SMC CG1 Air Cylinder (Double Acting, ø20 to ø40)

SMC CG1 series standard air cylinder, double acting, single rod, in the ø20 to ø40 mm bore range, with rubber or air cushion, eight mounting styles and optional built-in auto switch magnet (CDG1).

Key features

Standard round body cylinder with aluminum tube and rod cover, ø20 to ø100 mm bore
Eight mounting styles: basic with or without trunnion female thread (B/Z), axial foot, rod/head flange, rod/head trunnion and clevis
Rubber cushion (N) or air cushion (A); port thread Rc standard (air cushion ø20/ø25: M5x0.8); NPT (TN) and G (TF) on order
Female rod end (F), bellows (J/K), pivot bracket (N), knuckle joints and rod end (V/W/Q) ordered as suffixes
Auto switch ready with built-in magnet (CDG1): D-M9 solid state (ø20 to ø63), D-G59/K59 (ø80, ø100), D-A9 reed switches

Specifications

Action	Double acting, single rod
Fluid	Air
Proof pressure	1.5 MPa
Max. operating pressure	1.0 MPa
Min. operating pressure	0.05 MPa
Ambient and fluid temperature	-10 to 70°C (with auto switch -10 to 60°C), no freezing
Lubrication	Not required (non-lube)
Piston speed	50 to 1000 mm/s (ø80, ø100: 50 to 700 mm/s)
Stroke length tolerance	+1.4/0 mm up to 1000 st, +1.8/0 mm up to 1500 st
Standard strokes	ø20: 25 to 200 mm; ø25 to ø100: 25 to 300 mm (max. 1500 mm on order)
Source	SMC Korea catalog CAT.KS20-268B (SMCKR_CG1-Z1.pdf), p. 4-6

CG1BN20-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN20-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN20-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN20-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN20-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN20-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN20-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN25-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN25-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN25-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN25-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN25-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN25-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN25-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN25-250Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN25-300Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN32-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN32-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN32-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN32-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN32-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN32-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN32-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN32-250Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN32-300Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN40-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN40-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN40-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN40-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN40-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN40-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN40-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN40-250Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BN40-300Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA20-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA20-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA20-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA20-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA20-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA20-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA20-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA25-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA25-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA25-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA25-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA25-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA25-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA25-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA25-250Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA25-300Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1BA32-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA32-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA32-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA32-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA32-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA32-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA32-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA32-250Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA32-300Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA40-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA40-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA40-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA40-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA40-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA40-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA40-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA40-250Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1BA40-300Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN20-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN20-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN20-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN20-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN20-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN20-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN20-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN25-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN25-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN25-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN25-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN25-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN25-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN25-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN25-250Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN25-300Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN32-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN32-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN32-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN32-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN32-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN32-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN32-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN32-250Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN32-300Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN40-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN40-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN40-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN40-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN40-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN40-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN40-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN40-250Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZN40-300Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA20-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA20-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA20-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA20-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA20-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA20-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA20-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA25-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA25-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA25-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA25-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA25-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA25-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA25-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA25-250Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA25-300Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1ZA32-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA32-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA32-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA32-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA32-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA32-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA32-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA32-250Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA32-300Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA40-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA40-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA40-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA40-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA40-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA40-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA40-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA40-250Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1ZA40-300Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN20-25Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN20-50Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN20-75Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN20-100Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN20-125Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN20-150Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN20-200Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN25-25Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN25-50Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN25-75Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN25-100Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN25-125Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN25-150Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN25-200Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN25-250Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN25-300Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN32-25Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN32-50Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN32-75Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN32-100Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN32-125Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN32-150Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN32-200Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN32-250Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN32-300Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN40-25Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN40-50Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN40-75Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN40-100Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN40-125Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN40-150Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN40-200Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN40-250Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LN40-300Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA20-25Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA20-50Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA20-75Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA20-100Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA20-125Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA20-150Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA20-200Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA25-25Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA25-50Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA25-75Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA25-100Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA25-125Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA25-150Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA25-200Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA25-250Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA25-300Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1LA32-25Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA32-50Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA32-75Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA32-100Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA32-125Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA32-150Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA32-200Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA32-250Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA32-300Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA40-25Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA40-50Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA40-75Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA40-100Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA40-125Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA40-150Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA40-200Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA40-250Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1LA40-300Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN20-25Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN20-50Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN20-75Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN20-100Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN20-125Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN20-150Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN20-200Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN25-25Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN25-50Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN25-75Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN25-100Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN25-125Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN25-150Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN25-200Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN25-250Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN25-300Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN32-25Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN32-50Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN32-75Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN32-100Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN32-125Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN32-150Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN32-200Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN32-250Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN32-300Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN40-25Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN40-50Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN40-75Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN40-100Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN40-125Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN40-150Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN40-200Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN40-250Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FN40-300Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA20-25Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA20-50Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA20-75Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA20-100Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA20-125Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA20-150Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA20-200Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA25-25Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA25-50Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA25-75Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA25-100Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA25-125Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA25-150Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA25-200Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA25-250Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA25-300Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1FA32-25Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA32-50Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA32-75Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA32-100Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA32-125Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA32-150Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA32-200Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA32-250Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA32-300Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA40-25Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA40-50Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA40-75Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA40-100Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA40-125Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA40-150Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA40-200Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA40-250Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1FA40-300Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN20-25Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN20-50Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN20-75Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN20-100Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN20-125Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN20-150Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN20-200Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN25-25Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN25-50Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN25-75Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN25-100Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN25-125Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN25-150Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN25-200Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN25-250Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN25-300Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN32-25Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN32-50Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN32-75Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN32-100Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN32-125Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN32-150Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN32-200Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN32-250Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN32-300Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN40-25Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN40-50Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN40-75Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN40-100Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN40-125Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN40-150Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN40-200Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN40-250Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GN40-300Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA20-25Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA20-50Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA20-75Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA20-100Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA20-125Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA20-150Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA20-200Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA25-25Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA25-50Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA25-75Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA25-100Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA25-125Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA25-150Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA25-200Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA25-250Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA25-300Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1GA32-25Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA32-50Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA32-75Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA32-100Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA32-125Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA32-150Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA32-200Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA32-250Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA32-300Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA40-25Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA40-50Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA40-75Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA40-100Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA40-125Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA40-150Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA40-200Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA40-250Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1GA40-300Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN20-25Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN20-50Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN20-75Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN20-100Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN20-125Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN20-150Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN20-200Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN25-25Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN25-50Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN25-75Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN25-100Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN25-125Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN25-150Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN25-200Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN25-250Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN25-300Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN32-25Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN32-50Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN32-75Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN32-100Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN32-125Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN32-150Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN32-200Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN32-250Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN32-300Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN40-25Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN40-50Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN40-75Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN40-100Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN40-125Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN40-150Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN40-200Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN40-250Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UN40-300Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA20-25Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA20-50Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA20-75Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA20-100Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA20-125Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA20-150Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA20-200Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA25-25Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA25-50Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA25-75Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA25-100Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA25-125Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA25-150Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA25-200Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA25-250Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA25-300Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1UA32-25Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA32-50Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA32-75Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA32-100Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA32-125Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA32-150Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA32-200Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA32-250Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA32-300Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA40-25Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA40-50Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA40-75Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA40-100Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA40-125Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA40-150Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA40-200Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA40-250Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1UA40-300Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN20-25Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN20-50Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN20-75Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN20-100Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN20-125Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN20-150Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN20-200Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN25-25Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN25-50Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN25-75Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN25-100Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN25-125Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN25-150Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN25-200Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN25-250Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN25-300Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN32-25Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN32-50Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN32-75Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN32-100Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN32-125Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN32-150Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN32-200Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN32-250Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN32-300Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN40-25Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN40-50Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN40-75Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN40-100Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN40-125Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN40-150Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN40-200Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN40-250Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TN40-300Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA20-25Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA20-50Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA20-75Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA20-100Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA20-125Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA20-150Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA20-200Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA25-25Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA25-50Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA25-75Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA25-100Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA25-125Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA25-150Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA25-200Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA25-250Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA25-300Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1TA32-25Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA32-50Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA32-75Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA32-100Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA32-125Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA32-150Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA32-200Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA32-250Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA32-300Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA40-25Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA40-50Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA40-75Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA40-100Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA40-125Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA40-150Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA40-200Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA40-250Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1TA40-300Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN20-25Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN20-50Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN20-75Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN20-100Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN20-125Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN20-150Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN20-200Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN25-25Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN25-50Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN25-75Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN25-100Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN25-125Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN25-150Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN25-200Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN25-250Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN25-300Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN32-25Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN32-50Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN32-75Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN32-100Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN32-125Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN32-150Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN32-200Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN32-250Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN32-300Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN40-25Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN40-50Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN40-75Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN40-100Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN40-125Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN40-150Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN40-200Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN40-250Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DN40-300Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA20-25Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA20-50Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA20-75Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA20-100Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA20-125Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA20-150Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA20-200Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA25-25Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA25-50Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA25-75Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA25-100Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA25-125Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA25-150Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA25-200Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA25-250Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA25-300Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
CG1DA32-25Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA32-50Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA32-75Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA32-100Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA32-125Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA32-150Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA32-200Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA32-250Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA32-300Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA40-25Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA40-50Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA40-75Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA40-100Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA40-125Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA40-150Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA40-200Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA40-250Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
CG1DA40-300Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
CDG1BN20-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN20-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN20-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN20-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN20-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN20-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN20-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN25-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN25-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN25-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN25-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN25-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN25-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN25-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN25-250Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN25-300Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN32-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN32-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN32-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN32-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN32-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN32-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN32-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN32-250Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN32-300Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN40-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN40-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN40-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN40-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN40-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN40-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN40-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN40-250Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BN40-300Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA20-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA20-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA20-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA20-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA20-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA20-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA20-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA25-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA25-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA25-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA25-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA25-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA25-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA25-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA25-250Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA25-300Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1BA32-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA32-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA32-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA32-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA32-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA32-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA32-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA32-250Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA32-300Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA40-25Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA40-50Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA40-75Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA40-100Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA40-125Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA40-150Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA40-200Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA40-250Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1BA40-300Z1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN20-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN20-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN20-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN20-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN20-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN20-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN20-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN25-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN25-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN25-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN25-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN25-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN25-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN25-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN25-250Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN25-300Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN32-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN32-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN32-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN32-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN32-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN32-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN32-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN32-250Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN32-300Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN40-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN40-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN40-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN40-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN40-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN40-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN40-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN40-250Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZN40-300Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA20-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA20-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA20-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA20-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA20-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA20-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA20-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA25-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA25-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA25-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA25-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA25-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA25-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA25-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA25-250Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA25-300Z1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1ZA32-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA32-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA32-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA32-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA32-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA32-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA32-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA32-250Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA32-300Z1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA40-25Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA40-50Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA40-75Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA40-100Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA40-125Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA40-150Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA40-200Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA40-250Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1ZA40-300Z1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN20-25Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN20-50Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN20-75Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN20-100Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN20-125Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN20-150Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN20-200Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN25-25Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN25-50Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN25-75Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN25-100Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN25-125Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN25-150Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN25-200Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN25-250Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN25-300Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN32-25Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN32-50Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN32-75Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN32-100Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN32-125Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN32-150Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN32-200Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN32-250Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN32-300Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN40-25Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN40-50Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN40-75Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN40-100Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN40-125Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN40-150Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN40-200Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN40-250Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LN40-300Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA20-25Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA20-50Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA20-75Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA20-100Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA20-125Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA20-150Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA20-200Z1		Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA25-25Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA25-50Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA25-75Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA25-100Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA25-125Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA25-150Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA25-200Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA25-250Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA25-300Z1		Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1LA32-25Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA32-50Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA32-75Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA32-100Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA32-125Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA32-150Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA32-200Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA32-250Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA32-300Z1		Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA40-25Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA40-50Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA40-75Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA40-100Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA40-125Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA40-150Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA40-200Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA40-250Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1LA40-300Z1		Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN20-25Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN20-50Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN20-75Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN20-100Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN20-125Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN20-150Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN20-200Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN25-25Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN25-50Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN25-75Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN25-100Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN25-125Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN25-150Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN25-200Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN25-250Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN25-300Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN32-25Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN32-50Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN32-75Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN32-100Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN32-125Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN32-150Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN32-200Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN32-250Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN32-300Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN40-25Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN40-50Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN40-75Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN40-100Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN40-125Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN40-150Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN40-200Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN40-250Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FN40-300Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA20-25Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA20-50Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA20-75Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA20-100Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA20-125Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA20-150Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA20-200Z1		Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA25-25Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA25-50Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA25-75Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA25-100Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA25-125Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA25-150Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA25-200Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA25-250Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA25-300Z1		Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1FA32-25Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA32-50Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA32-75Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA32-100Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA32-125Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA32-150Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA32-200Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA32-250Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA32-300Z1		Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA40-25Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA40-50Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA40-75Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA40-100Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA40-125Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA40-150Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA40-200Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA40-250Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1FA40-300Z1		Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN20-25Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN20-50Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN20-75Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN20-100Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN20-125Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN20-150Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN20-200Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN25-25Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN25-50Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN25-75Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN25-100Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN25-125Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN25-150Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN25-200Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN25-250Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN25-300Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN32-25Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN32-50Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN32-75Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN32-100Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN32-125Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN32-150Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN32-200Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN32-250Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN32-300Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN40-25Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN40-50Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN40-75Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN40-100Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN40-125Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN40-150Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN40-200Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN40-250Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GN40-300Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA20-25Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA20-50Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA20-75Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA20-100Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA20-125Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA20-150Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA20-200Z1		Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA25-25Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA25-50Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA25-75Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA25-100Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA25-125Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA25-150Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA25-200Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA25-250Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA25-300Z1		Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1GA32-25Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA32-50Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA32-75Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA32-100Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA32-125Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA32-150Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA32-200Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA32-250Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA32-300Z1		Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA40-25Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA40-50Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA40-75Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA40-100Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA40-125Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA40-150Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA40-200Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA40-250Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1GA40-300Z1		Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN20-25Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN20-50Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN20-75Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN20-100Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN20-125Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN20-150Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN20-200Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN25-25Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN25-50Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN25-75Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN25-100Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN25-125Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN25-150Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN25-200Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN25-250Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN25-300Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN32-25Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN32-50Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN32-75Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN32-100Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN32-125Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN32-150Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN32-200Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN32-250Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN32-300Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN40-25Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN40-50Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN40-75Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN40-100Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN40-125Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN40-150Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN40-200Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN40-250Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UN40-300Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA20-25Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA20-50Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA20-75Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA20-100Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA20-125Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA20-150Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA20-200Z1		Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA25-25Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA25-50Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA25-75Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA25-100Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA25-125Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA25-150Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA25-200Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA25-250Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA25-300Z1		Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1UA32-25Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA32-50Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA32-75Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA32-100Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA32-125Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA32-150Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA32-200Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA32-250Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA32-300Z1		Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA40-25Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA40-50Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA40-75Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA40-100Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA40-125Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA40-150Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA40-200Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA40-250Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1UA40-300Z1		Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN20-25Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN20-50Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN20-75Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN20-100Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN20-125Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN20-150Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN20-200Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN25-25Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN25-50Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN25-75Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN25-100Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN25-125Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN25-150Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN25-200Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN25-250Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN25-300Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN32-25Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN32-50Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN32-75Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN32-100Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN32-125Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN32-150Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN32-200Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN32-250Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN32-300Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN40-25Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN40-50Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN40-75Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN40-100Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN40-125Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN40-150Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN40-200Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN40-250Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TN40-300Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA20-25Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA20-50Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA20-75Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA20-100Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA20-125Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA20-150Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA20-200Z1		Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA25-25Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA25-50Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA25-75Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA25-100Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA25-125Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA25-150Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA25-200Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA25-250Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA25-300Z1		Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1TA32-25Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA32-50Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA32-75Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA32-100Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA32-125Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA32-150Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA32-200Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA32-250Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA32-300Z1		Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA40-25Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA40-50Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA40-75Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA40-100Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA40-125Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA40-150Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA40-200Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA40-250Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1TA40-300Z1		Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN20-25Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN20-50Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN20-75Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN20-100Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN20-125Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN20-150Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN20-200Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN25-25Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN25-50Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN25-75Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN25-100Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN25-125Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN25-150Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN25-200Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN25-250Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN25-300Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN32-25Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN32-50Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN32-75Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN32-100Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN32-125Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN32-150Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN32-200Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN32-250Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN32-300Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN40-25Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN40-50Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN40-75Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN40-100Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN40-125Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN40-150Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN40-200Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN40-250Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DN40-300Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA20-25Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA20-50Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA20-75Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA20-100Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA20-125Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA20-150Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA20-200Z1		Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA25-25Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA25-50Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA25-75Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA25-100Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA25-125Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA25-150Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA25-200Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA25-250Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA25-300Z1		Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
CDG1DA32-25Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA32-50Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA32-75Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA32-100Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA32-125Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA32-150Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA32-200Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA32-250Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA32-300Z1		Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA40-25Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA40-50Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA40-75Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA40-100Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA40-125Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA40-150Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA40-200Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA40-250Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
CDG1DA40-300Z1		Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8

Round Body CylindersSMC

1088 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC CG1 Air Cylinder (Double Acting, ø20 to ø40)

Brand SMC·Round Body Cylinders

Available part numbers (1088)

CG1BN20-25Z1, CG1BN20-50Z1, CG1BN20-75Z1, CG1BN20-100Z1, CG1BN20-125Z1, CG1BN20-150Z1, CG1BN20-200Z1, CG1BN25-25Z1, CG1BN25-50Z1, CG1BN25-75Z1 + 1078 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	CG1BN20-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN20-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN20-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN20-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN20-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN20-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN20-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN25-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN25-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN25-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN25-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN25-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN25-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN25-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN25-250Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN25-300Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN32-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN32-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN32-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN32-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN32-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN32-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN32-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN32-250Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN32-300Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN40-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN40-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN40-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN40-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN40-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN40-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN40-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN40-250Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BN40-300Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA20-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA20-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA20-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA20-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA20-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA20-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA20-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA25-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA25-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA25-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA25-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA25-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA25-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA25-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA25-250Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA25-300Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1BA32-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA32-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA32-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA32-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA32-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA32-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA32-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA32-250Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA32-300Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA40-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA40-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA40-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA40-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA40-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA40-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA40-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA40-250Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1BA40-300Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN20-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN20-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN20-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN20-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN20-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN20-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN20-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN25-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN25-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN25-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN25-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN25-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN25-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN25-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN25-250Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN25-300Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN32-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN32-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN32-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN32-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN32-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN32-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN32-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN32-250Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN32-300Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN40-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN40-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN40-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN40-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN40-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN40-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN40-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN40-250Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZN40-300Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA20-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA20-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA20-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA20-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA20-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA20-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA20-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA25-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA25-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA25-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA25-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA25-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA25-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA25-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA25-250Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA25-300Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1ZA32-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA32-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA32-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA32-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA32-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA32-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA32-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA32-250Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA32-300Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA40-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA40-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA40-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA40-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA40-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA40-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA40-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA40-250Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1ZA40-300Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN20-25Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN20-50Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN20-75Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN20-100Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN20-125Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN20-150Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN20-200Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN25-25Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN25-50Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN25-75Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN25-100Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN25-125Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN25-150Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN25-200Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN25-250Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN25-300Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN32-25Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN32-50Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN32-75Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN32-100Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN32-125Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN32-150Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN32-200Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN32-250Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN32-300Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN40-25Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN40-50Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN40-75Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN40-100Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN40-125Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN40-150Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN40-200Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN40-250Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LN40-300Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA20-25Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA20-50Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA20-75Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA20-100Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA20-125Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA20-150Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA20-200Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA25-25Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA25-50Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA25-75Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA25-100Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA25-125Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA25-150Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA25-200Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA25-250Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA25-300Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1LA32-25Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA32-50Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA32-75Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA32-100Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA32-125Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA32-150Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA32-200Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA32-250Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA32-300Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA40-25Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA40-50Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA40-75Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA40-100Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA40-125Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA40-150Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA40-200Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA40-250Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1LA40-300Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN20-25Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN20-50Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN20-75Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN20-100Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN20-125Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN20-150Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN20-200Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN25-25Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN25-50Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN25-75Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN25-100Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN25-125Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN25-150Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN25-200Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN25-250Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN25-300Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN32-25Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN32-50Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN32-75Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN32-100Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN32-125Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN32-150Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN32-200Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN32-250Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN32-300Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN40-25Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN40-50Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN40-75Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN40-100Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN40-125Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN40-150Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN40-200Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN40-250Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FN40-300Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA20-25Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA20-50Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA20-75Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA20-100Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA20-125Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA20-150Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA20-200Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA25-25Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA25-50Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA25-75Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA25-100Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA25-125Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA25-150Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA25-200Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA25-250Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA25-300Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1FA32-25Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA32-50Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA32-75Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA32-100Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA32-125Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA32-150Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA32-200Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA32-250Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA32-300Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA40-25Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA40-50Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA40-75Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA40-100Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA40-125Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA40-150Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA40-200Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA40-250Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1FA40-300Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN20-25Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN20-50Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN20-75Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN20-100Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN20-125Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN20-150Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN20-200Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN25-25Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN25-50Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN25-75Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN25-100Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN25-125Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN25-150Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN25-200Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN25-250Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN25-300Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN32-25Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN32-50Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN32-75Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN32-100Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN32-125Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN32-150Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN32-200Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN32-250Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN32-300Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN40-25Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN40-50Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN40-75Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN40-100Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN40-125Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN40-150Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN40-200Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN40-250Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GN40-300Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA20-25Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA20-50Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA20-75Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA20-100Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA20-125Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA20-150Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA20-200Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA25-25Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA25-50Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA25-75Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA25-100Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA25-125Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA25-150Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA25-200Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA25-250Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA25-300Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1GA32-25Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA32-50Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA32-75Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA32-100Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA32-125Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA32-150Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA32-200Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA32-250Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA32-300Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA40-25Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA40-50Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA40-75Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA40-100Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA40-125Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA40-150Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA40-200Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA40-250Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1GA40-300Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN20-25Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN20-50Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN20-75Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN20-100Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN20-125Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN20-150Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN20-200Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN25-25Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN25-50Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN25-75Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN25-100Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN25-125Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN25-150Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN25-200Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN25-250Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN25-300Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN32-25Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN32-50Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN32-75Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN32-100Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN32-125Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN32-150Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN32-200Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN32-250Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN32-300Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN40-25Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN40-50Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN40-75Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN40-100Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN40-125Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN40-150Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN40-200Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN40-250Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UN40-300Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA20-25Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA20-50Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA20-75Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA20-100Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA20-125Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA20-150Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA20-200Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA25-25Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA25-50Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA25-75Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA25-100Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA25-125Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA25-150Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA25-200Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA25-250Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA25-300Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1UA32-25Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA32-50Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA32-75Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA32-100Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA32-125Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA32-150Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA32-200Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA32-250Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA32-300Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA40-25Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA40-50Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA40-75Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA40-100Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA40-125Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA40-150Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA40-200Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA40-250Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1UA40-300Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN20-25Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN20-50Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN20-75Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN20-100Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN20-125Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN20-150Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN20-200Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN25-25Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN25-50Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN25-75Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN25-100Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN25-125Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN25-150Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN25-200Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN25-250Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN25-300Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN32-25Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN32-50Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN32-75Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN32-100Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN32-125Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN32-150Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN32-200Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN32-250Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN32-300Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN40-25Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN40-50Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN40-75Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN40-100Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN40-125Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN40-150Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN40-200Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN40-250Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TN40-300Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA20-25Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA20-50Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA20-75Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA20-100Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA20-125Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA20-150Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA20-200Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA25-25Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA25-50Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA25-75Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA25-100Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA25-125Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA25-150Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA25-200Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA25-250Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA25-300Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1TA32-25Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA32-50Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA32-75Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA32-100Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA32-125Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA32-150Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA32-200Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA32-250Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA32-300Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA40-25Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA40-50Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA40-75Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA40-100Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA40-125Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA40-150Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA40-200Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA40-250Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1TA40-300Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN20-25Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN20-50Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN20-75Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN20-100Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN20-125Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN20-150Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN20-200Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN25-25Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN25-50Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN25-75Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN25-100Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN25-125Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN25-150Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN25-200Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN25-250Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN25-300Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN32-25Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN32-50Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN32-75Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN32-100Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN32-125Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN32-150Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN32-200Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN32-250Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN32-300Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN40-25Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN40-50Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN40-75Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN40-100Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN40-125Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN40-150Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN40-200Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN40-250Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DN40-300Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA20-25Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA20-50Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA20-75Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA20-100Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA20-125Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA20-150Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA20-200Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA25-25Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA25-50Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA25-75Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA25-100Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA25-125Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA25-150Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA25-200Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA25-250Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA25-300Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: M5x0.8
	CG1DA32-25Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA32-50Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA32-75Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA32-100Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA32-125Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA32-150Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA32-200Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA32-250Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA32-300Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA40-25Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA40-50Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA40-75Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA40-100Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA40-125Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA40-150Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA40-200Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA40-250Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: No \| Port: Rc1/8
	CG1DA40-300Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: No \| Port: Rc1/8
	CDG1BN20-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN20-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN20-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN20-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN20-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN20-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN20-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN25-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN25-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN25-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN25-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN25-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN25-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN25-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN25-250Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN25-300Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN32-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN32-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN32-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN32-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN32-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN32-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN32-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN32-250Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN32-300Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN40-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN40-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN40-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN40-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN40-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN40-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN40-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN40-250Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BN40-300Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA20-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA20-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA20-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA20-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA20-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA20-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA20-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA25-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA25-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA25-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA25-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA25-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA25-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA25-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA25-250Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA25-300Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1BA32-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA32-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA32-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA32-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA32-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA32-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA32-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA32-250Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA32-300Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA40-25Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA40-50Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA40-75Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA40-100Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA40-125Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA40-150Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA40-200Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA40-250Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1BA40-300Z1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN20-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN20-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN20-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN20-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN20-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN20-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN20-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN25-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN25-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN25-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN25-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN25-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN25-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN25-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN25-250Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN25-300Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN32-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN32-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN32-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN32-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN32-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN32-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN32-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN32-250Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN32-300Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN40-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN40-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN40-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN40-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN40-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN40-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN40-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN40-250Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZN40-300Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA20-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA20-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA20-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA20-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA20-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA20-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA20-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA25-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA25-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA25-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA25-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA25-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA25-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA25-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA25-250Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA25-300Z1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1ZA32-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA32-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA32-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA32-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA32-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA32-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA32-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA32-250Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA32-300Z1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA40-25Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA40-50Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA40-75Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA40-100Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA40-125Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA40-150Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA40-200Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA40-250Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1ZA40-300Z1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN20-25Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN20-50Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN20-75Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN20-100Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN20-125Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN20-150Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN20-200Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN25-25Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN25-50Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN25-75Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN25-100Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN25-125Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN25-150Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN25-200Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN25-250Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN25-300Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN32-25Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN32-50Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN32-75Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN32-100Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN32-125Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN32-150Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN32-200Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN32-250Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN32-300Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN40-25Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN40-50Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN40-75Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN40-100Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN40-125Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN40-150Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN40-200Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN40-250Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LN40-300Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA20-25Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA20-50Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA20-75Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA20-100Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA20-125Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA20-150Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA20-200Z1	Mounting: Axial foot \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA25-25Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA25-50Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA25-75Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA25-100Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA25-125Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA25-150Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA25-200Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA25-250Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA25-300Z1	Mounting: Axial foot \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1LA32-25Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA32-50Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA32-75Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA32-100Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA32-125Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA32-150Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA32-200Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA32-250Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA32-300Z1	Mounting: Axial foot \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA40-25Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA40-50Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA40-75Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA40-100Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA40-125Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA40-150Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA40-200Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA40-250Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1LA40-300Z1	Mounting: Axial foot \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN20-25Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN20-50Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN20-75Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN20-100Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN20-125Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN20-150Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN20-200Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN25-25Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN25-50Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN25-75Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN25-100Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN25-125Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN25-150Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN25-200Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN25-250Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN25-300Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN32-25Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN32-50Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN32-75Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN32-100Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN32-125Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN32-150Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN32-200Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN32-250Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN32-300Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN40-25Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN40-50Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN40-75Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN40-100Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN40-125Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN40-150Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN40-200Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN40-250Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FN40-300Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA20-25Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA20-50Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA20-75Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA20-100Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA20-125Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA20-150Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA20-200Z1	Mounting: Rod flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA25-25Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA25-50Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA25-75Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA25-100Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA25-125Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA25-150Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA25-200Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA25-250Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA25-300Z1	Mounting: Rod flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1FA32-25Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA32-50Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA32-75Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA32-100Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA32-125Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA32-150Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA32-200Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA32-250Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA32-300Z1	Mounting: Rod flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA40-25Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA40-50Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA40-75Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA40-100Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA40-125Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA40-150Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA40-200Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA40-250Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1FA40-300Z1	Mounting: Rod flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN20-25Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN20-50Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN20-75Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN20-100Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN20-125Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN20-150Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN20-200Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN25-25Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN25-50Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN25-75Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN25-100Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN25-125Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN25-150Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN25-200Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN25-250Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN25-300Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN32-25Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN32-50Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN32-75Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN32-100Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN32-125Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN32-150Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN32-200Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN32-250Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN32-300Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN40-25Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN40-50Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN40-75Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN40-100Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN40-125Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN40-150Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN40-200Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN40-250Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GN40-300Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA20-25Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA20-50Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA20-75Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA20-100Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA20-125Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA20-150Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA20-200Z1	Mounting: Head flange \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA25-25Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA25-50Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA25-75Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA25-100Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA25-125Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA25-150Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA25-200Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA25-250Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA25-300Z1	Mounting: Head flange \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1GA32-25Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA32-50Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA32-75Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA32-100Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA32-125Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA32-150Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA32-200Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA32-250Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA32-300Z1	Mounting: Head flange \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA40-25Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA40-50Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA40-75Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA40-100Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA40-125Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA40-150Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA40-200Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA40-250Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1GA40-300Z1	Mounting: Head flange \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN20-25Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN20-50Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN20-75Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN20-100Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN20-125Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN20-150Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN20-200Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN25-25Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN25-50Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN25-75Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN25-100Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN25-125Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN25-150Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN25-200Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN25-250Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN25-300Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN32-25Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN32-50Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN32-75Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN32-100Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN32-125Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN32-150Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN32-200Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN32-250Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN32-300Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN40-25Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN40-50Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN40-75Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN40-100Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN40-125Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN40-150Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN40-200Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN40-250Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UN40-300Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA20-25Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA20-50Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA20-75Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA20-100Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA20-125Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA20-150Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA20-200Z1	Mounting: Rod trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA25-25Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA25-50Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA25-75Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA25-100Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA25-125Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA25-150Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA25-200Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA25-250Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA25-300Z1	Mounting: Rod trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1UA32-25Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA32-50Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA32-75Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA32-100Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA32-125Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA32-150Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA32-200Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA32-250Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA32-300Z1	Mounting: Rod trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA40-25Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA40-50Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA40-75Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA40-100Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA40-125Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA40-150Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA40-200Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA40-250Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1UA40-300Z1	Mounting: Rod trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN20-25Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN20-50Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN20-75Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN20-100Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN20-125Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN20-150Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN20-200Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN25-25Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN25-50Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN25-75Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN25-100Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN25-125Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN25-150Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN25-200Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN25-250Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN25-300Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN32-25Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN32-50Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN32-75Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN32-100Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN32-125Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN32-150Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN32-200Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN32-250Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN32-300Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN40-25Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN40-50Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN40-75Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN40-100Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN40-125Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN40-150Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN40-200Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN40-250Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TN40-300Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA20-25Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA20-50Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA20-75Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA20-100Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA20-125Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA20-150Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA20-200Z1	Mounting: Head trunnion \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA25-25Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA25-50Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA25-75Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA25-100Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA25-125Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA25-150Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA25-200Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA25-250Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA25-300Z1	Mounting: Head trunnion \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1TA32-25Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA32-50Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA32-75Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA32-100Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA32-125Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA32-150Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA32-200Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA32-250Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA32-300Z1	Mounting: Head trunnion \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA40-25Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA40-50Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA40-75Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA40-100Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA40-125Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA40-150Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA40-200Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA40-250Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1TA40-300Z1	Mounting: Head trunnion \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN20-25Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN20-50Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN20-75Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN20-100Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN20-125Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN20-150Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN20-200Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN25-25Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN25-50Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN25-75Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN25-100Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN25-125Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN25-150Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN25-200Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN25-250Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN25-300Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN32-25Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN32-50Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN32-75Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN32-100Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN32-125Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN32-150Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN32-200Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN32-250Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN32-300Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN40-25Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN40-50Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN40-75Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN40-100Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN40-125Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN40-150Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN40-200Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN40-250Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DN40-300Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Rubber \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA20-25Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA20-50Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA20-75Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA20-100Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA20-125Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA20-150Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA20-200Z1	Mounting: Clevis \| Bore: ø20 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA25-25Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA25-50Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA25-75Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA25-100Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA25-125Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA25-150Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA25-200Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA25-250Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA25-300Z1	Mounting: Clevis \| Bore: ø25 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: M5x0.8
	CDG1DA32-25Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA32-50Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA32-75Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA32-100Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA32-125Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA32-150Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA32-200Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA32-250Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA32-300Z1	Mounting: Clevis \| Bore: ø32 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA40-25Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 25 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA40-50Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 50 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA40-75Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 75 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA40-100Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 100 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA40-125Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 125 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA40-150Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 150 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA40-200Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 200 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA40-250Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 250 mm \| Auto switch magnet: Yes \| Port: Rc1/8
	CDG1DA40-300Z1	Mounting: Clevis \| Bore: ø40 mm \| Cushion: Air \| Stroke: 300 mm \| Auto switch magnet: Yes \| Port: Rc1/8

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

SMC CG1 Air Cylinder (Double Acting, ø20 to ø40)
