SMC AS-FG Stainless Inline Speed Controller (Push-Lock)

SMC AS-FG Stainless Inline Speed Controller (Push-Lock)

SMC AS2FG-A stainless steel inline speed controllers with one-touch fittings on both ends and a push-lock handle.

Key features

  • Metal parts in stainless steel (SUS303) for corrosive or copper-free environments
  • Push-lock handle for one-push needle locking and easy fine adjustment
  • Face-contact rotation stopper gives repeatable flow versus handle turns
  • Same flow characteristics and mounting options as the brass AS-A inline series
  • White release bushing (metric and inch)

Specifications

Fluid Air
Proof pressure 1.5 MPa
Max. operating pressure 1 MPa
Min. operating pressure 0.1 MPa
Ambient and fluid temperature -5 to 60 °C (no freezing)
Applicable tubing Nylon, soft nylon, polyurethane, FEP, PFA
Metal parts material Stainless steel (SUS303)
Release bushing colour White
Options (not expanded) -X12, -X21, -X214, 10- (clean)
Source SMC Korea catalog CAT.KS20-243C (SMCKR_AS_inline_push_.pdf), p. 9-13
AS1002FG-23A Body size: AS1002FG (M5 class) | Tube OD: ø3.2 mm | Tube sizing: Metric
AS1002FG-04A Body size: AS1002FG (M5 class) | Tube OD: ø4 mm | Tube sizing: Metric
AS1002FG-06A Body size: AS1002FG (M5 class) | Tube OD: ø6 mm | Tube sizing: Metric
AS1002FG-01A Body size: AS1002FG (M5 class) | Tube OD: ø1/8 in | Tube sizing: Inch
AS1002FG-03A Body size: AS1002FG (M5 class) | Tube OD: ø5/32 in | Tube sizing: Inch
AS1002FG-07A Body size: AS1002FG (M5 class) | Tube OD: ø1/4 in | Tube sizing: Inch
AS2002FG-04A Body size: AS2002FG (1/8 class) | Tube OD: ø4 mm | Tube sizing: Metric
AS2002FG-06A Body size: AS2002FG (1/8 class) | Tube OD: ø6 mm | Tube sizing: Metric
AS2002FG-03A Body size: AS2002FG (1/8 class) | Tube OD: ø5/32 in | Tube sizing: Inch
AS2002FG-07A Body size: AS2002FG (1/8 class) | Tube OD: ø1/4 in | Tube sizing: Inch
AS2052FG-06A Body size: AS2052FG (1/4 class) | Tube OD: ø6 mm | Tube sizing: Metric
AS2052FG-08A Body size: AS2052FG (1/4 class) | Tube OD: ø8 mm | Tube sizing: Metric
AS2052FG-07A Body size: AS2052FG (1/4 class) | Tube OD: ø1/4 in | Tube sizing: Inch
AS2052FG-09A Body size: AS2052FG (1/4 class) | Tube OD: ø5/16 in | Tube sizing: Inch
AS3002FG-06A Body size: AS3002FG (3/8 class) | Tube OD: ø6 mm | Tube sizing: Metric
AS3002FG-08A Body size: AS3002FG (3/8 class) | Tube OD: ø8 mm | Tube sizing: Metric
AS3002FG-10A Body size: AS3002FG (3/8 class) | Tube OD: ø10 mm | Tube sizing: Metric
AS3002FG-12A Body size: AS3002FG (3/8 class) | Tube OD: ø12 mm | Tube sizing: Metric
AS3002FG-07A Body size: AS3002FG (3/8 class) | Tube OD: ø1/4 in | Tube sizing: Inch
AS3002FG-09A Body size: AS3002FG (3/8 class) | Tube OD: ø5/16 in | Tube sizing: Inch
AS3002FG-11A Body size: AS3002FG (3/8 class) | Tube OD: ø3/8 in | Tube sizing: Inch
AS4002FG-10A Body size: AS4002FG (1/2 class) | Tube OD: ø10 mm | Tube sizing: Metric
AS4002FG-12A Body size: AS4002FG (1/2 class) | Tube OD: ø12 mm | Tube sizing: Metric
AS4002FG-11A Body size: AS4002FG (1/2 class) | Tube OD: ø3/8 in | Tube sizing: Inch
AS4002FG-13A Body size: AS4002FG (1/2 class) | Tube OD: ø1/2 in | Tube sizing: Inch
Speed ControllersSMC
25 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AS-FG Stainless Inline Speed Controller (Push-Lock)

Brand SMC·Speed Controllers

Available part numbers (25)

AS1002FG-23A, AS1002FG-04A, AS1002FG-06A, AS1002FG-01A, AS1002FG-03A, AS1002FG-07A, AS2002FG-04A, AS2002FG-06A, AS2002FG-03A, AS2002FG-07A + 15 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AS1002FG-23ABody size: AS1002FG (M5 class) | Tube OD: ø3.2 mm | Tube sizing: Metric
AS1002FG-04ABody size: AS1002FG (M5 class) | Tube OD: ø4 mm | Tube sizing: Metric
AS1002FG-06ABody size: AS1002FG (M5 class) | Tube OD: ø6 mm | Tube sizing: Metric
AS1002FG-01ABody size: AS1002FG (M5 class) | Tube OD: ø1/8 in | Tube sizing: Inch
AS1002FG-03ABody size: AS1002FG (M5 class) | Tube OD: ø5/32 in | Tube sizing: Inch
AS1002FG-07ABody size: AS1002FG (M5 class) | Tube OD: ø1/4 in | Tube sizing: Inch
AS2002FG-04ABody size: AS2002FG (1/8 class) | Tube OD: ø4 mm | Tube sizing: Metric
AS2002FG-06ABody size: AS2002FG (1/8 class) | Tube OD: ø6 mm | Tube sizing: Metric
AS2002FG-03ABody size: AS2002FG (1/8 class) | Tube OD: ø5/32 in | Tube sizing: Inch
AS2002FG-07ABody size: AS2002FG (1/8 class) | Tube OD: ø1/4 in | Tube sizing: Inch
AS2052FG-06ABody size: AS2052FG (1/4 class) | Tube OD: ø6 mm | Tube sizing: Metric
AS2052FG-08ABody size: AS2052FG (1/4 class) | Tube OD: ø8 mm | Tube sizing: Metric
AS2052FG-07ABody size: AS2052FG (1/4 class) | Tube OD: ø1/4 in | Tube sizing: Inch
AS2052FG-09ABody size: AS2052FG (1/4 class) | Tube OD: ø5/16 in | Tube sizing: Inch
AS3002FG-06ABody size: AS3002FG (3/8 class) | Tube OD: ø6 mm | Tube sizing: Metric
AS3002FG-08ABody size: AS3002FG (3/8 class) | Tube OD: ø8 mm | Tube sizing: Metric
AS3002FG-10ABody size: AS3002FG (3/8 class) | Tube OD: ø10 mm | Tube sizing: Metric
AS3002FG-12ABody size: AS3002FG (3/8 class) | Tube OD: ø12 mm | Tube sizing: Metric
AS3002FG-07ABody size: AS3002FG (3/8 class) | Tube OD: ø1/4 in | Tube sizing: Inch
AS3002FG-09ABody size: AS3002FG (3/8 class) | Tube OD: ø5/16 in | Tube sizing: Inch
AS3002FG-11ABody size: AS3002FG (3/8 class) | Tube OD: ø3/8 in | Tube sizing: Inch
AS4002FG-10ABody size: AS4002FG (1/2 class) | Tube OD: ø10 mm | Tube sizing: Metric
AS4002FG-12ABody size: AS4002FG (1/2 class) | Tube OD: ø12 mm | Tube sizing: Metric
AS4002FG-11ABody size: AS4002FG (1/2 class) | Tube OD: ø3/8 in | Tube sizing: Inch
AS4002FG-13ABody size: AS4002FG (1/2 class) | Tube OD: ø1/2 in | Tube sizing: Inch
