SMC JSP Proportional Flow Control Valve (Air / Water, Size 10/20)

SMC JSP Proportional Flow Control Valve (Air / Water, Size 10/20)

SMC JSP series direct-operated poppet proportional valve that controls air or water flow steplessly in proportion to the coil current, up to 100 L/min (size 10) or 300 L/min (size 20) of air.

Key features

  • One valve replaces several on/off 2-port valves with orifices: flow set steplessly by current (mA) control
  • Repeatability ±3% F.S. or less, sensitivity 2% F.S. or less; power consumption 4 W (JSP10) / 5.6 W (JSP20)
  • Direct piping (Rc1/8, 1/4, 3/8) and base-mounted types, stainless steel or brass body, FKM seals, IP67 (DIN terminal IP65)
  • Water usable with ø1.4 (size 10) and ø2.0 (size 20) orifices; air with all orifices
  • Bracket (-B, direct piping only) ordered as suffix; NPT (N) and G (F) threads available; listed codes cover Rc (R)
  • Requires a current-control driver; consult SMC on controller specification. CE/UKCA, RoHS

Specifications

Valve construction Direct operated poppet, 2-port N.C.
Fluid and temperature Air 0 to 50°C, water 1 to 50°C (no freezing)
Ambient temperature 0 to 50°C
Proof pressure 0.6 MPa
Max. system pressure 1.0 MPa
Max. operating pressure differential 0.35 MPa (size 10), 0.4 MPa (size 20)
Max. flow (air) ø1.4 50, ø2.3 100, ø2.0 125, ø3.2 300 L/min
Max. flow (water) ø1.4 1.5 L/min, ø2.0 3 L/min
Rated current Size 10: 200 mA/DC24V, 400 mA/DC12V; size 20: 260/520 mA
Leakage 1 cm³/min (ANR) or less
Mounting orientation Unrestricted (solenoid upward recommended)
Source SMC Korea catalog CAT.KS70-63A (SMCKR_JSP.pdf), p. 3-4 (PDF p. 4-5)
JSP11-SF101R-5G Size: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: Grommet
JSP11-SF101R-5DS Size: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP11-SF101R-5DN Size: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP11-SF101R-6G Size: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: Grommet
JSP11-SF101R-6DS Size: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP11-SF101R-6DN Size: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP11-SF201R-5G Size: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: Grommet
JSP11-SF201R-5DS Size: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP11-SF201R-5DN Size: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP11-SF201R-6G Size: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: Grommet
JSP11-SF201R-6DS Size: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP11-SF201R-6DN Size: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP13-SF100-5G Size: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP13-SF100-5DS Size: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP13-SF100-5DN Size: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP13-SF100-6G Size: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP13-SF100-6DS Size: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP13-SF100-6DN Size: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP13-SF200-5G Size: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP13-SF200-5DS Size: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP13-SF200-5DN Size: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP13-SF200-6G Size: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP13-SF200-6DS Size: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP13-SF200-6DN Size: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP11-CF101R-5G Size: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: Grommet
JSP11-CF101R-5DS Size: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP11-CF101R-5DN Size: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP11-CF101R-6G Size: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: Grommet
JSP11-CF101R-6DS Size: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP11-CF101R-6DN Size: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP11-CF201R-5G Size: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: Grommet
JSP11-CF201R-5DS Size: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP11-CF201R-5DN Size: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP11-CF201R-6G Size: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: Grommet
JSP11-CF201R-6DS Size: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP11-CF201R-6DN Size: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP13-CF100-5G Size: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP13-CF100-5DS Size: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP13-CF100-5DN Size: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP13-CF100-6G Size: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP13-CF100-6DS Size: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP13-CF100-6DN Size: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP13-CF200-5G Size: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP13-CF200-5DS Size: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP13-CF200-5DN Size: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP13-CF200-6G Size: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP13-CF200-6DS Size: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP13-CF200-6DN Size: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-SF202R-5G Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Grommet
JSP21-SF202R-5CS Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-SF202R-5DS Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF202R-5DN Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-SF202R-6G Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Grommet
JSP21-SF202R-6CS Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-SF202R-6DS Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF202R-6DN Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-SF203R-5G Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Grommet
JSP21-SF203R-5CS Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-SF203R-5DS Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF203R-5DN Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-SF203R-6G Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Grommet
JSP21-SF203R-6CS Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-SF203R-6DS Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF203R-6DN Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-SF302R-5G Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Grommet
JSP21-SF302R-5CS Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-SF302R-5DS Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF302R-5DN Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-SF302R-6G Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Grommet
JSP21-SF302R-6CS Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-SF302R-6DS Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF302R-6DN Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-SF303R-5G Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Grommet
JSP21-SF303R-5CS Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-SF303R-5DS Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF303R-5DN Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-SF303R-6G Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Grommet
JSP21-SF303R-6CS Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-SF303R-6DS Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF303R-6DN Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP23-SF200-5G Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP23-SF200-5CS Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP23-SF200-5DS Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP23-SF200-5DN Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP23-SF200-6G Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP23-SF200-6CS Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP23-SF200-6DS Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP23-SF200-6DN Size: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP23-SF300-5G Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP23-SF300-5CS Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP23-SF300-5DS Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP23-SF300-5DN Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP23-SF300-6G Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP23-SF300-6CS Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP23-SF300-6DS Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP23-SF300-6DN Size: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-CF202R-5G Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Grommet
JSP21-CF202R-5CS Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-CF202R-5DS Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF202R-5DN Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-CF202R-6G Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Grommet
JSP21-CF202R-6CS Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-CF202R-6DS Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF202R-6DN Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-CF203R-5G Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Grommet
JSP21-CF203R-5CS Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-CF203R-5DS Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF203R-5DN Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-CF203R-6G Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Grommet
JSP21-CF203R-6CS Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-CF203R-6DS Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF203R-6DN Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-CF302R-5G Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Grommet
JSP21-CF302R-5CS Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-CF302R-5DS Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF302R-5DN Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-CF302R-6G Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Grommet
JSP21-CF302R-6CS Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-CF302R-6DS Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF302R-6DN Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-CF303R-5G Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Grommet
JSP21-CF303R-5CS Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-CF303R-5DS Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF303R-5DN Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-CF303R-6G Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Grommet
JSP21-CF303R-6CS Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-CF303R-6DS Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF303R-6DN Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP23-CF200-5G Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP23-CF200-5CS Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP23-CF200-5DS Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP23-CF200-5DN Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP23-CF200-6G Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP23-CF200-6CS Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP23-CF200-6DS Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP23-CF200-6DN Size: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP23-CF300-5G Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP23-CF300-5CS Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP23-CF300-5DS Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP23-CF300-5DN Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP23-CF300-6G Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP23-CF300-6CS Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP23-CF300-6DS Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP23-CF300-6DN Size: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
2-Port ValvesSMC
144 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC JSP Proportional Flow Control Valve (Air / Water, Size 10/20)

Brand SMC·2-Port Valves

Available part numbers (144)

JSP11-SF101R-5G, JSP11-SF101R-5DS, JSP11-SF101R-5DN, JSP11-SF101R-6G, JSP11-SF101R-6DS, JSP11-SF101R-6DN, JSP11-SF201R-5G, JSP11-SF201R-5DS, JSP11-SF201R-5DN, JSP11-SF201R-6G + 134 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
JSP11-SF101R-5GSize: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: Grommet
JSP11-SF101R-5DSSize: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP11-SF101R-5DNSize: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP11-SF101R-6GSize: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: Grommet
JSP11-SF101R-6DSSize: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP11-SF101R-6DNSize: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP11-SF201R-5GSize: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: Grommet
JSP11-SF201R-5DSSize: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP11-SF201R-5DNSize: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP11-SF201R-6GSize: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: Grommet
JSP11-SF201R-6DSSize: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP11-SF201R-6DNSize: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP13-SF100-5GSize: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP13-SF100-5DSSize: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP13-SF100-5DNSize: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP13-SF100-6GSize: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP13-SF100-6DSSize: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP13-SF100-6DNSize: JSP10 | Body: Stainless steel | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP13-SF200-5GSize: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP13-SF200-5DSSize: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP13-SF200-5DNSize: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP13-SF200-6GSize: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP13-SF200-6DSSize: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP13-SF200-6DNSize: JSP10 | Body: Stainless steel | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP11-CF101R-5GSize: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: Grommet
JSP11-CF101R-5DSSize: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP11-CF101R-5DNSize: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP11-CF101R-6GSize: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: Grommet
JSP11-CF101R-6DSSize: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP11-CF101R-6DNSize: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP11-CF201R-5GSize: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: Grommet
JSP11-CF201R-5DSSize: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP11-CF201R-5DNSize: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP11-CF201R-6GSize: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: Grommet
JSP11-CF201R-6DSSize: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP11-CF201R-6DNSize: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Rc1/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP13-CF100-5GSize: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP13-CF100-5DSSize: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP13-CF100-5DNSize: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP13-CF100-6GSize: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP13-CF100-6DSSize: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP13-CF100-6DNSize: JSP10 | Body: Brass | Orifice: ø1.4 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP13-CF200-5GSize: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP13-CF200-5DSSize: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP13-CF200-5DNSize: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP13-CF200-6GSize: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP13-CF200-6DSSize: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP13-CF200-6DNSize: JSP10 | Body: Brass | Orifice: ø2.3 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-SF202R-5GSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Grommet
JSP21-SF202R-5CSSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-SF202R-5DSSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF202R-5DNSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-SF202R-6GSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Grommet
JSP21-SF202R-6CSSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-SF202R-6DSSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF202R-6DNSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-SF203R-5GSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Grommet
JSP21-SF203R-5CSSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-SF203R-5DSSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF203R-5DNSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-SF203R-6GSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Grommet
JSP21-SF203R-6CSSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-SF203R-6DSSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF203R-6DNSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-SF302R-5GSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Grommet
JSP21-SF302R-5CSSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-SF302R-5DSSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF302R-5DNSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-SF302R-6GSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Grommet
JSP21-SF302R-6CSSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-SF302R-6DSSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF302R-6DNSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-SF303R-5GSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Grommet
JSP21-SF303R-5CSSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-SF303R-5DSSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF303R-5DNSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-SF303R-6GSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Grommet
JSP21-SF303R-6CSSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-SF303R-6DSSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-SF303R-6DNSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP23-SF200-5GSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP23-SF200-5CSSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP23-SF200-5DSSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP23-SF200-5DNSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP23-SF200-6GSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP23-SF200-6CSSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP23-SF200-6DSSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP23-SF200-6DNSize: JSP20 | Body: Stainless steel | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP23-SF300-5GSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP23-SF300-5CSSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP23-SF300-5DSSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP23-SF300-5DNSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP23-SF300-6GSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP23-SF300-6CSSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP23-SF300-6DSSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP23-SF300-6DNSize: JSP20 | Body: Stainless steel | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-CF202R-5GSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Grommet
JSP21-CF202R-5CSSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-CF202R-5DSSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF202R-5DNSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-CF202R-6GSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Grommet
JSP21-CF202R-6CSSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-CF202R-6DSSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF202R-6DNSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-CF203R-5GSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Grommet
JSP21-CF203R-5CSSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-CF203R-5DSSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF203R-5DNSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-CF203R-6GSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Grommet
JSP21-CF203R-6CSSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-CF203R-6DSSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF203R-6DNSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-CF302R-5GSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Grommet
JSP21-CF302R-5CSSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-CF302R-5DSSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF302R-5DNSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-CF302R-6GSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Grommet
JSP21-CF302R-6CSSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-CF302R-6DSSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF302R-6DNSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc1/4 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP21-CF303R-5GSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Grommet
JSP21-CF303R-5CSSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP21-CF303R-5DSSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF303R-5DNSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP21-CF303R-6GSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Grommet
JSP21-CF303R-6CSSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP21-CF303R-6DSSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP21-CF303R-6DNSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Rc3/8 | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP23-CF200-5GSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP23-CF200-5CSSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP23-CF200-5DSSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP23-CF200-5DNSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP23-CF200-6GSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP23-CF200-6CSSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP23-CF200-6DSSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP23-CF200-6DNSize: JSP20 | Body: Brass | Orifice: ø2.0 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)
JSP23-CF300-5GSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Grommet
JSP23-CF300-5CSSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: Conduit (surge suppr.)
JSP23-CF300-5DSSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN terminal (surge suppr.)
JSP23-CF300-5DNSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC24V | Electrical entry: DIN, no connector (surge)
JSP23-CF300-6GSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Grommet
JSP23-CF300-6CSSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: Conduit (surge suppr.)
JSP23-CF300-6DSSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN terminal (surge suppr.)
JSP23-CF300-6DNSize: JSP20 | Body: Brass | Orifice: ø3.2 mm | Port: Base mounted (sub-plate) | Voltage: DC12V | Electrical entry: DIN, no connector (surge)

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
