handle, 1/4 turn | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal female
AP3625H2PWMV6MV6Type: Lever handle, 1/4 turn | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal male
AP3625H2PWTW6TW6Type: Lever handle, 1/4 turn | Body: Ni-Cr-Mo alloy body | Connection: 3/8 tube weld
AP3650S2PWFV4FV4Type: Round 1/4 turn, indicator | Body: SUS316L double melt | Connection: 1/4 face seal female
AP3650S2PWMV4MV4Type: Round 1/4 turn, indicator | Body: SUS316L double melt | Connection: 1/4 face seal male
AP3650S2PWTW4TW4Type: Round 1/4 turn, indicator | Body: SUS316L double melt | Connection: 1/4 tube weld
AP3650S2PWFV6FV6Type: Round 1/4 turn, indicator | Body: SUS316L double melt | Connection: 3/8 face seal female
AP3650S2PWMV6MV6Type: Round 1/4 turn, indicator | Body: SUS316L double melt | Connection: 3/8 face seal male
AP3650S2PWTW6TW6Type: Round 1/4 turn, indicator | Body: SUS316L double melt | Connection: 3/8 tube weld
AP3650H2PWFV4FV4Type: Round 1/4 turn, indicator | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal female
AP3650H2PWMV4MV4Type: Round 1/4 turn, indicator | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal male
AP3650H2PWTW4TW4Type: Round 1/4 turn, indicator | Body: Ni-Cr-Mo alloy body | Connection: 1/4 tube weld
AP3650H2PWFV6FV6Type: Round 1/4 turn, indicator | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal female
AP3650H2PWMV6MV6Type: Round 1/4 turn, indicator | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal male
AP3650H2PWTW6TW6Type: Round 1/4 turn, indicator | Body: Ni-Cr-Mo alloy body | Connection: 3/8 tube weld
AP3657S2PWFV4FV4Type: Flat round handle, LOTO | Body: SUS316L double melt | Connection: 1/4 face seal female
AP3657S2PWMV4MV4Type: Flat round handle, LOTO | Body: SUS316L double melt | Connection: 1/4 face seal male
AP3657S2PWTW4TW4Type: Flat round handle, LOTO | Body: SUS316L double melt | Connection: 1/4 tube weld
AP3657S2PWFV6FV6Type: Flat round handle, LOTO | Body: SUS316L double melt | Connection: 3/8 face seal female
AP3657S2PWMV6MV6Type: Flat round handle, LOTO | Body: SUS316L double melt | Connection: 3/8 face seal male
AP3657S2PWTW6TW6Type: Flat round handle, LOTO | Body: SUS316L double melt | Connection: 3/8 tube weld
AP3657H2PWFV4FV4Type: Flat round handle, LOTO | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal female
AP3657H2PWMV4MV4Type: Flat round handle, LOTO | Body: Ni-Cr-Mo alloy body | Connection: 1/4 face seal male
AP3657H2PWTW4TW4Type: Flat round handle, LOTO | Body: Ni-Cr-Mo alloy body | Connection: 1/4 tube weld
AP3657H2PWFV6FV6Type: Flat round handle, LOTO | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal female
AP3657H2PWMV6MV6Type: Flat round handle, LOTO | Body: Ni-Cr-Mo alloy body | Connection: 3/8 face seal male
AP3657H2PWTW6TW6Type: Flat round handle, LOTO | Body: Ni-Cr-Mo alloy body | Connection: 3/8 tube weld

Need a different model, or a part not listed here? Send us your parts list →
