SMC LVH-M Manual Valve for Organic Solvents (SUS Body)

SMC LVH-M Manual Valve for Organic Solvents (SUS Body)

SMC LVHM series manual 2-port valve for organic solvents with SUS body, available with compression fitting, face seal fitting or tube extension in body classes 2 to 6.

Key features

  • SUS body, ADC actuator and PTFE diaphragm; FKM (AD) or EPDM (ND) packing and buffer
  • Connection by compression fitting (D), face seal fitting (G) or tube extension (T); metric sizes for D and T only
  • Body classes 2 to 6, orifice 4 to 22 mm, tube 6 to 19 mm or 1/4 to 1 in
  • EP-grade wetted surface option (E) as suffix

Specifications

Operation Manual handle
Proof pressure 1 MPa
Operating pressure 0 to 0.5 MPa (A to B)
Fluid temperature 0 to 100°C
Ambient temperature 0 to 60°C
Valve leakage 0 cm3/min (with water)
Flow Kv LVH20M 0.3, 30M 1.4, 40M 2.8, 50M 5.1, 60M 6.8
Source SMC Korea catalog LVC/LVA/LVH Series (SMCKR_LVC_LVA_LVH.pdf), p. 201-204 (PDF p. 50-53)
LVH20M-D06-AD Body class: 2 (orifice 4 mm) | Connection: Compression fitting, ø6 mm | Material: SUS, ADC, PTFE, FKM
LVH20M-D06-ND Body class: 2 (orifice 4 mm) | Connection: Compression fitting, ø6 mm | Material: SUS, ADC, PTFE, EPDM
LVH20M-D07-AD Body class: 2 (orifice 4 mm) | Connection: Compression fitting, 1/4 in | Material: SUS, ADC, PTFE, FKM
LVH20M-D07-ND Body class: 2 (orifice 4 mm) | Connection: Compression fitting, 1/4 in | Material: SUS, ADC, PTFE, EPDM
LVH20M-G07-AD Body class: 2 (orifice 4 mm) | Connection: Face seal fitting, 1/4 in | Material: SUS, ADC, PTFE, FKM
LVH20M-G07-ND Body class: 2 (orifice 4 mm) | Connection: Face seal fitting, 1/4 in | Material: SUS, ADC, PTFE, EPDM
LVH20M-T06-AD Body class: 2 (orifice 4 mm) | Connection: Tube extension, ø6 mm | Material: SUS, ADC, PTFE, FKM
LVH20M-T06-ND Body class: 2 (orifice 4 mm) | Connection: Tube extension, ø6 mm | Material: SUS, ADC, PTFE, EPDM
LVH20M-T07-AD Body class: 2 (orifice 4 mm) | Connection: Tube extension, 1/4 in | Material: SUS, ADC, PTFE, FKM
LVH20M-T07-ND Body class: 2 (orifice 4 mm) | Connection: Tube extension, 1/4 in | Material: SUS, ADC, PTFE, EPDM
LVH30M-D10-AD Body class: 3 (orifice 8 mm) | Connection: Compression fitting, ø10 mm | Material: SUS, ADC, PTFE, FKM
LVH30M-D10-ND Body class: 3 (orifice 8 mm) | Connection: Compression fitting, ø10 mm | Material: SUS, ADC, PTFE, EPDM
LVH30M-D11-AD Body class: 3 (orifice 8 mm) | Connection: Compression fitting, 3/8 in | Material: SUS, ADC, PTFE, FKM
LVH30M-D11-ND Body class: 3 (orifice 8 mm) | Connection: Compression fitting, 3/8 in | Material: SUS, ADC, PTFE, EPDM
LVH30M-G11-AD Body class: 3 (orifice 8 mm) | Connection: Face seal fitting, 3/8 in | Material: SUS, ADC, PTFE, FKM
LVH30M-G11-ND Body class: 3 (orifice 8 mm) | Connection: Face seal fitting, 3/8 in | Material: SUS, ADC, PTFE, EPDM
LVH30M-T10-AD Body class: 3 (orifice 8 mm) | Connection: Tube extension, ø10 mm | Material: SUS, ADC, PTFE, FKM
LVH30M-T10-ND Body class: 3 (orifice 8 mm) | Connection: Tube extension, ø10 mm | Material: SUS, ADC, PTFE, EPDM
LVH30M-T11-AD Body class: 3 (orifice 8 mm) | Connection: Tube extension, 3/8 in | Material: SUS, ADC, PTFE, FKM
LVH30M-T11-ND Body class: 3 (orifice 8 mm) | Connection: Tube extension, 3/8 in | Material: SUS, ADC, PTFE, EPDM
LVH40M-D12-AD Body class: 4 (orifice 12 mm) | Connection: Compression fitting, ø12 mm | Material: SUS, ADC, PTFE, FKM
LVH40M-D12-ND Body class: 4 (orifice 12 mm) | Connection: Compression fitting, ø12 mm | Material: SUS, ADC, PTFE, EPDM
LVH40M-D13-AD Body class: 4 (orifice 12 mm) | Connection: Compression fitting, 1/2 in | Material: SUS, ADC, PTFE, FKM
LVH40M-D13-ND Body class: 4 (orifice 12 mm) | Connection: Compression fitting, 1/2 in | Material: SUS, ADC, PTFE, EPDM
LVH40M-G13-AD Body class: 4 (orifice 12 mm) | Connection: Face seal fitting, 1/2 in | Material: SUS, ADC, PTFE, FKM
LVH40M-G13-ND Body class: 4 (orifice 12 mm) | Connection: Face seal fitting, 1/2 in | Material: SUS, ADC, PTFE, EPDM
LVH40M-T12-AD Body class: 4 (orifice 12 mm) | Connection: Tube extension, ø12 mm | Material: SUS, ADC, PTFE, FKM
LVH40M-T12-ND Body class: 4 (orifice 12 mm) | Connection: Tube extension, ø12 mm | Material: SUS, ADC, PTFE, EPDM
LVH40M-T13-AD Body class: 4 (orifice 12 mm) | Connection: Tube extension, 1/2 in | Material: SUS, ADC, PTFE, FKM
LVH40M-T13-ND Body class: 4 (orifice 12 mm) | Connection: Tube extension, 1/2 in | Material: SUS, ADC, PTFE, EPDM
LVH50M-D19-AD Body class: 5 (orifice 20 mm) | Connection: Compression fitting, ø19 mm or 3/4 in | Material: SUS, ADC, PTFE, FKM
LVH50M-D19-ND Body class: 5 (orifice 20 mm) | Connection: Compression fitting, ø19 mm or 3/4 in | Material: SUS, ADC, PTFE, EPDM
LVH50M-G19-AD Body class: 5 (orifice 20 mm) | Connection: Face seal fitting, ø19 mm or 3/4 in | Material: SUS, ADC, PTFE, FKM
LVH50M-G19-ND Body class: 5 (orifice 20 mm) | Connection: Face seal fitting, ø19 mm or 3/4 in | Material: SUS, ADC, PTFE, EPDM
LVH50M-T19-AD Body class: 5 (orifice 20 mm) | Connection: Tube extension, ø19 mm or 3/4 in | Material: SUS, ADC, PTFE, FKM
LVH50M-T19-ND Body class: 5 (orifice 20 mm) | Connection: Tube extension, ø19 mm or 3/4 in | Material: SUS, ADC, PTFE, EPDM
LVH60M-D25-AD Body class: 6 (orifice 22 mm) | Connection: Compression fitting, 1 in | Material: SUS, ADC, PTFE, FKM
LVH60M-D25-ND Body class: 6 (orifice 22 mm) | Connection: Compression fitting, 1 in | Material: SUS, ADC, PTFE, EPDM
LVH60M-G25-AD Body class: 6 (orifice 22 mm) | Connection: Face seal fitting, 1 in | Material: SUS, ADC, PTFE, FKM
LVH60M-G25-ND Body class: 6 (orifice 22 mm) | Connection: Face seal fitting, 1 in | Material: SUS, ADC, PTFE, EPDM
LVH60M-T25-AD Body class: 6 (orifice 22 mm) | Connection: Tube extension, 1 in | Material: SUS, ADC, PTFE, FKM
LVH60M-T25-ND Body class: 6 (orifice 22 mm) | Connection: Tube extension, 1 in | Material: SUS, ADC, PTFE, EPDM
