SMC ITV0000 Compact Electro-Pneumatic Regulator (Thin Type)

SMC ITV0000 Compact Electro-Pneumatic Regulator (Thin Type)

SMC ITV0000 thin, 15 mm wide electro-pneumatic regulator with built-in one-touch fittings, for single use or DIN-rail IITV00 manifold mounting.

Key features

  • 15 mm width, 100 g or less; built-in one-touch fittings (ø4 single unit; ø6/ø4 on manifold)
  • Set pressure ranges 0.1, 0.5 and 0.9 MPa; DC24V or DC12-15V supply
  • Current (4-20mA, 0-20mA) or voltage (0-5V, 0-10V) input; analog DC1-5V monitor output
  • Manifold mount type (M) for IITV00 DIN-rail manifold, up to 10 stations
  • Listed codes: millimeter fittings, no bracket, straight 3 m cable; inch fittings (U), brackets (B, C), right-angle 2 m (L) or no cable (N) on order

Specifications

Fluid Air
Min. supply pressure Set pressure + 0.1 MPa
Max. supply pressure 0.2 MPa (0.1 MPa range), 1.0 MPa (others)
Power consumption DC24V: 0.12 A or less; DC12-15V: 0.18 A or less
Monitor output Analog DC1-5V
Linearity / hysteresis ±1% F.S. / 0.5% F.S. or less
Repeatability ±0.5% F.S. or less
Ambient temperature 0 to 50°C (no condensation)
Enclosure IP65 equivalent
Mass 100 g or less
Source SMC Korea catalog CAT.KS60-15G (SMCKR_ITV.pdf), p. 5-6 (PDF p. 6-7)
ITV0010-0S Set pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC4-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0010-0MS Set pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC4-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0010-1S Set pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC0-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0010-1MS Set pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC0-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0010-2S Set pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC0-5V | Base type: Single unit (ø4 fittings)
ITV0010-2MS Set pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC0-5V | Base type: Manifold mount (IITV00)
ITV0010-3S Set pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC0-10V | Base type: Single unit (ø4 fittings)
ITV0010-3MS Set pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC0-10V | Base type: Manifold mount (IITV00)
ITV0011-0S Set pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC4-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0011-0MS Set pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC4-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0011-1S Set pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC0-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0011-1MS Set pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC0-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0011-2S Set pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC0-5V | Base type: Single unit (ø4 fittings)
ITV0011-2MS Set pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC0-5V | Base type: Manifold mount (IITV00)
ITV0011-3S Set pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC0-10V | Base type: Single unit (ø4 fittings)
ITV0011-3MS Set pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC0-10V | Base type: Manifold mount (IITV00)
ITV0030-0S Set pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC4-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0030-0MS Set pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC4-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0030-1S Set pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC0-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0030-1MS Set pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC0-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0030-2S Set pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC0-5V | Base type: Single unit (ø4 fittings)
ITV0030-2MS Set pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC0-5V | Base type: Manifold mount (IITV00)
ITV0030-3S Set pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC0-10V | Base type: Single unit (ø4 fittings)
ITV0030-3MS Set pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC0-10V | Base type: Manifold mount (IITV00)
ITV0031-0S Set pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC4-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0031-0MS Set pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC4-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0031-1S Set pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC0-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0031-1MS Set pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC0-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0031-2S Set pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC0-5V | Base type: Single unit (ø4 fittings)
ITV0031-2MS Set pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC0-5V | Base type: Manifold mount (IITV00)
ITV0031-3S Set pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC0-10V | Base type: Single unit (ø4 fittings)
ITV0031-3MS Set pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC0-10V | Base type: Manifold mount (IITV00)
ITV0050-0S Set pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC4-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0050-0MS Set pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC4-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0050-1S Set pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC0-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0050-1MS Set pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC0-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0050-2S Set pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC0-5V | Base type: Single unit (ø4 fittings)
ITV0050-2MS Set pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC0-5V | Base type: Manifold mount (IITV00)
ITV0050-3S Set pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC0-10V | Base type: Single unit (ø4 fittings)
ITV0050-3MS Set pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC0-10V | Base type: Manifold mount (IITV00)
ITV0051-0S Set pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC4-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0051-0MS Set pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC4-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0051-1S Set pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC0-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0051-1MS Set pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC0-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0051-2S Set pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC0-5V | Base type: Single unit (ø4 fittings)
ITV0051-2MS Set pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC0-5V | Base type: Manifold mount (IITV00)
ITV0051-3S Set pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC0-10V | Base type: Single unit (ø4 fittings)
ITV0051-3MS Set pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC0-10V | Base type: Manifold mount (IITV00)
Electro-Pneumatic RegulatorsSMC
48 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC ITV0000 Compact Electro-Pneumatic Regulator (Thin Type)

Brand SMC·Electro-Pneumatic Regulators

Available part numbers (48)

ITV0010-0S, ITV0010-0MS, ITV0010-1S, ITV0010-1MS, ITV0010-2S, ITV0010-2MS, ITV0010-3S, ITV0010-3MS, ITV0011-0S, ITV0011-0MS + 38 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ITV0010-0SSet pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC4-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0010-0MSSet pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC4-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0010-1SSet pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC0-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0010-1MSSet pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC0-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0010-2SSet pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC0-5V | Base type: Single unit (ø4 fittings)
ITV0010-2MSSet pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC0-5V | Base type: Manifold mount (IITV00)
ITV0010-3SSet pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC0-10V | Base type: Single unit (ø4 fittings)
ITV0010-3MSSet pressure: 0.001-0.1 MPa | Power supply: DC24V | Input signal: DC0-10V | Base type: Manifold mount (IITV00)
ITV0011-0SSet pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC4-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0011-0MSSet pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC4-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0011-1SSet pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC0-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0011-1MSSet pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC0-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0011-2SSet pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC0-5V | Base type: Single unit (ø4 fittings)
ITV0011-2MSSet pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC0-5V | Base type: Manifold mount (IITV00)
ITV0011-3SSet pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC0-10V | Base type: Single unit (ø4 fittings)
ITV0011-3MSSet pressure: 0.001-0.1 MPa | Power supply: DC12-15V | Input signal: DC0-10V | Base type: Manifold mount (IITV00)
ITV0030-0SSet pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC4-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0030-0MSSet pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC4-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0030-1SSet pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC0-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0030-1MSSet pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC0-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0030-2SSet pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC0-5V | Base type: Single unit (ø4 fittings)
ITV0030-2MSSet pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC0-5V | Base type: Manifold mount (IITV00)
ITV0030-3SSet pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC0-10V | Base type: Single unit (ø4 fittings)
ITV0030-3MSSet pressure: 0.001-0.5 MPa | Power supply: DC24V | Input signal: DC0-10V | Base type: Manifold mount (IITV00)
ITV0031-0SSet pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC4-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0031-0MSSet pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC4-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0031-1SSet pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC0-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0031-1MSSet pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC0-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0031-2SSet pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC0-5V | Base type: Single unit (ø4 fittings)
ITV0031-2MSSet pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC0-5V | Base type: Manifold mount (IITV00)
ITV0031-3SSet pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC0-10V | Base type: Single unit (ø4 fittings)
ITV0031-3MSSet pressure: 0.001-0.5 MPa | Power supply: DC12-15V | Input signal: DC0-10V | Base type: Manifold mount (IITV00)
ITV0050-0SSet pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC4-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0050-0MSSet pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC4-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0050-1SSet pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC0-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0050-1MSSet pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC0-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0050-2SSet pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC0-5V | Base type: Single unit (ø4 fittings)
ITV0050-2MSSet pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC0-5V | Base type: Manifold mount (IITV00)
ITV0050-3SSet pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC0-10V | Base type: Single unit (ø4 fittings)
ITV0050-3MSSet pressure: 0.001-0.9 MPa | Power supply: DC24V | Input signal: DC0-10V | Base type: Manifold mount (IITV00)
ITV0051-0SSet pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC4-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0051-0MSSet pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC4-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0051-1SSet pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC0-20mA (sink) | Base type: Single unit (ø4 fittings)
ITV0051-1MSSet pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC0-20mA (sink) | Base type: Manifold mount (IITV00)
ITV0051-2SSet pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC0-5V | Base type: Single unit (ø4 fittings)
ITV0051-2MSSet pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC0-5V | Base type: Manifold mount (IITV00)
ITV0051-3SSet pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC0-10V | Base type: Single unit (ø4 fittings)
ITV0051-3MSSet pressure: 0.001-0.9 MPa | Power supply: DC12-15V | Input signal: DC0-10V | Base type: Manifold mount (IITV00)
