SMC CXT Platform Cylinder (ø12 to ø40)

SMC CXT series platform cylinder, ø12 to ø40 mm bore, a high-rigidity, high-precision slide table integrating the table and actuator with strokes up to 300 mm.

Key features

Table and actuator integrated for high rigidity and precision; slide bearing (M) or ball bushing (L) guide
Stroke adjustment of -10 mm (-5 mm at each end) by adjusting bolts with dampers as standard
Shock absorber option: 2 shock absorbers (B) or 1 shock absorber (BS) for high-speed or heavy loads
M thread ports for ø12 to ø25 and Rc for ø32 and ø40; NPT (TN) and G (TF) available for ø32 and ø40
Built-in magnet as standard for D-M9, D-A9 and D-P3DWA auto switches (ordered as suffix, e.g. -M9BW)
Long-adjustment-bolt version with wider stroke adjustment available as made-to-order (-X138)

Specifications

Action	Double acting
Fluid	Air
Proof pressure	1.5 MPa
Max. operating pressure	0.7 MPa
Min. operating pressure	0.15 MPa
Ambient and fluid temperature	-10 to 60°C (no freezing)
Piston speed	50 to 500 mm/s
Cushion	Dampers on both ends (standard), shock absorbers (option)
Lubrication	Not required (non-lube)
Stroke adjustment range	-10 mm (-5 mm at each end)
Source	SMC Korea catalog (SMCKR_CXT.pdf), p. 728-729

CXTM12-15		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM12-15B		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM12-15BS		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM12-25		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM12-25B		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM12-25BS		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM12-50		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM12-50B		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM12-50BS		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM12-75		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM12-75B		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM12-75BS		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM12-100		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM12-100B		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM12-100BS		Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM16-15		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM16-15B		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM16-15BS		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM16-25		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM16-25B		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM16-25BS		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM16-50		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM16-50B		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM16-50BS		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM16-75		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM16-75B		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM16-75BS		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM16-100		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM16-100B		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM16-100BS		Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM20-25		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM20-25B		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM20-25BS		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM20-50		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM20-50B		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM20-50BS		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM20-75		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM20-75B		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM20-75BS		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM20-100		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM20-100B		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM20-100BS		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM20-125		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM20-125B		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM20-125BS		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM20-150		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM20-150B		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM20-150BS		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM20-175		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM20-175B		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM20-175BS		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM20-200		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM20-200B		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM20-200BS		Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM25-25		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM25-25B		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM25-25BS		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM25-50		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM25-50B		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM25-50BS		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM25-75		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM25-75B		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM25-75BS		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM25-100		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM25-100B		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM25-100BS		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM25-125		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM25-125B		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM25-125BS		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM25-150		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM25-150B		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM25-150BS		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM25-175		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM25-175B		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM25-175BS		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM25-200		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM25-200B		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM25-200BS		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM25-250		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM25-250B		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM25-250BS		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM25-300		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTM25-300B		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTM25-300BS		Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTM32-25		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM32-25B		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM32-25BS		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM32-50		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM32-50B		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM32-50BS		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM32-75		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM32-75B		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM32-75BS		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM32-100		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM32-100B		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM32-100BS		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM32-125		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM32-125B		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM32-125BS		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM32-150		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM32-150B		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM32-150BS		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM32-175		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM32-175B		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM32-175BS		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM32-200		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM32-200B		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM32-200BS		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM32-250		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM32-250B		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM32-250BS		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM32-300		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM32-300B		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM32-300BS		Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM40-25		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM40-25B		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM40-25BS		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM40-50		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM40-50B		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM40-50BS		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM40-75		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM40-75B		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM40-75BS		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM40-100		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM40-100B		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM40-100BS		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM40-125		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM40-125B		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM40-125BS		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM40-150		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM40-150B		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM40-150BS		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM40-175		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM40-175B		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM40-175BS		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM40-200		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM40-200B		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM40-200BS		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM40-250		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM40-250B		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM40-250BS		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTM40-300		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTM40-300B		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTM40-300BS		Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL12-15		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL12-15B		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL12-15BS		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL12-25		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL12-25B		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL12-25BS		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL12-50		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL12-50B		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL12-50BS		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL12-75		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL12-75B		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL12-75BS		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL12-100		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL12-100B		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL12-100BS		Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL16-15		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL16-15B		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL16-15BS		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL16-25		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL16-25B		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL16-25BS		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL16-50		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL16-50B		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL16-50BS		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL16-75		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL16-75B		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL16-75BS		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL16-100		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL16-100B		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL16-100BS		Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL20-25		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL20-25B		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL20-25BS		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL20-50		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL20-50B		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL20-50BS		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL20-75		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL20-75B		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL20-75BS		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL20-100		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL20-100B		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL20-100BS		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL20-125		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL20-125B		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL20-125BS		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL20-150		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL20-150B		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL20-150BS		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL20-175		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL20-175B		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL20-175BS		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL20-200		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL20-200B		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL20-200BS		Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL25-25		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL25-25B		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL25-25BS		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL25-50		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL25-50B		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL25-50BS		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL25-75		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL25-75B		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL25-75BS		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL25-100		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL25-100B		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL25-100BS		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL25-125		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL25-125B		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL25-125BS		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL25-150		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL25-150B		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL25-150BS		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL25-175		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL25-175B		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL25-175BS		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL25-200		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL25-200B		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL25-200BS		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL25-250		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL25-250B		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL25-250BS		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL25-300		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
CXTL25-300B		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
CXTL25-300BS		Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
CXTL32-25		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL32-25B		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL32-25BS		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL32-50		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL32-50B		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL32-50BS		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL32-75		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL32-75B		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL32-75BS		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL32-100		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL32-100B		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL32-100BS		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL32-125		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL32-125B		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL32-125BS		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL32-150		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL32-150B		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL32-150BS		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL32-175		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL32-175B		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL32-175BS		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL32-200		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL32-200B		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL32-200BS		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL32-250		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL32-250B		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL32-250BS		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL32-300		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL32-300B		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL32-300BS		Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL40-25		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL40-25B		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL40-25BS		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL40-50		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL40-50B		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL40-50BS		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL40-75		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL40-75B		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL40-75BS		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL40-100		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL40-100B		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL40-100BS		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL40-125		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL40-125B		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL40-125BS		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL40-150		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL40-150B		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL40-150BS		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL40-175		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL40-175B		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL40-175BS		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL40-200		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL40-200B		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL40-200BS		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL40-250		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL40-250B		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL40-250BS		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
CXTL40-300		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
CXTL40-300B		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
CXTL40-300BS		Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc

Slide TablesSMC

288 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC CXT Platform Cylinder (ø12 to ø40)

Brand SMC·Slide Tables

Available part numbers (288)

CXTM12-15, CXTM12-15B, CXTM12-15BS, CXTM12-25, CXTM12-25B, CXTM12-25BS, CXTM12-50, CXTM12-50B, CXTM12-50BS, CXTM12-75 + 278 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	CXTM12-15	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM12-15B	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM12-15BS	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM12-25	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM12-25B	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM12-25BS	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM12-50	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM12-50B	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM12-50BS	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM12-75	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM12-75B	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM12-75BS	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM12-100	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM12-100B	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM12-100BS	Bearing: Slide bearing \| Bore: ø12 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM16-15	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM16-15B	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM16-15BS	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM16-25	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM16-25B	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM16-25BS	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM16-50	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM16-50B	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM16-50BS	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM16-75	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM16-75B	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM16-75BS	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM16-100	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM16-100B	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM16-100BS	Bearing: Slide bearing \| Bore: ø16 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM20-25	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM20-25B	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM20-25BS	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM20-50	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM20-50B	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM20-50BS	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM20-75	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM20-75B	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM20-75BS	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM20-100	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM20-100B	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM20-100BS	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM20-125	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM20-125B	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM20-125BS	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM20-150	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM20-150B	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM20-150BS	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM20-175	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM20-175B	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM20-175BS	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM20-200	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM20-200B	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM20-200BS	Bearing: Slide bearing \| Bore: ø20 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM25-25	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM25-25B	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM25-25BS	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM25-50	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM25-50B	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM25-50BS	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM25-75	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM25-75B	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM25-75BS	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM25-100	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM25-100B	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM25-100BS	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM25-125	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM25-125B	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM25-125BS	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM25-150	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM25-150B	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM25-150BS	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM25-175	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM25-175B	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM25-175BS	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM25-200	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM25-200B	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM25-200BS	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM25-250	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM25-250B	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM25-250BS	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM25-300	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTM25-300B	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTM25-300BS	Bearing: Slide bearing \| Bore: ø25 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTM32-25	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM32-25B	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM32-25BS	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM32-50	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM32-50B	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM32-50BS	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM32-75	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM32-75B	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM32-75BS	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM32-100	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM32-100B	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM32-100BS	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM32-125	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM32-125B	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM32-125BS	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM32-150	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM32-150B	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM32-150BS	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM32-175	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM32-175B	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM32-175BS	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM32-200	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM32-200B	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM32-200BS	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM32-250	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM32-250B	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM32-250BS	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM32-300	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM32-300B	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM32-300BS	Bearing: Slide bearing \| Bore: ø32 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM40-25	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM40-25B	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM40-25BS	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM40-50	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM40-50B	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM40-50BS	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM40-75	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM40-75B	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM40-75BS	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM40-100	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM40-100B	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM40-100BS	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM40-125	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM40-125B	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM40-125BS	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM40-150	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM40-150B	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM40-150BS	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM40-175	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM40-175B	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM40-175BS	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM40-200	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM40-200B	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM40-200BS	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM40-250	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM40-250B	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM40-250BS	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTM40-300	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTM40-300B	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTM40-300BS	Bearing: Slide bearing \| Bore: ø40 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL12-15	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL12-15B	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL12-15BS	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL12-25	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL12-25B	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL12-25BS	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL12-50	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL12-50B	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL12-50BS	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL12-75	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL12-75B	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL12-75BS	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL12-100	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL12-100B	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL12-100BS	Bearing: Ball bushing \| Bore: ø12 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL16-15	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL16-15B	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL16-15BS	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 15 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL16-25	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL16-25B	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL16-25BS	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL16-50	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL16-50B	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL16-50BS	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 50 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL16-75	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL16-75B	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL16-75BS	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL16-100	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL16-100B	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL16-100BS	Bearing: Ball bushing \| Bore: ø16 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL20-25	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL20-25B	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL20-25BS	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL20-50	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL20-50B	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL20-50BS	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL20-75	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL20-75B	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL20-75BS	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL20-100	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL20-100B	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL20-100BS	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL20-125	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL20-125B	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL20-125BS	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL20-150	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL20-150B	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL20-150BS	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL20-175	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL20-175B	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL20-175BS	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL20-200	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL20-200B	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL20-200BS	Bearing: Ball bushing \| Bore: ø20 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL25-25	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL25-25B	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL25-25BS	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL25-50	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL25-50B	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL25-50BS	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL25-75	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL25-75B	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL25-75BS	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 75 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL25-100	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL25-100B	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL25-100BS	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 100 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL25-125	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL25-125B	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL25-125BS	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL25-150	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL25-150B	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL25-150BS	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL25-175	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL25-175B	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL25-175BS	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL25-200	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL25-200B	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL25-200BS	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL25-250	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL25-250B	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL25-250BS	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL25-300	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: M thread
	CXTL25-300B	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: M thread
	CXTL25-300BS	Bearing: Ball bushing \| Bore: ø25 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: M thread
	CXTL32-25	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL32-25B	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL32-25BS	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL32-50	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL32-50B	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL32-50BS	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL32-75	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL32-75B	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL32-75BS	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL32-100	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL32-100B	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL32-100BS	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL32-125	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL32-125B	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL32-125BS	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL32-150	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL32-150B	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL32-150BS	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL32-175	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL32-175B	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL32-175BS	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL32-200	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL32-200B	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL32-200BS	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL32-250	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL32-250B	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL32-250BS	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL32-300	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL32-300B	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL32-300BS	Bearing: Ball bushing \| Bore: ø32 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL40-25	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL40-25B	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL40-25BS	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 25 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL40-50	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL40-50B	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL40-50BS	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 50 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL40-75	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL40-75B	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL40-75BS	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 75 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL40-100	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL40-100B	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL40-100BS	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 100 mm \| Stroke range: Standard \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL40-125	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL40-125B	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL40-125BS	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 125 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL40-150	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL40-150B	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL40-150BS	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 150 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL40-175	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL40-175B	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL40-175BS	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 175 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL40-200	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL40-200B	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL40-200BS	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 200 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL40-250	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL40-250B	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL40-250BS	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 250 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc
	CXTL40-300	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: Damper (adjusting bolt) \| Port thread: Rc
	CXTL40-300B	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 2 shock absorbers \| Port thread: Rc
	CXTL40-300BS	Bearing: Ball bushing \| Bore: ø40 mm \| Stroke: 300 mm \| Stroke range: Long \| Stopper: 1 shock absorber \| Port thread: Rc

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

SMC CXT Platform Cylinder (ø12 to ø40)
