SMC C85W ISO Air Cylinder (Double Rod, ø8 to ø25)

SMC C85W ISO Air Cylinder (Double Rod, ø8 to ø25)

SMC C85W series ISO 6432 compliant round body air cylinder, double acting with double rod (through rod), ø8 to ø25.

Key features

  • Double acting, double rod design based on the C85 ISO 6432 cylinder
  • Rubber cushion as standard; air cushion (C) for ø10 to ø25, strokes 25 mm and over
  • Mounting brackets L/M (foot), G (flange) and U (trunnion), rod end V/W and bellows J/K/JJ/KK (ø20, ø25) ordered as code suffixes
  • CD models have a built-in magnet for rail-mounted (A) or band-mounted (B) auto switches such as D-M9B/M9BW and D-A93 (ordered as a suffix, e.g. -B-M9BW)
  • Made-to-order: -XA rod end change, -XB6 heat-resistant, -XB7 cold-resistant, -XC4 heavy scraper, -XC6 stainless steel

Specifications

Action Double acting, double rod
Fluid Air
Proof pressure 1.5 MPa
Max. operating pressure 1.0 MPa
Min. operating pressure 0.1 MPa (ø8), 0.08 MPa (ø10, ø12), 0.05 MPa (ø16 to ø25)
Ambient and fluid temperature -20 to 80°C without auto switch, -10 to 60°C with auto switch (no freezing)
Lubrication Not required (non-lube)
Piston speed 50 to 1500 mm/s
Port size M5 x 0.8 (ø8 to ø16), G1/8 (ø20, ø25)
Max. stroke 100 mm (ø8, ø10), 200 mm (ø12, ø16), 500 mm (ø20, ø25)
Source SMC Korea catalog C85/C75 (SMCKR_C85_C75.pdf), p. 17-18 (PDF p. 14-15)
C85WE8-10 Bore: ø8 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE8-25 Bore: ø8 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE8-40 Bore: ø8 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE8-50 Bore: ø8 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE8-80 Bore: ø8 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE8-100 Bore: ø8 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-10 Bore: ø10 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-25 Bore: ø10 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-25C Bore: ø10 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE10-40 Bore: ø10 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-40C Bore: ø10 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE10-50 Bore: ø10 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-50C Bore: ø10 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE10-80 Bore: ø10 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-80C Bore: ø10 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE10-100 Bore: ø10 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-100C Bore: ø10 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-10 Bore: ø12 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-25 Bore: ø12 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-25C Bore: ø12 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-40 Bore: ø12 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-40C Bore: ø12 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-50 Bore: ø12 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-50C Bore: ø12 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-80 Bore: ø12 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-80C Bore: ø12 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-100 Bore: ø12 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-100C Bore: ø12 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-125 Bore: ø12 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-125C Bore: ø12 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-160 Bore: ø12 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-160C Bore: ø12 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-200 Bore: ø12 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-200C Bore: ø12 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-10 Bore: ø16 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-25 Bore: ø16 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-25C Bore: ø16 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-40 Bore: ø16 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-40C Bore: ø16 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-50 Bore: ø16 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-50C Bore: ø16 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-80 Bore: ø16 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-80C Bore: ø16 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-100 Bore: ø16 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-100C Bore: ø16 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-125 Bore: ø16 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-125C Bore: ø16 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-160 Bore: ø16 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-160C Bore: ø16 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-200 Bore: ø16 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-200C Bore: ø16 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-10 Bore: ø20 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-25 Bore: ø20 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-25C Bore: ø20 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-40 Bore: ø20 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-40C Bore: ø20 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-50 Bore: ø20 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-50C Bore: ø20 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-80 Bore: ø20 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-80C Bore: ø20 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-100 Bore: ø20 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-100C Bore: ø20 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-125 Bore: ø20 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-125C Bore: ø20 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-160 Bore: ø20 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-160C Bore: ø20 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-200 Bore: ø20 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-200C Bore: ø20 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-250 Bore: ø20 mm | Stroke: 250 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-250C Bore: ø20 mm | Stroke: 250 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-300 Bore: ø20 mm | Stroke: 300 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-300C Bore: ø20 mm | Stroke: 300 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-10 Bore: ø25 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-25 Bore: ø25 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-25C Bore: ø25 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-40 Bore: ø25 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-40C Bore: ø25 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-50 Bore: ø25 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-50C Bore: ø25 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-80 Bore: ø25 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-80C Bore: ø25 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-100 Bore: ø25 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-100C Bore: ø25 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-125 Bore: ø25 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-125C Bore: ø25 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-160 Bore: ø25 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-160C Bore: ø25 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-200 Bore: ø25 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-200C Bore: ø25 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-250 Bore: ø25 mm | Stroke: 250 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-250C Bore: ø25 mm | Stroke: 250 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-300 Bore: ø25 mm | Stroke: 300 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-300C Bore: ø25 mm | Stroke: 300 mm | Cushion: Air cushion | Auto switch magnet: No
CD85WE8-10 Bore: ø8 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE8-25 Bore: ø8 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE8-40 Bore: ø8 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE8-50 Bore: ø8 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE8-80 Bore: ø8 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE8-100 Bore: ø8 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-10 Bore: ø10 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-25 Bore: ø10 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-25C Bore: ø10 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE10-40 Bore: ø10 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-40C Bore: ø10 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE10-50 Bore: ø10 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-50C Bore: ø10 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE10-80 Bore: ø10 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-80C Bore: ø10 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE10-100 Bore: ø10 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-100C Bore: ø10 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-10 Bore: ø12 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-25 Bore: ø12 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-25C Bore: ø12 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-40 Bore: ø12 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-40C Bore: ø12 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-50 Bore: ø12 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-50C Bore: ø12 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-80 Bore: ø12 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-80C Bore: ø12 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-100 Bore: ø12 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-100C Bore: ø12 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-125 Bore: ø12 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-125C Bore: ø12 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-160 Bore: ø12 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-160C Bore: ø12 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-200 Bore: ø12 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-200C Bore: ø12 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-10 Bore: ø16 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-25 Bore: ø16 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-25C Bore: ø16 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-40 Bore: ø16 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-40C Bore: ø16 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-50 Bore: ø16 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-50C Bore: ø16 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-80 Bore: ø16 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-80C Bore: ø16 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-100 Bore: ø16 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-100C Bore: ø16 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-125 Bore: ø16 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-125C Bore: ø16 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-160 Bore: ø16 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-160C Bore: ø16 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-200 Bore: ø16 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-200C Bore: ø16 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-10 Bore: ø20 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-25 Bore: ø20 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-25C Bore: ø20 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-40 Bore: ø20 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-40C Bore: ø20 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-50 Bore: ø20 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-50C Bore: ø20 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-80 Bore: ø20 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-80C Bore: ø20 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-100 Bore: ø20 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-100C Bore: ø20 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-125 Bore: ø20 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-125C Bore: ø20 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-160 Bore: ø20 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-160C Bore: ø20 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-200 Bore: ø20 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-200C Bore: ø20 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-250 Bore: ø20 mm | Stroke: 250 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-250C Bore: ø20 mm | Stroke: 250 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-300 Bore: ø20 mm | Stroke: 300 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-300C Bore: ø20 mm | Stroke: 300 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-10 Bore: ø25 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-25 Bore: ø25 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-25C Bore: ø25 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-40 Bore: ø25 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-40C Bore: ø25 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-50 Bore: ø25 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-50C Bore: ø25 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-80 Bore: ø25 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-80C Bore: ø25 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-100 Bore: ø25 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-100C Bore: ø25 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-125 Bore: ø25 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-125C Bore: ø25 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-160 Bore: ø25 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-160C Bore: ø25 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-200 Bore: ø25 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-200C Bore: ø25 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-250 Bore: ø25 mm | Stroke: 250 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-250C Bore: ø25 mm | Stroke: 250 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-300 Bore: ø25 mm | Stroke: 300 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-300C Bore: ø25 mm | Stroke: 300 mm | Cushion: Air cushion | Auto switch magnet: Yes
Round Body CylindersSMC
186 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC C85W ISO Air Cylinder (Double Rod, ø8 to ø25)

Brand SMC·Round Body Cylinders

Available part numbers (186)

C85WE8-10, C85WE8-25, C85WE8-40, C85WE8-50, C85WE8-80, C85WE8-100, C85WE10-10, C85WE10-25, C85WE10-25C, C85WE10-40 + 176 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
C85WE8-10Bore: ø8 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE8-25Bore: ø8 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE8-40Bore: ø8 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE8-50Bore: ø8 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE8-80Bore: ø8 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE8-100Bore: ø8 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-10Bore: ø10 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-25Bore: ø10 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-25CBore: ø10 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE10-40Bore: ø10 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-40CBore: ø10 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE10-50Bore: ø10 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-50CBore: ø10 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE10-80Bore: ø10 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-80CBore: ø10 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE10-100Bore: ø10 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE10-100CBore: ø10 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-10Bore: ø12 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-25Bore: ø12 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-25CBore: ø12 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-40Bore: ø12 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-40CBore: ø12 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-50Bore: ø12 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-50CBore: ø12 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-80Bore: ø12 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-80CBore: ø12 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-100Bore: ø12 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-100CBore: ø12 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-125Bore: ø12 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-125CBore: ø12 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-160Bore: ø12 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-160CBore: ø12 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE12-200Bore: ø12 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE12-200CBore: ø12 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-10Bore: ø16 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-25Bore: ø16 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-25CBore: ø16 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-40Bore: ø16 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-40CBore: ø16 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-50Bore: ø16 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-50CBore: ø16 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-80Bore: ø16 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-80CBore: ø16 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-100Bore: ø16 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-100CBore: ø16 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-125Bore: ø16 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-125CBore: ø16 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-160Bore: ø16 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-160CBore: ø16 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE16-200Bore: ø16 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE16-200CBore: ø16 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-10Bore: ø20 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-25Bore: ø20 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-25CBore: ø20 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-40Bore: ø20 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-40CBore: ø20 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-50Bore: ø20 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-50CBore: ø20 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-80Bore: ø20 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-80CBore: ø20 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-100Bore: ø20 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-100CBore: ø20 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-125Bore: ø20 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-125CBore: ø20 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-160Bore: ø20 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-160CBore: ø20 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-200Bore: ø20 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-200CBore: ø20 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-250Bore: ø20 mm | Stroke: 250 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-250CBore: ø20 mm | Stroke: 250 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE20-300Bore: ø20 mm | Stroke: 300 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE20-300CBore: ø20 mm | Stroke: 300 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-10Bore: ø25 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-25Bore: ø25 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-25CBore: ø25 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-40Bore: ø25 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-40CBore: ø25 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-50Bore: ø25 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-50CBore: ø25 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-80Bore: ø25 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-80CBore: ø25 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-100Bore: ø25 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-100CBore: ø25 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-125Bore: ø25 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-125CBore: ø25 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-160Bore: ø25 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-160CBore: ø25 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-200Bore: ø25 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-200CBore: ø25 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-250Bore: ø25 mm | Stroke: 250 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-250CBore: ø25 mm | Stroke: 250 mm | Cushion: Air cushion | Auto switch magnet: No
C85WE25-300Bore: ø25 mm | Stroke: 300 mm | Cushion: Rubber cushion | Auto switch magnet: No
C85WE25-300CBore: ø25 mm | Stroke: 300 mm | Cushion: Air cushion | Auto switch magnet: No
CD85WE8-10Bore: ø8 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE8-25Bore: ø8 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE8-40Bore: ø8 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE8-50Bore: ø8 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE8-80Bore: ø8 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE8-100Bore: ø8 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-10Bore: ø10 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-25Bore: ø10 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-25CBore: ø10 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE10-40Bore: ø10 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-40CBore: ø10 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE10-50Bore: ø10 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-50CBore: ø10 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE10-80Bore: ø10 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-80CBore: ø10 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE10-100Bore: ø10 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE10-100CBore: ø10 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-10Bore: ø12 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-25Bore: ø12 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-25CBore: ø12 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-40Bore: ø12 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-40CBore: ø12 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-50Bore: ø12 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-50CBore: ø12 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-80Bore: ø12 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-80CBore: ø12 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-100Bore: ø12 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-100CBore: ø12 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-125Bore: ø12 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-125CBore: ø12 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-160Bore: ø12 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-160CBore: ø12 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE12-200Bore: ø12 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE12-200CBore: ø12 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-10Bore: ø16 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-25Bore: ø16 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-25CBore: ø16 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-40Bore: ø16 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-40CBore: ø16 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-50Bore: ø16 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-50CBore: ø16 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-80Bore: ø16 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-80CBore: ø16 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-100Bore: ø16 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-100CBore: ø16 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-125Bore: ø16 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-125CBore: ø16 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-160Bore: ø16 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-160CBore: ø16 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE16-200Bore: ø16 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE16-200CBore: ø16 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-10Bore: ø20 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-25Bore: ø20 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-25CBore: ø20 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-40Bore: ø20 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-40CBore: ø20 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-50Bore: ø20 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-50CBore: ø20 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-80Bore: ø20 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-80CBore: ø20 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-100Bore: ø20 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-100CBore: ø20 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-125Bore: ø20 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-125CBore: ø20 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-160Bore: ø20 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-160CBore: ø20 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-200Bore: ø20 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-200CBore: ø20 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-250Bore: ø20 mm | Stroke: 250 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-250CBore: ø20 mm | Stroke: 250 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE20-300Bore: ø20 mm | Stroke: 300 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE20-300CBore: ø20 mm | Stroke: 300 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-10Bore: ø25 mm | Stroke: 10 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-25Bore: ø25 mm | Stroke: 25 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-25CBore: ø25 mm | Stroke: 25 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-40Bore: ø25 mm | Stroke: 40 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-40CBore: ø25 mm | Stroke: 40 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-50Bore: ø25 mm | Stroke: 50 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-50CBore: ø25 mm | Stroke: 50 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-80Bore: ø25 mm | Stroke: 80 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-80CBore: ø25 mm | Stroke: 80 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-100Bore: ø25 mm | Stroke: 100 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-100CBore: ø25 mm | Stroke: 100 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-125Bore: ø25 mm | Stroke: 125 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-125CBore: ø25 mm | Stroke: 125 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-160Bore: ø25 mm | Stroke: 160 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-160CBore: ø25 mm | Stroke: 160 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-200Bore: ø25 mm | Stroke: 200 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-200CBore: ø25 mm | Stroke: 200 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-250Bore: ø25 mm | Stroke: 250 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-250CBore: ø25 mm | Stroke: 250 mm | Cushion: Air cushion | Auto switch magnet: Yes
CD85WE25-300Bore: ø25 mm | Stroke: 300 mm | Cushion: Rubber cushion | Auto switch magnet: Yes
CD85WE25-300CBore: ø25 mm | Stroke: 300 mm | Cushion: Air cushion | Auto switch magnet: Yes

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
