SMC C96 ISO 15552 Tie-rod Air Cylinder (Double Rod, ø32 to ø100)

SMC C96 series ISO 15552 tie-rod air cylinder, double acting, double rod, ø32 to ø100 mm bore, with air cushion plus damper cushion and optional built-in magnet (C96SD).

Key features

ISO 15552 compliant; lighter body than the previous C96 (up to 17% weight reduction)
Two-stage cushioning (air cushion + damper) shortens cycle time and reduces impact noise
Mounting styles: basic (B), axial foot (L), rod/head flange (F/G), single/double clevis (C/D), center trunnion (T), adjustable trunnion (V)
Compact D-M9 / D-A9 auto switches mount directly on the tie rod and adjust from one direction; tie-rod and band mount switches also available
Bellows (J, JJ, K, KK), auto switches and made-to-order specs (-XA, -XB6, -XB7, -XC14, -XC35 etc.) ordered as suffixes

Specifications

Standard	ISO 15552
Action	Double acting
Fluid	Air
Proof pressure	1.5 MPa
Max. operating pressure	1.0 MPa
Min. operating pressure	0.05 MPa
Ambient and fluid temperature	-20 to 70°C without switch, -10 to 60°C with switch (no freezing)
Piston speed	50 to 1000 mm/s
Lubrication	Not required (non-lube)
Cushion	Air cushion + damper cushion on both ends (C)
Rod	Double Rod
Max. stroke	ø32 1000 mm, ø40 to ø100 1900 mm
Source	SMC Korea catalog C96 (SMCKR_C96.pdf), p. 161-162 (PDF p. 4-5)

C96SB32-25CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
C96SDB32-25CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SB32-50CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
C96SDB32-50CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SB32-80CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
C96SDB32-80CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SB32-100CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
C96SDB32-100CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SB32-125CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
C96SDB32-125CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SB32-160CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
C96SDB32-160CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SB32-200CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
C96SDB32-200CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SB32-250CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
C96SDB32-250CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SB32-320CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
C96SDB32-320CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SB32-400CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
C96SDB32-400CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SB32-500CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
C96SDB32-500CW		Mounting: Basic \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SB40-25CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB40-25CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB40-50CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB40-50CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB40-80CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB40-80CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB40-100CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB40-100CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB40-125CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB40-125CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB40-160CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB40-160CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB40-200CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB40-200CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB40-250CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB40-250CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB40-320CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB40-320CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB40-400CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB40-400CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB40-500CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB40-500CW		Mounting: Basic \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB50-25CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB50-25CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB50-50CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB50-50CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB50-80CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB50-80CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB50-100CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB50-100CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB50-125CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB50-125CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB50-160CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB50-160CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB50-200CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB50-200CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB50-250CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB50-250CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB50-320CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB50-320CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB50-400CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB50-400CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB50-500CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB50-500CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB50-600CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
C96SDB50-600CW		Mounting: Basic \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SB63-25CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB63-25CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB63-50CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB63-50CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB63-80CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB63-80CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB63-100CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB63-100CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB63-125CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB63-125CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB63-160CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB63-160CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB63-200CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB63-200CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB63-250CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB63-250CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB63-320CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB63-320CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB63-400CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB63-400CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB63-500CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB63-500CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB63-600CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB63-600CW		Mounting: Basic \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-25CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-25CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-50CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-50CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-80CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-80CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-100CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-100CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-125CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-125CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-160CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-160CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-200CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-200CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-250CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-250CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-320CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-320CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-400CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-400CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-500CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-500CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-600CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-600CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-700CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-700CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB80-800CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
C96SDB80-800CW		Mounting: Basic \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SB100-25CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-25CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-50CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-50CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-80CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-80CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-100CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-100CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-125CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-125CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-160CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-160CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-200CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-200CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-250CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-250CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-320CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-320CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-400CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-400CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-500CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-500CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-600CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-600CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-700CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-700CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SB100-800CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
C96SDB100-800CW		Mounting: Basic \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL32-25CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
C96SDL32-25CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SL32-50CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
C96SDL32-50CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SL32-80CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
C96SDL32-80CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SL32-100CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
C96SDL32-100CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SL32-125CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
C96SDL32-125CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SL32-160CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
C96SDL32-160CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SL32-200CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
C96SDL32-200CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SL32-250CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
C96SDL32-250CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SL32-320CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
C96SDL32-320CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SL32-400CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
C96SDL32-400CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SL32-500CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
C96SDL32-500CW		Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SL40-25CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL40-25CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL40-50CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL40-50CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL40-80CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL40-80CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL40-100CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL40-100CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL40-125CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL40-125CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL40-160CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL40-160CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL40-200CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL40-200CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL40-250CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL40-250CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL40-320CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL40-320CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL40-400CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL40-400CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL40-500CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL40-500CW		Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL50-25CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL50-25CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL50-50CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL50-50CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL50-80CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL50-80CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL50-100CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL50-100CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL50-125CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL50-125CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL50-160CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL50-160CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL50-200CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL50-200CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL50-250CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL50-250CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL50-320CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL50-320CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL50-400CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL50-400CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL50-500CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL50-500CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL50-600CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
C96SDL50-600CW		Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SL63-25CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL63-25CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL63-50CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL63-50CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL63-80CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL63-80CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL63-100CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL63-100CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL63-125CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL63-125CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL63-160CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL63-160CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL63-200CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL63-200CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL63-250CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL63-250CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL63-320CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL63-320CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL63-400CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL63-400CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL63-500CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL63-500CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL63-600CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL63-600CW		Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-25CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-25CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-50CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-50CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-80CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-80CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-100CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-100CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-125CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-125CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-160CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-160CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-200CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-200CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-250CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-250CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-320CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-320CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-400CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-400CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-500CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-500CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-600CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-600CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-700CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-700CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL80-800CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
C96SDL80-800CW		Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SL100-25CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-25CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-50CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-50CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-80CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-80CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-100CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-100CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-125CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-125CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-160CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-160CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-200CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-200CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-250CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-250CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-320CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-320CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-400CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-400CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-500CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-500CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-600CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-600CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-700CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-700CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SL100-800CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
C96SDL100-800CW		Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF32-25CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
C96SDF32-25CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SF32-50CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
C96SDF32-50CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SF32-80CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
C96SDF32-80CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SF32-100CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
C96SDF32-100CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SF32-125CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
C96SDF32-125CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SF32-160CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
C96SDF32-160CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SF32-200CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
C96SDF32-200CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SF32-250CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
C96SDF32-250CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SF32-320CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
C96SDF32-320CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SF32-400CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
C96SDF32-400CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SF32-500CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
C96SDF32-500CW		Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SF40-25CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF40-25CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF40-50CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF40-50CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF40-80CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF40-80CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF40-100CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF40-100CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF40-125CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF40-125CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF40-160CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF40-160CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF40-200CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF40-200CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF40-250CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF40-250CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF40-320CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF40-320CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF40-400CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF40-400CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF40-500CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF40-500CW		Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF50-25CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF50-25CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF50-50CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF50-50CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF50-80CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF50-80CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF50-100CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF50-100CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF50-125CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF50-125CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF50-160CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF50-160CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF50-200CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF50-200CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF50-250CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF50-250CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF50-320CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF50-320CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF50-400CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF50-400CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF50-500CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF50-500CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF50-600CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
C96SDF50-600CW		Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SF63-25CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF63-25CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF63-50CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF63-50CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF63-80CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF63-80CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF63-100CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF63-100CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF63-125CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF63-125CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF63-160CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF63-160CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF63-200CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF63-200CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF63-250CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF63-250CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF63-320CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF63-320CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF63-400CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF63-400CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF63-500CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF63-500CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF63-600CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF63-600CW		Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-25CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-25CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-50CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-50CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-80CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-80CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-100CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-100CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-125CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-125CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-160CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-160CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-200CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-200CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-250CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-250CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-320CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-320CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-400CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-400CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-500CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-500CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-600CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-600CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-700CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-700CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF80-800CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
C96SDF80-800CW		Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SF100-25CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-25CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-50CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-50CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-80CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-80CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-100CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-100CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-125CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-125CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-160CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-160CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-200CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-200CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-250CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-250CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-320CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-320CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-400CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-400CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-500CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-500CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-600CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-600CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-700CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-700CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SF100-800CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
C96SDF100-800CW		Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG32-25CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
C96SDG32-25CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SG32-50CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
C96SDG32-50CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SG32-80CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
C96SDG32-80CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SG32-100CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
C96SDG32-100CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SG32-125CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
C96SDG32-125CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SG32-160CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
C96SDG32-160CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SG32-200CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
C96SDG32-200CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SG32-250CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
C96SDG32-250CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SG32-320CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
C96SDG32-320CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SG32-400CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
C96SDG32-400CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SG32-500CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
C96SDG32-500CW		Mounting: Head flange \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SG40-25CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG40-25CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG40-50CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG40-50CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG40-80CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG40-80CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG40-100CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG40-100CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG40-125CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG40-125CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG40-160CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG40-160CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG40-200CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG40-200CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG40-250CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG40-250CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG40-320CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG40-320CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG40-400CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG40-400CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG40-500CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG40-500CW		Mounting: Head flange \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG50-25CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG50-25CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG50-50CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG50-50CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG50-80CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG50-80CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG50-100CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG50-100CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG50-125CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG50-125CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG50-160CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG50-160CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG50-200CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG50-200CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG50-250CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG50-250CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG50-320CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG50-320CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG50-400CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG50-400CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG50-500CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG50-500CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG50-600CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
C96SDG50-600CW		Mounting: Head flange \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SG63-25CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG63-25CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG63-50CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG63-50CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG63-80CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG63-80CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG63-100CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG63-100CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG63-125CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG63-125CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG63-160CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG63-160CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG63-200CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG63-200CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG63-250CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG63-250CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG63-320CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG63-320CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG63-400CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG63-400CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG63-500CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG63-500CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG63-600CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG63-600CW		Mounting: Head flange \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-25CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-25CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-50CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-50CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-80CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-80CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-100CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-100CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-125CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-125CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-160CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-160CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-200CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-200CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-250CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-250CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-320CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-320CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-400CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-400CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-500CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-500CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-600CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-600CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-700CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-700CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG80-800CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
C96SDG80-800CW		Mounting: Head flange \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SG100-25CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-25CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-50CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-50CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-80CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-80CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-100CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-100CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-125CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-125CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-160CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-160CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-200CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-200CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-250CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-250CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-320CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-320CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-400CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-400CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-500CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-500CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-600CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-600CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-700CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-700CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SG100-800CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
C96SDG100-800CW		Mounting: Head flange \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC32-25CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
C96SDC32-25CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SC32-50CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
C96SDC32-50CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SC32-80CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
C96SDC32-80CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SC32-100CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
C96SDC32-100CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SC32-125CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
C96SDC32-125CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SC32-160CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
C96SDC32-160CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SC32-200CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
C96SDC32-200CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SC32-250CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
C96SDC32-250CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SC32-320CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
C96SDC32-320CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SC32-400CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
C96SDC32-400CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SC32-500CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
C96SDC32-500CW		Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SC40-25CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC40-25CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC40-50CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC40-50CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC40-80CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC40-80CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC40-100CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC40-100CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC40-125CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC40-125CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC40-160CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC40-160CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC40-200CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC40-200CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC40-250CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC40-250CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC40-320CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC40-320CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC40-400CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC40-400CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC40-500CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC40-500CW		Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC50-25CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC50-25CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC50-50CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC50-50CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC50-80CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC50-80CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC50-100CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC50-100CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC50-125CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC50-125CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC50-160CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC50-160CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC50-200CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC50-200CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC50-250CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC50-250CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC50-320CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC50-320CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC50-400CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC50-400CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC50-500CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC50-500CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC50-600CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
C96SDC50-600CW		Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SC63-25CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC63-25CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC63-50CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC63-50CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC63-80CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC63-80CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC63-100CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC63-100CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC63-125CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC63-125CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC63-160CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC63-160CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC63-200CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC63-200CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC63-250CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC63-250CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC63-320CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC63-320CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC63-400CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC63-400CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC63-500CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC63-500CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC63-600CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC63-600CW		Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-25CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-25CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-50CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-50CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-80CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-80CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-100CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-100CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-125CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-125CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-160CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-160CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-200CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-200CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-250CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-250CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-320CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-320CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-400CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-400CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-500CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-500CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-600CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-600CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-700CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-700CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC80-800CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
C96SDC80-800CW		Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SC100-25CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-25CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-50CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-50CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-80CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-80CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-100CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-100CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-125CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-125CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-160CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-160CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-200CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-200CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-250CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-250CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-320CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-320CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-400CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-400CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-500CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-500CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-600CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-600CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-700CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-700CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SC100-800CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
C96SDC100-800CW		Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD32-25CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
C96SDD32-25CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SD32-50CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
C96SDD32-50CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SD32-80CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
C96SDD32-80CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SD32-100CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
C96SDD32-100CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SD32-125CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
C96SDD32-125CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SD32-160CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
C96SDD32-160CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SD32-200CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
C96SDD32-200CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SD32-250CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
C96SDD32-250CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SD32-320CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
C96SDD32-320CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SD32-400CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
C96SDD32-400CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SD32-500CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
C96SDD32-500CW		Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SD40-25CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD40-25CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD40-50CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD40-50CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD40-80CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD40-80CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD40-100CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD40-100CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD40-125CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD40-125CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD40-160CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD40-160CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD40-200CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD40-200CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD40-250CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD40-250CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD40-320CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD40-320CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD40-400CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD40-400CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD40-500CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD40-500CW		Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD50-25CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD50-25CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD50-50CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD50-50CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD50-80CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD50-80CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD50-100CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD50-100CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD50-125CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD50-125CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD50-160CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD50-160CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD50-200CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD50-200CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD50-250CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD50-250CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD50-320CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD50-320CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD50-400CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD50-400CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD50-500CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD50-500CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD50-600CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
C96SDD50-600CW		Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SD63-25CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD63-25CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD63-50CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD63-50CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD63-80CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD63-80CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD63-100CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD63-100CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD63-125CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD63-125CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD63-160CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD63-160CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD63-200CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD63-200CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD63-250CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD63-250CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD63-320CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD63-320CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD63-400CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD63-400CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD63-500CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD63-500CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD63-600CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD63-600CW		Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-25CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-25CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-50CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-50CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-80CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-80CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-100CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-100CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-125CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-125CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-160CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-160CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-200CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-200CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-250CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-250CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-320CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-320CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-400CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-400CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-500CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-500CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-600CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-600CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-700CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-700CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD80-800CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
C96SDD80-800CW		Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SD100-25CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-25CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-50CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-50CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-80CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-80CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-100CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-100CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-125CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-125CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-160CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-160CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-200CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-200CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-250CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-250CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-320CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-320CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-400CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-400CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-500CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-500CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-600CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-600CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-700CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-700CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SD100-800CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
C96SDD100-800CW		Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST32-25CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
C96SDT32-25CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
C96ST32-50CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
C96SDT32-50CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
C96ST32-80CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
C96SDT32-80CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
C96ST32-100CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
C96SDT32-100CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
C96ST32-125CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
C96SDT32-125CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
C96ST32-160CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
C96SDT32-160CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
C96ST32-200CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
C96SDT32-200CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
C96ST32-250CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
C96SDT32-250CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
C96ST32-320CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
C96SDT32-320CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
C96ST32-400CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
C96SDT32-400CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
C96ST32-500CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
C96SDT32-500CW		Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
C96ST40-25CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT40-25CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST40-50CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT40-50CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST40-80CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT40-80CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST40-100CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT40-100CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST40-125CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT40-125CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST40-160CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT40-160CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST40-200CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT40-200CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST40-250CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT40-250CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST40-320CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT40-320CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST40-400CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT40-400CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST40-500CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT40-500CW		Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST50-25CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT50-25CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST50-50CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT50-50CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST50-80CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT50-80CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST50-100CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT50-100CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST50-125CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT50-125CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST50-160CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT50-160CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST50-200CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT50-200CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST50-250CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT50-250CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST50-320CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT50-320CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST50-400CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT50-400CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST50-500CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT50-500CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST50-600CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
C96SDT50-600CW		Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
C96ST63-25CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT63-25CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST63-50CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT63-50CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST63-80CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT63-80CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST63-100CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT63-100CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST63-125CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT63-125CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST63-160CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT63-160CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST63-200CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT63-200CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST63-250CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT63-250CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST63-320CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT63-320CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST63-400CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT63-400CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST63-500CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT63-500CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST63-600CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT63-600CW		Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-25CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-25CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-50CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-50CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-80CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-80CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-100CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-100CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-125CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-125CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-160CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-160CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-200CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-200CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-250CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-250CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-320CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-320CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-400CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-400CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-500CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-500CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-600CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-600CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-700CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-700CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST80-800CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
C96SDT80-800CW		Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
C96ST100-25CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-25CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-50CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-50CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-80CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-80CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-100CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-100CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-125CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-125CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-160CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-160CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-200CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-200CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-250CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-250CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-320CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-320CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-400CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-400CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-500CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-500CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-600CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-600CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-700CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-700CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
C96ST100-800CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
C96SDT100-800CW		Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV32-25CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
C96SDV32-25CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SV32-50CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
C96SDV32-50CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SV32-80CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
C96SDV32-80CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SV32-100CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
C96SDV32-100CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SV32-125CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
C96SDV32-125CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SV32-160CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
C96SDV32-160CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SV32-200CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
C96SDV32-200CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SV32-250CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
C96SDV32-250CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SV32-320CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
C96SDV32-320CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SV32-400CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
C96SDV32-400CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SV32-500CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
C96SDV32-500CW		Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
C96SV40-25CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV40-25CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV40-50CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV40-50CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV40-80CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV40-80CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV40-100CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV40-100CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV40-125CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV40-125CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV40-160CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV40-160CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV40-200CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV40-200CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV40-250CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV40-250CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV40-320CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV40-320CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV40-400CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV40-400CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV40-500CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV40-500CW		Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV50-25CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV50-25CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV50-50CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV50-50CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV50-80CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV50-80CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV50-100CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV50-100CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV50-125CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV50-125CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV50-160CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV50-160CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV50-200CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV50-200CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV50-250CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV50-250CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV50-320CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV50-320CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV50-400CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV50-400CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV50-500CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV50-500CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV50-600CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
C96SDV50-600CW		Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
C96SV63-25CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV63-25CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV63-50CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV63-50CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV63-80CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV63-80CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV63-100CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV63-100CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV63-125CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV63-125CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV63-160CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV63-160CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV63-200CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV63-200CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV63-250CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV63-250CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV63-320CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV63-320CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV63-400CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV63-400CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV63-500CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV63-500CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV63-600CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV63-600CW		Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-25CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-25CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-50CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-50CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-80CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-80CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-100CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-100CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-125CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-125CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-160CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-160CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-200CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-200CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-250CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-250CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-320CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-320CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-400CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-400CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-500CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-500CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-600CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-600CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-700CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-700CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV80-800CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
C96SDV80-800CW		Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
C96SV100-25CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-25CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-50CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-50CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-80CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-80CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-100CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-100CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-125CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-125CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-160CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-160CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-200CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-200CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-250CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-250CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-320CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-320CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-400CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-400CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-500CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-500CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-600CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-600CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-700CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-700CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
C96SV100-800CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
C96SDV100-800CW		Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2

Round Body CylindersSMC

1184 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC C96 ISO 15552 Tie-rod Air Cylinder (Double Rod, ø32 to ø100)

Brand SMC·Round Body Cylinders

Available part numbers (1184)

C96SB32-25CW, C96SDB32-25CW, C96SB32-50CW, C96SDB32-50CW, C96SB32-80CW, C96SDB32-80CW, C96SB32-100CW, C96SDB32-100CW, C96SB32-125CW, C96SDB32-125CW + 1174 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	C96SB32-25CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDB32-25CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SB32-50CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDB32-50CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SB32-80CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDB32-80CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SB32-100CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDB32-100CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SB32-125CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDB32-125CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SB32-160CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDB32-160CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SB32-200CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDB32-200CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SB32-250CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDB32-250CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SB32-320CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDB32-320CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SB32-400CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDB32-400CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SB32-500CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDB32-500CW	Mounting: Basic \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SB40-25CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB40-25CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB40-50CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB40-50CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB40-80CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB40-80CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB40-100CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB40-100CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB40-125CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB40-125CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB40-160CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB40-160CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB40-200CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB40-200CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB40-250CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB40-250CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB40-320CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB40-320CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB40-400CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB40-400CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB40-500CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB40-500CW	Mounting: Basic \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB50-25CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB50-25CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB50-50CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB50-50CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB50-80CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB50-80CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB50-100CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB50-100CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB50-125CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB50-125CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB50-160CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB50-160CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB50-200CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB50-200CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB50-250CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB50-250CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB50-320CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB50-320CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB50-400CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB50-400CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB50-500CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB50-500CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB50-600CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDB50-600CW	Mounting: Basic \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SB63-25CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB63-25CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB63-50CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB63-50CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB63-80CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB63-80CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB63-100CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB63-100CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB63-125CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB63-125CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB63-160CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB63-160CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB63-200CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB63-200CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB63-250CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB63-250CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB63-320CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB63-320CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB63-400CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB63-400CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB63-500CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB63-500CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB63-600CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB63-600CW	Mounting: Basic \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-25CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-25CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-50CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-50CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-80CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-80CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-100CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-100CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-125CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-125CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-160CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-160CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-200CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-200CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-250CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-250CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-320CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-320CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-400CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-400CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-500CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-500CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-600CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-600CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-700CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-700CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB80-800CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDB80-800CW	Mounting: Basic \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SB100-25CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-25CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-50CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-50CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-80CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-80CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-100CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-100CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-125CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-125CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-160CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-160CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-200CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-200CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-250CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-250CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-320CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-320CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-400CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-400CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-500CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-500CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-600CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-600CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-700CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-700CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SB100-800CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDB100-800CW	Mounting: Basic \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL32-25CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDL32-25CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SL32-50CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDL32-50CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SL32-80CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDL32-80CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SL32-100CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDL32-100CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SL32-125CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDL32-125CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SL32-160CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDL32-160CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SL32-200CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDL32-200CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SL32-250CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDL32-250CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SL32-320CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDL32-320CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SL32-400CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDL32-400CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SL32-500CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDL32-500CW	Mounting: Axial foot \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SL40-25CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL40-25CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL40-50CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL40-50CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL40-80CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL40-80CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL40-100CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL40-100CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL40-125CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL40-125CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL40-160CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL40-160CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL40-200CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL40-200CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL40-250CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL40-250CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL40-320CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL40-320CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL40-400CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL40-400CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL40-500CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL40-500CW	Mounting: Axial foot \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL50-25CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL50-25CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL50-50CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL50-50CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL50-80CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL50-80CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL50-100CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL50-100CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL50-125CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL50-125CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL50-160CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL50-160CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL50-200CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL50-200CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL50-250CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL50-250CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL50-320CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL50-320CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL50-400CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL50-400CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL50-500CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL50-500CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL50-600CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDL50-600CW	Mounting: Axial foot \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SL63-25CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL63-25CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL63-50CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL63-50CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL63-80CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL63-80CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL63-100CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL63-100CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL63-125CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL63-125CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL63-160CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL63-160CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL63-200CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL63-200CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL63-250CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL63-250CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL63-320CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL63-320CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL63-400CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL63-400CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL63-500CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL63-500CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL63-600CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL63-600CW	Mounting: Axial foot \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-25CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-25CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-50CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-50CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-80CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-80CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-100CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-100CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-125CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-125CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-160CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-160CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-200CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-200CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-250CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-250CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-320CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-320CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-400CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-400CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-500CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-500CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-600CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-600CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-700CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-700CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL80-800CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDL80-800CW	Mounting: Axial foot \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SL100-25CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-25CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-50CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-50CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-80CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-80CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-100CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-100CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-125CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-125CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-160CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-160CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-200CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-200CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-250CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-250CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-320CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-320CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-400CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-400CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-500CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-500CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-600CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-600CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-700CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-700CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SL100-800CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDL100-800CW	Mounting: Axial foot \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF32-25CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDF32-25CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SF32-50CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDF32-50CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SF32-80CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDF32-80CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SF32-100CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDF32-100CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SF32-125CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDF32-125CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SF32-160CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDF32-160CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SF32-200CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDF32-200CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SF32-250CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDF32-250CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SF32-320CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDF32-320CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SF32-400CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDF32-400CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SF32-500CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDF32-500CW	Mounting: Rod flange \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SF40-25CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF40-25CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF40-50CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF40-50CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF40-80CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF40-80CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF40-100CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF40-100CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF40-125CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF40-125CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF40-160CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF40-160CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF40-200CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF40-200CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF40-250CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF40-250CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF40-320CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF40-320CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF40-400CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF40-400CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF40-500CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF40-500CW	Mounting: Rod flange \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF50-25CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF50-25CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF50-50CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF50-50CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF50-80CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF50-80CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF50-100CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF50-100CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF50-125CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF50-125CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF50-160CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF50-160CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF50-200CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF50-200CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF50-250CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF50-250CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF50-320CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF50-320CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF50-400CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF50-400CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF50-500CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF50-500CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF50-600CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDF50-600CW	Mounting: Rod flange \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SF63-25CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF63-25CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF63-50CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF63-50CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF63-80CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF63-80CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF63-100CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF63-100CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF63-125CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF63-125CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF63-160CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF63-160CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF63-200CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF63-200CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF63-250CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF63-250CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF63-320CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF63-320CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF63-400CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF63-400CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF63-500CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF63-500CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF63-600CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF63-600CW	Mounting: Rod flange \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-25CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-25CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-50CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-50CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-80CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-80CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-100CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-100CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-125CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-125CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-160CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-160CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-200CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-200CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-250CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-250CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-320CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-320CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-400CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-400CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-500CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-500CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-600CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-600CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-700CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-700CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF80-800CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDF80-800CW	Mounting: Rod flange \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SF100-25CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-25CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-50CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-50CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-80CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-80CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-100CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-100CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-125CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-125CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-160CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-160CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-200CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-200CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-250CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-250CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-320CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-320CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-400CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-400CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-500CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-500CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-600CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-600CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-700CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-700CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SF100-800CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDF100-800CW	Mounting: Rod flange \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG32-25CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDG32-25CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SG32-50CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDG32-50CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SG32-80CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDG32-80CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SG32-100CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDG32-100CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SG32-125CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDG32-125CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SG32-160CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDG32-160CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SG32-200CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDG32-200CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SG32-250CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDG32-250CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SG32-320CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDG32-320CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SG32-400CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDG32-400CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SG32-500CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDG32-500CW	Mounting: Head flange \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SG40-25CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG40-25CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG40-50CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG40-50CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG40-80CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG40-80CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG40-100CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG40-100CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG40-125CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG40-125CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG40-160CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG40-160CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG40-200CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG40-200CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG40-250CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG40-250CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG40-320CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG40-320CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG40-400CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG40-400CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG40-500CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG40-500CW	Mounting: Head flange \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG50-25CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG50-25CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG50-50CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG50-50CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG50-80CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG50-80CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG50-100CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG50-100CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG50-125CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG50-125CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG50-160CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG50-160CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG50-200CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG50-200CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG50-250CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG50-250CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG50-320CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG50-320CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG50-400CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG50-400CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG50-500CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG50-500CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG50-600CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDG50-600CW	Mounting: Head flange \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SG63-25CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG63-25CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG63-50CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG63-50CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG63-80CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG63-80CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG63-100CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG63-100CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG63-125CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG63-125CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG63-160CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG63-160CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG63-200CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG63-200CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG63-250CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG63-250CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG63-320CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG63-320CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG63-400CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG63-400CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG63-500CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG63-500CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG63-600CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG63-600CW	Mounting: Head flange \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-25CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-25CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-50CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-50CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-80CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-80CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-100CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-100CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-125CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-125CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-160CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-160CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-200CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-200CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-250CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-250CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-320CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-320CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-400CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-400CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-500CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-500CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-600CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-600CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-700CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-700CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG80-800CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDG80-800CW	Mounting: Head flange \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SG100-25CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-25CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-50CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-50CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-80CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-80CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-100CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-100CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-125CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-125CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-160CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-160CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-200CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-200CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-250CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-250CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-320CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-320CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-400CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-400CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-500CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-500CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-600CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-600CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-700CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-700CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SG100-800CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDG100-800CW	Mounting: Head flange \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC32-25CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDC32-25CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SC32-50CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDC32-50CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SC32-80CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDC32-80CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SC32-100CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDC32-100CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SC32-125CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDC32-125CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SC32-160CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDC32-160CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SC32-200CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDC32-200CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SC32-250CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDC32-250CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SC32-320CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDC32-320CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SC32-400CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDC32-400CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SC32-500CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDC32-500CW	Mounting: Single clevis \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SC40-25CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC40-25CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC40-50CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC40-50CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC40-80CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC40-80CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC40-100CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC40-100CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC40-125CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC40-125CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC40-160CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC40-160CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC40-200CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC40-200CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC40-250CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC40-250CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC40-320CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC40-320CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC40-400CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC40-400CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC40-500CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC40-500CW	Mounting: Single clevis \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC50-25CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC50-25CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC50-50CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC50-50CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC50-80CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC50-80CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC50-100CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC50-100CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC50-125CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC50-125CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC50-160CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC50-160CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC50-200CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC50-200CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC50-250CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC50-250CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC50-320CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC50-320CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC50-400CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC50-400CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC50-500CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC50-500CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC50-600CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDC50-600CW	Mounting: Single clevis \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SC63-25CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC63-25CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC63-50CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC63-50CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC63-80CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC63-80CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC63-100CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC63-100CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC63-125CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC63-125CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC63-160CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC63-160CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC63-200CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC63-200CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC63-250CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC63-250CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC63-320CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC63-320CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC63-400CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC63-400CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC63-500CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC63-500CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC63-600CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC63-600CW	Mounting: Single clevis \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-25CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-25CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-50CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-50CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-80CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-80CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-100CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-100CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-125CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-125CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-160CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-160CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-200CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-200CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-250CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-250CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-320CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-320CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-400CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-400CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-500CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-500CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-600CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-600CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-700CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-700CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC80-800CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDC80-800CW	Mounting: Single clevis \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SC100-25CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-25CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-50CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-50CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-80CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-80CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-100CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-100CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-125CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-125CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-160CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-160CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-200CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-200CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-250CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-250CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-320CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-320CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-400CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-400CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-500CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-500CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-600CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-600CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-700CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-700CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SC100-800CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDC100-800CW	Mounting: Single clevis \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD32-25CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDD32-25CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SD32-50CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDD32-50CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SD32-80CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDD32-80CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SD32-100CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDD32-100CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SD32-125CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDD32-125CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SD32-160CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDD32-160CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SD32-200CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDD32-200CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SD32-250CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDD32-250CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SD32-320CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDD32-320CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SD32-400CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDD32-400CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SD32-500CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDD32-500CW	Mounting: Double clevis \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SD40-25CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD40-25CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD40-50CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD40-50CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD40-80CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD40-80CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD40-100CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD40-100CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD40-125CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD40-125CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD40-160CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD40-160CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD40-200CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD40-200CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD40-250CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD40-250CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD40-320CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD40-320CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD40-400CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD40-400CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD40-500CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD40-500CW	Mounting: Double clevis \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD50-25CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD50-25CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD50-50CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD50-50CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD50-80CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD50-80CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD50-100CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD50-100CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD50-125CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD50-125CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD50-160CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD50-160CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD50-200CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD50-200CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD50-250CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD50-250CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD50-320CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD50-320CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD50-400CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD50-400CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD50-500CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD50-500CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD50-600CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDD50-600CW	Mounting: Double clevis \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SD63-25CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD63-25CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD63-50CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD63-50CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD63-80CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD63-80CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD63-100CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD63-100CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD63-125CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD63-125CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD63-160CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD63-160CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD63-200CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD63-200CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD63-250CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD63-250CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD63-320CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD63-320CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD63-400CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD63-400CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD63-500CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD63-500CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD63-600CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD63-600CW	Mounting: Double clevis \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-25CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-25CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-50CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-50CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-80CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-80CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-100CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-100CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-125CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-125CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-160CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-160CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-200CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-200CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-250CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-250CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-320CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-320CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-400CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-400CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-500CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-500CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-600CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-600CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-700CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-700CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD80-800CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDD80-800CW	Mounting: Double clevis \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SD100-25CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-25CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-50CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-50CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-80CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-80CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-100CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-100CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-125CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-125CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-160CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-160CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-200CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-200CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-250CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-250CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-320CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-320CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-400CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-400CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-500CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-500CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-600CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-600CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-700CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-700CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SD100-800CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDD100-800CW	Mounting: Double clevis \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST32-25CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDT32-25CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96ST32-50CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDT32-50CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96ST32-80CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDT32-80CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96ST32-100CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDT32-100CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96ST32-125CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDT32-125CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96ST32-160CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDT32-160CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96ST32-200CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDT32-200CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96ST32-250CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDT32-250CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96ST32-320CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDT32-320CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96ST32-400CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDT32-400CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96ST32-500CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDT32-500CW	Mounting: Center trunnion \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96ST40-25CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT40-25CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST40-50CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT40-50CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST40-80CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT40-80CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST40-100CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT40-100CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST40-125CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT40-125CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST40-160CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT40-160CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST40-200CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT40-200CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST40-250CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT40-250CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST40-320CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT40-320CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST40-400CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT40-400CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST40-500CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT40-500CW	Mounting: Center trunnion \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST50-25CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT50-25CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST50-50CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT50-50CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST50-80CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT50-80CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST50-100CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT50-100CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST50-125CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT50-125CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST50-160CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT50-160CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST50-200CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT50-200CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST50-250CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT50-250CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST50-320CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT50-320CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST50-400CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT50-400CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST50-500CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT50-500CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST50-600CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDT50-600CW	Mounting: Center trunnion \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96ST63-25CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT63-25CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST63-50CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT63-50CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST63-80CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT63-80CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST63-100CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT63-100CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST63-125CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT63-125CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST63-160CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT63-160CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST63-200CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT63-200CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST63-250CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT63-250CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST63-320CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT63-320CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST63-400CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT63-400CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST63-500CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT63-500CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST63-600CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT63-600CW	Mounting: Center trunnion \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-25CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-25CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-50CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-50CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-80CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-80CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-100CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-100CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-125CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-125CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-160CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-160CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-200CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-200CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-250CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-250CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-320CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-320CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-400CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-400CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-500CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-500CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-600CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-600CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-700CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-700CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST80-800CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDT80-800CW	Mounting: Center trunnion \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96ST100-25CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-25CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-50CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-50CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-80CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-80CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-100CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-100CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-125CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-125CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-160CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-160CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-200CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-200CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-250CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-250CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-320CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-320CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-400CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-400CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-500CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-500CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-600CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-600CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-700CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-700CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96ST100-800CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDT100-800CW	Mounting: Center trunnion \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV32-25CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDV32-25CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SV32-50CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDV32-50CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SV32-80CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDV32-80CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SV32-100CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDV32-100CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SV32-125CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDV32-125CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SV32-160CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDV32-160CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SV32-200CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDV32-200CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SV32-250CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDV32-250CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SV32-320CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDV32-320CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SV32-400CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDV32-400CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SV32-500CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/8
	C96SDV32-500CW	Mounting: Adjustable trunnion \| Bore: ø32 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/8
	C96SV40-25CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV40-25CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV40-50CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV40-50CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV40-80CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV40-80CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV40-100CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV40-100CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV40-125CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV40-125CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV40-160CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV40-160CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV40-200CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV40-200CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV40-250CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV40-250CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV40-320CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV40-320CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV40-400CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV40-400CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV40-500CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV40-500CW	Mounting: Adjustable trunnion \| Bore: ø40 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV50-25CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV50-25CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV50-50CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV50-50CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV50-80CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV50-80CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV50-100CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV50-100CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV50-125CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV50-125CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV50-160CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV50-160CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV50-200CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV50-200CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV50-250CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV50-250CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV50-320CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV50-320CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV50-400CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV50-400CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV50-500CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV50-500CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV50-600CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/4
	C96SDV50-600CW	Mounting: Adjustable trunnion \| Bore: ø50 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/4
	C96SV63-25CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV63-25CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV63-50CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV63-50CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV63-80CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV63-80CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV63-100CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV63-100CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV63-125CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV63-125CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV63-160CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV63-160CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV63-200CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV63-200CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV63-250CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV63-250CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV63-320CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV63-320CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV63-400CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV63-400CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV63-500CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV63-500CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV63-600CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV63-600CW	Mounting: Adjustable trunnion \| Bore: ø63 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-25CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-25CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-50CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-50CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-80CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-80CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-100CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-100CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-125CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-125CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-160CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-160CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-200CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-200CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-250CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-250CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-320CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-320CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-400CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-400CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-500CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-500CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-600CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-600CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-700CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-700CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV80-800CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G3/8
	C96SDV80-800CW	Mounting: Adjustable trunnion \| Bore: ø80 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G3/8
	C96SV100-25CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-25CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-50CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-50CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-80CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-80CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 80 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-100CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-100CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-125CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-125CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-160CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-160CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 160 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-200CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-200CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-250CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-250CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-320CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-320CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 320 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-400CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-400CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 400 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-500CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-500CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 500 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-600CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-600CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 600 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-700CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-700CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 700 mm \| Auto switch magnet: Yes \| Port: G1/2
	C96SV100-800CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: No \| Port: G1/2
	C96SDV100-800CW	Mounting: Adjustable trunnion \| Bore: ø100 mm \| Stroke: 800 mm \| Auto switch magnet: Yes \| Port: G1/2

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

SMC C96 ISO 15552 Tie-rod Air Cylinder (Double Rod, ø32 to ø100)
