SMC LMV Mixing Valve, LMH Magnet Holder, LMD Distributor (for LMU)

SMC LMV Mixing Valve, LMH Magnet Holder, LMD Distributor (for LMU)

SMC LMV mixing valves, LMH magnet holders and LMD distributors used with the LMU mist spray unit to mix, aim and branch oil and air for intermittent mist spraying.

Key features

  • LMV mixing valve: oil and air needles adjust oil and air volume and the nozzle sprays oil mist; flexible or copper nozzle tube, 200 to 350 mm
  • LMV1x0 includes an air blow circuit (for LMU100); LMV2x0 is mist only (for LMU200)
  • LMH magnet holder mounts a mixing valve freely on steel machine parts
  • LMD distributor branches oil and air from the unit to 1 to 6 mixing valves (Rc1/8 ports)

Specifications

Inlet air pressure (LMV) 0.3 MPa max.
Ambient and fluid temperature (LMV) 5 to 60°C
Tube connection AIR T0604 (ø6), OIL T0425 (ø4), AIR BLOW T0806 (ø8)
LMD ports Rc1/8
Applicable unit LMU100 / LMU200 mist spray unit
Source SMC Korea catalog LMU100/200 (SMCKR_LMU.pdf), p. 1333-1334 (PDF p. 4-5)
LMV110-20 Item: LMV mixing valve | Air blow: With air blow | Nozzle tube: Flexible tube | Size or length: L = 200 mm
LMV110-25 Item: LMV mixing valve | Air blow: With air blow | Nozzle tube: Flexible tube | Size or length: L = 250 mm
LMV110-30 Item: LMV mixing valve | Air blow: With air blow | Nozzle tube: Flexible tube | Size or length: L = 300 mm
LMV110-35 Item: LMV mixing valve | Air blow: With air blow | Nozzle tube: Flexible tube | Size or length: L = 350 mm
LMV120-20 Item: LMV mixing valve | Air blow: With air blow | Nozzle tube: Copper tube | Size or length: L = 200 mm
LMV120-25 Item: LMV mixing valve | Air blow: With air blow | Nozzle tube: Copper tube | Size or length: L = 250 mm
LMV120-30 Item: LMV mixing valve | Air blow: With air blow | Nozzle tube: Copper tube | Size or length: L = 300 mm
LMV120-35 Item: LMV mixing valve | Air blow: With air blow | Nozzle tube: Copper tube | Size or length: L = 350 mm
LMV210-20 Item: LMV mixing valve | Air blow: Without air blow | Nozzle tube: Flexible tube | Size or length: L = 200 mm
LMV210-25 Item: LMV mixing valve | Air blow: Without air blow | Nozzle tube: Flexible tube | Size or length: L = 250 mm
LMV210-30 Item: LMV mixing valve | Air blow: Without air blow | Nozzle tube: Flexible tube | Size or length: L = 300 mm
LMV210-35 Item: LMV mixing valve | Air blow: Without air blow | Nozzle tube: Flexible tube | Size or length: L = 350 mm
LMV220-20 Item: LMV mixing valve | Air blow: Without air blow | Nozzle tube: Copper tube | Size or length: L = 200 mm
LMV220-25 Item: LMV mixing valve | Air blow: Without air blow | Nozzle tube: Copper tube | Size or length: L = 250 mm
LMV220-30 Item: LMV mixing valve | Air blow: Without air blow | Nozzle tube: Copper tube | Size or length: L = 300 mm
LMV220-35 Item: LMV mixing valve | Air blow: Without air blow | Nozzle tube: Copper tube | Size or length: L = 350 mm
LMH10 Item: LMH magnet holder | Air blow: With air blow | Nozzle tube: For LMV1x0 | Size or length: -
LMH20 Item: LMH magnet holder | Air blow: Without air blow | Nozzle tube: For LMV2x0 | Size or length: -
LMD1-1 Item: LMD distributor | Air blow: With air blow | Nozzle tube: - | Size or length: 1 mixing valve
LMD1-2 Item: LMD distributor | Air blow: With air blow | Nozzle tube: - | Size or length: 2 mixing valves
LMD1-3 Item: LMD distributor | Air blow: With air blow | Nozzle tube: - | Size or length: 3 mixing valves
LMD1-4 Item: LMD distributor | Air blow: With air blow | Nozzle tube: - | Size or length: 4 mixing valves
LMD1-5 Item: LMD distributor | Air blow: With air blow | Nozzle tube: - | Size or length: 5 mixing valves
LMD1-6 Item: LMD distributor | Air blow: With air blow | Nozzle tube: - | Size or length: 6 mixing valves
LMD2-1 Item: LMD distributor | Air blow: Without air blow | Nozzle tube: - | Size or length: 1 mixing valve
LMD2-2 Item: LMD distributor | Air blow: Without air blow | Nozzle tube: - | Size or length: 2 mixing valves
LMD2-3 Item: LMD distributor | Air blow: Without air blow | Nozzle tube: - | Size or length: 3 mixing valves
LMD2-4 Item: LMD distributor | Air blow: Without air blow | Nozzle tube: - | Size or length: 4 mixing valves
LMD2-5 Item: LMD distributor | Air blow: Without air blow | Nozzle tube: - | Size or length: 5 mixing valves
LMD2-6 Item: LMD distributor | Air blow: Without air blow | Nozzle tube: - | Size or length: 6 mixing valves
