SMC BP1000 General Gas Back Pressure Valve (NPT / Compression)

SMC BP1000 General Gas Back Pressure Valve (NPT / Compression)

SMC BP1000 series back pressure valve (back pressure regulator) for general gases, holding upstream pressure at 0.0034 to 2.1 MPa, in stainless steel or brass.

Key features

  • Relieves to keep upstream (inlet) pressure at the set value; six set ranges 0.5-300 psig (0.0034-2.1 MPa)
  • Stainless steel (SUS316) or brass body; Ni-Cr-Mo internals (SH) for corrosive gases
  • NPT1/4 female or 1/4 compression fitting connections
  • 2P body (stainless) or 4PL body with two inlet gauge ports (stainless or brass)
  • Listed codes: gauge ports "0" (NPT1/4 port, no gauge); gauges (V3 to 40), plug C, MPA scale, FKM/PTFE/FFKM seat and panel mount (P) are ordered as suffixes

Specifications

Fluid Gases that do not corrode wetted parts
External leakage 1x10^-10 Pa m3/s
Ambient and fluid temperature -10 to 71 C (no freezing)
Port connection NPT female thread or compression fitting
Internal volume 8 cm3
Mass 1.2 kg
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP_SL_AZ_AK_BP.pdf), p. 724-725
BP1001B4PL4400 Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1001B4PL4T4T00 Set pressure: 0.0034 to 0.07 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1001S2P44 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
BP1001S2P4T4T Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
BP1001S4PL4400 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1001S4PL4T4T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1001SH2P44 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
BP1001SH2P4T4T Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
BP1001SH4PL4400 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1001SH4PL4T4T00 Set pressure: 0.0034 to 0.07 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1002B4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1002B4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1002S2P44 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
BP1002S2P4T4T Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
BP1002S4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1002S4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1002SH2P44 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
BP1002SH2P4T4T Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
BP1002SH4PL4400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1002SH4PL4T4T00 Set pressure: 0.007 to 0.2 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1006B4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1006B4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1006S2P44 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
BP1006S2P4T4T Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
BP1006S4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1006S4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1006SH2P44 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
BP1006SH2P4T4T Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
BP1006SH4PL4400 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1006SH4PL4T4T00 Set pressure: 0.014 to 0.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1010B4PL4400 Set pressure: 0.034 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1010B4PL4T4T00 Set pressure: 0.034 to 0.7 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1010S2P44 Set pressure: 0.034 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
BP1010S2P4T4T Set pressure: 0.034 to 0.7 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
BP1010S4PL4400 Set pressure: 0.034 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1010S4PL4T4T00 Set pressure: 0.034 to 0.7 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1010SH2P44 Set pressure: 0.034 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
BP1010SH2P4T4T Set pressure: 0.034 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
BP1010SH4PL4400 Set pressure: 0.034 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1010SH4PL4T4T00 Set pressure: 0.034 to 0.7 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1020B4PL4400 Set pressure: 0.1 to 1.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1020B4PL4T4T00 Set pressure: 0.1 to 1.4 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1020S2P44 Set pressure: 0.1 to 1.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
BP1020S2P4T4T Set pressure: 0.1 to 1.4 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
BP1020S4PL4400 Set pressure: 0.1 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1020S4PL4T4T00 Set pressure: 0.1 to 1.4 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1020SH2P44 Set pressure: 0.1 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
BP1020SH2P4T4T Set pressure: 0.1 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
BP1020SH4PL4400 Set pressure: 0.1 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1020SH4PL4T4T00 Set pressure: 0.1 to 1.4 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1030B4PL4400 Set pressure: 0.1 to 2.1 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1030B4PL4T4T00 Set pressure: 0.1 to 2.1 MPa | Material: Brass body | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1030S2P44 Set pressure: 0.1 to 2.1 MPa | Material: SUS316 | Ports: 2 ports | Connection: NPT1/4 female
BP1030S2P4T4T Set pressure: 0.1 to 2.1 MPa | Material: SUS316 | Ports: 2 ports | Connection: 1/4 compression fitting
BP1030S4PL4400 Set pressure: 0.1 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1030S4PL4T4T00 Set pressure: 0.1 to 2.1 MPa | Material: SUS316 | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
BP1030SH2P44 Set pressure: 0.1 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: NPT1/4 female
BP1030SH2P4T4T Set pressure: 0.1 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 compression fitting
BP1030SH4PL4400 Set pressure: 0.1 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: NPT1/4 female
BP1030SH4PL4T4T00 Set pressure: 0.1 to 2.1 MPa | Material: SUS316, Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (OUT extra + OUT gauge) | Connection: 1/4 compression fitting
