SMC IR1000-A/2000-A/3000-A Precision Regulator (1/8 to 1/2)

SMC IR1000-A/2000-A/3000-A Precision Regulator (1/8 to 1/2)

SMC IR-A series precision regulator with relief, in three body sizes (1/8 to 1/2), offering 0.2% F.S. sensitivity with air consumption cut to 1 L/min or less by a new structure without a fixed orifice.

Key features

  • Sensitivity within 0.2% F.S. and repeatability within +/-0.5% F.S.
  • New structure without fixed orifice: air consumption 1 L/min (ANR) or less, no mist separator required upstream
  • Flow rate approx. 2x and mass up to 27% lower than the previous IR series; mounting compatible with previous models
  • IR3000-A: exhaust direction selectable (bottom, front or back)
  • Options ordered as suffixes: bracket (B), hex panel nut (H), digital pressure switch (EA/EB/EC/ED), flow direction right-to-left (R), handle downward (V), psi units (Z/ZA); listed codes cover no gauge and round gauge (G)
  • Made to order: clean room (10-), secondary battery (25A-), fluororubber (-X1155), grease-free (-X1), IRM manifold

Specifications

Fluid Air
Proof pressure 1.5 MPa
Max. supply pressure 1.0 MPa
Min. supply pressure Set pressure + 0.05 MPa (IR3000-A: + 0.1 MPa)
Sensitivity Within 0.2% of full span
Repeatability Within +/-0.5% of full span
Air consumption 1 L/min (ANR) or less (supply 1.0 MPa, set 0.2 MPa)
Gauge port 1/8 (2 locations)
Ambient and fluid temperature -5 to 60 C (no freezing; with digital switch -5 to 50 C)
Mass 0.13 / 0.23 / 0.47 kg (IR1000-A / 2000-A / 3000-A)
Thread type Rc (NPT: N, G: F on order)
Source SMC Korea catalog IR1000-A/2000-A/3000-A (SMCKR_IR1000_2000_3000-A.pdf), p. 789-795
IR1000-01-A Body size: IR1000-A | Set pressure: 0.005 to 0.2 MPa | Exhaust direction: Bottom | Port size: Rc1/8 | Pressure gauge: None
IR1000-01G-A Body size: IR1000-A | Set pressure: 0.005 to 0.2 MPa | Exhaust direction: Bottom | Port size: Rc1/8 | Pressure gauge: Round pressure gauge
IR1010-01-A Body size: IR1000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Bottom | Port size: Rc1/8 | Pressure gauge: None
IR1010-01G-A Body size: IR1000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Bottom | Port size: Rc1/8 | Pressure gauge: Round pressure gauge
IR1020-01-A Body size: IR1000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Bottom | Port size: Rc1/8 | Pressure gauge: None
IR1020-01G-A Body size: IR1000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Bottom | Port size: Rc1/8 | Pressure gauge: Round pressure gauge
IR2000-02-A Body size: IR2000-A | Set pressure: 0.005 to 0.2 MPa | Exhaust direction: Bottom | Port size: Rc1/4 | Pressure gauge: None
IR2000-02G-A Body size: IR2000-A | Set pressure: 0.005 to 0.2 MPa | Exhaust direction: Bottom | Port size: Rc1/4 | Pressure gauge: Round pressure gauge
IR2010-02-A Body size: IR2000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Bottom | Port size: Rc1/4 | Pressure gauge: None
IR2010-02G-A Body size: IR2000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Bottom | Port size: Rc1/4 | Pressure gauge: Round pressure gauge
IR2020-02-A Body size: IR2000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Bottom | Port size: Rc1/4 | Pressure gauge: None
IR2020-02G-A Body size: IR2000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Bottom | Port size: Rc1/4 | Pressure gauge: Round pressure gauge
IR3000-02-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Bottom | Port size: Rc1/4 | Pressure gauge: None
IR3000-02G-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Bottom | Port size: Rc1/4 | Pressure gauge: Round pressure gauge
IR3000-03-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Bottom | Port size: Rc3/8 | Pressure gauge: None
IR3000-03G-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Bottom | Port size: Rc3/8 | Pressure gauge: Round pressure gauge
IR3000-04-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Bottom | Port size: Rc1/2 | Pressure gauge: None
IR3000-04G-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Bottom | Port size: Rc1/2 | Pressure gauge: Round pressure gauge
IR3001-02-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Front | Port size: Rc1/4 | Pressure gauge: None
IR3001-02G-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Front | Port size: Rc1/4 | Pressure gauge: Round pressure gauge
IR3001-03-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Front | Port size: Rc3/8 | Pressure gauge: None
IR3001-03G-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Front | Port size: Rc3/8 | Pressure gauge: Round pressure gauge
IR3001-04-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Front | Port size: Rc1/2 | Pressure gauge: None
IR3001-04G-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Front | Port size: Rc1/2 | Pressure gauge: Round pressure gauge
IR3002-02-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Back | Port size: Rc1/4 | Pressure gauge: None
IR3002-02G-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Back | Port size: Rc1/4 | Pressure gauge: Round pressure gauge
IR3002-03-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Back | Port size: Rc3/8 | Pressure gauge: None
IR3002-03G-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Back | Port size: Rc3/8 | Pressure gauge: Round pressure gauge
IR3002-04-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Back | Port size: Rc1/2 | Pressure gauge: None
IR3002-04G-A Body size: IR3000-A | Set pressure: 0.01 to 0.2 MPa | Exhaust direction: Back | Port size: Rc1/2 | Pressure gauge: Round pressure gauge
IR3010-02-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Bottom | Port size: Rc1/4 | Pressure gauge: None
IR3010-02G-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Bottom | Port size: Rc1/4 | Pressure gauge: Round pressure gauge
IR3010-03-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Bottom | Port size: Rc3/8 | Pressure gauge: None
IR3010-03G-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Bottom | Port size: Rc3/8 | Pressure gauge: Round pressure gauge
IR3010-04-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Bottom | Port size: Rc1/2 | Pressure gauge: None
IR3010-04G-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Bottom | Port size: Rc1/2 | Pressure gauge: Round pressure gauge
IR3011-02-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Front | Port size: Rc1/4 | Pressure gauge: None
IR3011-02G-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Front | Port size: Rc1/4 | Pressure gauge: Round pressure gauge
IR3011-03-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Front | Port size: Rc3/8 | Pressure gauge: None
IR3011-03G-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Front | Port size: Rc3/8 | Pressure gauge: Round pressure gauge
IR3011-04-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Front | Port size: Rc1/2 | Pressure gauge: None
IR3011-04G-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Front | Port size: Rc1/2 | Pressure gauge: Round pressure gauge
IR3012-02-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Back | Port size: Rc1/4 | Pressure gauge: None
IR3012-02G-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Back | Port size: Rc1/4 | Pressure gauge: Round pressure gauge
IR3012-03-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Back | Port size: Rc3/8 | Pressure gauge: None
IR3012-03G-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Back | Port size: Rc3/8 | Pressure gauge: Round pressure gauge
IR3012-04-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Back | Port size: Rc1/2 | Pressure gauge: None
IR3012-04G-A Body size: IR3000-A | Set pressure: 0.01 to 0.4 MPa | Exhaust direction: Back | Port size: Rc1/2 | Pressure gauge: Round pressure gauge
IR3020-02-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Bottom | Port size: Rc1/4 | Pressure gauge: None
IR3020-02G-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Bottom | Port size: Rc1/4 | Pressure gauge: Round pressure gauge
IR3020-03-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Bottom | Port size: Rc3/8 | Pressure gauge: None
IR3020-03G-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Bottom | Port size: Rc3/8 | Pressure gauge: Round pressure gauge
IR3020-04-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Bottom | Port size: Rc1/2 | Pressure gauge: None
IR3020-04G-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Bottom | Port size: Rc1/2 | Pressure gauge: Round pressure gauge
IR3021-02-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Front | Port size: Rc1/4 | Pressure gauge: None
IR3021-02G-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Front | Port size: Rc1/4 | Pressure gauge: Round pressure gauge
IR3021-03-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Front | Port size: Rc3/8 | Pressure gauge: None
IR3021-03G-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Front | Port size: Rc3/8 | Pressure gauge: Round pressure gauge
IR3021-04-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Front | Port size: Rc1/2 | Pressure gauge: None
IR3021-04G-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Front | Port size: Rc1/2 | Pressure gauge: Round pressure gauge
IR3022-02-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Back | Port size: Rc1/4 | Pressure gauge: None
IR3022-02G-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Back | Port size: Rc1/4 | Pressure gauge: Round pressure gauge
IR3022-03-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Back | Port size: Rc3/8 | Pressure gauge: None
IR3022-03G-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Back | Port size: Rc3/8 | Pressure gauge: Round pressure gauge
IR3022-04-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Back | Port size: Rc1/2 | Pressure gauge: None
IR3022-04G-A Body size: IR3000-A | Set pressure: 0.01 to 0.8 MPa | Exhaust direction: Back | Port size: Rc1/2 | Pressure gauge: Round pressure gauge
