SMC AP500 High-Purity Miniature Regulator (Single-Stage, 1/4 Face Seal)

SMC AP500 High-Purity Miniature Regulator (Single-Stage, 1/4 Face Seal)

SMC AP500 series compact single-stage high-purity regulator for process gas supply lines, with standard flow below 15 slpm and an optional vacuum-regulation version for low vapour-pressure gases.

Key features

  • High-purity SUS316L double-melt body, electropolished and passivated; precision cleaned and helium leak tested
  • Flow range below 15 slpm (HF option below 30 slpm); Cv 0.06 (HF 0.1)
  • Set pressure ranges 0.07 to 0.7 MPa plus vacuum-regulation version AP501..A (-88 kPa to 0.07 MPa)
  • 2-port (2PW) or 3-port body with outlet gauge port (3PWG); 1/4 face seal female/male or tube weld connections
  • SH material: Ni-Cr-Mo alloy poppet for corrosive gases; friction damper (FI) option stabilises downstream MFC control
  • Listed 3PWG codes carry an MV4 gauge port without gauge; gauges (V3, L, 1), seat VS/TF, FI/HF and MPA scale are suffixes

Specifications

Fluid Gases that do not corrode wetted parts
Leakage Inboard 2x10^-11, outboard 2x10^-10 Pa m3/s
Ambient and fluid temperature -40 to 71 C (no freezing)
Inlet pressure Vacuum to 1.0 MPa
Internal finish Ra max 0.4 um (options 0.25/0.18/0.13 um)
Pressure characteristic 0.0014 MPa rise per 0.14 MPa inlet drop
Internal volume 2.4 cm3
Mass 0.45 kg
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP_SL_AZ_AK_BP.pdf), p. 666-667
AP501S2PWFV4FV4 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP501S2PWMV4MV4 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP501S2PWTW4TW4 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP501S3PWGFV4FV4MV4 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP501S3PWGMV4MV4MV4 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP501S3PWGTW4TW4MV4 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP501SH2PWFV4FV4 Set pressure: 0.0034 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP501SH2PWMV4MV4 Set pressure: 0.0034 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP501SH2PWTW4TW4 Set pressure: 0.0034 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP501SH3PWGFV4FV4MV4 Set pressure: 0.0034 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP501SH3PWGMV4MV4MV4 Set pressure: 0.0034 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP501SH3PWGTW4TW4MV4 Set pressure: 0.0034 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP502S2PWFV4FV4 Set pressure: 0.0034 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP502S2PWMV4MV4 Set pressure: 0.0034 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP502S2PWTW4TW4 Set pressure: 0.0034 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP502S3PWGFV4FV4MV4 Set pressure: 0.0034 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP502S3PWGMV4MV4MV4 Set pressure: 0.0034 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP502S3PWGTW4TW4MV4 Set pressure: 0.0034 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP502SH2PWFV4FV4 Set pressure: 0.0034 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP502SH2PWMV4MV4 Set pressure: 0.0034 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP502SH2PWTW4TW4 Set pressure: 0.0034 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP502SH3PWGFV4FV4MV4 Set pressure: 0.0034 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP502SH3PWGMV4MV4MV4 Set pressure: 0.0034 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP502SH3PWGTW4TW4MV4 Set pressure: 0.0034 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP506S2PWFV4FV4 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP506S2PWMV4MV4 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP506S2PWTW4TW4 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP506S3PWGFV4FV4MV4 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP506S3PWGMV4MV4MV4 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP506S3PWGTW4TW4MV4 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP506SH2PWFV4FV4 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP506SH2PWMV4MV4 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP506SH2PWTW4TW4 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP506SH3PWGFV4FV4MV4 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP506SH3PWGMV4MV4MV4 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP506SH3PWGTW4TW4MV4 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP510S2PWFV4FV4 Set pressure: 0.007 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP510S2PWMV4MV4 Set pressure: 0.007 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP510S2PWTW4TW4 Set pressure: 0.007 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP510S3PWGFV4FV4MV4 Set pressure: 0.007 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP510S3PWGMV4MV4MV4 Set pressure: 0.007 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP510S3PWGTW4TW4MV4 Set pressure: 0.007 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP510SH2PWFV4FV4 Set pressure: 0.007 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP510SH2PWMV4MV4 Set pressure: 0.007 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP510SH2PWTW4TW4 Set pressure: 0.007 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP510SH3PWGFV4FV4MV4 Set pressure: 0.007 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP510SH3PWGMV4MV4MV4 Set pressure: 0.007 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP510SH3PWGTW4TW4MV4 Set pressure: 0.007 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP501SA2PWFV4FV4 Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP501SA2PWMV4MV4 Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP501SA2PWTW4TW4 Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP501SA3PWGFV4FV4MV4 Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP501SA3PWGMV4MV4MV4 Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP501SA3PWGTW4TW4MV4 Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP501SHA2PWFV4FV4 Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP501SHA2PWMV4MV4 Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP501SHA2PWTW4TW4 Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP501SHA3PWGFV4FV4MV4 Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP501SHA3PWGMV4MV4MV4 Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP501SHA3PWGTW4TW4MV4 Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
RegulatorsSMC
60 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AP500 High-Purity Miniature Regulator (Single-Stage, 1/4 Face Seal)

Brand SMC·Regulators

Available part numbers (60)

AP501S2PWFV4FV4, AP501S2PWMV4MV4, AP501S2PWTW4TW4, AP501S3PWGFV4FV4MV4, AP501S3PWGMV4MV4MV4, AP501S3PWGTW4TW4MV4, AP501SH2PWFV4FV4, AP501SH2PWMV4MV4, AP501SH2PWTW4TW4, AP501SH3PWGFV4FV4MV4 + 50 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AP501S2PWFV4FV4Set pressure: 0.0034 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP501S2PWMV4MV4Set pressure: 0.0034 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP501S2PWTW4TW4Set pressure: 0.0034 to 0.07 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP501S3PWGFV4FV4MV4Set pressure: 0.0034 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP501S3PWGMV4MV4MV4Set pressure: 0.0034 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP501S3PWGTW4TW4MV4Set pressure: 0.0034 to 0.07 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP501SH2PWFV4FV4Set pressure: 0.0034 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP501SH2PWMV4MV4Set pressure: 0.0034 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP501SH2PWTW4TW4Set pressure: 0.0034 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP501SH3PWGFV4FV4MV4Set pressure: 0.0034 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP501SH3PWGMV4MV4MV4Set pressure: 0.0034 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP501SH3PWGTW4TW4MV4Set pressure: 0.0034 to 0.07 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP502S2PWFV4FV4Set pressure: 0.0034 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP502S2PWMV4MV4Set pressure: 0.0034 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP502S2PWTW4TW4Set pressure: 0.0034 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP502S3PWGFV4FV4MV4Set pressure: 0.0034 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP502S3PWGMV4MV4MV4Set pressure: 0.0034 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP502S3PWGTW4TW4MV4Set pressure: 0.0034 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP502SH2PWFV4FV4Set pressure: 0.0034 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP502SH2PWMV4MV4Set pressure: 0.0034 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP502SH2PWTW4TW4Set pressure: 0.0034 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP502SH3PWGFV4FV4MV4Set pressure: 0.0034 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP502SH3PWGMV4MV4MV4Set pressure: 0.0034 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP502SH3PWGTW4TW4MV4Set pressure: 0.0034 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP506S2PWFV4FV4Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP506S2PWMV4MV4Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP506S2PWTW4TW4Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP506S3PWGFV4FV4MV4Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP506S3PWGMV4MV4MV4Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP506S3PWGTW4TW4MV4Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP506SH2PWFV4FV4Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP506SH2PWMV4MV4Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP506SH2PWTW4TW4Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP506SH3PWGFV4FV4MV4Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP506SH3PWGMV4MV4MV4Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP506SH3PWGTW4TW4MV4Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP510S2PWFV4FV4Set pressure: 0.007 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP510S2PWMV4MV4Set pressure: 0.007 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP510S2PWTW4TW4Set pressure: 0.007 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP510S3PWGFV4FV4MV4Set pressure: 0.007 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP510S3PWGMV4MV4MV4Set pressure: 0.007 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP510S3PWGTW4TW4MV4Set pressure: 0.007 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP510SH2PWFV4FV4Set pressure: 0.007 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP510SH2PWMV4MV4Set pressure: 0.007 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP510SH2PWTW4TW4Set pressure: 0.007 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP510SH3PWGFV4FV4MV4Set pressure: 0.007 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP510SH3PWGMV4MV4MV4Set pressure: 0.007 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP510SH3PWGTW4TW4MV4Set pressure: 0.007 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP501SA2PWFV4FV4Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
AP501SA2PWMV4MV4Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
AP501SA2PWTW4TW4Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
AP501SA3PWGFV4FV4MV4Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP501SA3PWGMV4MV4MV4Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP501SA3PWGTW4TW4MV4Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
AP501SHA2PWFV4FV4Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
AP501SHA2PWMV4MV4Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
AP501SHA2PWTW4TW4Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
AP501SHA3PWGFV4FV4MV4Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal female
AP501SHA3PWGMV4MV4MV4Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 face seal male
AP501SHA3PWGTW4TW4MV4Set pressure: -88 kPa to 0.07 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet | Ports: 3 ports (OUT gauge port) | Connection: 1/4 tube weld
