SMC CEU5 Multi Counter (for CE1/CEP1/CE2/ML2B Scale Cylinders)

SMC CEU5 Multi Counter (for CE1/CEP1/CE2/ML2B Scale Cylinders)

SMC CEU5 series 6-digit multi counter that reads A/B phase pulses from SMC scale cylinders and outputs preset, stop-position and serial data.

Key features

  • Count mode, data setting mode and function setting mode; 6-digit backlit LCD
  • Five preset outputs (20 with bank switching) or 31-point binary output
  • RS-232C standard; BCD output on CEU5(P)B types
  • Count speed 100 kHz, 90 deg phase difference or UP/DOWN individual pulse input
  • Surface or DIN rail mounting; CE/UKCA compliant with DC24V (-D) type
  • Supplies DC12V sensor power (60 mA) to the connected scale cylinder

Specifications

Type Multi counter, 6 digits
Mounting Surface (DIN rail or screw)
Count input No-voltage pulse, 90 deg phase or UP/DOWN
Count speed 100 kHz
Output 5 outputs / binary code, max. DC30V 50 mA
Memory EEPROM
Power consumption 20 VA (AC), 10 W (DC)
Operating temperature 0 to 50 C
Mass 350 g or less
Source SMC Korea catalog CE series (SMCKR_CE1_CEP1_CEU5.pdf), p. 1075-1076 (PDF p. 27-28)
CEU5 Output transistor: NPN open collector | External output: RS-232C | Power supply: AC100 to 240 V
CEU5-D Output transistor: NPN open collector | External output: RS-232C | Power supply: DC24V
CEU5B Output transistor: NPN open collector | External output: RS-232C + BCD | Power supply: AC100 to 240 V
CEU5B-D Output transistor: NPN open collector | External output: RS-232C + BCD | Power supply: DC24V
CEU5P Output transistor: PNP open collector | External output: RS-232C | Power supply: AC100 to 240 V
CEU5P-D Output transistor: PNP open collector | External output: RS-232C | Power supply: DC24V
CEU5PB Output transistor: PNP open collector | External output: RS-232C + BCD | Power supply: AC100 to 240 V
CEU5PB-D Output transistor: PNP open collector | External output: RS-232C + BCD | Power supply: DC24V
AccessoriesSMC
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC CEU5 Multi Counter (for CE1/CEP1/CE2/ML2B Scale Cylinders)

Brand SMC·Accessories

Available part numbers (8)

CEU5, CEU5-D, CEU5B, CEU5B-D, CEU5P, CEU5P-D, CEU5PB, CEU5PB-D
