SMC AS-FE Speed Controller with Residual Exhaust Valve, One-touch

SMC AS-FE Speed Controller with Residual Exhaust Valve, One-touch

SMC AS1FE series speed controller with built-in residual pressure exhaust valve and one-touch fitting, releasing trapped cylinder pressure with a single push.

Key features

  • Residual pressure exhausted with one push of the red push button
  • Elbow (AS21FE) and universal (AS31FE) types
  • Body sizes 2 to 4 for R1/8, R1/4, R3/8 and R1/2 ports, tube OD ø4 to ø12 mm
  • Meter-out (electroless Ni lock nut) and meter-in (black zinc chromate lock nut) versions
  • Made to order: -X12 (vaseline), -X21 (grease-free + orifice valve), -X214 (orifice valve)

Specifications

Fluid Air
Proof pressure 1.5 MPa
Max. operating pressure 1.0 MPa
Min. operating pressure 0.1 MPa
Ambient and fluid temperature -5 to 60°C (no freezing)
Residual exhaust valve C 0.16 dm³/(s·bar)
Applicable tubing Nylon, soft nylon, polyurethane
Seal / lock nut Sealant (S), hex lock nut (K)
Source SMC Korea catalog AS-FE (SMCKR_AS________E_FE.pdf), p. 658-661
AS2201FE-01-04SK Body type: Elbow | Control: Meter-out | Port: R1/8 | Tube OD: ø4 mm
AS2211FE-01-04SK Body type: Elbow | Control: Meter-in | Port: R1/8 | Tube OD: ø4 mm
AS2201FE-01-06SK Body type: Elbow | Control: Meter-out | Port: R1/8 | Tube OD: ø6 mm
AS2211FE-01-06SK Body type: Elbow | Control: Meter-in | Port: R1/8 | Tube OD: ø6 mm
AS2201FE-01-08SK Body type: Elbow | Control: Meter-out | Port: R1/8 | Tube OD: ø8 mm
AS2211FE-01-08SK Body type: Elbow | Control: Meter-in | Port: R1/8 | Tube OD: ø8 mm
AS2201FE-01-10SK Body type: Elbow | Control: Meter-out | Port: R1/8 | Tube OD: ø10 mm
AS2211FE-01-10SK Body type: Elbow | Control: Meter-in | Port: R1/8 | Tube OD: ø10 mm
AS2201FE-02-04SK Body type: Elbow | Control: Meter-out | Port: R1/4 | Tube OD: ø4 mm
AS2211FE-02-04SK Body type: Elbow | Control: Meter-in | Port: R1/4 | Tube OD: ø4 mm
AS2201FE-02-06SK Body type: Elbow | Control: Meter-out | Port: R1/4 | Tube OD: ø6 mm
AS2211FE-02-06SK Body type: Elbow | Control: Meter-in | Port: R1/4 | Tube OD: ø6 mm
AS2201FE-02-08SK Body type: Elbow | Control: Meter-out | Port: R1/4 | Tube OD: ø8 mm
AS2211FE-02-08SK Body type: Elbow | Control: Meter-in | Port: R1/4 | Tube OD: ø8 mm
AS2201FE-02-10SK Body type: Elbow | Control: Meter-out | Port: R1/4 | Tube OD: ø10 mm
AS2211FE-02-10SK Body type: Elbow | Control: Meter-in | Port: R1/4 | Tube OD: ø10 mm
AS3201FE-03-06SK Body type: Elbow | Control: Meter-out | Port: R3/8 | Tube OD: ø6 mm
AS3211FE-03-06SK Body type: Elbow | Control: Meter-in | Port: R3/8 | Tube OD: ø6 mm
AS3201FE-03-08SK Body type: Elbow | Control: Meter-out | Port: R3/8 | Tube OD: ø8 mm
AS3211FE-03-08SK Body type: Elbow | Control: Meter-in | Port: R3/8 | Tube OD: ø8 mm
AS3201FE-03-10SK Body type: Elbow | Control: Meter-out | Port: R3/8 | Tube OD: ø10 mm
AS3211FE-03-10SK Body type: Elbow | Control: Meter-in | Port: R3/8 | Tube OD: ø10 mm
AS3201FE-03-12SK Body type: Elbow | Control: Meter-out | Port: R3/8 | Tube OD: ø12 mm
AS3211FE-03-12SK Body type: Elbow | Control: Meter-in | Port: R3/8 | Tube OD: ø12 mm
AS4201FE-04-10SK Body type: Elbow | Control: Meter-out | Port: R1/2 | Tube OD: ø10 mm
AS4211FE-04-10SK Body type: Elbow | Control: Meter-in | Port: R1/2 | Tube OD: ø10 mm
AS4201FE-04-12SK Body type: Elbow | Control: Meter-out | Port: R1/2 | Tube OD: ø12 mm
AS4211FE-04-12SK Body type: Elbow | Control: Meter-in | Port: R1/2 | Tube OD: ø12 mm
AS2301FE-01-04SK Body type: Universal | Control: Meter-out | Port: R1/8 | Tube OD: ø4 mm
AS2311FE-01-04SK Body type: Universal | Control: Meter-in | Port: R1/8 | Tube OD: ø4 mm
AS2301FE-01-06SK Body type: Universal | Control: Meter-out | Port: R1/8 | Tube OD: ø6 mm
AS2311FE-01-06SK Body type: Universal | Control: Meter-in | Port: R1/8 | Tube OD: ø6 mm
AS2301FE-01-08SK Body type: Universal | Control: Meter-out | Port: R1/8 | Tube OD: ø8 mm
AS2311FE-01-08SK Body type: Universal | Control: Meter-in | Port: R1/8 | Tube OD: ø8 mm
AS2301FE-02-04SK Body type: Universal | Control: Meter-out | Port: R1/4 | Tube OD: ø4 mm
AS2311FE-02-04SK Body type: Universal | Control: Meter-in | Port: R1/4 | Tube OD: ø4 mm
AS2301FE-02-06SK Body type: Universal | Control: Meter-out | Port: R1/4 | Tube OD: ø6 mm
AS2311FE-02-06SK Body type: Universal | Control: Meter-in | Port: R1/4 | Tube OD: ø6 mm
AS2301FE-02-08SK Body type: Universal | Control: Meter-out | Port: R1/4 | Tube OD: ø8 mm
AS2311FE-02-08SK Body type: Universal | Control: Meter-in | Port: R1/4 | Tube OD: ø8 mm
AS2301FE-02-10SK Body type: Universal | Control: Meter-out | Port: R1/4 | Tube OD: ø10 mm
AS2311FE-02-10SK Body type: Universal | Control: Meter-in | Port: R1/4 | Tube OD: ø10 mm
AS3301FE-03-06SK Body type: Universal | Control: Meter-out | Port: R3/8 | Tube OD: ø6 mm
AS3311FE-03-06SK Body type: Universal | Control: Meter-in | Port: R3/8 | Tube OD: ø6 mm
AS3301FE-03-08SK Body type: Universal | Control: Meter-out | Port: R3/8 | Tube OD: ø8 mm
AS3311FE-03-08SK Body type: Universal | Control: Meter-in | Port: R3/8 | Tube OD: ø8 mm
AS3301FE-03-10SK Body type: Universal | Control: Meter-out | Port: R3/8 | Tube OD: ø10 mm
AS3311FE-03-10SK Body type: Universal | Control: Meter-in | Port: R3/8 | Tube OD: ø10 mm
AS3301FE-03-12SK Body type: Universal | Control: Meter-out | Port: R3/8 | Tube OD: ø12 mm
AS3311FE-03-12SK Body type: Universal | Control: Meter-in | Port: R3/8 | Tube OD: ø12 mm
AS4301FE-04-10SK Body type: Universal | Control: Meter-out | Port: R1/2 | Tube OD: ø10 mm
AS4311FE-04-10SK Body type: Universal | Control: Meter-in | Port: R1/2 | Tube OD: ø10 mm
AS4301FE-04-12SK Body type: Universal | Control: Meter-out | Port: R1/2 | Tube OD: ø12 mm
AS4311FE-04-12SK Body type: Universal | Control: Meter-in | Port: R1/2 | Tube OD: ø12 mm
Speed ControllersSMC
54 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AS-FE Speed Controller with Residual Exhaust Valve, One-touch

Brand SMC·Speed Controllers

Available part numbers (54)

AS2201FE-01-04SK, AS2211FE-01-04SK, AS2201FE-01-06SK, AS2211FE-01-06SK, AS2201FE-01-08SK, AS2211FE-01-08SK, AS2201FE-01-10SK, AS2211FE-01-10SK, AS2201FE-02-04SK, AS2211FE-02-04SK + 44 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AS2201FE-01-04SKBody type: Elbow | Control: Meter-out | Port: R1/8 | Tube OD: ø4 mm
AS2211FE-01-04SKBody type: Elbow | Control: Meter-in | Port: R1/8 | Tube OD: ø4 mm
AS2201FE-01-06SKBody type: Elbow | Control: Meter-out | Port: R1/8 | Tube OD: ø6 mm
AS2211FE-01-06SKBody type: Elbow | Control: Meter-in | Port: R1/8 | Tube OD: ø6 mm
AS2201FE-01-08SKBody type: Elbow | Control: Meter-out | Port: R1/8 | Tube OD: ø8 mm
AS2211FE-01-08SKBody type: Elbow | Control: Meter-in | Port: R1/8 | Tube OD: ø8 mm
AS2201FE-01-10SKBody type: Elbow | Control: Meter-out | Port: R1/8 | Tube OD: ø10 mm
AS2211FE-01-10SKBody type: Elbow | Control: Meter-in | Port: R1/8 | Tube OD: ø10 mm
AS2201FE-02-04SKBody type: Elbow | Control: Meter-out | Port: R1/4 | Tube OD: ø4 mm
AS2211FE-02-04SKBody type: Elbow | Control: Meter-in | Port: R1/4 | Tube OD: ø4 mm
AS2201FE-02-06SKBody type: Elbow | Control: Meter-out | Port: R1/4 | Tube OD: ø6 mm
AS2211FE-02-06SKBody type: Elbow | Control: Meter-in | Port: R1/4 | Tube OD: ø6 mm
AS2201FE-02-08SKBody type: Elbow | Control: Meter-out | Port: R1/4 | Tube OD: ø8 mm
AS2211FE-02-08SKBody type: Elbow | Control: Meter-in | Port: R1/4 | Tube OD: ø8 mm
AS2201FE-02-10SKBody type: Elbow | Control: Meter-out | Port: R1/4 | Tube OD: ø10 mm
AS2211FE-02-10SKBody type: Elbow | Control: Meter-in | Port: R1/4 | Tube OD: ø10 mm
AS3201FE-03-06SKBody type: Elbow | Control: Meter-out | Port: R3/8 | Tube OD: ø6 mm
AS3211FE-03-06SKBody type: Elbow | Control: Meter-in | Port: R3/8 | Tube OD: ø6 mm
AS3201FE-03-08SKBody type: Elbow | Control: Meter-out | Port: R3/8 | Tube OD: ø8 mm
AS3211FE-03-08SKBody type: Elbow | Control: Meter-in | Port: R3/8 | Tube OD: ø8 mm
AS3201FE-03-10SKBody type: Elbow | Control: Meter-out | Port: R3/8 | Tube OD: ø10 mm
AS3211FE-03-10SKBody type: Elbow | Control: Meter-in | Port: R3/8 | Tube OD: ø10 mm
AS3201FE-03-12SKBody type: Elbow | Control: Meter-out | Port: R3/8 | Tube OD: ø12 mm
AS3211FE-03-12SKBody type: Elbow | Control: Meter-in | Port: R3/8 | Tube OD: ø12 mm
AS4201FE-04-10SKBody type: Elbow | Control: Meter-out | Port: R1/2 | Tube OD: ø10 mm
AS4211FE-04-10SKBody type: Elbow | Control: Meter-in | Port: R1/2 | Tube OD: ø10 mm
AS4201FE-04-12SKBody type: Elbow | Control: Meter-out | Port: R1/2 | Tube OD: ø12 mm
AS4211FE-04-12SKBody type: Elbow | Control: Meter-in | Port: R1/2 | Tube OD: ø12 mm
AS2301FE-01-04SKBody type: Universal | Control: Meter-out | Port: R1/8 | Tube OD: ø4 mm
AS2311FE-01-04SKBody type: Universal | Control: Meter-in | Port: R1/8 | Tube OD: ø4 mm
AS2301FE-01-06SKBody type: Universal | Control: Meter-out | Port: R1/8 | Tube OD: ø6 mm
AS2311FE-01-06SKBody type: Universal | Control: Meter-in | Port: R1/8 | Tube OD: ø6 mm
AS2301FE-01-08SKBody type: Universal | Control: Meter-out | Port: R1/8 | Tube OD: ø8 mm
AS2311FE-01-08SKBody type: Universal | Control: Meter-in | Port: R1/8 | Tube OD: ø8 mm
AS2301FE-02-04SKBody type: Universal | Control: Meter-out | Port: R1/4 | Tube OD: ø4 mm
AS2311FE-02-04SKBody type: Universal | Control: Meter-in | Port: R1/4 | Tube OD: ø4 mm
AS2301FE-02-06SKBody type: Universal | Control: Meter-out | Port: R1/4 | Tube OD: ø6 mm
AS2311FE-02-06SKBody type: Universal | Control: Meter-in | Port: R1/4 | Tube OD: ø6 mm
AS2301FE-02-08SKBody type: Universal | Control: Meter-out | Port: R1/4 | Tube OD: ø8 mm
AS2311FE-02-08SKBody type: Universal | Control: Meter-in | Port: R1/4 | Tube OD: ø8 mm
AS2301FE-02-10SKBody type: Universal | Control: Meter-out | Port: R1/4 | Tube OD: ø10 mm
AS2311FE-02-10SKBody type: Universal | Control: Meter-in | Port: R1/4 | Tube OD: ø10 mm
AS3301FE-03-06SKBody type: Universal | Control: Meter-out | Port: R3/8 | Tube OD: ø6 mm
AS3311FE-03-06SKBody type: Universal | Control: Meter-in | Port: R3/8 | Tube OD: ø6 mm
AS3301FE-03-08SKBody type: Universal | Control: Meter-out | Port: R3/8 | Tube OD: ø8 mm
AS3311FE-03-08SKBody type: Universal | Control: Meter-in | Port: R3/8 | Tube OD: ø8 mm
AS3301FE-03-10SKBody type: Universal | Control: Meter-out | Port: R3/8 | Tube OD: ø10 mm
AS3311FE-03-10SKBody type: Universal | Control: Meter-in | Port: R3/8 | Tube OD: ø10 mm
AS3301FE-03-12SKBody type: Universal | Control: Meter-out | Port: R3/8 | Tube OD: ø12 mm
AS3311FE-03-12SKBody type: Universal | Control: Meter-in | Port: R3/8 | Tube OD: ø12 mm
AS4301FE-04-10SKBody type: Universal | Control: Meter-out | Port: R1/2 | Tube OD: ø10 mm
AS4311FE-04-10SKBody type: Universal | Control: Meter-in | Port: R1/2 | Tube OD: ø10 mm
AS4301FE-04-12SKBody type: Universal | Control: Meter-out | Port: R1/2 | Tube OD: ø12 mm
AS4311FE-04-12SKBody type: Universal | Control: Meter-in | Port: R1/2 | Tube OD: ø12 mm
