SMC AS-FSA/AS-FSGA Inline Speed Controller with Scale

SMC AS-FSA/AS-FSGA Inline Speed Controller with Scale

SMC AS-FSA (brass) and AS-FSGA (stainless) inline speed controllers with one-touch fittings on both ends and a needle-turn scale window.

Key features

  • Inline body with one-touch fittings both ends, tube to tube connection
  • Scale window with vernier for 1/4-turn flow setting resolution; index plate for flow direction identification
  • Five body sizes (M5 to 1/2 class) for ø3.2 to ø12 mm and 1/8 to 1/2 in tubing
  • AS-FSGA stainless (SUS303) version with white release bushing
  • Panel mount adapter (suffix -3) and made to order -X12, -X21, -X214, 10- available

Specifications

Fluid Air
Proof pressure 1.5 MPa
Max. operating pressure 1 MPa
Min. operating pressure 0.1 MPa
Ambient and fluid temperature -5 to 60°C (no freezing)
Applicable tubing Nylon, soft nylon, polyurethane, FEP, PFA
Needle turns 8 (AS100), 10 (AS200 to AS400)
Source SMC Korea catalog AS-FSA/AS-FSGA inline (SMCKR_AS-FSA_AS-FSGA_Inline.pdf), PDF p. 1-12
AS1002FS-01A Material: Brass (electroless Ni) | Body size: M5 class | Tube OD: ø1/8 in
AS1002FS-03A Material: Brass (electroless Ni) | Body size: M5 class | Tube OD: ø5/32 in
AS1002FS-04A Material: Brass (electroless Ni) | Body size: M5 class | Tube OD: ø4 mm
AS1002FS-06A Material: Brass (electroless Ni) | Body size: M5 class | Tube OD: ø6 mm
AS1002FS-07A Material: Brass (electroless Ni) | Body size: M5 class | Tube OD: ø1/4 in
AS1002FS-23A Material: Brass (electroless Ni) | Body size: M5 class | Tube OD: ø3.2 mm
AS2002FS-03A Material: Brass (electroless Ni) | Body size: 1/8 class | Tube OD: ø5/32 in
AS2002FS-04A Material: Brass (electroless Ni) | Body size: 1/8 class | Tube OD: ø4 mm
AS2002FS-06A Material: Brass (electroless Ni) | Body size: 1/8 class | Tube OD: ø6 mm
AS2002FS-07A Material: Brass (electroless Ni) | Body size: 1/8 class | Tube OD: ø1/4 in
AS2052FS-06A Material: Brass (electroless Ni) | Body size: 1/4 class | Tube OD: ø6 mm
AS2052FS-07A Material: Brass (electroless Ni) | Body size: 1/4 class | Tube OD: ø1/4 in
AS2052FS-08A Material: Brass (electroless Ni) | Body size: 1/4 class | Tube OD: ø8 mm
AS2052FS-09A Material: Brass (electroless Ni) | Body size: 1/4 class | Tube OD: ø5/16 in
AS3002FS-06A Material: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø6 mm
AS3002FS-07A Material: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø1/4 in
AS3002FS-08A Material: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø8 mm
AS3002FS-09A Material: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø5/16 in
AS3002FS-10A Material: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø10 mm
AS3002FS-11A Material: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø3/8 in
AS3002FS-12A Material: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø12 mm
AS4002FS-10A Material: Brass (electroless Ni) | Body size: 1/2 class | Tube OD: ø10 mm
AS4002FS-11A Material: Brass (electroless Ni) | Body size: 1/2 class | Tube OD: ø3/8 in
AS4002FS-12A Material: Brass (electroless Ni) | Body size: 1/2 class | Tube OD: ø12 mm
AS4002FS-13A Material: Brass (electroless Ni) | Body size: 1/2 class | Tube OD: ø1/2 in
AS1002FSG-01A Material: Stainless steel | Body size: M5 class | Tube OD: ø1/8 in
AS1002FSG-03A Material: Stainless steel | Body size: M5 class | Tube OD: ø5/32 in
AS1002FSG-04A Material: Stainless steel | Body size: M5 class | Tube OD: ø4 mm
AS1002FSG-06A Material: Stainless steel | Body size: M5 class | Tube OD: ø6 mm
AS1002FSG-07A Material: Stainless steel | Body size: M5 class | Tube OD: ø1/4 in
AS1002FSG-23A Material: Stainless steel | Body size: M5 class | Tube OD: ø3.2 mm
AS2002FSG-03A Material: Stainless steel | Body size: 1/8 class | Tube OD: ø5/32 in
AS2002FSG-04A Material: Stainless steel | Body size: 1/8 class | Tube OD: ø4 mm
AS2002FSG-06A Material: Stainless steel | Body size: 1/8 class | Tube OD: ø6 mm
AS2002FSG-07A Material: Stainless steel | Body size: 1/8 class | Tube OD: ø1/4 in
AS2052FSG-06A Material: Stainless steel | Body size: 1/4 class | Tube OD: ø6 mm
AS2052FSG-07A Material: Stainless steel | Body size: 1/4 class | Tube OD: ø1/4 in
AS2052FSG-08A Material: Stainless steel | Body size: 1/4 class | Tube OD: ø8 mm
AS2052FSG-09A Material: Stainless steel | Body size: 1/4 class | Tube OD: ø5/16 in
AS3002FSG-06A Material: Stainless steel | Body size: 3/8 class | Tube OD: ø6 mm
AS3002FSG-07A Material: Stainless steel | Body size: 3/8 class | Tube OD: ø1/4 in
AS3002FSG-08A Material: Stainless steel | Body size: 3/8 class | Tube OD: ø8 mm
AS3002FSG-09A Material: Stainless steel | Body size: 3/8 class | Tube OD: ø5/16 in
AS3002FSG-10A Material: Stainless steel | Body size: 3/8 class | Tube OD: ø10 mm
AS3002FSG-11A Material: Stainless steel | Body size: 3/8 class | Tube OD: ø3/8 in
AS3002FSG-12A Material: Stainless steel | Body size: 3/8 class | Tube OD: ø12 mm
AS4002FSG-10A Material: Stainless steel | Body size: 1/2 class | Tube OD: ø10 mm
AS4002FSG-11A Material: Stainless steel | Body size: 1/2 class | Tube OD: ø3/8 in
AS4002FSG-12A Material: Stainless steel | Body size: 1/2 class | Tube OD: ø12 mm
AS4002FSG-13A Material: Stainless steel | Body size: 1/2 class | Tube OD: ø1/2 in
Speed ControllersSMC
50 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AS-FSA/AS-FSGA Inline Speed Controller with Scale

Brand SMC·Speed Controllers

Available part numbers (50)

AS1002FS-01A, AS1002FS-03A, AS1002FS-04A, AS1002FS-06A, AS1002FS-07A, AS1002FS-23A, AS2002FS-03A, AS2002FS-04A, AS2002FS-06A, AS2002FS-07A + 40 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AS1002FS-01AMaterial: Brass (electroless Ni) | Body size: M5 class | Tube OD: ø1/8 in
AS1002FS-03AMaterial: Brass (electroless Ni) | Body size: M5 class | Tube OD: ø5/32 in
AS1002FS-04AMaterial: Brass (electroless Ni) | Body size: M5 class | Tube OD: ø4 mm
AS1002FS-06AMaterial: Brass (electroless Ni) | Body size: M5 class | Tube OD: ø6 mm
AS1002FS-07AMaterial: Brass (electroless Ni) | Body size: M5 class | Tube OD: ø1/4 in
AS1002FS-23AMaterial: Brass (electroless Ni) | Body size: M5 class | Tube OD: ø3.2 mm
AS2002FS-03AMaterial: Brass (electroless Ni) | Body size: 1/8 class | Tube OD: ø5/32 in
AS2002FS-04AMaterial: Brass (electroless Ni) | Body size: 1/8 class | Tube OD: ø4 mm
AS2002FS-06AMaterial: Brass (electroless Ni) | Body size: 1/8 class | Tube OD: ø6 mm
AS2002FS-07AMaterial: Brass (electroless Ni) | Body size: 1/8 class | Tube OD: ø1/4 in
AS2052FS-06AMaterial: Brass (electroless Ni) | Body size: 1/4 class | Tube OD: ø6 mm
AS2052FS-07AMaterial: Brass (electroless Ni) | Body size: 1/4 class | Tube OD: ø1/4 in
AS2052FS-08AMaterial: Brass (electroless Ni) | Body size: 1/4 class | Tube OD: ø8 mm
AS2052FS-09AMaterial: Brass (electroless Ni) | Body size: 1/4 class | Tube OD: ø5/16 in
AS3002FS-06AMaterial: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø6 mm
AS3002FS-07AMaterial: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø1/4 in
AS3002FS-08AMaterial: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø8 mm
AS3002FS-09AMaterial: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø5/16 in
AS3002FS-10AMaterial: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø10 mm
AS3002FS-11AMaterial: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø3/8 in
AS3002FS-12AMaterial: Brass (electroless Ni) | Body size: 3/8 class | Tube OD: ø12 mm
AS4002FS-10AMaterial: Brass (electroless Ni) | Body size: 1/2 class | Tube OD: ø10 mm
AS4002FS-11AMaterial: Brass (electroless Ni) | Body size: 1/2 class | Tube OD: ø3/8 in
AS4002FS-12AMaterial: Brass (electroless Ni) | Body size: 1/2 class | Tube OD: ø12 mm
AS4002FS-13AMaterial: Brass (electroless Ni) | Body size: 1/2 class | Tube OD: ø1/2 in
AS1002FSG-01AMaterial: Stainless steel | Body size: M5 class | Tube OD: ø1/8 in
AS1002FSG-03AMaterial: Stainless steel | Body size: M5 class | Tube OD: ø5/32 in
AS1002FSG-04AMaterial: Stainless steel | Body size: M5 class | Tube OD: ø4 mm
AS1002FSG-06AMaterial: Stainless steel | Body size: M5 class | Tube OD: ø6 mm
AS1002FSG-07AMaterial: Stainless steel | Body size: M5 class | Tube OD: ø1/4 in
AS1002FSG-23AMaterial: Stainless steel | Body size: M5 class | Tube OD: ø3.2 mm
AS2002FSG-03AMaterial: Stainless steel | Body size: 1/8 class | Tube OD: ø5/32 in
AS2002FSG-04AMaterial: Stainless steel | Body size: 1/8 class | Tube OD: ø4 mm
AS2002FSG-06AMaterial: Stainless steel | Body size: 1/8 class | Tube OD: ø6 mm
AS2002FSG-07AMaterial: Stainless steel | Body size: 1/8 class | Tube OD: ø1/4 in
AS2052FSG-06AMaterial: Stainless steel | Body size: 1/4 class | Tube OD: ø6 mm
AS2052FSG-07AMaterial: Stainless steel | Body size: 1/4 class | Tube OD: ø1/4 in
AS2052FSG-08AMaterial: Stainless steel | Body size: 1/4 class | Tube OD: ø8 mm
AS2052FSG-09AMaterial: Stainless steel | Body size: 1/4 class | Tube OD: ø5/16 in
AS3002FSG-06AMaterial: Stainless steel | Body size: 3/8 class | Tube OD: ø6 mm
AS3002FSG-07AMaterial: Stainless steel | Body size: 3/8 class | Tube OD: ø1/4 in
AS3002FSG-08AMaterial: Stainless steel | Body size: 3/8 class | Tube OD: ø8 mm
AS3002FSG-09AMaterial: Stainless steel | Body size: 3/8 class | Tube OD: ø5/16 in
AS3002FSG-10AMaterial: Stainless steel | Body size: 3/8 class | Tube OD: ø10 mm
AS3002FSG-11AMaterial: Stainless steel | Body size: 3/8 class | Tube OD: ø3/8 in
AS3002FSG-12AMaterial: Stainless steel | Body size: 3/8 class | Tube OD: ø12 mm
AS4002FSG-10AMaterial: Stainless steel | Body size: 1/2 class | Tube OD: ø10 mm
AS4002FSG-11AMaterial: Stainless steel | Body size: 1/2 class | Tube OD: ø3/8 in
AS4002FSG-12AMaterial: Stainless steel | Body size: 1/2 class | Tube OD: ø12 mm
AS4002FSG-13AMaterial: Stainless steel | Body size: 1/2 class | Tube OD: ø1/2 in
