SMC JSXM Modular Mounting 2-Port Solenoid Valve (Size 20-40)

SMC JSXM Modular Mounting 2-Port Solenoid Valve (Size 20-40)

SMC JSXM series modular mounting direct operated 2-port solenoid valve for air, N.C., with aluminum body that connects to AC-D modular F.R.L. units via spacers.

Key features

  • Modular connection to AC20-D to AC40-D air combinations with Y200-D to Y400-D spacers
  • Sizes 20/30/40, orifice ø3.2 or ø4.0 mm, ports 1/8 to 1/2; aluminum body, NBR or FKM seal
  • Coil upward (standard) or downward (U); blow port on bottom/top (standard) or front (-F suffix)
  • Lead wire: grommet G (DC only), surge-protected grommet GS, conduit CS, DIN terminal DS/DZ/DN, M12 connector WN; listed codes use G for DC and GS for AC
  • Options as suffixes: NPT/G thread (N/F), front blow port (-F), oil-free (-D)

Specifications

Valve structure Direct operated poppet, N.C.
Fluid Air, -10 to 60°C (dew point -10°C or less)
Body / seal Aluminum / NBR, FKM
Max. operating pressure differential 0.7 MPa (size 20), 1.0 MPa (size 30/40)
Proof pressure 2 MPa
Max. system pressure 1 MPa
Ambient temperature -20 to 60°C
Enclosure IP67 (DIN terminal IP65)
Rated voltage AC 24, 48, 100, 110, 120, 200, 220, 230, 240V; DC 12, 24V (listed: DC24V, AC100/200/220V)
Power consumption AC 8/9.5 VA, DC 6/8 W
Source SMC Korea catalog JSX/JSX Series (SMCKR_JSX.pdf), p. 75-81 (PDF p. 76-82)
JSXM21-AN301R-5G Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM21-AN301R-1GS Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM21-AN301R-2GS Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM21-AN301R-4GS Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM21-AN301R-5G-U Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM21-AN301R-1GS-U Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM21-AN301R-2GS-U Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM21-AN301R-4GS-U Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM21-AN302R-5G Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM21-AN302R-1GS Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM21-AN302R-2GS Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM21-AN302R-4GS Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM21-AN302R-5G-U Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM21-AN302R-1GS-U Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM21-AN302R-2GS-U Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM21-AN302R-4GS-U Size: 20 | Seal: NBR | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM21-AF301R-5G Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM21-AF301R-1GS Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM21-AF301R-2GS Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM21-AF301R-4GS Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM21-AF301R-5G-U Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM21-AF301R-1GS-U Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM21-AF301R-2GS-U Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM21-AF301R-4GS-U Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/8 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM21-AF302R-5G Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM21-AF302R-1GS Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM21-AF302R-2GS Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM21-AF302R-4GS Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM21-AF302R-5G-U Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM21-AF302R-1GS-U Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM21-AF302R-2GS-U Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM21-AF302R-4GS-U Size: 20 | Seal: FKM | Orifice / port: ø3.2 mm, Rc1/4 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM31-AN402R-5G Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM31-AN402R-1GS Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM31-AN402R-2GS Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM31-AN402R-4GS Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM31-AN402R-5G-U Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM31-AN402R-1GS-U Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM31-AN402R-2GS-U Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM31-AN402R-4GS-U Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM31-AN403R-5G Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM31-AN403R-1GS Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM31-AN403R-2GS Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM31-AN403R-4GS Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM31-AN403R-5G-U Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM31-AN403R-1GS-U Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM31-AN403R-2GS-U Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM31-AN403R-4GS-U Size: 30 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM31-AF402R-5G Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM31-AF402R-1GS Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM31-AF402R-2GS Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM31-AF402R-4GS Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM31-AF402R-5G-U Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM31-AF402R-1GS-U Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM31-AF402R-2GS-U Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM31-AF402R-4GS-U Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM31-AF403R-5G Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM31-AF403R-1GS Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM31-AF403R-2GS Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM31-AF403R-4GS Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM31-AF403R-5G-U Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM31-AF403R-1GS-U Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM31-AF403R-2GS-U Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM31-AF403R-4GS-U Size: 30 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM41-AN402R-5G Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM41-AN402R-1GS Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM41-AN402R-2GS Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM41-AN402R-4GS Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM41-AN402R-5G-U Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM41-AN402R-1GS-U Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM41-AN402R-2GS-U Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM41-AN402R-4GS-U Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM41-AN403R-5G Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM41-AN403R-1GS Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM41-AN403R-2GS Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM41-AN403R-4GS Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM41-AN403R-5G-U Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM41-AN403R-1GS-U Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM41-AN403R-2GS-U Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM41-AN403R-4GS-U Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM41-AN404R-5G Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM41-AN404R-1GS Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM41-AN404R-2GS Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM41-AN404R-4GS Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM41-AN404R-5G-U Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM41-AN404R-1GS-U Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM41-AN404R-2GS-U Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM41-AN404R-4GS-U Size: 40 | Seal: NBR | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM41-AF402R-5G Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM41-AF402R-1GS Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM41-AF402R-2GS Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM41-AF402R-4GS Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM41-AF402R-5G-U Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM41-AF402R-1GS-U Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM41-AF402R-2GS-U Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM41-AF402R-4GS-U Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/4 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM41-AF403R-5G Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM41-AF403R-1GS Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM41-AF403R-2GS Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM41-AF403R-4GS Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM41-AF403R-5G-U Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM41-AF403R-1GS-U Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM41-AF403R-2GS-U Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM41-AF403R-4GS-U Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc3/8 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM41-AF404R-5G Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Upward | Coil: DC24V, grommet (G)
JSXM41-AF404R-1GS Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Upward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM41-AF404R-2GS Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Upward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM41-AF404R-4GS Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Upward | Coil: AC220V, grommet w/ surge circuit (GS)
JSXM41-AF404R-5G-U Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Downward | Coil: DC24V, grommet (G)
JSXM41-AF404R-1GS-U Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Downward | Coil: AC100V, grommet w/ surge circuit (GS)
JSXM41-AF404R-2GS-U Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Downward | Coil: AC200V, grommet w/ surge circuit (GS)
JSXM41-AF404R-4GS-U Size: 40 | Seal: FKM | Orifice / port: ø4.0 mm, Rc1/2 | Coil direction: Downward | Coil: AC220V, grommet w/ surge circuit (GS)
