SMC AS-D In-line Speed Controller, Screwdriver Adjust (One-touch)

SMC AS001F-D series in-line speed controller with one-touch fittings on both ends, adjusted with a flat-blade screwdriver to prevent careless manual changes of the flow setting.

Key features

Needle adjusted with a flat-blade screwdriver; no handle to turn by hand
In-line body with one-touch fittings both ends for tube-to-tube installation
Five sizes AS1001F to AS4001F, metric tube ø3.2 to ø12 mm and inch tube ø1/8 to ø1/2 in
Flow up to 1390 L/min (ANR) at 0.5 MPa (AS4001F ø12)
Made to order: -X12 (vaseline), -X21 (grease-free + orifice valve), -X214 (orifice valve)

Specifications

Fluid	Air
Proof pressure	1.5 MPa
Max. operating pressure	1 MPa
Min. operating pressure	0.1 MPa
Ambient and fluid temperature	-5 to 60°C (no freezing)
Adjustment	Flat-blade screwdriver (D type)
Body type	In-line, one-touch fitting both ends
Applicable tubing	Nylon, soft nylon, polyurethane
Source	SMC Korea catalog AS-D (SMCKR_AS________-D.pdf), PDF p. 7-10

AS1001F-23D		Body size: AS1001F \| Tube OD: ø3.2 mm (use ø1/8 in) \| Tube sizing: Metric
AS1001F-04D		Body size: AS1001F \| Tube OD: ø4 mm \| Tube sizing: Metric
AS1001F-06D		Body size: AS1001F \| Tube OD: ø6 mm \| Tube sizing: Metric
AS1001F-01D		Body size: AS1001F \| Tube OD: ø1/8 in \| Tube sizing: Inch
AS1001F-03D		Body size: AS1001F \| Tube OD: ø5/32 in \| Tube sizing: Inch
AS1001F-05D		Body size: AS1001F \| Tube OD: ø3/16 in \| Tube sizing: Inch
AS1001F-07D		Body size: AS1001F \| Tube OD: ø1/4 in \| Tube sizing: Inch
AS2001F-04D		Body size: AS2001F \| Tube OD: ø4 mm \| Tube sizing: Metric
AS2001F-06D		Body size: AS2001F \| Tube OD: ø6 mm \| Tube sizing: Metric
AS2001F-03D		Body size: AS2001F \| Tube OD: ø5/32 in \| Tube sizing: Inch
AS2001F-05D		Body size: AS2001F \| Tube OD: ø3/16 in \| Tube sizing: Inch
AS2001F-07D		Body size: AS2001F \| Tube OD: ø1/4 in \| Tube sizing: Inch
AS2051F-06D		Body size: AS2051F \| Tube OD: ø6 mm \| Tube sizing: Metric
AS2051F-08D		Body size: AS2051F \| Tube OD: ø8 mm \| Tube sizing: Metric
AS2051F-05D		Body size: AS2051F \| Tube OD: ø3/16 in \| Tube sizing: Inch
AS2051F-07D		Body size: AS2051F \| Tube OD: ø1/4 in \| Tube sizing: Inch
AS2051F-09D		Body size: AS2051F \| Tube OD: ø5/16 in \| Tube sizing: Inch
AS3001F-06D		Body size: AS3001F \| Tube OD: ø6 mm \| Tube sizing: Metric
AS3001F-08D		Body size: AS3001F \| Tube OD: ø8 mm \| Tube sizing: Metric
AS3001F-10D		Body size: AS3001F \| Tube OD: ø10 mm \| Tube sizing: Metric
AS3001F-12D		Body size: AS3001F \| Tube OD: ø12 mm \| Tube sizing: Metric
AS3001F-07D		Body size: AS3001F \| Tube OD: ø1/4 in \| Tube sizing: Inch
AS3001F-09D		Body size: AS3001F \| Tube OD: ø5/16 in \| Tube sizing: Inch
AS3001F-11D		Body size: AS3001F \| Tube OD: ø3/8 in \| Tube sizing: Inch
AS4001F-10D		Body size: AS4001F \| Tube OD: ø10 mm \| Tube sizing: Metric
AS4001F-12D		Body size: AS4001F \| Tube OD: ø12 mm \| Tube sizing: Metric
AS4001F-11D		Body size: AS4001F \| Tube OD: ø3/8 in \| Tube sizing: Inch
AS4001F-13D		Body size: AS4001F \| Tube OD: ø1/2 in \| Tube sizing: Inch

Speed ControllersSMC

28 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AS-D In-line Speed Controller, Screwdriver Adjust (One-touch)

Brand SMC·Speed Controllers

Available part numbers (28)

AS1001F-23D, AS1001F-04D, AS1001F-06D, AS1001F-01D, AS1001F-03D, AS1001F-05D, AS1001F-07D, AS2001F-04D, AS2001F-06D, AS2001F-03D + 18 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
