SMC JAS-SML/SCL Thin Low Speed Controller with Scale (Elbow)

SMC JAS-SML/SCL Thin Low Speed Controller with Scale (Elbow)

SMC JAS-SML/SCL series thin compact elbow low speed controller with one-touch fitting and scale window, for cylinder speeds of 1-50 mm/s (M) or 50-150 mm/s (C).

Key features

  • Low profile elbow body: height reduced by up to 20.8 mm, for mounting directly on cylinder ports
  • Low speed control: SML 1-50 mm/s, SCL 50-150 mm/s
  • Scale window with vernier, 1/4-turn setting (32 divisions M3/M5/10-32UNF, 40 divisions 1/8)
  • Stud position right (A) or left (B); meter-out grey handle, meter-in light blue handle
  • Ports M3, M5 and R1/8 (with or without sealant); 10-32UNF, NPT1/8 and G1/8 packing seal also offered

Specifications

Fluid Air
Proof pressure 1.05 MPa
Max. operating pressure 0.7 MPa
Min. operating pressure 0.05 MPa
Ambient and fluid temperature -5 to 60°C (no freezing)
Applicable tubing Nylon, soft nylon, polyurethane, FEP, PFA
Type Elbow
Source SMC Korea catalog CAT.KS20-296A (SMCKR_JAS-SML_JAS-SCL.pdf), PDF p. 1-7
JAS-SMLEA04-01 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Right (A) | Port: R1/8 | Tube OD: ø4 mm | Seal: No sealant
JAS-SMLEA04-01S Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Right (A) | Port: R1/8 | Tube OD: ø4 mm | Seal: Sealant (S)
JAS-SMLEB04-01 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Left (B) | Port: R1/8 | Tube OD: ø4 mm | Seal: No sealant
JAS-SMLEB04-01S Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Left (B) | Port: R1/8 | Tube OD: ø4 mm | Seal: Sealant (S)
JAS-SMLSA04-01 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Right (A) | Port: R1/8 | Tube OD: ø4 mm | Seal: No sealant
JAS-SMLSA04-01S Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Right (A) | Port: R1/8 | Tube OD: ø4 mm | Seal: Sealant (S)
JAS-SMLSB04-01 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Left (B) | Port: R1/8 | Tube OD: ø4 mm | Seal: No sealant
JAS-SMLSB04-01S Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Left (B) | Port: R1/8 | Tube OD: ø4 mm | Seal: Sealant (S)
JAS-SCLEA04-01 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Right (A) | Port: R1/8 | Tube OD: ø4 mm | Seal: No sealant
JAS-SCLEA04-01S Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Right (A) | Port: R1/8 | Tube OD: ø4 mm | Seal: Sealant (S)
JAS-SCLEB04-01 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Left (B) | Port: R1/8 | Tube OD: ø4 mm | Seal: No sealant
JAS-SCLEB04-01S Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Left (B) | Port: R1/8 | Tube OD: ø4 mm | Seal: Sealant (S)
JAS-SCLSA04-01 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Right (A) | Port: R1/8 | Tube OD: ø4 mm | Seal: No sealant
JAS-SCLSA04-01S Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Right (A) | Port: R1/8 | Tube OD: ø4 mm | Seal: Sealant (S)
JAS-SCLSB04-01 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Left (B) | Port: R1/8 | Tube OD: ø4 mm | Seal: No sealant
JAS-SCLSB04-01S Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Left (B) | Port: R1/8 | Tube OD: ø4 mm | Seal: Sealant (S)
JAS-SMLEA04-M3 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Right (A) | Port: M3x0.5 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SMLEB04-M3 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Left (B) | Port: M3x0.5 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SMLSA04-M3 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Right (A) | Port: M3x0.5 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SMLSB04-M3 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Left (B) | Port: M3x0.5 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SCLEA04-M3 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Right (A) | Port: M3x0.5 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SCLEB04-M3 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Left (B) | Port: M3x0.5 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SCLSA04-M3 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Right (A) | Port: M3x0.5 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SCLSB04-M3 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Left (B) | Port: M3x0.5 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SMLEA04-M5 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Right (A) | Port: M5x0.8 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SMLEB04-M5 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Left (B) | Port: M5x0.8 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SMLSA04-M5 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Right (A) | Port: M5x0.8 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SMLSB04-M5 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Left (B) | Port: M5x0.8 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SCLEA04-M5 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Right (A) | Port: M5x0.8 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SCLEB04-M5 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Left (B) | Port: M5x0.8 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SCLSA04-M5 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Right (A) | Port: M5x0.8 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SCLSB04-M5 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Left (B) | Port: M5x0.8 | Tube OD: ø4 mm | Seal: Gasket seal
JAS-SMLEA06-01 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Right (A) | Port: R1/8 | Tube OD: ø6 mm | Seal: No sealant
JAS-SMLEA06-01S Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Right (A) | Port: R1/8 | Tube OD: ø6 mm | Seal: Sealant (S)
JAS-SMLEB06-01 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Left (B) | Port: R1/8 | Tube OD: ø6 mm | Seal: No sealant
JAS-SMLEB06-01S Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Left (B) | Port: R1/8 | Tube OD: ø6 mm | Seal: Sealant (S)
JAS-SMLSA06-01 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Right (A) | Port: R1/8 | Tube OD: ø6 mm | Seal: No sealant
JAS-SMLSA06-01S Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Right (A) | Port: R1/8 | Tube OD: ø6 mm | Seal: Sealant (S)
JAS-SMLSB06-01 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Left (B) | Port: R1/8 | Tube OD: ø6 mm | Seal: No sealant
JAS-SMLSB06-01S Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Left (B) | Port: R1/8 | Tube OD: ø6 mm | Seal: Sealant (S)
JAS-SCLEA06-01 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Right (A) | Port: R1/8 | Tube OD: ø6 mm | Seal: No sealant
JAS-SCLEA06-01S Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Right (A) | Port: R1/8 | Tube OD: ø6 mm | Seal: Sealant (S)
JAS-SCLEB06-01 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Left (B) | Port: R1/8 | Tube OD: ø6 mm | Seal: No sealant
JAS-SCLEB06-01S Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Left (B) | Port: R1/8 | Tube OD: ø6 mm | Seal: Sealant (S)
JAS-SCLSA06-01 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Right (A) | Port: R1/8 | Tube OD: ø6 mm | Seal: No sealant
JAS-SCLSA06-01S Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Right (A) | Port: R1/8 | Tube OD: ø6 mm | Seal: Sealant (S)
JAS-SCLSB06-01 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Left (B) | Port: R1/8 | Tube OD: ø6 mm | Seal: No sealant
JAS-SCLSB06-01S Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Left (B) | Port: R1/8 | Tube OD: ø6 mm | Seal: Sealant (S)
JAS-SMLEA06-M3 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Right (A) | Port: M3x0.5 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SMLEB06-M3 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Left (B) | Port: M3x0.5 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SMLSA06-M3 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Right (A) | Port: M3x0.5 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SMLSB06-M3 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Left (B) | Port: M3x0.5 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SCLEA06-M3 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Right (A) | Port: M3x0.5 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SCLEB06-M3 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Left (B) | Port: M3x0.5 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SCLSA06-M3 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Right (A) | Port: M3x0.5 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SCLSB06-M3 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Left (B) | Port: M3x0.5 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SMLEA06-M5 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Right (A) | Port: M5x0.8 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SMLEB06-M5 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Left (B) | Port: M5x0.8 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SMLSA06-M5 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Right (A) | Port: M5x0.8 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SMLSB06-M5 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Left (B) | Port: M5x0.8 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SCLEA06-M5 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Right (A) | Port: M5x0.8 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SCLEB06-M5 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Left (B) | Port: M5x0.8 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SCLSA06-M5 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Right (A) | Port: M5x0.8 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SCLSB06-M5 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Left (B) | Port: M5x0.8 | Tube OD: ø6 mm | Seal: Gasket seal
JAS-SMLEA23-M3 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Right (A) | Port: M3x0.5 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SMLEB23-M3 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Left (B) | Port: M3x0.5 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SMLSA23-M3 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Right (A) | Port: M3x0.5 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SMLSB23-M3 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Left (B) | Port: M3x0.5 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SCLEA23-M3 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Right (A) | Port: M3x0.5 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SCLEB23-M3 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Left (B) | Port: M3x0.5 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SCLSA23-M3 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Right (A) | Port: M3x0.5 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SCLSB23-M3 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Left (B) | Port: M3x0.5 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SMLEA23-M5 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Right (A) | Port: M5x0.8 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SMLEB23-M5 Speed range: 1-50 mm/s | Control: Meter-out | Stud position: Left (B) | Port: M5x0.8 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SMLSA23-M5 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Right (A) | Port: M5x0.8 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SMLSB23-M5 Speed range: 1-50 mm/s | Control: Meter-in | Stud position: Left (B) | Port: M5x0.8 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SCLEA23-M5 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Right (A) | Port: M5x0.8 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SCLEB23-M5 Speed range: 50-150 mm/s | Control: Meter-out | Stud position: Left (B) | Port: M5x0.8 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SCLSA23-M5 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Right (A) | Port: M5x0.8 | Tube OD: ø3.2 mm | Seal: Gasket seal
JAS-SCLSB23-M5 Speed range: 50-150 mm/s | Control: Meter-in | Stud position: Left (B) | Port: M5x0.8 | Tube OD: ø3.2 mm | Seal: Gasket seal
