SMC LVDH-F/FN Compact Manual Chemical Valve (LQ1, LQ3, Tube)

SMC LVDH-F/FN Compact Manual Chemical Valve (LQ1, LQ3, Tube)

SMC LVDH-F/FN series compact manually operated chemical valve with New PFA body and PVDF actuator, LQ1 (V), LQ3 flare (Z) or integral tube (T) connection.

Key features

  • Hand-wheel operated diaphragm valve: 6-7 turns (class 2), 3-4 turns (class 3-4), 5-6 turns (class 5-6) full open to full close
  • New PFA body, PTFE diaphragm, PVDF actuator; FKM (F) or EPDM (FN) buffer and packing
  • LQ1 insert-bushing fitting with reducer tube sizes, LQ3 flare fitting or integral tube
  • Compact body sharing dimensions with the LVD-F/FN air-operated valves

Specifications

Fluid Deionized water, chemicals (see compatibility list)
Proof pressure 1 MPa
Operating pressure (A to B) 0 to 0.5 MPa
Valve leakage 0 cm3/min (water pressure)
Flow Cv (class 2/3/4/5/6) 0.35 / 1.3 / 1.9 / 5 / 8
Fluid temperature 0 to 100 C
Ambient temperature 0 to 60 C
Operation Manual handle
Source SMC Korea catalog LVD Series (SMCKR_LVD.pdf), p. 760-765 (PDF p. 24-29)
LVDH20-V03-F Body class: 2 (ø4 orifice) | Connection: LQ1 fitting | Tube size: 3x2 mm / 1/8 in | Material: FKM buffer/packing
LVDH20-V03-FN Body class: 2 (ø4 orifice) | Connection: LQ1 fitting | Tube size: 3x2 mm / 1/8 in | Material: EPDM buffer/packing
LVDH20-V04-F Body class: 2 (ø4 orifice) | Connection: LQ1 fitting | Tube size: 4x3 mm | Material: FKM buffer/packing
LVDH20-V04-FN Body class: 2 (ø4 orifice) | Connection: LQ1 fitting | Tube size: 4x3 mm | Material: EPDM buffer/packing
LVDH20-V06-F Body class: 2 (ø4 orifice) | Connection: LQ1 fitting | Tube size: 6x4 mm | Material: FKM buffer/packing
LVDH20-V06-FN Body class: 2 (ø4 orifice) | Connection: LQ1 fitting | Tube size: 6x4 mm | Material: EPDM buffer/packing
LVDH20-V05-F Body class: 2 (ø4 orifice) | Connection: LQ1 fitting | Tube size: 3/16 in | Material: FKM buffer/packing
LVDH20-V05-FN Body class: 2 (ø4 orifice) | Connection: LQ1 fitting | Tube size: 3/16 in | Material: EPDM buffer/packing
LVDH20-V07-F Body class: 2 (ø4 orifice) | Connection: LQ1 fitting | Tube size: 1/4 in | Material: FKM buffer/packing
LVDH20-V07-FN Body class: 2 (ø4 orifice) | Connection: LQ1 fitting | Tube size: 1/4 in | Material: EPDM buffer/packing
LVDH30-V06-F Body class: 3 (ø8 orifice) | Connection: LQ1 fitting | Tube size: 6x4 mm | Material: FKM buffer/packing
LVDH30-V06-FN Body class: 3 (ø8 orifice) | Connection: LQ1 fitting | Tube size: 6x4 mm | Material: EPDM buffer/packing
LVDH30-V08-F Body class: 3 (ø8 orifice) | Connection: LQ1 fitting | Tube size: 8x6 mm | Material: FKM buffer/packing
LVDH30-V08-FN Body class: 3 (ø8 orifice) | Connection: LQ1 fitting | Tube size: 8x6 mm | Material: EPDM buffer/packing
LVDH30-V10-F Body class: 3 (ø8 orifice) | Connection: LQ1 fitting | Tube size: 10x8 mm | Material: FKM buffer/packing
LVDH30-V10-FN Body class: 3 (ø8 orifice) | Connection: LQ1 fitting | Tube size: 10x8 mm | Material: EPDM buffer/packing
LVDH30-V07-F Body class: 3 (ø8 orifice) | Connection: LQ1 fitting | Tube size: 1/4 in | Material: FKM buffer/packing
LVDH30-V07-FN Body class: 3 (ø8 orifice) | Connection: LQ1 fitting | Tube size: 1/4 in | Material: EPDM buffer/packing
LVDH30-V11-F Body class: 3 (ø8 orifice) | Connection: LQ1 fitting | Tube size: 3/8 in | Material: FKM buffer/packing
LVDH30-V11-FN Body class: 3 (ø8 orifice) | Connection: LQ1 fitting | Tube size: 3/8 in | Material: EPDM buffer/packing
LVDH40-V10-F Body class: 4 (ø10 orifice) | Connection: LQ1 fitting | Tube size: 10x8 mm | Material: FKM buffer/packing
LVDH40-V10-FN Body class: 4 (ø10 orifice) | Connection: LQ1 fitting | Tube size: 10x8 mm | Material: EPDM buffer/packing
LVDH40-V12-F Body class: 4 (ø10 orifice) | Connection: LQ1 fitting | Tube size: 12x10 mm | Material: FKM buffer/packing
LVDH40-V12-FN Body class: 4 (ø10 orifice) | Connection: LQ1 fitting | Tube size: 12x10 mm | Material: EPDM buffer/packing
LVDH40-V11-F Body class: 4 (ø10 orifice) | Connection: LQ1 fitting | Tube size: 3/8 in | Material: FKM buffer/packing
LVDH40-V11-FN Body class: 4 (ø10 orifice) | Connection: LQ1 fitting | Tube size: 3/8 in | Material: EPDM buffer/packing
LVDH40-V13-F Body class: 4 (ø10 orifice) | Connection: LQ1 fitting | Tube size: 1/2 in | Material: FKM buffer/packing
LVDH40-V13-FN Body class: 4 (ø10 orifice) | Connection: LQ1 fitting | Tube size: 1/2 in | Material: EPDM buffer/packing
LVDH50-V12-F Body class: 5 (ø16 orifice) | Connection: LQ1 fitting | Tube size: 12x10 mm | Material: FKM buffer/packing
LVDH50-V12-FN Body class: 5 (ø16 orifice) | Connection: LQ1 fitting | Tube size: 12x10 mm | Material: EPDM buffer/packing
LVDH50-V19-F Body class: 5 (ø16 orifice) | Connection: LQ1 fitting | Tube size: 19x16 mm / 3/4 in | Material: FKM buffer/packing
LVDH50-V19-FN Body class: 5 (ø16 orifice) | Connection: LQ1 fitting | Tube size: 19x16 mm / 3/4 in | Material: EPDM buffer/packing
LVDH50-V13-F Body class: 5 (ø16 orifice) | Connection: LQ1 fitting | Tube size: 1/2 in | Material: FKM buffer/packing
LVDH50-V13-FN Body class: 5 (ø16 orifice) | Connection: LQ1 fitting | Tube size: 1/2 in | Material: EPDM buffer/packing
LVDH60-V19-F Body class: 6 (ø22 orifice) | Connection: LQ1 fitting | Tube size: 19x16 mm / 3/4 in | Material: FKM buffer/packing
LVDH60-V19-FN Body class: 6 (ø22 orifice) | Connection: LQ1 fitting | Tube size: 19x16 mm / 3/4 in | Material: EPDM buffer/packing
LVDH60-V25-F Body class: 6 (ø22 orifice) | Connection: LQ1 fitting | Tube size: 25x22 mm / 1 in | Material: FKM buffer/packing
LVDH60-V25-FN Body class: 6 (ø22 orifice) | Connection: LQ1 fitting | Tube size: 25x22 mm / 1 in | Material: EPDM buffer/packing
LVDH20-Z06-F Body class: 2 (ø4 orifice) | Connection: LQ3 flare fitting | Tube size: 6x4 mm | Material: FKM buffer/packing
LVDH20-Z06-FN Body class: 2 (ø4 orifice) | Connection: LQ3 flare fitting | Tube size: 6x4 mm | Material: EPDM buffer/packing
LVDH20-Z07-F Body class: 2 (ø4 orifice) | Connection: LQ3 flare fitting | Tube size: 1/4 in | Material: FKM buffer/packing
LVDH20-Z07-FN Body class: 2 (ø4 orifice) | Connection: LQ3 flare fitting | Tube size: 1/4 in | Material: EPDM buffer/packing
LVDH30-Z08-F Body class: 3 (ø8 orifice) | Connection: LQ3 flare fitting | Tube size: 8x6 mm | Material: FKM buffer/packing
LVDH30-Z08-FN Body class: 3 (ø8 orifice) | Connection: LQ3 flare fitting | Tube size: 8x6 mm | Material: EPDM buffer/packing
LVDH30-Z10-F Body class: 3 (ø8 orifice) | Connection: LQ3 flare fitting | Tube size: 10x8 mm | Material: FKM buffer/packing
LVDH30-Z10-FN Body class: 3 (ø8 orifice) | Connection: LQ3 flare fitting | Tube size: 10x8 mm | Material: EPDM buffer/packing
LVDH30-Z11-F Body class: 3 (ø8 orifice) | Connection: LQ3 flare fitting | Tube size: 3/8 in | Material: FKM buffer/packing
LVDH30-Z11-FN Body class: 3 (ø8 orifice) | Connection: LQ3 flare fitting | Tube size: 3/8 in | Material: EPDM buffer/packing
LVDH40-Z12-F Body class: 4 (ø10 orifice) | Connection: LQ3 flare fitting | Tube size: 12x10 mm | Material: FKM buffer/packing
LVDH40-Z12-FN Body class: 4 (ø10 orifice) | Connection: LQ3 flare fitting | Tube size: 12x10 mm | Material: EPDM buffer/packing
LVDH40-Z13-F Body class: 4 (ø10 orifice) | Connection: LQ3 flare fitting | Tube size: 1/2 in | Material: FKM buffer/packing
LVDH40-Z13-FN Body class: 4 (ø10 orifice) | Connection: LQ3 flare fitting | Tube size: 1/2 in | Material: EPDM buffer/packing
LVDH50-Z19-F Body class: 5 (ø16 orifice) | Connection: LQ3 flare fitting | Tube size: 19x16 mm / 3/4 in | Material: FKM buffer/packing
LVDH50-Z19-FN Body class: 5 (ø16 orifice) | Connection: LQ3 flare fitting | Tube size: 19x16 mm / 3/4 in | Material: EPDM buffer/packing
LVDH60-Z25-F Body class: 6 (ø22 orifice) | Connection: LQ3 flare fitting | Tube size: 25x22 mm / 1 in | Material: FKM buffer/packing
LVDH60-Z25-FN Body class: 6 (ø22 orifice) | Connection: LQ3 flare fitting | Tube size: 25x22 mm / 1 in | Material: EPDM buffer/packing
LVDH20-T06-F Body class: 2 (ø4 orifice) | Connection: Integral tube | Tube size: OD 6 mm | Material: FKM buffer/packing
LVDH20-T06-FN Body class: 2 (ø4 orifice) | Connection: Integral tube | Tube size: OD 6 mm | Material: EPDM buffer/packing
LVDH20-T07-F Body class: 2 (ø4 orifice) | Connection: Integral tube | Tube size: OD 1/4 in | Material: FKM buffer/packing
LVDH20-T07-FN Body class: 2 (ø4 orifice) | Connection: Integral tube | Tube size: OD 1/4 in | Material: EPDM buffer/packing
LVDH30-T10-F Body class: 3 (ø8 orifice) | Connection: Integral tube | Tube size: OD 10 mm | Material: FKM buffer/packing
LVDH30-T10-FN Body class: 3 (ø8 orifice) | Connection: Integral tube | Tube size: OD 10 mm | Material: EPDM buffer/packing
LVDH30-T11-F Body class: 3 (ø8 orifice) | Connection: Integral tube | Tube size: OD 3/8 in | Material: FKM buffer/packing
LVDH30-T11-FN Body class: 3 (ø8 orifice) | Connection: Integral tube | Tube size: OD 3/8 in | Material: EPDM buffer/packing
LVDH40-T12-F Body class: 4 (ø10 orifice) | Connection: Integral tube | Tube size: OD 12 mm | Material: FKM buffer/packing
LVDH40-T12-FN Body class: 4 (ø10 orifice) | Connection: Integral tube | Tube size: OD 12 mm | Material: EPDM buffer/packing
LVDH40-T13-F Body class: 4 (ø10 orifice) | Connection: Integral tube | Tube size: OD 1/2 in | Material: FKM buffer/packing
LVDH40-T13-FN Body class: 4 (ø10 orifice) | Connection: Integral tube | Tube size: OD 1/2 in | Material: EPDM buffer/packing
LVDH50-T19-F Body class: 5 (ø16 orifice) | Connection: Integral tube | Tube size: OD 19 mm / 3/4 in | Material: FKM buffer/packing
LVDH50-T19-FN Body class: 5 (ø16 orifice) | Connection: Integral tube | Tube size: OD 19 mm / 3/4 in | Material: EPDM buffer/packing
LVDH60-T25-F Body class: 6 (ø22 orifice) | Connection: Integral tube | Tube size: OD 25 mm / 1 in | Material: FKM buffer/packing
LVDH60-T25-FN Body class: 6 (ø22 orifice) | Connection: Integral tube | Tube size: OD 25 mm / 1 in | Material: EPDM buffer/packing
