SMC ITV2090/2091 Electronic Vacuum Regulator

SMC ITV2090/2091 Electronic Vacuum Regulator

SMC ITV2090/2091 electronic vacuum regulator that steplessly controls vacuum pressure from -1.3 to -80 kPa in proportion to an electrical or fieldbus signal.

Key features

  • Set vacuum range -1.3 to -80 kPa, Rc1/4 ports, kPa digital display
  • ITV2090 DC24V, ITV2091 DC12-15V supply
  • Analog current/voltage input with analog or NPN/PNP switch monitor output
  • Preset (4/16-point), 10-bit digital, CC-Link, DeviceNet, PROFIBUS DP, RS-232C and IO-Link types (DC24V)
  • Listed codes: Rc thread, no bracket, straight 3 m cable; NPT/NPTF/G, brackets (B, C) and other cables on order

Specifications

Fluid Air
Set pressure range -1.3 to -80 kPa
Min. supply vacuum Set pressure -13.3 kPa
Max. supply vacuum -101 kPa
Port size Rc1/4
Power consumption DC24V: 0.12 A or less; DC12-15V: 0.18 A or less
Pressure display unit kPa (symbol 5); none for fieldbus types
Ambient and fluid temperature 0 to 50°C (no condensation)
Enclosure IP65
Source SMC Korea catalog CAT.KS60-15G (SMCKR_ITV.pdf), p. 46-47 (PDF p. 47-48)
ITV2090-012S5 Power supply: DC24V | Input / communication: DC4-20mA (sink) | Monitor output: Analog DC1-5V
ITV2090-022S5 Power supply: DC24V | Input / communication: DC4-20mA (sink) | Monitor output: Switch NPN
ITV2090-032S5 Power supply: DC24V | Input / communication: DC4-20mA (sink) | Monitor output: Switch PNP
ITV2090-042S5 Power supply: DC24V | Input / communication: DC4-20mA (sink) | Monitor output: Analog DC4-20mA (sink)
ITV2090-112S5 Power supply: DC24V | Input / communication: DC0-20mA (sink) | Monitor output: Analog DC1-5V
ITV2090-122S5 Power supply: DC24V | Input / communication: DC0-20mA (sink) | Monitor output: Switch NPN
ITV2090-132S5 Power supply: DC24V | Input / communication: DC0-20mA (sink) | Monitor output: Switch PNP
ITV2090-142S5 Power supply: DC24V | Input / communication: DC0-20mA (sink) | Monitor output: Analog DC4-20mA (sink)
ITV2090-212S5 Power supply: DC24V | Input / communication: DC0-5V | Monitor output: Analog DC1-5V
ITV2090-222S5 Power supply: DC24V | Input / communication: DC0-5V | Monitor output: Switch NPN
ITV2090-232S5 Power supply: DC24V | Input / communication: DC0-5V | Monitor output: Switch PNP
ITV2090-242S5 Power supply: DC24V | Input / communication: DC0-5V | Monitor output: Analog DC4-20mA (sink)
ITV2090-312S5 Power supply: DC24V | Input / communication: DC0-10V | Monitor output: Analog DC1-5V
ITV2090-322S5 Power supply: DC24V | Input / communication: DC0-10V | Monitor output: Switch NPN
ITV2090-332S5 Power supply: DC24V | Input / communication: DC0-10V | Monitor output: Switch PNP
ITV2090-342S5 Power supply: DC24V | Input / communication: DC0-10V | Monitor output: Analog DC4-20mA (sink)
ITV2091-012S5 Power supply: DC12-15V | Input / communication: DC4-20mA (sink) | Monitor output: Analog DC1-5V
ITV2091-022S5 Power supply: DC12-15V | Input / communication: DC4-20mA (sink) | Monitor output: Switch NPN
ITV2091-032S5 Power supply: DC12-15V | Input / communication: DC4-20mA (sink) | Monitor output: Switch PNP
ITV2091-042S5 Power supply: DC12-15V | Input / communication: DC4-20mA (sink) | Monitor output: Analog DC4-20mA (sink)
ITV2091-112S5 Power supply: DC12-15V | Input / communication: DC0-20mA (sink) | Monitor output: Analog DC1-5V
ITV2091-122S5 Power supply: DC12-15V | Input / communication: DC0-20mA (sink) | Monitor output: Switch NPN
ITV2091-132S5 Power supply: DC12-15V | Input / communication: DC0-20mA (sink) | Monitor output: Switch PNP
ITV2091-142S5 Power supply: DC12-15V | Input / communication: DC0-20mA (sink) | Monitor output: Analog DC4-20mA (sink)
ITV2091-212S5 Power supply: DC12-15V | Input / communication: DC0-5V | Monitor output: Analog DC1-5V
ITV2091-222S5 Power supply: DC12-15V | Input / communication: DC0-5V | Monitor output: Switch NPN
ITV2091-232S5 Power supply: DC12-15V | Input / communication: DC0-5V | Monitor output: Switch PNP
ITV2091-242S5 Power supply: DC12-15V | Input / communication: DC0-5V | Monitor output: Analog DC4-20mA (sink)
ITV2091-312S5 Power supply: DC12-15V | Input / communication: DC0-10V | Monitor output: Analog DC1-5V
ITV2091-322S5 Power supply: DC12-15V | Input / communication: DC0-10V | Monitor output: Switch NPN
ITV2091-332S5 Power supply: DC12-15V | Input / communication: DC0-10V | Monitor output: Switch PNP
ITV2091-342S5 Power supply: DC12-15V | Input / communication: DC0-10V | Monitor output: Analog DC4-20mA (sink)
ITV2090-402S5 Power supply: DC24V | Input / communication: 4-point preset input | Monitor output: None
ITV2090-522S5 Power supply: DC24V | Input / communication: 16-point preset (NPN switch out) | Monitor output: None
ITV2090-532S5 Power supply: DC24V | Input / communication: 16-point preset (PNP switch out) | Monitor output: None
ITV2090-602S5 Power supply: DC24V | Input / communication: 10-bit digital input | Monitor output: None
ITV2090-CC2S Power supply: DC24V | Input / communication: CC-Link | Monitor output: None
ITV2090-DE2S Power supply: DC24V | Input / communication: DeviceNet | Monitor output: None
ITV2090-PR2S Power supply: DC24V | Input / communication: PROFIBUS DP | Monitor output: None
ITV2090-RC2S Power supply: DC24V | Input / communication: RS-232C | Monitor output: None
ITV2090-IL2S Power supply: DC24V | Input / communication: IO-Link | Monitor output: None
Electro-Pneumatic RegulatorsSMC
41 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC ITV2090/2091 Electronic Vacuum Regulator

Brand SMC·Electro-Pneumatic Regulators

Available part numbers (41)

ITV2090-012S5, ITV2090-022S5, ITV2090-032S5, ITV2090-042S5, ITV2090-112S5, ITV2090-122S5, ITV2090-132S5, ITV2090-142S5, ITV2090-212S5, ITV2090-222S5 + 31 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ITV2090-012S5Power supply: DC24V | Input / communication: DC4-20mA (sink) | Monitor output: Analog DC1-5V
ITV2090-022S5Power supply: DC24V | Input / communication: DC4-20mA (sink) | Monitor output: Switch NPN
ITV2090-032S5Power supply: DC24V | Input / communication: DC4-20mA (sink) | Monitor output: Switch PNP
ITV2090-042S5Power supply: DC24V | Input / communication: DC4-20mA (sink) | Monitor output: Analog DC4-20mA (sink)
ITV2090-112S5Power supply: DC24V | Input / communication: DC0-20mA (sink) | Monitor output: Analog DC1-5V
ITV2090-122S5Power supply: DC24V | Input / communication: DC0-20mA (sink) | Monitor output: Switch NPN
ITV2090-132S5Power supply: DC24V | Input / communication: DC0-20mA (sink) | Monitor output: Switch PNP
ITV2090-142S5Power supply: DC24V | Input / communication: DC0-20mA (sink) | Monitor output: Analog DC4-20mA (sink)
ITV2090-212S5Power supply: DC24V | Input / communication: DC0-5V | Monitor output: Analog DC1-5V
ITV2090-222S5Power supply: DC24V | Input / communication: DC0-5V | Monitor output: Switch NPN
ITV2090-232S5Power supply: DC24V | Input / communication: DC0-5V | Monitor output: Switch PNP
ITV2090-242S5Power supply: DC24V | Input / communication: DC0-5V | Monitor output: Analog DC4-20mA (sink)
ITV2090-312S5Power supply: DC24V | Input / communication: DC0-10V | Monitor output: Analog DC1-5V
ITV2090-322S5Power supply: DC24V | Input / communication: DC0-10V | Monitor output: Switch NPN
ITV2090-332S5Power supply: DC24V | Input / communication: DC0-10V | Monitor output: Switch PNP
ITV2090-342S5Power supply: DC24V | Input / communication: DC0-10V | Monitor output: Analog DC4-20mA (sink)
ITV2091-012S5Power supply: DC12-15V | Input / communication: DC4-20mA (sink) | Monitor output: Analog DC1-5V
ITV2091-022S5Power supply: DC12-15V | Input / communication: DC4-20mA (sink) | Monitor output: Switch NPN
ITV2091-032S5Power supply: DC12-15V | Input / communication: DC4-20mA (sink) | Monitor output: Switch PNP
ITV2091-042S5Power supply: DC12-15V | Input / communication: DC4-20mA (sink) | Monitor output: Analog DC4-20mA (sink)
ITV2091-112S5Power supply: DC12-15V | Input / communication: DC0-20mA (sink) | Monitor output: Analog DC1-5V
ITV2091-122S5Power supply: DC12-15V | Input / communication: DC0-20mA (sink) | Monitor output: Switch NPN
ITV2091-132S5Power supply: DC12-15V | Input / communication: DC0-20mA (sink) | Monitor output: Switch PNP
ITV2091-142S5Power supply: DC12-15V | Input / communication: DC0-20mA (sink) | Monitor output: Analog DC4-20mA (sink)
ITV2091-212S5Power supply: DC12-15V | Input / communication: DC0-5V | Monitor output: Analog DC1-5V
ITV2091-222S5Power supply: DC12-15V | Input / communication: DC0-5V | Monitor output: Switch NPN
ITV2091-232S5Power supply: DC12-15V | Input / communication: DC0-5V | Monitor output: Switch PNP
ITV2091-242S5Power supply: DC12-15V | Input / communication: DC0-5V | Monitor output: Analog DC4-20mA (sink)
ITV2091-312S5Power supply: DC12-15V | Input / communication: DC0-10V | Monitor output: Analog DC1-5V
ITV2091-322S5Power supply: DC12-15V | Input / communication: DC0-10V | Monitor output: Switch NPN
ITV2091-332S5Power supply: DC12-15V | Input / communication: DC0-10V | Monitor output: Switch PNP
ITV2091-342S5Power supply: DC12-15V | Input / communication: DC0-10V | Monitor output: Analog DC4-20mA (sink)
ITV2090-402S5Power supply: DC24V | Input / communication: 4-point preset input | Monitor output: None
ITV2090-522S5Power supply: DC24V | Input / communication: 16-point preset (NPN switch out) | Monitor output: None
ITV2090-532S5Power supply: DC24V | Input / communication: 16-point preset (PNP switch out) | Monitor output: None
ITV2090-602S5Power supply: DC24V | Input / communication: 10-bit digital input | Monitor output: None
ITV2090-CC2SPower supply: DC24V | Input / communication: CC-Link | Monitor output: None
ITV2090-DE2SPower supply: DC24V | Input / communication: DeviceNet | Monitor output: None
ITV2090-PR2SPower supply: DC24V | Input / communication: PROFIBUS DP | Monitor output: None
ITV2090-RC2SPower supply: DC24V | Input / communication: RS-232C | Monitor output: None
ITV2090-IL2SPower supply: DC24V | Input / communication: IO-Link | Monitor output: None
