SMC CK1/CKG1/CKP1-Z1 Clamp Cylinder (ø40 to ø63)

SMC CK1-Z1 series double-acting clamp cylinder with double clevis mounting for welding jigs, in bores ø40, ø50 and ø63 with three clevis widths.

Key features

Three versions: CK1 without magnet, CKG1 with built-in magnet for auto switches, CKP1 with strong magnet for welding-resistant switches
Three clevis widths (A 16.5 mm, B 19.5 mm, C 12.5 mm), mounting dimensions interchangeable with the previous CK1 series
Lighter body: about 7% less mass than the previous CK1 (ø63, 150 st)
Rod end brackets: single (I/IA) or double (Y/YA) knuckle joint; clevis pin, split pin and washers included with Y/YA
Options as suffix: B limit switch stand, D dog fitting, L foot, K clamp jig (A width, 75/100/150 st); NPT (TN) and G (TF) ports; auto switches D-P3DWA/P4DW/M9 (CKG1) or D-P79WSE/P74 (CKP1) ordered as suffix
Made to order: -X1515 cushion on both ends, -XC88/-XC89/-XC91 spatter-resistant versions

Specifications

Action	Double acting
Fluid	Air
Proof pressure	1.5 MPa
Max. operating pressure	1.0 MPa
Min. operating pressure	0.05 MPa
Ambient and fluid temperature	-10 to 70°C without switch, -10 to 60°C with switch
Piston speed	50 to 500 mm/s
Cushion	Air cushion on unclamp side (head end)
Speed controller	Built in, both ends
Mounting	Double clevis
Port thread	Rc1/4
Source	SMC Korea catalog CAT.S20-278A (SMCKR_CK1-Z1_CKG1-Z1.pdf), p. 3-6 (PDF p. 4-7)

CK1A40-50Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
CK1A40-50IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CK1A40-50IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A40-50YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CK1A40-50YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A40-75Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
CK1A40-75IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CK1A40-75IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A40-75YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CK1A40-75YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A40-100Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
CK1A40-100IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CK1A40-100IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A40-100YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CK1A40-100YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A40-125Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
CK1A40-125IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CK1A40-125IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A40-125YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CK1A40-125YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A40-150Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
CK1A40-150IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CK1A40-150IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A40-150YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CK1A40-150YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A50-50Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
CK1A50-50IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CK1A50-50IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A50-50YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CK1A50-50YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A50-75Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
CK1A50-75IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CK1A50-75IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A50-75YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CK1A50-75YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A50-100Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
CK1A50-100IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CK1A50-100IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A50-100YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CK1A50-100YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A50-125Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
CK1A50-125IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CK1A50-125IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A50-125YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CK1A50-125YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A50-150Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
CK1A50-150IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CK1A50-150IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A50-150YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CK1A50-150YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A50-200Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
CK1A50-200IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CK1A50-200IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A50-200YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CK1A50-200YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A63-50Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
CK1A63-50IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CK1A63-50IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A63-50YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CK1A63-50YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A63-75Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
CK1A63-75IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CK1A63-75IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A63-75YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CK1A63-75YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A63-100Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
CK1A63-100IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CK1A63-100IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A63-100YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CK1A63-100YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A63-125Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
CK1A63-125IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CK1A63-125IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A63-125YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CK1A63-125YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A63-150Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
CK1A63-150IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CK1A63-150IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A63-150YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CK1A63-150YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1A63-200Z1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
CK1A63-200IZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CK1A63-200IAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1A63-200YZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CK1A63-200YAZ1		Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B40-50Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
CK1B40-50IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CK1B40-50IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B40-50YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CK1B40-50YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B40-75Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
CK1B40-75IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CK1B40-75IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B40-75YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CK1B40-75YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B40-100Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
CK1B40-100IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CK1B40-100IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B40-100YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CK1B40-100YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B40-125Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
CK1B40-125IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CK1B40-125IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B40-125YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CK1B40-125YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B40-150Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
CK1B40-150IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CK1B40-150IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B40-150YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CK1B40-150YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B50-50Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
CK1B50-50IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CK1B50-50IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B50-50YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CK1B50-50YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B50-75Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
CK1B50-75IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CK1B50-75IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B50-75YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CK1B50-75YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B50-100Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
CK1B50-100IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CK1B50-100IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B50-100YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CK1B50-100YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B50-125Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
CK1B50-125IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CK1B50-125IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B50-125YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CK1B50-125YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B50-150Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
CK1B50-150IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CK1B50-150IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B50-150YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CK1B50-150YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B50-200Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
CK1B50-200IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CK1B50-200IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B50-200YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CK1B50-200YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B63-50Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
CK1B63-50IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CK1B63-50IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B63-50YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CK1B63-50YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B63-75Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
CK1B63-75IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CK1B63-75IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B63-75YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CK1B63-75YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B63-100Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
CK1B63-100IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CK1B63-100IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B63-100YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CK1B63-100YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B63-125Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
CK1B63-125IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CK1B63-125IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B63-125YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CK1B63-125YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B63-150Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
CK1B63-150IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CK1B63-150IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B63-150YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CK1B63-150YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1B63-200Z1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
CK1B63-200IZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CK1B63-200IAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1B63-200YZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CK1B63-200YAZ1		Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C40-50Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
CK1C40-50IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CK1C40-50IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C40-50YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CK1C40-50YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C40-75Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
CK1C40-75IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CK1C40-75IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C40-75YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CK1C40-75YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C40-100Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
CK1C40-100IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CK1C40-100IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C40-100YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CK1C40-100YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C40-125Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
CK1C40-125IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CK1C40-125IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C40-125YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CK1C40-125YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C40-150Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
CK1C40-150IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CK1C40-150IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C40-150YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CK1C40-150YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C50-50Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
CK1C50-50IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CK1C50-50IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C50-50YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CK1C50-50YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C50-75Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
CK1C50-75IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CK1C50-75IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C50-75YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CK1C50-75YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C50-100Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
CK1C50-100IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CK1C50-100IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C50-100YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CK1C50-100YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C50-125Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
CK1C50-125IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CK1C50-125IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C50-125YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CK1C50-125YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C50-150Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
CK1C50-150IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CK1C50-150IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C50-150YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CK1C50-150YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C50-200Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
CK1C50-200IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CK1C50-200IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C50-200YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CK1C50-200YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C63-50Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
CK1C63-50IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CK1C63-50IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C63-50YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CK1C63-50YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C63-75Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
CK1C63-75IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CK1C63-75IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C63-75YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CK1C63-75YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C63-100Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
CK1C63-100IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CK1C63-100IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C63-100YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CK1C63-100YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C63-125Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
CK1C63-125IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CK1C63-125IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C63-125YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CK1C63-125YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C63-150Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
CK1C63-150IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CK1C63-150IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C63-150YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CK1C63-150YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CK1C63-200Z1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
CK1C63-200IZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CK1C63-200IAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CK1C63-200YZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CK1C63-200YAZ1		Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A40-50Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
CKG1A40-50IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKG1A40-50IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A40-50YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKG1A40-50YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A40-75Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
CKG1A40-75IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKG1A40-75IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A40-75YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKG1A40-75YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A40-100Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
CKG1A40-100IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKG1A40-100IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A40-100YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKG1A40-100YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A40-125Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
CKG1A40-125IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKG1A40-125IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A40-125YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKG1A40-125YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A40-150Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
CKG1A40-150IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKG1A40-150IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A40-150YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKG1A40-150YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A50-50Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
CKG1A50-50IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKG1A50-50IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A50-50YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKG1A50-50YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A50-75Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
CKG1A50-75IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKG1A50-75IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A50-75YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKG1A50-75YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A50-100Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
CKG1A50-100IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKG1A50-100IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A50-100YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKG1A50-100YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A50-125Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
CKG1A50-125IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKG1A50-125IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A50-125YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKG1A50-125YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A50-150Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
CKG1A50-150IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKG1A50-150IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A50-150YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKG1A50-150YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A50-200Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
CKG1A50-200IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CKG1A50-200IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A50-200YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CKG1A50-200YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A63-50Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
CKG1A63-50IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKG1A63-50IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A63-50YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKG1A63-50YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A63-75Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
CKG1A63-75IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKG1A63-75IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A63-75YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKG1A63-75YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A63-100Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
CKG1A63-100IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKG1A63-100IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A63-100YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKG1A63-100YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A63-125Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
CKG1A63-125IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKG1A63-125IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A63-125YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKG1A63-125YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A63-150Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
CKG1A63-150IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKG1A63-150IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A63-150YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKG1A63-150YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1A63-200Z1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
CKG1A63-200IZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CKG1A63-200IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1A63-200YZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CKG1A63-200YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B40-50Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
CKG1B40-50IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKG1B40-50IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B40-50YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKG1B40-50YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B40-75Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
CKG1B40-75IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKG1B40-75IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B40-75YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKG1B40-75YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B40-100Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
CKG1B40-100IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKG1B40-100IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B40-100YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKG1B40-100YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B40-125Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
CKG1B40-125IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKG1B40-125IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B40-125YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKG1B40-125YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B40-150Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
CKG1B40-150IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKG1B40-150IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B40-150YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKG1B40-150YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B50-50Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
CKG1B50-50IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKG1B50-50IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B50-50YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKG1B50-50YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B50-75Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
CKG1B50-75IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKG1B50-75IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B50-75YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKG1B50-75YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B50-100Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
CKG1B50-100IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKG1B50-100IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B50-100YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKG1B50-100YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B50-125Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
CKG1B50-125IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKG1B50-125IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B50-125YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKG1B50-125YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B50-150Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
CKG1B50-150IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKG1B50-150IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B50-150YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKG1B50-150YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B50-200Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
CKG1B50-200IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CKG1B50-200IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B50-200YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CKG1B50-200YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B63-50Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
CKG1B63-50IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKG1B63-50IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B63-50YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKG1B63-50YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B63-75Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
CKG1B63-75IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKG1B63-75IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B63-75YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKG1B63-75YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B63-100Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
CKG1B63-100IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKG1B63-100IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B63-100YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKG1B63-100YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B63-125Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
CKG1B63-125IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKG1B63-125IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B63-125YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKG1B63-125YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B63-150Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
CKG1B63-150IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKG1B63-150IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B63-150YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKG1B63-150YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1B63-200Z1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
CKG1B63-200IZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CKG1B63-200IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1B63-200YZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CKG1B63-200YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C40-50Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
CKG1C40-50IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKG1C40-50IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C40-50YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKG1C40-50YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C40-75Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
CKG1C40-75IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKG1C40-75IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C40-75YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKG1C40-75YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C40-100Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
CKG1C40-100IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKG1C40-100IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C40-100YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKG1C40-100YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C40-125Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
CKG1C40-125IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKG1C40-125IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C40-125YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKG1C40-125YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C40-150Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
CKG1C40-150IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKG1C40-150IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C40-150YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKG1C40-150YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C50-50Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
CKG1C50-50IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKG1C50-50IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C50-50YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKG1C50-50YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C50-75Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
CKG1C50-75IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKG1C50-75IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C50-75YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKG1C50-75YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C50-100Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
CKG1C50-100IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKG1C50-100IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C50-100YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKG1C50-100YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C50-125Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
CKG1C50-125IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKG1C50-125IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C50-125YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKG1C50-125YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C50-150Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
CKG1C50-150IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKG1C50-150IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C50-150YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKG1C50-150YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C50-200Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
CKG1C50-200IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CKG1C50-200IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C50-200YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CKG1C50-200YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C63-50Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
CKG1C63-50IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKG1C63-50IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C63-50YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKG1C63-50YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C63-75Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
CKG1C63-75IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKG1C63-75IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C63-75YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKG1C63-75YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C63-100Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
CKG1C63-100IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKG1C63-100IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C63-100YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKG1C63-100YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C63-125Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
CKG1C63-125IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKG1C63-125IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C63-125YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKG1C63-125YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C63-150Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
CKG1C63-150IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKG1C63-150IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C63-150YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKG1C63-150YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKG1C63-200Z1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
CKG1C63-200IZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CKG1C63-200IAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKG1C63-200YZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CKG1C63-200YAZ1		Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A40-50Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
CKP1A40-50IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKP1A40-50IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A40-50YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKP1A40-50YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A40-75Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
CKP1A40-75IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKP1A40-75IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A40-75YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKP1A40-75YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A40-100Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
CKP1A40-100IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKP1A40-100IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A40-100YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKP1A40-100YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A40-125Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
CKP1A40-125IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKP1A40-125IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A40-125YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKP1A40-125YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A40-150Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
CKP1A40-150IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKP1A40-150IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A40-150YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKP1A40-150YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A50-50Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
CKP1A50-50IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKP1A50-50IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A50-50YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKP1A50-50YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A50-75Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
CKP1A50-75IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKP1A50-75IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A50-75YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKP1A50-75YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A50-100Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
CKP1A50-100IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKP1A50-100IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A50-100YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKP1A50-100YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A50-125Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
CKP1A50-125IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKP1A50-125IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A50-125YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKP1A50-125YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A50-150Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
CKP1A50-150IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKP1A50-150IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A50-150YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKP1A50-150YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A50-200Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
CKP1A50-200IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CKP1A50-200IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A50-200YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CKP1A50-200YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A63-50Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
CKP1A63-50IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKP1A63-50IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A63-50YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKP1A63-50YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A63-75Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
CKP1A63-75IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKP1A63-75IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A63-75YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKP1A63-75YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A63-100Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
CKP1A63-100IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKP1A63-100IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A63-100YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKP1A63-100YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A63-125Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
CKP1A63-125IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKP1A63-125IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A63-125YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKP1A63-125YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A63-150Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
CKP1A63-150IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKP1A63-150IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A63-150YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKP1A63-150YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1A63-200Z1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
CKP1A63-200IZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CKP1A63-200IAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1A63-200YZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CKP1A63-200YAZ1		Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B40-50Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
CKP1B40-50IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKP1B40-50IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B40-50YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKP1B40-50YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B40-75Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
CKP1B40-75IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKP1B40-75IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B40-75YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKP1B40-75YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B40-100Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
CKP1B40-100IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKP1B40-100IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B40-100YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKP1B40-100YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B40-125Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
CKP1B40-125IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKP1B40-125IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B40-125YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKP1B40-125YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B40-150Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
CKP1B40-150IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKP1B40-150IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B40-150YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKP1B40-150YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B50-50Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
CKP1B50-50IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKP1B50-50IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B50-50YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKP1B50-50YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B50-75Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
CKP1B50-75IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKP1B50-75IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B50-75YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKP1B50-75YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B50-100Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
CKP1B50-100IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKP1B50-100IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B50-100YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKP1B50-100YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B50-125Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
CKP1B50-125IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKP1B50-125IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B50-125YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKP1B50-125YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B50-150Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
CKP1B50-150IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKP1B50-150IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B50-150YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKP1B50-150YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B50-200Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
CKP1B50-200IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CKP1B50-200IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B50-200YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CKP1B50-200YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B63-50Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
CKP1B63-50IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKP1B63-50IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B63-50YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKP1B63-50YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B63-75Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
CKP1B63-75IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKP1B63-75IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B63-75YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKP1B63-75YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B63-100Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
CKP1B63-100IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKP1B63-100IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B63-100YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKP1B63-100YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B63-125Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
CKP1B63-125IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKP1B63-125IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B63-125YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKP1B63-125YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B63-150Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
CKP1B63-150IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKP1B63-150IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B63-150YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKP1B63-150YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1B63-200Z1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
CKP1B63-200IZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CKP1B63-200IAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1B63-200YZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CKP1B63-200YAZ1		Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C40-50Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
CKP1C40-50IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKP1C40-50IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C40-50YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKP1C40-50YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C40-75Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
CKP1C40-75IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKP1C40-75IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C40-75YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKP1C40-75YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C40-100Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
CKP1C40-100IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKP1C40-100IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C40-100YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKP1C40-100YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C40-125Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
CKP1C40-125IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKP1C40-125IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C40-125YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKP1C40-125YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C40-150Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
CKP1C40-150IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKP1C40-150IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C40-150YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKP1C40-150YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C50-50Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
CKP1C50-50IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKP1C50-50IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C50-50YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKP1C50-50YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C50-75Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
CKP1C50-75IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKP1C50-75IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C50-75YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKP1C50-75YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C50-100Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
CKP1C50-100IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKP1C50-100IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C50-100YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKP1C50-100YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C50-125Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
CKP1C50-125IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKP1C50-125IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C50-125YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKP1C50-125YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C50-150Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
CKP1C50-150IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKP1C50-150IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C50-150YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKP1C50-150YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C50-200Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
CKP1C50-200IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CKP1C50-200IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C50-200YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CKP1C50-200YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C63-50Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
CKP1C63-50IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
CKP1C63-50IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C63-50YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
CKP1C63-50YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C63-75Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
CKP1C63-75IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
CKP1C63-75IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C63-75YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
CKP1C63-75YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C63-100Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
CKP1C63-100IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
CKP1C63-100IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C63-100YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
CKP1C63-100YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C63-125Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
CKP1C63-125IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
CKP1C63-125IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C63-125YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
CKP1C63-125YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C63-150Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
CKP1C63-150IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
CKP1C63-150IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C63-150YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
CKP1C63-150YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
CKP1C63-200Z1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
CKP1C63-200IZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
CKP1C63-200IAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
CKP1C63-200YZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
CKP1C63-200YAZ1		Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap

Clamp CylindersSMC

765 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC CK1/CKG1/CKP1-Z1 Clamp Cylinder (ø40 to ø63)

Brand SMC·Clamp Cylinders

Available part numbers (765)

CK1A40-50Z1, CK1A40-50IZ1, CK1A40-50IAZ1, CK1A40-50YZ1, CK1A40-50YAZ1, CK1A40-75Z1, CK1A40-75IZ1, CK1A40-75IAZ1, CK1A40-75YZ1, CK1A40-75YAZ1 + 755 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	CK1A40-50Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
	CK1A40-50IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CK1A40-50IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A40-50YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CK1A40-50YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A40-75Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
	CK1A40-75IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CK1A40-75IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A40-75YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CK1A40-75YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A40-100Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
	CK1A40-100IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CK1A40-100IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A40-100YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CK1A40-100YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A40-125Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
	CK1A40-125IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CK1A40-125IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A40-125YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CK1A40-125YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A40-150Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
	CK1A40-150IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CK1A40-150IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A40-150YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CK1A40-150YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A50-50Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
	CK1A50-50IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CK1A50-50IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A50-50YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CK1A50-50YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A50-75Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
	CK1A50-75IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CK1A50-75IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A50-75YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CK1A50-75YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A50-100Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
	CK1A50-100IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CK1A50-100IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A50-100YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CK1A50-100YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A50-125Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
	CK1A50-125IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CK1A50-125IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A50-125YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CK1A50-125YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A50-150Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
	CK1A50-150IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CK1A50-150IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A50-150YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CK1A50-150YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A50-200Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
	CK1A50-200IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CK1A50-200IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A50-200YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CK1A50-200YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A63-50Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
	CK1A63-50IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CK1A63-50IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A63-50YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CK1A63-50YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A63-75Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
	CK1A63-75IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CK1A63-75IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A63-75YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CK1A63-75YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A63-100Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
	CK1A63-100IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CK1A63-100IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A63-100YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CK1A63-100YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A63-125Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
	CK1A63-125IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CK1A63-125IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A63-125YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CK1A63-125YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A63-150Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
	CK1A63-150IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CK1A63-150IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A63-150YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CK1A63-150YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1A63-200Z1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
	CK1A63-200IZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CK1A63-200IAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1A63-200YZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CK1A63-200YAZ1	Series: CK1 (no magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B40-50Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
	CK1B40-50IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CK1B40-50IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B40-50YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CK1B40-50YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B40-75Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
	CK1B40-75IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CK1B40-75IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B40-75YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CK1B40-75YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B40-100Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
	CK1B40-100IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CK1B40-100IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B40-100YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CK1B40-100YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B40-125Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
	CK1B40-125IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CK1B40-125IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B40-125YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CK1B40-125YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B40-150Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
	CK1B40-150IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CK1B40-150IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B40-150YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CK1B40-150YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B50-50Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
	CK1B50-50IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CK1B50-50IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B50-50YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CK1B50-50YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B50-75Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
	CK1B50-75IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CK1B50-75IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B50-75YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CK1B50-75YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B50-100Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
	CK1B50-100IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CK1B50-100IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B50-100YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CK1B50-100YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B50-125Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
	CK1B50-125IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CK1B50-125IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B50-125YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CK1B50-125YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B50-150Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
	CK1B50-150IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CK1B50-150IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B50-150YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CK1B50-150YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B50-200Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
	CK1B50-200IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CK1B50-200IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B50-200YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CK1B50-200YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B63-50Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
	CK1B63-50IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CK1B63-50IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B63-50YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CK1B63-50YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B63-75Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
	CK1B63-75IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CK1B63-75IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B63-75YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CK1B63-75YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B63-100Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
	CK1B63-100IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CK1B63-100IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B63-100YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CK1B63-100YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B63-125Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
	CK1B63-125IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CK1B63-125IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B63-125YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CK1B63-125YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B63-150Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
	CK1B63-150IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CK1B63-150IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B63-150YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CK1B63-150YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1B63-200Z1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
	CK1B63-200IZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CK1B63-200IAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1B63-200YZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CK1B63-200YAZ1	Series: CK1 (no magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C40-50Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
	CK1C40-50IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CK1C40-50IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C40-50YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CK1C40-50YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C40-75Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
	CK1C40-75IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CK1C40-75IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C40-75YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CK1C40-75YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C40-100Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
	CK1C40-100IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CK1C40-100IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C40-100YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CK1C40-100YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C40-125Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
	CK1C40-125IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CK1C40-125IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C40-125YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CK1C40-125YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C40-150Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
	CK1C40-150IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CK1C40-150IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C40-150YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CK1C40-150YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C50-50Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
	CK1C50-50IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CK1C50-50IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C50-50YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CK1C50-50YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C50-75Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
	CK1C50-75IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CK1C50-75IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C50-75YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CK1C50-75YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C50-100Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
	CK1C50-100IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CK1C50-100IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C50-100YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CK1C50-100YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C50-125Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
	CK1C50-125IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CK1C50-125IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C50-125YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CK1C50-125YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C50-150Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
	CK1C50-150IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CK1C50-150IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C50-150YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CK1C50-150YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C50-200Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
	CK1C50-200IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CK1C50-200IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C50-200YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CK1C50-200YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C63-50Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
	CK1C63-50IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CK1C63-50IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C63-50YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CK1C63-50YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C63-75Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
	CK1C63-75IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CK1C63-75IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C63-75YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CK1C63-75YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C63-100Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
	CK1C63-100IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CK1C63-100IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C63-100YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CK1C63-100YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C63-125Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
	CK1C63-125IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CK1C63-125IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C63-125YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CK1C63-125YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C63-150Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
	CK1C63-150IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CK1C63-150IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C63-150YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CK1C63-150YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CK1C63-200Z1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
	CK1C63-200IZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CK1C63-200IAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CK1C63-200YZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CK1C63-200YAZ1	Series: CK1 (no magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A40-50Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKG1A40-50IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKG1A40-50IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A40-50YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKG1A40-50YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A40-75Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKG1A40-75IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKG1A40-75IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A40-75YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKG1A40-75YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A40-100Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKG1A40-100IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKG1A40-100IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A40-100YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKG1A40-100YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A40-125Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKG1A40-125IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKG1A40-125IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A40-125YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKG1A40-125YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A40-150Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKG1A40-150IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKG1A40-150IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A40-150YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKG1A40-150YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A50-50Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKG1A50-50IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKG1A50-50IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A50-50YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKG1A50-50YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A50-75Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKG1A50-75IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKG1A50-75IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A50-75YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKG1A50-75YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A50-100Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKG1A50-100IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKG1A50-100IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A50-100YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKG1A50-100YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A50-125Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKG1A50-125IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKG1A50-125IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A50-125YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKG1A50-125YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A50-150Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKG1A50-150IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKG1A50-150IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A50-150YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKG1A50-150YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A50-200Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
	CKG1A50-200IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CKG1A50-200IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A50-200YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CKG1A50-200YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A63-50Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKG1A63-50IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKG1A63-50IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A63-50YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKG1A63-50YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A63-75Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKG1A63-75IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKG1A63-75IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A63-75YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKG1A63-75YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A63-100Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKG1A63-100IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKG1A63-100IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A63-100YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKG1A63-100YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A63-125Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKG1A63-125IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKG1A63-125IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A63-125YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKG1A63-125YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A63-150Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKG1A63-150IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKG1A63-150IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A63-150YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKG1A63-150YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1A63-200Z1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
	CKG1A63-200IZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CKG1A63-200IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1A63-200YZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CKG1A63-200YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B40-50Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKG1B40-50IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKG1B40-50IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B40-50YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKG1B40-50YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B40-75Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKG1B40-75IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKG1B40-75IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B40-75YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKG1B40-75YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B40-100Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKG1B40-100IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKG1B40-100IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B40-100YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKG1B40-100YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B40-125Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKG1B40-125IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKG1B40-125IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B40-125YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKG1B40-125YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B40-150Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKG1B40-150IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKG1B40-150IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B40-150YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKG1B40-150YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B50-50Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKG1B50-50IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKG1B50-50IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B50-50YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKG1B50-50YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B50-75Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKG1B50-75IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKG1B50-75IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B50-75YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKG1B50-75YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B50-100Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKG1B50-100IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKG1B50-100IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B50-100YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKG1B50-100YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B50-125Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKG1B50-125IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKG1B50-125IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B50-125YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKG1B50-125YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B50-150Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKG1B50-150IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKG1B50-150IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B50-150YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKG1B50-150YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B50-200Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
	CKG1B50-200IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CKG1B50-200IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B50-200YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CKG1B50-200YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B63-50Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKG1B63-50IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKG1B63-50IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B63-50YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKG1B63-50YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B63-75Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKG1B63-75IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKG1B63-75IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B63-75YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKG1B63-75YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B63-100Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKG1B63-100IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKG1B63-100IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B63-100YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKG1B63-100YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B63-125Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKG1B63-125IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKG1B63-125IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B63-125YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKG1B63-125YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B63-150Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKG1B63-150IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKG1B63-150IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B63-150YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKG1B63-150YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1B63-200Z1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
	CKG1B63-200IZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CKG1B63-200IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1B63-200YZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CKG1B63-200YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C40-50Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKG1C40-50IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKG1C40-50IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C40-50YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKG1C40-50YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C40-75Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKG1C40-75IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKG1C40-75IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C40-75YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKG1C40-75YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C40-100Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKG1C40-100IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKG1C40-100IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C40-100YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKG1C40-100YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C40-125Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKG1C40-125IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKG1C40-125IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C40-125YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKG1C40-125YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C40-150Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKG1C40-150IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKG1C40-150IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C40-150YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKG1C40-150YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C50-50Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKG1C50-50IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKG1C50-50IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C50-50YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKG1C50-50YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C50-75Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKG1C50-75IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKG1C50-75IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C50-75YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKG1C50-75YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C50-100Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKG1C50-100IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKG1C50-100IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C50-100YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKG1C50-100YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C50-125Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKG1C50-125IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKG1C50-125IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C50-125YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKG1C50-125YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C50-150Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKG1C50-150IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKG1C50-150IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C50-150YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKG1C50-150YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C50-200Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
	CKG1C50-200IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CKG1C50-200IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C50-200YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CKG1C50-200YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C63-50Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKG1C63-50IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKG1C63-50IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C63-50YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKG1C63-50YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C63-75Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKG1C63-75IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKG1C63-75IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C63-75YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKG1C63-75YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C63-100Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKG1C63-100IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKG1C63-100IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C63-100YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKG1C63-100YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C63-125Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKG1C63-125IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKG1C63-125IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C63-125YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKG1C63-125YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C63-150Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKG1C63-150IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKG1C63-150IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C63-150YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKG1C63-150YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKG1C63-200Z1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
	CKG1C63-200IZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CKG1C63-200IAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKG1C63-200YZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CKG1C63-200YAZ1	Series: CKG1 (built-in magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A40-50Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKP1A40-50IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKP1A40-50IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A40-50YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKP1A40-50YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A40-75Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKP1A40-75IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKP1A40-75IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A40-75YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKP1A40-75YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A40-100Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKP1A40-100IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKP1A40-100IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A40-100YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKP1A40-100YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A40-125Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKP1A40-125IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKP1A40-125IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A40-125YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKP1A40-125YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A40-150Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKP1A40-150IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKP1A40-150IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A40-150YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKP1A40-150YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A50-50Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKP1A50-50IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKP1A50-50IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A50-50YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKP1A50-50YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A50-75Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKP1A50-75IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKP1A50-75IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A50-75YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKP1A50-75YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A50-100Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKP1A50-100IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKP1A50-100IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A50-100YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKP1A50-100YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A50-125Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKP1A50-125IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKP1A50-125IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A50-125YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKP1A50-125YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A50-150Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKP1A50-150IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKP1A50-150IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A50-150YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKP1A50-150YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A50-200Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
	CKP1A50-200IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CKP1A50-200IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A50-200YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CKP1A50-200YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A63-50Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKP1A63-50IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKP1A63-50IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A63-50YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKP1A63-50YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A63-75Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKP1A63-75IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKP1A63-75IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A63-75YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKP1A63-75YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A63-100Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKP1A63-100IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKP1A63-100IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A63-100YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKP1A63-100YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A63-125Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKP1A63-125IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKP1A63-125IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A63-125YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKP1A63-125YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A63-150Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKP1A63-150IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKP1A63-150IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A63-150YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKP1A63-150YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1A63-200Z1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
	CKP1A63-200IZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CKP1A63-200IAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1A63-200YZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CKP1A63-200YAZ1	Series: CKP1 (strong magnet) \| Clevis width: A (16.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B40-50Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKP1B40-50IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKP1B40-50IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B40-50YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKP1B40-50YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B40-75Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKP1B40-75IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKP1B40-75IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B40-75YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKP1B40-75YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B40-100Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKP1B40-100IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKP1B40-100IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B40-100YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKP1B40-100YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B40-125Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKP1B40-125IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKP1B40-125IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B40-125YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKP1B40-125YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B40-150Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKP1B40-150IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKP1B40-150IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B40-150YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKP1B40-150YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B50-50Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKP1B50-50IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKP1B50-50IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B50-50YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKP1B50-50YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B50-75Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKP1B50-75IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKP1B50-75IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B50-75YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKP1B50-75YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B50-100Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKP1B50-100IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKP1B50-100IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B50-100YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKP1B50-100YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B50-125Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKP1B50-125IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKP1B50-125IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B50-125YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKP1B50-125YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B50-150Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKP1B50-150IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKP1B50-150IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B50-150YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKP1B50-150YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B50-200Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
	CKP1B50-200IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CKP1B50-200IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B50-200YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CKP1B50-200YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B63-50Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKP1B63-50IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKP1B63-50IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B63-50YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKP1B63-50YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B63-75Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKP1B63-75IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKP1B63-75IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B63-75YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKP1B63-75YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B63-100Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKP1B63-100IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKP1B63-100IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B63-100YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKP1B63-100YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B63-125Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKP1B63-125IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKP1B63-125IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B63-125YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKP1B63-125YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B63-150Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKP1B63-150IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKP1B63-150IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B63-150YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKP1B63-150YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1B63-200Z1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
	CKP1B63-200IZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CKP1B63-200IAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1B63-200YZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CKP1B63-200YAZ1	Series: CKP1 (strong magnet) \| Clevis width: B (19.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C40-50Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKP1C40-50IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKP1C40-50IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C40-50YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKP1C40-50YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C40-75Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKP1C40-75IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKP1C40-75IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C40-75YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKP1C40-75YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C40-100Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKP1C40-100IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKP1C40-100IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C40-100YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKP1C40-100YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C40-125Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKP1C40-125IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKP1C40-125IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C40-125YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKP1C40-125YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C40-150Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKP1C40-150IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKP1C40-150IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C40-150YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKP1C40-150YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø40 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C50-50Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKP1C50-50IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKP1C50-50IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C50-50YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKP1C50-50YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C50-75Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKP1C50-75IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKP1C50-75IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C50-75YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKP1C50-75YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C50-100Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKP1C50-100IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKP1C50-100IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C50-100YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKP1C50-100YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C50-125Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKP1C50-125IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKP1C50-125IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C50-125YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKP1C50-125YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C50-150Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKP1C50-150IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKP1C50-150IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C50-150YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKP1C50-150YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C50-200Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: None
	CKP1C50-200IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CKP1C50-200IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C50-200YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CKP1C50-200YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø50 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C63-50Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: None
	CKP1C63-50IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint
	CKP1C63-50IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C63-50YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint
	CKP1C63-50YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 50 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C63-75Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: None
	CKP1C63-75IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint
	CKP1C63-75IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C63-75YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint
	CKP1C63-75YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 75 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C63-100Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: None
	CKP1C63-100IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint
	CKP1C63-100IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C63-100YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint
	CKP1C63-100YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 100 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C63-125Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: None
	CKP1C63-125IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint
	CKP1C63-125IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C63-125YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint
	CKP1C63-125YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 125 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C63-150Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: None
	CKP1C63-150IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint
	CKP1C63-150IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C63-150YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint
	CKP1C63-150YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 150 mm \| Rod end bracket: Double knuckle joint, M6 tap
	CKP1C63-200Z1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: None
	CKP1C63-200IZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint
	CKP1C63-200IAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Single knuckle joint, M6 tap
	CKP1C63-200YZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint
	CKP1C63-200YAZ1	Series: CKP1 (strong magnet) \| Clevis width: C (12.5 mm) \| Bore: ø63 mm \| Stroke: 200 mm \| Rod end bracket: Double knuckle joint, M6 tap

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

SMC CK1/CKG1/CKP1-Z1 Clamp Cylinder (ø40 to ø63)
