SMC ID Heatless Desiccant Air Dryer (ID20 to ID60)

SMC ID series heatless (pressure-swing) desiccant air dryer supplying dry air at an atmospheric dew point of -30C or lower.

Key features

Twin-tower adsorption with self-regeneration; no heater or electrical control panel, compact and light
Indicator shows outlet dew point condition
Atmospheric dew point -30C standard, -50C with option Z (not listed as separate codes)
Bracket mounting option B; G and NPT threads (F, N) available on request
Replacement desiccant set and indicator set available

Specifications

Fluid	Compressed air
Inlet air temperature	5 to 50C (no water droplets)
Inlet air pressure	0.3 to 1.0 MPa (ID60: 0.3 to 0.9 MPa)
Ambient temperature	2 to 50C
Rated inlet pressure	0.7 MPa
Outlet atmospheric dew point	-30C (option Z: -50C)
Power consumption	30 W
Mass	7 / 8.5 / 18.5 / 25 kg (ID20/30/40/60)
Source	SMC Korea catalog ID series (SMCKR_ID.pdf), p. 1-2

ID200-02		Size: ID20 \| Voltage: 1-ph AC100V 50Hz / 100-110V 60Hz \| Port: Rc1/4 \| Outlet flow: 80 L/min ANR
ID201-02		Size: ID20 \| Voltage: 1-ph AC110V 50Hz \| Port: Rc1/4 \| Outlet flow: 80 L/min ANR
ID205-02		Size: ID20 \| Voltage: 1-ph AC200V 50Hz / 200-220V 60Hz \| Port: Rc1/4 \| Outlet flow: 80 L/min ANR
ID206-02		Size: ID20 \| Voltage: 1-ph AC220V 50Hz \| Port: Rc1/4 \| Outlet flow: 80 L/min ANR
ID300-04		Size: ID30 \| Voltage: 1-ph AC100V 50Hz / 100-110V 60Hz \| Port: Rc1/2 \| Outlet flow: 155 L/min ANR
ID301-04		Size: ID30 \| Voltage: 1-ph AC110V 50Hz \| Port: Rc1/2 \| Outlet flow: 155 L/min ANR
ID305-04		Size: ID30 \| Voltage: 1-ph AC200V 50Hz / 200-220V 60Hz \| Port: Rc1/2 \| Outlet flow: 155 L/min ANR
ID306-04		Size: ID30 \| Voltage: 1-ph AC220V 50Hz \| Port: Rc1/2 \| Outlet flow: 155 L/min ANR
ID400-04		Size: ID40 \| Voltage: 1-ph AC100V 50Hz / 100-110V 60Hz \| Port: Rc1/2 \| Outlet flow: 330 L/min ANR
ID401-04		Size: ID40 \| Voltage: 1-ph AC110V 50Hz \| Port: Rc1/2 \| Outlet flow: 330 L/min ANR
ID405-04		Size: ID40 \| Voltage: 1-ph AC200V 50Hz / 200-220V 60Hz \| Port: Rc1/2 \| Outlet flow: 330 L/min ANR
ID406-04		Size: ID40 \| Voltage: 1-ph AC220V 50Hz \| Port: Rc1/2 \| Outlet flow: 330 L/min ANR
ID600-06		Size: ID60 \| Voltage: 1-ph AC100V 50Hz / 100-110V 60Hz \| Port: Rc3/4 \| Outlet flow: 780 L/min ANR
ID601-06		Size: ID60 \| Voltage: 1-ph AC110V 50Hz \| Port: Rc3/4 \| Outlet flow: 780 L/min ANR
ID605-06		Size: ID60 \| Voltage: 1-ph AC200V 50Hz / 200-220V 60Hz \| Port: Rc3/4 \| Outlet flow: 780 L/min ANR
ID606-06		Size: ID60 \| Voltage: 1-ph AC220V 50Hz \| Port: Rc3/4 \| Outlet flow: 780 L/min ANR
