SMC HF3A-ZP3F Metal-Detectable Bellows Vacuum Pad (4.5-Stage, dia 40)

SMC HF3A-ZP3F Metal-Detectable Bellows Vacuum Pad (4.5-Stage, dia 40)

SMC HF3A-ZP3F series 4.5-stage bellows vacuum pad made of metal-detectable blue silicone, for depanning and handling soft bakery products.

Key features

  • Metal-detectable silicone pad and resin retainer allow detection of fragments in foreign-matter inspection
  • Highly cushioned 4.5-stage bellows picks soft workpieces such as bread with a light pressing force (approx. 1.7 N)
  • Anti-sticking grooves around the bellows prevent fold adhesion and improve durability
  • Retainer type inserts directly into holes in resin belts (e.g. depanner); adapter type with G3/8 or G1/2 male thread
  • Materials conform to FDA 21CFR177.2600, Japan Food Sanitation Act and (EC) No.1935/2004; no lubricant or rust inhibitor

Specifications

Series HF3A-ZP3F (food manufacturing)
Pad diameter dia 40 (41.5 mm)
Pad shape Bellows, 4.5-stage (ZJ)
Pad material Metal-detectable silicone rubber (MS), blue
Rubber hardness Shore A 40 +/-5
Pad temperature range -40 to 200 C
Retainer Metal-detectable resin, -40 to 90 C
Adapter Stainless steel, silicone O-ring
Tightening torque G3/8 15-20 N.m, G1/2 20-25 N.m
Source SMC Korea catalog CAT.KS100-174A (SMCKR_HF3A-ZP3F.pdf), p. 1-6
HF3A-ZP3F-D40ZJMS Mounting: Retainer (belt insertion) | Adapter: Synthetic resin retainer | Connection: None
HF3A-ZP3FS-T40ZJMS-AG03 Mounting: Vertical adapter | Adapter: Stainless steel | Connection: G3/8 male
HF3A-ZP3FS-T40ZJMS-AG04 Mounting: Vertical adapter | Adapter: Stainless steel | Connection: G1/2 male
Vacuum PadsSMC
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC HF3A-ZP3F Metal-Detectable Bellows Vacuum Pad (4.5-Stage, dia 40)

Brand SMC·Vacuum Pads

Available part numbers (3)

HF3A-ZP3F-D40ZJMS, HF3A-ZP3FS-T40ZJMS-AG03, HF3A-ZP3FS-T40ZJMS-AG04

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
HF3A-ZP3F-D40ZJMSMounting: Retainer (belt insertion) | Adapter: Synthetic resin retainer | Connection: None
HF3A-ZP3FS-T40ZJMS-AG03Mounting: Vertical adapter | Adapter: Stainless steel | Connection: G3/8 male
HF3A-ZP3FS-T40ZJMS-AG04Mounting: Vertical adapter | Adapter: Stainless steel | Connection: G1/2 male
