SMC CG1 Air Cylinder (Single Acting, Push/Pull, ø20 to ø40)

SMC CG1 series single acting air cylinder with spring return (S) or spring extend (T), ø20 to ø40 mm bore, rubber cushion, eight mounting styles and optional built-in auto switch magnet (CDG1).

Key features

Single acting with spring: S type (spring return, air extends) and T type (spring extend, air retracts)
Eight mounting styles: basic with or without trunnion female thread (B/Z), axial foot, rod/head flange, rod/head trunnion and clevis
Rubber cushion; port thread Rc standard, NPT (TN) and G (TF) on order
Female rod end (F), pivot bracket (N), knuckle joints and rod end (V/W/Q) and auto switches ordered as suffixes
Standard strokes ø20: 25 to 125 mm; ø25 to ø40: 25 to 200 mm

Specifications

Fluid	Air
Proof pressure	1.5 MPa
Max. operating pressure	1.0 MPa
Min. operating pressure	0.18 MPa (S type), 0.23 MPa (T type)
Ambient and fluid temperature	-10 to 70°C (with auto switch -10 to 60°C), no freezing
Lubrication	Not required (non-lube)
Piston speed	50 to 1000 mm/s
Cushion	Rubber cushion
Stroke length tolerance	+1.4/0 mm
Port thread	Rc
Source	SMC Korea catalog CAT.KS20-268B (SMCKR_CG1-Z1.pdf), p. 18-19

CG1BN20-25SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1BN20-50SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1BN20-75SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1BN20-100SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1BN20-125SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1BN25-25SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1BN25-50SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1BN25-75SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1BN25-100SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1BN25-125SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1BN25-150SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1BN25-200SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1BN32-25SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1BN32-50SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1BN32-75SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1BN32-100SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1BN32-125SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1BN32-150SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1BN32-200SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1BN40-25SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1BN40-50SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1BN40-75SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1BN40-100SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1BN40-125SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1BN40-150SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1BN40-200SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1BN20-25TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1BN20-50TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1BN20-75TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1BN20-100TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1BN20-125TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1BN25-25TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1BN25-50TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1BN25-75TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1BN25-100TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1BN25-125TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1BN25-150TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1BN25-200TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1BN32-25TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1BN32-50TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1BN32-75TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1BN32-100TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1BN32-125TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1BN32-150TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1BN32-200TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1BN40-25TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1BN40-50TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1BN40-75TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1BN40-100TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1BN40-125TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1BN40-150TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1BN40-200TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1ZN20-25SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1ZN20-50SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1ZN20-75SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1ZN20-100SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1ZN20-125SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1ZN25-25SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1ZN25-50SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1ZN25-75SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1ZN25-100SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1ZN25-125SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1ZN25-150SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1ZN25-200SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1ZN32-25SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1ZN32-50SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1ZN32-75SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1ZN32-100SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1ZN32-125SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1ZN32-150SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1ZN32-200SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1ZN40-25SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1ZN40-50SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1ZN40-75SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1ZN40-100SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1ZN40-125SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1ZN40-150SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1ZN40-200SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1ZN20-25TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1ZN20-50TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1ZN20-75TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1ZN20-100TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1ZN20-125TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1ZN25-25TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1ZN25-50TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1ZN25-75TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1ZN25-100TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1ZN25-125TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1ZN25-150TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1ZN25-200TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1ZN32-25TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1ZN32-50TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1ZN32-75TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1ZN32-100TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1ZN32-125TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1ZN32-150TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1ZN32-200TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1ZN40-25TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1ZN40-50TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1ZN40-75TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1ZN40-100TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1ZN40-125TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1ZN40-150TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1ZN40-200TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1LN20-25SZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1LN20-50SZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1LN20-75SZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1LN20-100SZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1LN20-125SZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1LN25-25SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1LN25-50SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1LN25-75SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1LN25-100SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1LN25-125SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1LN25-150SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1LN25-200SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1LN32-25SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1LN32-50SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1LN32-75SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1LN32-100SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1LN32-125SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1LN32-150SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1LN32-200SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1LN40-25SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1LN40-50SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1LN40-75SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1LN40-100SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1LN40-125SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1LN40-150SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1LN40-200SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1LN20-25TZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1LN20-50TZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1LN20-75TZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1LN20-100TZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1LN20-125TZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1LN25-25TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1LN25-50TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1LN25-75TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1LN25-100TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1LN25-125TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1LN25-150TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1LN25-200TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1LN32-25TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1LN32-50TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1LN32-75TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1LN32-100TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1LN32-125TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1LN32-150TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1LN32-200TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1LN40-25TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1LN40-50TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1LN40-75TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1LN40-100TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1LN40-125TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1LN40-150TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1LN40-200TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1FN20-25SZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1FN20-50SZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1FN20-75SZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1FN20-100SZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1FN20-125SZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1FN25-25SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1FN25-50SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1FN25-75SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1FN25-100SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1FN25-125SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1FN25-150SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1FN25-200SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1FN32-25SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1FN32-50SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1FN32-75SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1FN32-100SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1FN32-125SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1FN32-150SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1FN32-200SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1FN40-25SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1FN40-50SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1FN40-75SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1FN40-100SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1FN40-125SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1FN40-150SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1FN40-200SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1FN20-25TZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1FN20-50TZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1FN20-75TZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1FN20-100TZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1FN20-125TZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1FN25-25TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1FN25-50TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1FN25-75TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1FN25-100TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1FN25-125TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1FN25-150TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1FN25-200TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1FN32-25TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1FN32-50TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1FN32-75TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1FN32-100TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1FN32-125TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1FN32-150TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1FN32-200TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1FN40-25TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1FN40-50TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1FN40-75TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1FN40-100TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1FN40-125TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1FN40-150TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1FN40-200TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1GN20-25SZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1GN20-50SZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1GN20-75SZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1GN20-100SZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1GN20-125SZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1GN25-25SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1GN25-50SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1GN25-75SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1GN25-100SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1GN25-125SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1GN25-150SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1GN25-200SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1GN32-25SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1GN32-50SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1GN32-75SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1GN32-100SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1GN32-125SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1GN32-150SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1GN32-200SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1GN40-25SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1GN40-50SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1GN40-75SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1GN40-100SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1GN40-125SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1GN40-150SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1GN40-200SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1GN20-25TZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1GN20-50TZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1GN20-75TZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1GN20-100TZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1GN20-125TZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1GN25-25TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1GN25-50TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1GN25-75TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1GN25-100TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1GN25-125TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1GN25-150TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1GN25-200TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1GN32-25TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1GN32-50TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1GN32-75TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1GN32-100TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1GN32-125TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1GN32-150TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1GN32-200TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1GN40-25TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1GN40-50TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1GN40-75TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1GN40-100TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1GN40-125TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1GN40-150TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1GN40-200TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1UN20-25SZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1UN20-50SZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1UN20-75SZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1UN20-100SZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1UN20-125SZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1UN25-25SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1UN25-50SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1UN25-75SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1UN25-100SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1UN25-125SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1UN25-150SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1UN25-200SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1UN32-25SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1UN32-50SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1UN32-75SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1UN32-100SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1UN32-125SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1UN32-150SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1UN32-200SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1UN40-25SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1UN40-50SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1UN40-75SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1UN40-100SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1UN40-125SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1UN40-150SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1UN40-200SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1UN20-25TZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1UN20-50TZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1UN20-75TZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1UN20-100TZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1UN20-125TZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1UN25-25TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1UN25-50TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1UN25-75TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1UN25-100TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1UN25-125TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1UN25-150TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1UN25-200TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1UN32-25TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1UN32-50TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1UN32-75TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1UN32-100TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1UN32-125TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1UN32-150TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1UN32-200TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1UN40-25TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1UN40-50TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1UN40-75TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1UN40-100TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1UN40-125TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1UN40-150TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1UN40-200TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1TN20-25SZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1TN20-50SZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1TN20-75SZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1TN20-100SZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1TN20-125SZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1TN25-25SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1TN25-50SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1TN25-75SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1TN25-100SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1TN25-125SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1TN25-150SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1TN25-200SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1TN32-25SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1TN32-50SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1TN32-75SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1TN32-100SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1TN32-125SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1TN32-150SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1TN32-200SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1TN40-25SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1TN40-50SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1TN40-75SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1TN40-100SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1TN40-125SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1TN40-150SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1TN40-200SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1TN20-25TZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1TN20-50TZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1TN20-75TZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1TN20-100TZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1TN20-125TZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1TN25-25TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1TN25-50TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1TN25-75TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1TN25-100TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1TN25-125TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1TN25-150TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1TN25-200TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1TN32-25TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1TN32-50TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1TN32-75TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1TN32-100TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1TN32-125TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1TN32-150TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1TN32-200TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1TN40-25TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1TN40-50TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1TN40-75TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1TN40-100TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1TN40-125TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1TN40-150TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1TN40-200TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1DN20-25SZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1DN20-50SZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1DN20-75SZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1DN20-100SZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1DN20-125SZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1DN25-25SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1DN25-50SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1DN25-75SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1DN25-100SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1DN25-125SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1DN25-150SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1DN25-200SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1DN32-25SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1DN32-50SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1DN32-75SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1DN32-100SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1DN32-125SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1DN32-150SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1DN32-200SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1DN40-25SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
CG1DN40-50SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
CG1DN40-75SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
CG1DN40-100SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
CG1DN40-125SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
CG1DN40-150SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
CG1DN40-200SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
CG1DN20-25TZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1DN20-50TZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1DN20-75TZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1DN20-100TZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1DN20-125TZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1DN25-25TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1DN25-50TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1DN25-75TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1DN25-100TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1DN25-125TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1DN25-150TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1DN25-200TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1DN32-25TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1DN32-50TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1DN32-75TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1DN32-100TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1DN32-125TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1DN32-150TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1DN32-200TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CG1DN40-25TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
CG1DN40-50TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
CG1DN40-75TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
CG1DN40-100TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
CG1DN40-125TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
CG1DN40-150TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
CG1DN40-200TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
CDG1BN20-25SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1BN20-50SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1BN20-75SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1BN20-100SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1BN20-125SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1BN25-25SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1BN25-50SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1BN25-75SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1BN25-100SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1BN25-125SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1BN25-150SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1BN25-200SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1BN32-25SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1BN32-50SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1BN32-75SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1BN32-100SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1BN32-125SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1BN32-150SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1BN32-200SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1BN40-25SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1BN40-50SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1BN40-75SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1BN40-100SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1BN40-125SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1BN40-150SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1BN40-200SZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1BN20-25TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1BN20-50TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1BN20-75TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1BN20-100TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1BN20-125TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1BN25-25TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1BN25-50TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1BN25-75TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1BN25-100TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1BN25-125TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1BN25-150TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1BN25-200TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1BN32-25TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1BN32-50TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1BN32-75TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1BN32-100TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1BN32-125TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1BN32-150TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1BN32-200TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1BN40-25TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1BN40-50TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1BN40-75TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1BN40-100TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1BN40-125TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1BN40-150TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1BN40-200TZ1		Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1ZN20-25SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1ZN20-50SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1ZN20-75SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1ZN20-100SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1ZN20-125SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1ZN25-25SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1ZN25-50SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1ZN25-75SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1ZN25-100SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1ZN25-125SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1ZN25-150SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1ZN25-200SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1ZN32-25SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1ZN32-50SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1ZN32-75SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1ZN32-100SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1ZN32-125SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1ZN32-150SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1ZN32-200SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1ZN40-25SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1ZN40-50SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1ZN40-75SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1ZN40-100SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1ZN40-125SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1ZN40-150SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1ZN40-200SZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1ZN20-25TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1ZN20-50TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1ZN20-75TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1ZN20-100TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1ZN20-125TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1ZN25-25TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1ZN25-50TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1ZN25-75TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1ZN25-100TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1ZN25-125TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1ZN25-150TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1ZN25-200TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1ZN32-25TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1ZN32-50TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1ZN32-75TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1ZN32-100TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1ZN32-125TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1ZN32-150TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1ZN32-200TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1ZN40-25TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1ZN40-50TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1ZN40-75TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1ZN40-100TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1ZN40-125TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1ZN40-150TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1ZN40-200TZ1		Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1LN20-25SZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1LN20-50SZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1LN20-75SZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1LN20-100SZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1LN20-125SZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1LN25-25SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1LN25-50SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1LN25-75SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1LN25-100SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1LN25-125SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1LN25-150SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1LN25-200SZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1LN32-25SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1LN32-50SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1LN32-75SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1LN32-100SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1LN32-125SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1LN32-150SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1LN32-200SZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1LN40-25SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1LN40-50SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1LN40-75SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1LN40-100SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1LN40-125SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1LN40-150SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1LN40-200SZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1LN20-25TZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1LN20-50TZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1LN20-75TZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1LN20-100TZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1LN20-125TZ1		Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1LN25-25TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1LN25-50TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1LN25-75TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1LN25-100TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1LN25-125TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1LN25-150TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1LN25-200TZ1		Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1LN32-25TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1LN32-50TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1LN32-75TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1LN32-100TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1LN32-125TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1LN32-150TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1LN32-200TZ1		Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1LN40-25TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1LN40-50TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1LN40-75TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1LN40-100TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1LN40-125TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1LN40-150TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1LN40-200TZ1		Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1FN20-25SZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1FN20-50SZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1FN20-75SZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1FN20-100SZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1FN20-125SZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1FN25-25SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1FN25-50SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1FN25-75SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1FN25-100SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1FN25-125SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1FN25-150SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1FN25-200SZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1FN32-25SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1FN32-50SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1FN32-75SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1FN32-100SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1FN32-125SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1FN32-150SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1FN32-200SZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1FN40-25SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1FN40-50SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1FN40-75SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1FN40-100SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1FN40-125SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1FN40-150SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1FN40-200SZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1FN20-25TZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1FN20-50TZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1FN20-75TZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1FN20-100TZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1FN20-125TZ1		Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1FN25-25TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1FN25-50TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1FN25-75TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1FN25-100TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1FN25-125TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1FN25-150TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1FN25-200TZ1		Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1FN32-25TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1FN32-50TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1FN32-75TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1FN32-100TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1FN32-125TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1FN32-150TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1FN32-200TZ1		Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1FN40-25TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1FN40-50TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1FN40-75TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1FN40-100TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1FN40-125TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1FN40-150TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1FN40-200TZ1		Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1GN20-25SZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1GN20-50SZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1GN20-75SZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1GN20-100SZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1GN20-125SZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1GN25-25SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1GN25-50SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1GN25-75SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1GN25-100SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1GN25-125SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1GN25-150SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1GN25-200SZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1GN32-25SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1GN32-50SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1GN32-75SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1GN32-100SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1GN32-125SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1GN32-150SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1GN32-200SZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1GN40-25SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1GN40-50SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1GN40-75SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1GN40-100SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1GN40-125SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1GN40-150SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1GN40-200SZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1GN20-25TZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1GN20-50TZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1GN20-75TZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1GN20-100TZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1GN20-125TZ1		Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1GN25-25TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1GN25-50TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1GN25-75TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1GN25-100TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1GN25-125TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1GN25-150TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1GN25-200TZ1		Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1GN32-25TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1GN32-50TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1GN32-75TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1GN32-100TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1GN32-125TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1GN32-150TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1GN32-200TZ1		Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1GN40-25TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1GN40-50TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1GN40-75TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1GN40-100TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1GN40-125TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1GN40-150TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1GN40-200TZ1		Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1UN20-25SZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1UN20-50SZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1UN20-75SZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1UN20-100SZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1UN20-125SZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1UN25-25SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1UN25-50SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1UN25-75SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1UN25-100SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1UN25-125SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1UN25-150SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1UN25-200SZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1UN32-25SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1UN32-50SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1UN32-75SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1UN32-100SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1UN32-125SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1UN32-150SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1UN32-200SZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1UN40-25SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1UN40-50SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1UN40-75SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1UN40-100SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1UN40-125SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1UN40-150SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1UN40-200SZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1UN20-25TZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1UN20-50TZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1UN20-75TZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1UN20-100TZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1UN20-125TZ1		Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1UN25-25TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1UN25-50TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1UN25-75TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1UN25-100TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1UN25-125TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1UN25-150TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1UN25-200TZ1		Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1UN32-25TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1UN32-50TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1UN32-75TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1UN32-100TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1UN32-125TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1UN32-150TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1UN32-200TZ1		Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1UN40-25TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1UN40-50TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1UN40-75TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1UN40-100TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1UN40-125TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1UN40-150TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1UN40-200TZ1		Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1TN20-25SZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1TN20-50SZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1TN20-75SZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1TN20-100SZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1TN20-125SZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1TN25-25SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1TN25-50SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1TN25-75SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1TN25-100SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1TN25-125SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1TN25-150SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1TN25-200SZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1TN32-25SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1TN32-50SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1TN32-75SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1TN32-100SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1TN32-125SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1TN32-150SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1TN32-200SZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1TN40-25SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1TN40-50SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1TN40-75SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1TN40-100SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1TN40-125SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1TN40-150SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1TN40-200SZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1TN20-25TZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1TN20-50TZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1TN20-75TZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1TN20-100TZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1TN20-125TZ1		Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1TN25-25TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1TN25-50TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1TN25-75TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1TN25-100TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1TN25-125TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1TN25-150TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1TN25-200TZ1		Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1TN32-25TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1TN32-50TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1TN32-75TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1TN32-100TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1TN32-125TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1TN32-150TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1TN32-200TZ1		Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1TN40-25TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1TN40-50TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1TN40-75TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1TN40-100TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1TN40-125TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1TN40-150TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1TN40-200TZ1		Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1DN20-25SZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1DN20-50SZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1DN20-75SZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1DN20-100SZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1DN20-125SZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1DN25-25SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1DN25-50SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1DN25-75SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1DN25-100SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1DN25-125SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1DN25-150SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1DN25-200SZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1DN32-25SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1DN32-50SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1DN32-75SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1DN32-100SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1DN32-125SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1DN32-150SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1DN32-200SZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1DN40-25SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1DN40-50SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1DN40-75SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1DN40-100SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1DN40-125SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1DN40-150SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1DN40-200SZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1DN20-25TZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1DN20-50TZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1DN20-75TZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1DN20-100TZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1DN20-125TZ1		Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1DN25-25TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1DN25-50TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1DN25-75TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1DN25-100TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1DN25-125TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1DN25-150TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1DN25-200TZ1		Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1DN32-25TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1DN32-50TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1DN32-75TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1DN32-100TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1DN32-125TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1DN32-150TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1DN32-200TZ1		Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
CDG1DN40-25TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
CDG1DN40-50TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
CDG1DN40-75TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
CDG1DN40-100TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
CDG1DN40-125TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
CDG1DN40-150TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
CDG1DN40-200TZ1		Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes

Round Body CylindersSMC

832 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC CG1 Air Cylinder (Single Acting, Push/Pull, ø20 to ø40)

Brand SMC·Round Body Cylinders

Available part numbers (832)

CG1BN20-25SZ1, CG1BN20-50SZ1, CG1BN20-75SZ1, CG1BN20-100SZ1, CG1BN20-125SZ1, CG1BN25-25SZ1, CG1BN25-50SZ1, CG1BN25-75SZ1, CG1BN25-100SZ1, CG1BN25-125SZ1 + 822 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	CG1BN20-25SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1BN20-50SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1BN20-75SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1BN20-100SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1BN20-125SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1BN25-25SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1BN25-50SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1BN25-75SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1BN25-100SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1BN25-125SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1BN25-150SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1BN25-200SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1BN32-25SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1BN32-50SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1BN32-75SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1BN32-100SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1BN32-125SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1BN32-150SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1BN32-200SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1BN40-25SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1BN40-50SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1BN40-75SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1BN40-100SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1BN40-125SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1BN40-150SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1BN40-200SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1BN20-25TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1BN20-50TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1BN20-75TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1BN20-100TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1BN20-125TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1BN25-25TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1BN25-50TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1BN25-75TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1BN25-100TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1BN25-125TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1BN25-150TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1BN25-200TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1BN32-25TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1BN32-50TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1BN32-75TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1BN32-100TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1BN32-125TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1BN32-150TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1BN32-200TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1BN40-25TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1BN40-50TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1BN40-75TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1BN40-100TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1BN40-125TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1BN40-150TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1BN40-200TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1ZN20-25SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1ZN20-50SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1ZN20-75SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1ZN20-100SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1ZN20-125SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1ZN25-25SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1ZN25-50SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1ZN25-75SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1ZN25-100SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1ZN25-125SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1ZN25-150SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1ZN25-200SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1ZN32-25SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1ZN32-50SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1ZN32-75SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1ZN32-100SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1ZN32-125SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1ZN32-150SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1ZN32-200SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1ZN40-25SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1ZN40-50SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1ZN40-75SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1ZN40-100SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1ZN40-125SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1ZN40-150SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1ZN40-200SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1ZN20-25TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1ZN20-50TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1ZN20-75TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1ZN20-100TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1ZN20-125TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1ZN25-25TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1ZN25-50TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1ZN25-75TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1ZN25-100TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1ZN25-125TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1ZN25-150TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1ZN25-200TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1ZN32-25TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1ZN32-50TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1ZN32-75TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1ZN32-100TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1ZN32-125TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1ZN32-150TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1ZN32-200TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1ZN40-25TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1ZN40-50TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1ZN40-75TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1ZN40-100TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1ZN40-125TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1ZN40-150TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1ZN40-200TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1LN20-25SZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1LN20-50SZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1LN20-75SZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1LN20-100SZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1LN20-125SZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1LN25-25SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1LN25-50SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1LN25-75SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1LN25-100SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1LN25-125SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1LN25-150SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1LN25-200SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1LN32-25SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1LN32-50SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1LN32-75SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1LN32-100SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1LN32-125SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1LN32-150SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1LN32-200SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1LN40-25SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1LN40-50SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1LN40-75SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1LN40-100SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1LN40-125SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1LN40-150SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1LN40-200SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1LN20-25TZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1LN20-50TZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1LN20-75TZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1LN20-100TZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1LN20-125TZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1LN25-25TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1LN25-50TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1LN25-75TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1LN25-100TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1LN25-125TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1LN25-150TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1LN25-200TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1LN32-25TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1LN32-50TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1LN32-75TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1LN32-100TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1LN32-125TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1LN32-150TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1LN32-200TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1LN40-25TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1LN40-50TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1LN40-75TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1LN40-100TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1LN40-125TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1LN40-150TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1LN40-200TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1FN20-25SZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1FN20-50SZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1FN20-75SZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1FN20-100SZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1FN20-125SZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1FN25-25SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1FN25-50SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1FN25-75SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1FN25-100SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1FN25-125SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1FN25-150SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1FN25-200SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1FN32-25SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1FN32-50SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1FN32-75SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1FN32-100SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1FN32-125SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1FN32-150SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1FN32-200SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1FN40-25SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1FN40-50SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1FN40-75SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1FN40-100SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1FN40-125SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1FN40-150SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1FN40-200SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1FN20-25TZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1FN20-50TZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1FN20-75TZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1FN20-100TZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1FN20-125TZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1FN25-25TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1FN25-50TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1FN25-75TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1FN25-100TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1FN25-125TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1FN25-150TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1FN25-200TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1FN32-25TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1FN32-50TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1FN32-75TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1FN32-100TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1FN32-125TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1FN32-150TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1FN32-200TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1FN40-25TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1FN40-50TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1FN40-75TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1FN40-100TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1FN40-125TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1FN40-150TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1FN40-200TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1GN20-25SZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1GN20-50SZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1GN20-75SZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1GN20-100SZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1GN20-125SZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1GN25-25SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1GN25-50SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1GN25-75SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1GN25-100SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1GN25-125SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1GN25-150SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1GN25-200SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1GN32-25SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1GN32-50SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1GN32-75SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1GN32-100SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1GN32-125SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1GN32-150SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1GN32-200SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1GN40-25SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1GN40-50SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1GN40-75SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1GN40-100SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1GN40-125SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1GN40-150SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1GN40-200SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1GN20-25TZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1GN20-50TZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1GN20-75TZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1GN20-100TZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1GN20-125TZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1GN25-25TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1GN25-50TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1GN25-75TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1GN25-100TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1GN25-125TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1GN25-150TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1GN25-200TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1GN32-25TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1GN32-50TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1GN32-75TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1GN32-100TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1GN32-125TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1GN32-150TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1GN32-200TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1GN40-25TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1GN40-50TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1GN40-75TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1GN40-100TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1GN40-125TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1GN40-150TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1GN40-200TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1UN20-25SZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1UN20-50SZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1UN20-75SZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1UN20-100SZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1UN20-125SZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1UN25-25SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1UN25-50SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1UN25-75SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1UN25-100SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1UN25-125SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1UN25-150SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1UN25-200SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1UN32-25SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1UN32-50SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1UN32-75SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1UN32-100SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1UN32-125SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1UN32-150SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1UN32-200SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1UN40-25SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1UN40-50SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1UN40-75SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1UN40-100SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1UN40-125SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1UN40-150SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1UN40-200SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1UN20-25TZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1UN20-50TZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1UN20-75TZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1UN20-100TZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1UN20-125TZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1UN25-25TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1UN25-50TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1UN25-75TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1UN25-100TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1UN25-125TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1UN25-150TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1UN25-200TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1UN32-25TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1UN32-50TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1UN32-75TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1UN32-100TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1UN32-125TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1UN32-150TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1UN32-200TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1UN40-25TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1UN40-50TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1UN40-75TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1UN40-100TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1UN40-125TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1UN40-150TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1UN40-200TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1TN20-25SZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1TN20-50SZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1TN20-75SZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1TN20-100SZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1TN20-125SZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1TN25-25SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1TN25-50SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1TN25-75SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1TN25-100SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1TN25-125SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1TN25-150SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1TN25-200SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1TN32-25SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1TN32-50SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1TN32-75SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1TN32-100SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1TN32-125SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1TN32-150SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1TN32-200SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1TN40-25SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1TN40-50SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1TN40-75SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1TN40-100SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1TN40-125SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1TN40-150SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1TN40-200SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1TN20-25TZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1TN20-50TZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1TN20-75TZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1TN20-100TZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1TN20-125TZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1TN25-25TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1TN25-50TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1TN25-75TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1TN25-100TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1TN25-125TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1TN25-150TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1TN25-200TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1TN32-25TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1TN32-50TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1TN32-75TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1TN32-100TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1TN32-125TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1TN32-150TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1TN32-200TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1TN40-25TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1TN40-50TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1TN40-75TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1TN40-100TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1TN40-125TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1TN40-150TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1TN40-200TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1DN20-25SZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1DN20-50SZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1DN20-75SZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1DN20-100SZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1DN20-125SZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1DN25-25SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1DN25-50SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1DN25-75SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1DN25-100SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1DN25-125SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1DN25-150SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1DN25-200SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1DN32-25SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1DN32-50SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1DN32-75SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1DN32-100SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1DN32-125SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1DN32-150SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1DN32-200SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1DN40-25SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: No
	CG1DN40-50SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: No
	CG1DN40-75SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: No
	CG1DN40-100SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: No
	CG1DN40-125SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: No
	CG1DN40-150SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: No
	CG1DN40-200SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: No
	CG1DN20-25TZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1DN20-50TZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1DN20-75TZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1DN20-100TZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1DN20-125TZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1DN25-25TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1DN25-50TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1DN25-75TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1DN25-100TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1DN25-125TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1DN25-150TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1DN25-200TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1DN32-25TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1DN32-50TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1DN32-75TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1DN32-100TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1DN32-125TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1DN32-150TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1DN32-200TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CG1DN40-25TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: No
	CG1DN40-50TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: No
	CG1DN40-75TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: No
	CG1DN40-100TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: No
	CG1DN40-125TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: No
	CG1DN40-150TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: No
	CG1DN40-200TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: No
	CDG1BN20-25SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1BN20-50SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1BN20-75SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1BN20-100SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1BN20-125SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1BN25-25SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1BN25-50SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1BN25-75SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1BN25-100SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1BN25-125SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1BN25-150SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1BN25-200SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1BN32-25SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1BN32-50SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1BN32-75SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1BN32-100SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1BN32-125SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1BN32-150SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1BN32-200SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1BN40-25SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1BN40-50SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1BN40-75SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1BN40-100SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1BN40-125SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1BN40-150SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1BN40-200SZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1BN20-25TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1BN20-50TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1BN20-75TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1BN20-100TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1BN20-125TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1BN25-25TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1BN25-50TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1BN25-75TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1BN25-100TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1BN25-125TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1BN25-150TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1BN25-200TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1BN32-25TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1BN32-50TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1BN32-75TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1BN32-100TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1BN32-125TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1BN32-150TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1BN32-200TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1BN40-25TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1BN40-50TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1BN40-75TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1BN40-100TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1BN40-125TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1BN40-150TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1BN40-200TZ1	Mounting: Basic (no trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1ZN20-25SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1ZN20-50SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1ZN20-75SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1ZN20-100SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1ZN20-125SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1ZN25-25SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1ZN25-50SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1ZN25-75SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1ZN25-100SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1ZN25-125SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1ZN25-150SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1ZN25-200SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1ZN32-25SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1ZN32-50SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1ZN32-75SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1ZN32-100SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1ZN32-125SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1ZN32-150SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1ZN32-200SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1ZN40-25SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1ZN40-50SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1ZN40-75SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1ZN40-100SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1ZN40-125SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1ZN40-150SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1ZN40-200SZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1ZN20-25TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1ZN20-50TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1ZN20-75TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1ZN20-100TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1ZN20-125TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1ZN25-25TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1ZN25-50TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1ZN25-75TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1ZN25-100TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1ZN25-125TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1ZN25-150TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1ZN25-200TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1ZN32-25TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1ZN32-50TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1ZN32-75TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1ZN32-100TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1ZN32-125TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1ZN32-150TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1ZN32-200TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1ZN40-25TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1ZN40-50TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1ZN40-75TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1ZN40-100TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1ZN40-125TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1ZN40-150TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1ZN40-200TZ1	Mounting: Basic (trunnion female thread) \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1LN20-25SZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1LN20-50SZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1LN20-75SZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1LN20-100SZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1LN20-125SZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1LN25-25SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1LN25-50SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1LN25-75SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1LN25-100SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1LN25-125SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1LN25-150SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1LN25-200SZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1LN32-25SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1LN32-50SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1LN32-75SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1LN32-100SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1LN32-125SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1LN32-150SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1LN32-200SZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1LN40-25SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1LN40-50SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1LN40-75SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1LN40-100SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1LN40-125SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1LN40-150SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1LN40-200SZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1LN20-25TZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1LN20-50TZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1LN20-75TZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1LN20-100TZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1LN20-125TZ1	Mounting: Axial foot \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1LN25-25TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1LN25-50TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1LN25-75TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1LN25-100TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1LN25-125TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1LN25-150TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1LN25-200TZ1	Mounting: Axial foot \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1LN32-25TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1LN32-50TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1LN32-75TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1LN32-100TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1LN32-125TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1LN32-150TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1LN32-200TZ1	Mounting: Axial foot \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1LN40-25TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1LN40-50TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1LN40-75TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1LN40-100TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1LN40-125TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1LN40-150TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1LN40-200TZ1	Mounting: Axial foot \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1FN20-25SZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1FN20-50SZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1FN20-75SZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1FN20-100SZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1FN20-125SZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1FN25-25SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1FN25-50SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1FN25-75SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1FN25-100SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1FN25-125SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1FN25-150SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1FN25-200SZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1FN32-25SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1FN32-50SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1FN32-75SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1FN32-100SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1FN32-125SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1FN32-150SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1FN32-200SZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1FN40-25SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1FN40-50SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1FN40-75SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1FN40-100SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1FN40-125SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1FN40-150SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1FN40-200SZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1FN20-25TZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1FN20-50TZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1FN20-75TZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1FN20-100TZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1FN20-125TZ1	Mounting: Rod flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1FN25-25TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1FN25-50TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1FN25-75TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1FN25-100TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1FN25-125TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1FN25-150TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1FN25-200TZ1	Mounting: Rod flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1FN32-25TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1FN32-50TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1FN32-75TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1FN32-100TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1FN32-125TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1FN32-150TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1FN32-200TZ1	Mounting: Rod flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1FN40-25TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1FN40-50TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1FN40-75TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1FN40-100TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1FN40-125TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1FN40-150TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1FN40-200TZ1	Mounting: Rod flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1GN20-25SZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1GN20-50SZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1GN20-75SZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1GN20-100SZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1GN20-125SZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1GN25-25SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1GN25-50SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1GN25-75SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1GN25-100SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1GN25-125SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1GN25-150SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1GN25-200SZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1GN32-25SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1GN32-50SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1GN32-75SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1GN32-100SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1GN32-125SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1GN32-150SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1GN32-200SZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1GN40-25SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1GN40-50SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1GN40-75SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1GN40-100SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1GN40-125SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1GN40-150SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1GN40-200SZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1GN20-25TZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1GN20-50TZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1GN20-75TZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1GN20-100TZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1GN20-125TZ1	Mounting: Head flange \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1GN25-25TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1GN25-50TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1GN25-75TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1GN25-100TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1GN25-125TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1GN25-150TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1GN25-200TZ1	Mounting: Head flange \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1GN32-25TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1GN32-50TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1GN32-75TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1GN32-100TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1GN32-125TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1GN32-150TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1GN32-200TZ1	Mounting: Head flange \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1GN40-25TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1GN40-50TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1GN40-75TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1GN40-100TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1GN40-125TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1GN40-150TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1GN40-200TZ1	Mounting: Head flange \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1UN20-25SZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1UN20-50SZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1UN20-75SZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1UN20-100SZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1UN20-125SZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1UN25-25SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1UN25-50SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1UN25-75SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1UN25-100SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1UN25-125SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1UN25-150SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1UN25-200SZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1UN32-25SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1UN32-50SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1UN32-75SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1UN32-100SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1UN32-125SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1UN32-150SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1UN32-200SZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1UN40-25SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1UN40-50SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1UN40-75SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1UN40-100SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1UN40-125SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1UN40-150SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1UN40-200SZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1UN20-25TZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1UN20-50TZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1UN20-75TZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1UN20-100TZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1UN20-125TZ1	Mounting: Rod trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1UN25-25TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1UN25-50TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1UN25-75TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1UN25-100TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1UN25-125TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1UN25-150TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1UN25-200TZ1	Mounting: Rod trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1UN32-25TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1UN32-50TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1UN32-75TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1UN32-100TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1UN32-125TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1UN32-150TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1UN32-200TZ1	Mounting: Rod trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1UN40-25TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1UN40-50TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1UN40-75TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1UN40-100TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1UN40-125TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1UN40-150TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1UN40-200TZ1	Mounting: Rod trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1TN20-25SZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1TN20-50SZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1TN20-75SZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1TN20-100SZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1TN20-125SZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1TN25-25SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1TN25-50SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1TN25-75SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1TN25-100SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1TN25-125SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1TN25-150SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1TN25-200SZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1TN32-25SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1TN32-50SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1TN32-75SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1TN32-100SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1TN32-125SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1TN32-150SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1TN32-200SZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1TN40-25SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1TN40-50SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1TN40-75SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1TN40-100SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1TN40-125SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1TN40-150SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1TN40-200SZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1TN20-25TZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1TN20-50TZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1TN20-75TZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1TN20-100TZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1TN20-125TZ1	Mounting: Head trunnion \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1TN25-25TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1TN25-50TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1TN25-75TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1TN25-100TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1TN25-125TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1TN25-150TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1TN25-200TZ1	Mounting: Head trunnion \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1TN32-25TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1TN32-50TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1TN32-75TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1TN32-100TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1TN32-125TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1TN32-150TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1TN32-200TZ1	Mounting: Head trunnion \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1TN40-25TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1TN40-50TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1TN40-75TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1TN40-100TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1TN40-125TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1TN40-150TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1TN40-200TZ1	Mounting: Head trunnion \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1DN20-25SZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1DN20-50SZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1DN20-75SZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1DN20-100SZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1DN20-125SZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1DN25-25SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1DN25-50SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1DN25-75SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1DN25-100SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1DN25-125SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1DN25-150SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1DN25-200SZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1DN32-25SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1DN32-50SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1DN32-75SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1DN32-100SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1DN32-125SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1DN32-150SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1DN32-200SZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1DN40-25SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1DN40-50SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1DN40-75SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1DN40-100SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1DN40-125SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1DN40-150SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1DN40-200SZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring return \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1DN20-25TZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1DN20-50TZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1DN20-75TZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1DN20-100TZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1DN20-125TZ1	Mounting: Clevis \| Bore: ø20 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1DN25-25TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1DN25-50TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1DN25-75TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1DN25-100TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1DN25-125TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1DN25-150TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1DN25-200TZ1	Mounting: Clevis \| Bore: ø25 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1DN32-25TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1DN32-50TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1DN32-75TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1DN32-100TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1DN32-125TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1DN32-150TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1DN32-200TZ1	Mounting: Clevis \| Bore: ø32 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes
	CDG1DN40-25TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 25 mm \| Auto switch magnet: Yes
	CDG1DN40-50TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 50 mm \| Auto switch magnet: Yes
	CDG1DN40-75TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 75 mm \| Auto switch magnet: Yes
	CDG1DN40-100TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 100 mm \| Auto switch magnet: Yes
	CDG1DN40-125TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 125 mm \| Auto switch magnet: Yes
	CDG1DN40-150TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 150 mm \| Auto switch magnet: Yes
	CDG1DN40-200TZ1	Mounting: Clevis \| Bore: ø40 mm \| Action: Single acting, spring extend \| Stroke: 200 mm \| Auto switch magnet: Yes

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

SMC CG1 Air Cylinder (Single Acting, Push/Pull, ø20 to ø40)
